JVC UX-G46B User manual

SERVICE MANUAL
COPYRIGHT © 2007 Victor Company of Japan, Limited No.MB602
2007/5
MICRO COMPONENT SYSTEM
MB60220075SERVICE MANUAL
UX-G46B, UX-G46E, UX-G46EN,
UX-G46EV, UX-G47E
COPYRIGHT © 2007 Victor Company of Japan, Limited
Lead free solder used in the board (material : Sn-Ag-Cu, melting point : 219 Centigrade)
TABLE OF CONTENTS
1 PRECAUTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
2 SPECIFIC SERVICE INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
3 DISASSEMBLY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-6
4 ADJUSTMENT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
5 TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
CA-UXG46 CA-UXG47SP-UXG46 SP-UXG46 SP-UXG47SP-UXG47

1-2 (No.MB602)
SPECIFICATION
Design and specifications are subject to change without notice.
Amplifier section Output Power 80 W per channel min. RMS driven into 6 Ωat 1 kHz with no
more than 10% total harmonic distortion. (IEC268-3)
Speakers/Impedance 6 Ω- 16 Ω
Audio Input AUX
(Input sensitivity/Impedance)
LEVEL1: 150 mV/47 kΩ
LEVEL2: 500 mV/47 kΩ
USB Ver.1.1
Tuner section FM tuning range 87.50 MHz ? 108.00 MHz
AM (MW) tuning range 522 kHz ? 1 629 kHz
CD player section Dynamic range 85 dB
Signal-to-noise ratio 85 dB
Wow and flutter Immeasurable
General Power requirement AC 230 V , 50 Hz
Power consumption 145 W (at operation)
20 W (on standby)
0.9 W (standby and on Display off)
Dimensions (approx.) 175 mm ×246 mm ×415 mm (W/H/D)
Mass (approx.) 6.2 kg
Speakers (for UX-G46) Type 2-way Bass reflex
Speaker units Woofer: 12 cm cone ×1
Tweeter: 4 cm cone ×1
Impedance 6 Ω
Dimensions (approx.) 145 mm ×246 mm ×199 mm (W/H/D)
Mass (approx.) 2.2 kg each
Speakers (for UX-G47) Type 3-way Bass reflex
Speaker units Woofer: 12 cm cone ×1
Midd: 4 cm cone ×1
Tweeter: 1.5 cm cone ×1
Impedance 6 Ω
Dimensions (approx.) 145 mm ×246 mm ×199 mm (W/H/D)
Mass (approx.) 2.2 kg each

(No.MB602)1-3
SECTION 1
PRECAUTION
1.1 Safety Precautions
(1) This design of this product contains special hardware and
many circuits and components specially for safety purpos-
es. For continued protection, no changes should be made
to the original design unless authorized in writing by the
manufacturer. Replacement parts must be identical to
those used in the original circuits. Services should be per-
formed by qualified personnel only.
(2) Alterations of the design or circuitry of the product should
not be made. Any design alterations of the product should
not be made. Any design alterations or additions will void
the manufacturers warranty and will further relieve the
manufacture of responsibility for personal injury or property
damage resulting therefrom.
(3) Many electrical and mechanical parts in the products have
special safety-related characteristics. These characteris-
tics are often not evident from visual inspection nor can the
protection afforded by them necessarily be obtained by us-
ing replacement components rated for higher voltage, watt-
age, etc. Replacement parts which have these special
safety characteristics are identified in the Parts List of Ser-
vice Manual. Electrical components having such features
are identified by shading on the schematics and by ( ) on
the Parts List in the Service Manual. The use of a substitute
replacement which does not have the same safety charac-
teristics as the recommended replacement parts shown in
the Parts List of Service Manual may create shock, fire, or
other hazards.
(4) The leads in the products are routed and dressed with ties,
clamps, tubings, barriers and the like to be separated from
live parts, high temperature parts, moving parts and/or
sharp edges for the prevention of electric shock and fire
hazard. When service is required, the original lead routing
and dress should be observed, and it should be confirmed
that they have been returned to normal, after reassem-
bling.
(5) Leakage shock hazard testing
After reassembling the product, always perform an isola-
tion check on the exposed metal parts of the product (an-
tenna terminals, knobs, metal cabinet, screw heads,
headphone jack, control shafts, etc.) to be sure the product
is safe to operate without danger of electrical shock.Do not
use a line isolation transformer during this check.
• Plug the AC line cord directly into the AC outlet. Using a
"Leakage Current Tester", measure the leakage current
from each exposed metal parts of the cabinet, particular-
ly any exposed metal part having a return path to the
chassis, to a known good earth ground. Any leakage cur-
rent must not exceed 0.5mA AC (r.m.s.).
• Alternate check method
Plug the AC line cord directly into the AC outlet. Use an
AC voltmeter having, 1,000Ωper volt or more sensitivity
in the following manner. Connect a 1,500Ω10W resistor
paralleled by a 0.15µF AC-type capacitor between an ex-
posed metal part and a known good earth ground.
Measure the AC voltage across the resistor with the AC
voltmeter.
Move the resistor connection to each exposed metal
part, particularly any exposed metal part having a return
path to the chassis, and measure the AC voltage across
the resistor. Now, reverse the plug in the AC outlet and
repeat each measurement. Voltage measured any must
not exceed 0.75 V AC (r.m.s.). This corresponds to 0.5
mA AC (r.m.s.).
1.2 Warning
(1) This equipment has been designed and manufactured to
meet international safety standards.
(2) It is the legal responsibility of the repairer to ensure that
these safety standards are maintained.
(3) Repairs must be made in accordance with the relevant
safety standards.
(4) It is essential that safety critical components are replaced
by approved parts.
(5) If mains voltage selector is provided, check setting for local
voltage.
1.3 Caution
Burrs formed during molding may be left over on some parts
of the chassis.
Therefore, pay attention to such burrs in the case of pre-
forming repair of this system.
1.4 Critical parts for safety
In regard with component parts appearing on the silk-screen
printed side (parts side) of the PWB diagrams, the parts that are
printed over with black such as the resistor ( ), diode ( )
and ICP ( ) or identified by the " " mark nearby are critical
for safety. When replacing them, be sure to use the parts of the
same type and rating as specified by the manufacturer.
(This regulation dose not Except the J and C version)
Good earth ground
Place this
probe on
each exposed
metal part.
AC VOLTMETER
(Having 1000
ohms/volts,
or more sensitivity)
1500 10W
0.15 F AC TYPE

