JVC RD-D227B User manual

Instruction Manual
Wireless Flat panel DAB
Hi-Fi
RD-D227B
RD-D227B_IB_Final190415V6.indd 1 16/04/2019 16:24

RD-D227B_IB_Final190415V6.indd 2 16/04/2019 16:24

Contents
Safety Warnings.............................................................................................................................5
Unpacking......................................................................................................................................7
Product Overview..........................................................................................................................8
Front View.................................................................................................................................................................. 8
Rear View ................................................................................................................................................................... 8
Top View..................................................................................................................................................................... 9
Remote Control............................................................................................................................10
Operating Your Remote Control.................................................................................................12
Replace the Remote Control Battery .............................................................................................................12
Remote Control Operation Range..............................................................................................13
Wall Mounting .............................................................................................................................13
Connections .................................................................................................................................14
Using the AUX Connection................................................................................................................................14
Connecting to the Mains Supply.....................................................................................................................15
General Operation.......................................................