1-4 (No.MB602)
1.5 Safety Precautions (U.K only)
(1) This design of this product contains special hardware and many circuits and components specially for safety purposes. For con-
tinued protection, no changes should be made to the original design unless authorized in writing by the manufacturer. Replace-
ment parts must be identical to those used in the original circuits.
(2) Any unauthorised design alterations or additions will void the manufacturer's guarantee; furthermore the manufacturer cannot
accept responsibility for personal injury or property damage resulting therefrom.
(3) Essential safety critical components are identified by ( ) on the Parts List and by shading on the schematics, and must never
be replaced by parts other than those listed in the manual. Please note however that many electrical and mechanical parts in
the product have special safety related characteristics. These characteristics are often not evident from visual inspection. Parts
other than specified by the manufacturer may not have the same safety characteristics as the recommended replacement parts
shown in the Parts List of the Service Manual and may create shock, fire, or other hazards.
(4) The leads in the products are routed and dressed with ties, clamps, tubings, barriers and the like to be separated from live parts,
high temperature parts, moving parts and/or sharp edges for the prevention of electric shock and fire hazard. When service is
required, the original lead routing and dress should be observed, and it should be confirmed that they have been returned to
normal, after re-assembling.
1.5.1 Warning
(1) Service should be performed by qualified personnel only.
(2) This equipment has been designed and manufactured to meet international safety standards.
(3) It is the legal responsibility of the repairer to ensure that these safety standards are maintained.
(4) Repairs must be made in accordance with the relevant safety standards.
(5) It is essential that safety critical components are replaced by approved parts.
(6) If mains voltage selector is provided, check setting for local voltage.
Burrs formed during molding may be left over on some parts of the chassis. Therefore,
pay attention to such burrs in the case of preforming repair of this system.

(No.MB602)1-5
1.6 Important for laser products
1.CLASS 1 LASER PRODUCT
2.CAUTION :
(For U.S.A.) Visible and/or invisible class II laser radiation
when open. Do not stare into beam.
(Others) Visible and/or invisible class 1M laser radiation
when open. Do not view directly with optical instruments.
3.CAUTION : Visible and/or invisible laser radiation when
open and inter lock failed or defeated. Avoid direct
exposure to beam.
4.CAUTION : This laser product uses visible and/or invisible
laser radiation and is equipped with safety switches which
prevent emission of radiation when the drawer is open and
the safety interlocks have failed or are defeated. It is
dangerous to defeat the safety switches.
5.CAUTION : If safety switches malfunction, the laser is able
to function.
6.CAUTION : Use of controls, adjustments or performance of
procedures other than those specified here in may result in
hazardous radiation exposure.
REPRODUCTION AND POSITION OF LABELS and PRINT
!Please use enough caution not to
see the beam directly or touch it
in case of an adjustment or operation
check.
WARNING LABEL and PRINT

1-6 (No.MB602)
SECTION 2
SPECIFIC SERVICE INSTRUCTIONS
This service manual does not describe SPECIFIC SERVICE INSTRUCTIONS.
SECTION 3
DISASSEMBLY
3.1 Main Body
3.1.1 Removing the side panel
(See Fig.1, 2)
(1) Remove the four screws Aattaching the rear cover. (See
Fig.1)
(2) Remove the six screws Battaching the side panel . (See
Fig.1)
(3) Remove the four screws Cattaching the side panel. (See
Fig.2)
Fig.1
Fig.2
A
BB
AA
E
CC

(No.MB602)1-7
3.1.2 Removing the top cover
(See Fig.1, 3)
(1) Remove the four screws Dattaching the top cover and the
side panel. (See Fig.3)
(2) Remove the one screw Eattaching the top cover. (See
Fig.1)
Caution:
When take out the top cover, raise slowly, take care not to
break the two claws of the front panel.
Fig.3
3.1.3 Removing the power trans board
(See Fig.4)
(1) Remove the two screws Fattaching the power trans board.
(2) Disconnect the connector wire from the connector CN103
of the main board.
(3) Disconnect the connector wires from the connectors
CN901, CN902 of the trans board.
Fig.4
D
D
b
b
F
CN901
CN902
CN103
Connector wire a

1-8 (No.MB602)
3.1.4 Removing the tuner pack
(See Fig.5, 6)
(1) Remove the two screws Gattaching the tuner pack. (See
Fig.5)
(2) Disconnect the card wire from the connector CN351 of the
main board. (See Fig.6)
3.1.5 Removing the fan
(See Fig.5, 6)
(1) Remove the four screws Hattaching the fan. (See Fig.5)
(2) Disconnect the connector wire from the connector CN141
of the main board. (See Fig.6)
3.1.6 Removing the main board
(See Fig.5, 7)
(1) Remove the two screws Jattaching the main board. (See
Fig.5)
(2) Remove the tow screws Kattaching the main board and
the front board. (See Fig.7)
(3) Disconnect the card wires from the connectors CN401,
CN402 of the main board. (See Fig.7)
(4) Disconnect the card wire from the connector CN403 of the
main board. (See Fig.7)
(5) Disconnect the parallel wire from the connector CN502 of
the main board. (See Fig.7)
(6) Disconnect the connector wires from the connectors
CN101, CN102, CN204, CN361 of the main board. (See
Fig.7)
(7) Remove the five screws Lattaching the main board. (See
Fig.7)
(8) Remove the two screws Mattaching the main board and
CD mechanism cover. (See Fig.7)
Fig.5
Fig.6
Fig.7
G
H
H
H
J
J
S
CN351
CN141
CN402
CN401 CN403
K
CN502
CN102
CN101
CN204
M
L
L
L
CN361

(No.MB602)1-9
3.1.7 Removing the front panel assembly
(See Fig.3, 4, 8, 9)
(1) Pull out the tow connector wires aon the bottom chassis.
(See Fig.4)
(2) Remove the two screws Nattaching the front panel. (See
Fig.8)
(3) Disconnect the connector wire from the connector CN860
of the CD board. (See Fig.9)
(4) Disengage the four hooks bare remove the front panel as-
sembly. (See Fig.3)
Fig.8
Fig.9
N
CN860 R
BN702
BN703
R
R
CN701

1-10 (No.MB602)
3.1.8 Removing the CD mechanism assembly
(See Fig.10 to 12)
(1) Remove the four screws Pattaching the CD mechanism
cover and then remove it. (See Fig.10)
(2) Turn the gear cand then undraw the CD tray. (See Fig.11)
(3) Remove the four screws Qattaching the CD mechanism
assembly. (See Fig.12)
Fig.10
Fig.11
Fig.12
P
c
QQ

(No.MB602)1-11
3.1.9 Removing the CD board
(See Fig.9)
(1) Remove the three screws Rattaching the CD Board.
(2) Disconnect the connector wires connected to the CD
mechanism assembly from the connectors BN702, BN703
of the CD board.
(3) Disconnect the card wire from the connector CN701 of the
CD board.
3.1.10 Removing the rear panel
(See Fig.5, 13)
(1) Remove the one screw Sattaching the rear panel. (See
Fig.5)
(2) Disengage the two hooks dand remove the rear panel.
(See Fig.13)
Fig.13
3.1.11 Removing the power transformer
(See Fig.14)
(1) Remove the four screws Tattaching the power transform-
er.
Fig.14
d
T
T

1-12 (No.MB602)
3.1.12 Removing the VFD board
(See Fig.15, 16)
(1) Take out the volume knob. (See Fig.15)
(2) Remove the four screws Uattaching the VFD board. (See
Fig.16)
3.1.13 Removing the key board
(See Fig.16)
(1) Remove the fourteen screws Vattaching the key board.
3.1.14 Removing the jack board
(See Fig.16)
(1) Remove the four screws Wattaching the jack board.
Fig.15
Fig.16
Volume knob
UU
VV
V
V
V
W

(No.MB602)1-13
SECTION 4
ADJUSTMENT
This service manual does not describe ADJUSTMENT.
SECTION 5
TROUBLESHOOTING
This service manual does not describe TROUBLESHOOTING.

(No.MB602)
VPT
Printed in Japan
Victor company of Japan, Limited
Audio/Video Systems category 10-1,1chome,Ohwatari-machi,Maebashi-city,371-8543,Japan

3-1
PARTS LIST
* All printed circuit boards and its assemblies are not available as service parts.
- Contents -
Exploded view of general assembly and parts list (Block No.M1)
Electrical parts list (Block No.01~04)
Packing materials and accessories parts list (Block No.M3)
UX-G46B,UX-G46E,UX-G46EN
UX-G46EV,UX-G47E
3- 2
3- 5
3-12
MB602

3-2
Exploded view of general assembly and parts list
Block No.
MM
M
1
Main board
VFD board
Power Trans board
Key board
Jack board
a
18
40
15
11
40
17
18
42
3
2
32
34
40
40
44
5
6
7
8
12
1
14
16
41
14
27
27
54
45
36
20
9
10
1
4
35
35
13
40 31
38
48
53

3-3
M
r
d
CD board
The parts without symbol number are not service.
a
18
18
8
30
34
2
2
34
51
46
18
24
25
49
18
23
32
45 26
22
39
38
35
27
37
55
35
52
28
18
47
3
1
52
21
43
33
31
50
18
52
48

3-4
General Assembly
Block No. [M][1][M][M]
 Symbol No. Part No. Part Name Description Local
1 BI372K30060YTN SCREW 3XL6(x2)
2 BIBI3021970101 RUBBER FOOT (x4)
3 BI372K30080NTN SCREW 3XL8(x2)
4 BI1084880301X1 FRONT PANEL
5 BI2031140101X1 CD DOOR SPRING
6 BI372B20050NTN SCREW B HEAD(x4)
7 BI1084220101X1 CD BAFFLE
8 BI1084870201X1 CD DOOR SPRING
9 BI1080800101V1 VOLUME KNOB ABS-T700 94HB
10 BI1084200101X1 VOLUME RING
11 BI1084230101X1 ILLUMI LENS
12 BI1084210301X1 DISPLAY LENS
13 BI2031160202X1 SIDE PANEL-L
14 BI372K30100NTN SCREW 3XL10(x2)
15 BI1084260101X1 LED HOLDER
16 BI1084250101X1 VFD HOLDER
17 BI2031130101X1 SENSOR HOLDER
18 BI372R30060YTN SCREW 3XL6(x21)
20 BI1084240201X1 TOP COVER
21 BI2400261V FAN
22 BIZ25096402VX TUNER PACK
23 BI1084270102X1 TRANS COVER
24 BI377P40080YRN SCREW 4XL8(x4)
25 BI2031090202X1 REAR PANEL T=0.8mm
 26 BI211011146001 POWER TRANS
27 BI372R30080BTN SCREW 3XL8(x4)
28 BI2031150202X1 SIDE PANEL-R
30 BI372B30140YTN SCREW 3XL14(x2)
31 BI372P30350BTH SCREW 3XL35(x2)
32 BI372B30120NTN SCREW 3XL12(x3)
33 BI2031370101X1 BOTTM CHASSIS T=1.0mm
34 BI372B30060YTN SCREW (x4)
35 BI372R30060YRN SCREW (x6)
36 BI2031390101X1 CD MECH HLD FRONT
37 BI2031400101X1 CD MECH HLD BACK
38 BI1085930201X1 PLASTIC CUSHION (x3)
39 BI671UXG45020 MECHANICAL ASSY
40 BI372B26080YTN SCREW (x26)
41 BI1084890101X1 BUTTON
42 BI372B30300YTN SCREW (x2)
43 BI2031380101X1 CD MECH COVER T=0.8mm
44 BI1084910101X1 PCB BRACKET (x2)
45 BI372R30080YTN SCREW (x2)
46 BI3000270101X1 FIBRE WASHER (x2)
47 BI2031530101X1 HEAT SINK
48 BI2031520101X1 HEAT SINK BKT FRONT
49 BI2029330101X2 BKT
50 BI2029350101W1 HEAT SINK BKT BACK
51 BI372R30080YTN SCREW 3XL8(x4)
52 BI372R30100YTN SCREW 3XL10(x8)
53 BI251011010000 CD MECHANISM
 54 BI403081 FUSE F901 1.25A 250V
 55 BI1401441V POWER CORD G46B
 55 BI1401352X POWER CORD G46E,G46EN,G46EV,G47E

3-5
Electrical parts list
Main board
Block No. [0][1]
 Symbol No. Part No. Part Name Description Local
IC105 BI120781X IC STK433-090
IC110 BI110841X IC KIA7812
IC111 BI118381X IC NJM79L09
IC112 BI111971X IC KIA7809
IC113 BI110891X IC KIA7808
IC371 BI103952X IC BA4558F
IC372 BI103952X IC BA4558F
IC401 BI120471X IC S3C825A
IC501 BI112721X IC BD3881FV
IC551 BI103952X IC BA4558F
IC625 BI115291X IC SENSOR
IC651 BI116661X IC S5G5128A
Q111 2SC3052 TRANSISTOR BI2SC3052FA013H
Q112 2SC3052 TRANSISTOR BI2SC3052FA013H
Q141 2SC3052 TRANSISTOR BI2SC3052FA013H
Q142 2SC3052 TRANSISTOR BI2SC3052FA013H
Q143 KTA1273Y TRANSISTOR BI2KTA1273YP000
Q144 KTA1273Y TRANSISTOR BI2KTA1273YP000
Q171 2SC3052 TRANSISTOR BI2SC3052FA013H
Q172 2SC3052 TRANSISTOR BI2SC3052FA013H
Q173 2SC3052 TRANSISTOR BI2SC3052FA013H
Q174 2SC3052 TRANSISTOR BI2SC3052FA013H
Q175 2SC3052 TRANSISTOR BI2SC3052FA013H
Q201 DTC323TK DIGI TRANSISTOR BI2DTC323TKA011
Q202 DTC323TK DIGI TRANSISTOR BI2DTC323TKA011
Q203 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
Q204 DTA114YK DIGI TRANSISTOR BI2DTA114YKA018
Q241 2SA1235F TRANSISTOR BI2SA1235FA012H
Q242 2SA1235F TRANSISTOR BI2SA1235FA012H
Q243 KTC3199GR TRANSISTOR BI2KTC3199GP00
Q244 DTC114YK DIGI TRANSISTOR BI2DTC114YKA018
Q291 DTC323TK DIGI TRANSISTOR BI2DTC323TKA011
Q292 DTC323TK DIGI TRANSISTOR BI2DTC323TKA011
Q293 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
Q294 DTA114YK DIGI TRANSISTOR BI2DTA114YKA018
Q351 2SC3052 TRANSISTOR BI2SC3052FA013H
Q352 KTA1267GR TRANSISTOR BI2KTA1267GP00
Q353 DTC114TK DIGI TRANSISTOR BI2DTC114TKA011
Q354 2SA1235F TRANSISTOR BI2SA1235FA012H
Q361 DTC323TK DIGI TRANSISTOR BI2DTC323TKA011
Q362 DTC323TK DIGI TRANSISTOR BI2DTC323TKA011
Q371 DTC124EKA DIGI TRANSISTOR BI2DTC124EKA018
Q401 DTC114YK DIGI TRANSISTOR BI2DTC114YKA018
Q402 DTC114YK DIGI TRANSISTOR BI2DTC114YKA018
Q404 2SC1815 TRANSISTOR BI2SC1815GRP000
Q501 2SC3052 TRANSISTOR BI2SC3052FA013H
Q502 2SC3052 TRANSISTOR BI2SC3052FA013H
Q551 KTC3199GR TRANSISTOR BI2KTC3199GP00
Q552 KTC3199GR TRANSISTOR BI2KTC3199GP00
Q625 KRA107S TRANSISTOR BI2KRA107SA0000
Q626 DTA114YK DIGI TRANSISTOR BI2DTA114YKA018
Q627 DTA114YK DIGI TRANSISTOR BI2DTA114YKA018
D101 RS603M DIODE BI3RS603M1
D111 RS202 DIODE BI3RS2021
D112 1SS133 FR DIODE BI31SS133M000V7
D132 1SS133 FR DIODE BI31SS133M000V7
D133 1SS133 FR DIODE BI31SS133M000V7
D134 1SS133 FR DIODE BI31SS133M000V7
D141 MC2838 DIODE BI3MC2838A002
D142 1SS133 FR DIODE BI31SS133M000V7
D161 1N4001 DIODE BI31N4001M0006
D172 1SS133 FR DIODE BI31SS133M000V7
D173 1SS133 FR DIODE BI31SS133M000V7
D174 1SS133 FR DIODE BI31SS133M000V7
D201 1SS133 FR DIODE BI31SS133M000V7
D231 1SS133 FR DIODE BI31SS133M000V7
D232 1SS133 FR DIODE BI31SS133M000V7
D233 1SS133 FR DIODE BI31SS133M000V7
D234 1SS133 FR DIODE BI31SS133M000V7
D235 1SS133 FR DIODE BI31SS133M000V7
D236 1SS133 FR DIODE BI31SS133M000V7
D361 1SS133 FR DIODE BI31SS133M000V7
D362 1SS133 FR DIODE BI31SS133M000V7
D363 1SS133 FR DIODE BI31SS133M000V7
D371 1SS133 FR DIODE BI31SS133M000V7
D401 1SS133 FR DIODE BI31SS133M000V7
D402 1SS133 FR DIODE BI31SS133M000V7
D403 1SS133 FR DIODE BI31SS133M000V7
D404 1SS133 FR DIODE BI31SS133M000V7
D405 1SS133 FR DIODE BI31SS133M000V7
D421 1SS133 FR DIODE BI31SS133M000V7
D551 1SS133 FR DIODE BI31SS133M000V7
D552 1SS133 FR DIODE BI31SS133M000V7
D601 1SS133 FR DIODE BI31SS133M000V7
D602 1SS133 FR DIODE BI31SS133M000V7
D625 BI28B4541EP01 LED RED BL-B4541-AV-
TBS2
D626 BI2801181V LED
D971 1SS133 FR DIODE BI31SS133M000V7
D972 1SS133 FR DIODE BI31SS133M000V7
D981 1SS133 FR DIODE BI31SS133M000V7
D982 1SS133 FR DIODE BI31SS133M000V7
D991 1SS133 FR DIODE BI31SS133M000V7
D992 1SS133 FR DIODE BI31SS133M000V7
C101 BICM103101KP01 M CAPACITOR 0.01uF 100V
C102 BICM103101KP01 M CAPACITOR 0.01uF 100V
C103 BICM223101KP01 M CAPACITOR 0.022uF 100V
C104 BICM103101KP01 M CAPACITOR 0.01uF 100V
C105 BICM103101KP01 M CAPACITOR 0.01uF 100V
C106 BICE33856M1Y E CAPACITOR 3300uF 56V
C107 BICE33856M1Y E CAPACITOR 3300uF 56V
C111 BICC103500KA04 C CAPACITOR 0.01uF 50V
C112 BICC103500KA04 C CAPACITOR 0.01uF 50V
C113 BICC223500KA04 C CAPACITOR 0.022uF 50V
C114 BICE106500MP01 E CAPACTIOR 10uF 50V
C115 BICE108250MP01 E CAPACITOR 1000uF 25V
C116 BICE47825M6Y1 E CAPACITOR 4700uF 25V
C117 BICC103500KA04 C CAPACITOR 0.01uF 50V
C118 BICC103500KA04 C CAPACITOR 0.01uF 50V
C121 BICE108160MP01 E CAPACITOR 1000uF 16V
C122 BICE477160MP01 E CAPACITOR 470uF 16V
C125 BICE108160MP01 E CAPACITOR 1000uF 16V
C126 BICC104500KA04 C CAPACITOR 0.1uF 50V
C127 BICE108160MP01 E CAPACITOR 1000uF 16V
C128 BICC104500KA04 C CAPACITOR 0.1uF 50V
C141 BICE105500MP11 E CAPACITOR 1uF 50V
C142 BICE106500MP01 E CAPACTIOR 10uF 50V
C144 BICE107160MP11 E CAPACITOR 100uF 16V
C161 BICE476500MP01 E CAPACITOR 47uF 50V
C162 BICE226500MP01 E CAPACITOR 22uF 50V
C163 BICC103500KA04 C CAPACITOR 0.01uF 50V
C164 BICE226500MP01 E CAPACITOR 22uF 50V
C165 BICE106500MP01 E CAPACTIOR 10uF 50V
C171 BICC222500KA04 C CAPACITOR 2200pF 50V
C172 BICE105500MP01 E CAPACITOR 1uF 50V
C173 BICE475500MP01 E CAPACITOR 4.7uF 50V
C174 BICE226160MP01 E CAPACITOR 22uF 16V
C175 BICE107160MP01 E CAPACITOR 100uF 16V
C203 BICE105500MP01 E CAPACITOR 1uF 50V
C204 BICE105500MP01 E CAPACITOR 1uF 50V
C205 BICC391500JA04 C CAPACITOR 390pF 50V
C206 BICC391500JA04 C CAPACITOR 390pF 50V
C207 BICC221500JA04 C CAPACITOR 220pF 50V
C208 BICC221500JA04 C CAPACITOR 220pF 50V
C213 BICE107630MP01 E CAPACITOR 100uF 63V
C214 BICE107630MP01 E CAPACITOR 100uF 63V
C215 BICE226500MP01 E CAPACITOR 22uF 50V
C216 BICE226500MP01 E CAPACITOR 22uF 50V
C217 BICC047500CA04 C CAPACITOR 4.7pF
C218 BICC047500CA04 C CAPACITOR 4.7pF
C237 BICC104500KA04 C CAPACITOR 0.1uF 50V
C238 BICC104500KA04 C CAPACITOR 0.1uF 50V
C239 BICC104500KA04 C CAPACITOR 0.1uF 50V
C240 BICC104500KA04 C CAPACITOR 0.1uF 50V
C241 BICE106500MP01 E CAPACTIOR 10uF 50V
 Symbol No. Part No. Part Name Description Local

3-6
C242 BICE105500MP01 E CAPACITOR 1uF 50V
C243 BICC153500KA04 C CAPACITOR 0.015uF 50V
C244 BICC153500KA04 C CAPACITOR 0.015uF 50V
C348 BICC104500KA04 C CAPACITOR 0.1uF 50V
C349 BICC104500KA04 C CAPACITOR 0.1uF 50V
C351 BICC101500JA04 C CAPACITOR 100pF 50V
C352 BICC101500JA04 C CAPACITOR 100pF 50V
C353 BICC101500JA04 C CAPACITOR 100pF 50V
C354 BICC101500JA04 C CAPACITOR 100pF 50V
C355 BICC103500KA04 C CAPACITOR 0.01uF 50V
C357 BICC102500JA04 C CAPACITOR 1000pF 50V
C358 BICC102500JA04 C CAPACITOR 1000pF 50V
C361 BICE225500MP41 E CAPACITOR 2.2uF/50V
C362 BICE225500MP41 E CAPACITOR 2.2uF/50V
C363 BICC102500JA04 C CAPACITOR 1000pF 50V
C364 BICC102500JA04 C CAPACITOR 1000pF 50V
C369 BICC104500KA04 C CAPACITOR 0.1uF 50V
C371 BICE476250MP01 E CAPACITOR 47uF 25V
C372 BICE476250MP01 E CAPACITOR 47uF 25V
C374 BICE106500MP01 E CAPACTIOR 10uF 50V
C375 BICE225500MP01 E CAPACITOR 2.2uF 50V
C376 BICE225500MP01 E CAPACITOR 2.2uF 50V
C377 BICC474100KA04 C CAPACITOR 0.47uF 10V
C378 BICC474100KA04 C CAPACITOR 0.47uF 10V
C381 BICC821500KA04 C CAPACITOR 820pF
C382 BICC821500KA04 C CAPACITOR 820pF
C383 BICC104500KA04 C CAPACITOR 0.1uF 50V
C401 BICC104500KA04 C CAPACITOR 0.1uF 50V
C402 BICE477063MP01 E CAPACITOR 470uF 6.3V
C403 BICC150500JA04 C CAPACITOR 15pF 50V
C404 BICC330500JA04 C CAPACITOR 33pF 50V
C405 BICC101500JA04 C CAPACITOR 100pF 50V
C406 BICC104500KA04 C CAPACITOR 0.1uF 50V
C407 BICC104500KA04 C CAPACITOR 0.1uF 50V
C408 BICE476500MP01 E CAPACITOR 47uF 50V
C410 BICC220500JA04 C CAPACITOR 22pF 50V
C411 BICC220500JA04 C CAPACITOR 22pF 50V
C412 BICE225500MP01 E CAPACITOR 2.2uF 50V
C413 BICE477063MP01 E CAPACITOR 470uF 6.3V
C414 BICE477063MP01 E CAPACITOR 470uF 6.3V
C415 BICC104500KA04 C CAPACITOR 0.1uF 50V
C416 BICE107100MP01 E CAPACITOR 100uF 10V
C417 BICC104500KA04 C CAPACITOR 0.1uF 50V
C418 BICE337160MP01 E CAPACITOR 330uF/16V
C420 BICC104500KA04 C CAPACITOR 0.1uF 50V
C421 BICC104500KA04 C CAPACITOR 0.1uF 50V
C422 BICC330500JA04 C CAPACITOR 33pF 50V
C423 BICC330500JA04 C CAPACITOR 33pF 50V
C424 BICC330500JA04 C CAPACITOR 33pF 50V
C425 BICC330500JA04 C CAPACITOR 33pF 50V
C426 BICC220500JA04 C CAPACITOR 22pF 50V
C511 BICE225500MP01 E CAPACITOR 2.2uF 50V
C512 BICE225500MP01 E CAPACITOR 2.2uF 50V
C513 BICC822500KA04 C CAPACITOR 8200pF 50V
C514 BICC822500KA04 C CAPACITOR 8200pF 50V
C515 BICC101500JA04 C CAPACITOR 100pF 50V
C516 BICC104500KA04 C CAPACITOR 0.1uF 50V
C517 BICE227100MP01 E CAPACITOR 220uF 10V
C518 BICC104500KA04 C CAPACITOR 0.1uF 50V
C519 BICE107100MP01 E CAPACITOR 100uF 10V
C525 BICM124101KP01 M CAPACITOR 0.12uF 100V
C526 BICM124101KP01 M CAPACITOR 0.12uF 100V
C527 BICE104500MP01 E CAPACITOR 0.1uF 50V
C528 BICE104500MP01 E CAPACITOR 0.1uF 50V
C529 BICC683160KA04 C CAPACITOR 0.068uF 16V
C530 BICC683160KA04 C CAPACITOR 0.068uF 16V
C531 BICE474500MP01 E CAPACITOR 0.47uF 50V
C532 BICE474500MP01 E CAPACITOR 0.47uF 50V
C537 BICC222500KA04 C CAPACITOR 2200pF 50V
C538 BICC222500KA04 C CAPACITOR 2200pF 50V
C551 BICE107160MP01 E CAPACITOR 100uF 16V
C552 BICE107160MP01 E CAPACITOR 100uF 16V
C553 BICC104500KA04 C CAPACITOR 0.1uF 50V
C554 BICC104500KA04 C CAPACITOR 0.1uF 50V
C555 BICM124101KP01 M CAPACITOR 0.12uF 100V
C556 BICM124101KP01 M CAPACITOR 0.12uF 100V
C557 BICE107160MP01 E CAPACITOR 100uF 16V
C558 BICE107160MP01 E CAPACITOR 100uF 16V
 Symbol No. Part No. Part Name Description Local
C559 BICE475500MP01 E CAPACITOR 4.7uF 50V
C560 BICE475500MP01 E CAPACITOR 4.7uF 50V
C561 BICE475500MP01 E CAPACITOR 4.7uF 50V
C562 BICC471500JA04 C CAPACITOR 470pF
C563 BICC471500JA04 C CAPACITOR 470pF
C601 BICC103500KA04 C CAPACITOR 0.01uF 50V
C602 BICC103500KA04 C CAPACITOR 0.01uF 50V
C603 BICC471500JA04 C CAPACITOR 470pF
C604 BICC471500JA04 C CAPACITOR 470pF
C625 BICC102500JA04 C CAPACITOR 1000pF 50V
C626 BICE107100MP01 E CAPACITOR 100uF 10V
C652 BICE226500MP11 E CAPACITOR 22uF/50V
C654 BICE226500MP11 E CAPACITOR 22uF/50V
C655 BICC104500KA04 C CAPACITOR 0.1uF 50V
C656 BICE107630MP01 E CAPACITOR 100uF 63V
C657 BICC103500KA04 C CAPACITOR 0.01uF 50V
C658 BICC101500JA04 C CAPACITOR 100pF 50V
C659 BICC101500JA04 C CAPACITOR 100pF 50V
C660 BICC101500JA04 C CAPACITOR 100pF 50V
C661 BICC104500KA04 C CAPACITOR 0.1uF 50V
C662 BICE108100MP01 E CAPACITOR 1000uF 10V
C663 BICC104500KA04 C CAPACITOR 0.1uF 50V
C664 BICC104500KA04 C CAPACITOR 0.1uF 50V
C665 BICC104500KA04 C CAPACITOR 0.1uF 50V
C981 BICC471500JA04 C CAPACITOR 470pF
C982 BICC471500JA04 C CAPACITOR 470pF
C983 BICC102500JA04 C CAPACITOR 1000pF 50V
C984 BICC102500JA04 C CAPACITOR 1000pF 50V
C991 BICC102500JA04 C CAPACITOR 1000pF 50V
C992 BICC102500JA04 C CAPACITOR 1000pF 50V
R111 BIRC2200105A00 C RESISTOR 22 Ω 1/10W
R112 BIRC2230085M00 C RESISTOR 22K Ω 1/8W
R113 BIRC2220105A00 C RESISTOR 2.2K Ω 1/10W
R116 BIRF0220045N00 C RESISTOR 2.2 Ω
R117 BIRC3320105A00 C RESISTOR 3.3K Ω 1/10W
R118 BIRC6820105A00 C RESISTOR 6.8K Ω 1/10W
R133 BIRC2210105A00 C RESISTOR 220 Ω 1/10W
R134 BIRC2210105A00 C RESISTOR 220 Ω 1/10W
R135 BIRC2210105A00 C RESISTOR 220 Ω 1/10W
R141 BIRC4730105A00 C RESISTOR 47K Ω 1/10W
R142 BIRC4730105A00 C RESISTOR 47K Ω 1/10W
R144 BIRC2240105A00 C RESISTOR 220K Ω 1/10W
R145 BIRC4730105A00 C RESISTOR 47K Ω 1/10W
R146 BIRC5600105A00 C RESISTOR 56 Ω 1/10W
R147 BIRC5620105A00 C RESISTOR 5.6K Ω 1/10W
R148 BIRC5620105A00 C RESISTOR 5.6K Ω 1/10W
R149 BIRC1030105A00 C RESISTOR 10K Ω 1/10W
R150 BIRC1210025N00 C RESISTOR 120 Ω 1/2W
R151 BIRC1030105A00 C RESISTOR 10K
Ω 1/10W
R152 BIRC1030105A00 C RESISTOR 10K Ω 1/10W
 R153 BIRF3300025N00 FUSE RESISTOR 33 Ω 1/2W
 R161 BIRF3300025N00 FUSE RESISTOR 33 Ω 1/2W
R162 BIRC3320105A00 C RESISTOR 3.3K Ω 1/10W
R163 BIRC2220105A00 C RESISTOR 2.2K
Ω 1/10W
R164 BIRC5620085M00 C RESISTOR 5.6K
Ω 1/8W
R165 BIRC1010085M00 C RESISTOR 100 Ω 1/8W J
R166 BIRC1010085M00 C RESISTOR 100
Ω 1/8W J
R171 BIRC6840105A00 C RESISTOR 680K Ω 1/10W
R172 BIRC1830105A00 C RESISTOR 18K
Ω 1/10W
R173 BIRC4700105A00 C RESISTOR 47
Ω 1/10W
R174 BIRC1040105A00 C RESISTOR 100K Ω 1/10W
R175 BIRC3320105A00 C RESISTOR 3.3K
Ω 1/10W
R176 BIRC3910105A00 C RESISTOR 390
Ω 1/10W
R201 BIRC3920105A00 C RESISTOR 3.9K Ω 1/10W
R203 BIRC4720105A00 C RESISTOR 4.7K
Ω 1/10W
R204 BIRC4720105A00 C RESISTOR 4.7K
Ω 1/10W
R205 BIRC2220105A00 C RESISTOR 2.2K
Ω 1/10W
R206 BIRC2220105A00 C RESISTOR 2.2K
Ω 1/10W
R207 BIRC4730105A00 C RESISTOR 47K Ω 1/10W
R208 BIRC4730105A00 C RESISTOR 47K
Ω 1/10W
R209 BIRC2220105A00 C RESISTOR 2.2K
Ω 1/10W
R210 BIRC2220105A00 C RESISTOR 2.2K Ω 1/10W
 R211 BIRF1010025N00 FUSE RESISTOR 100 Ω 1/2W
 R212 BIRF1010025N00 FUSE RESISTOR 100 Ω 1/2W
R215 BIRC5630105A00 C RESISTOR 56K Ω 1/10W
R216 BIRC5630105A00 C RESISTOR 56K
Ω 1/10W
R217 BIRM0022N25N00 M RESISTOR 0.22
Ω 2W
 Symbol No. Part No. Part Name Description Local
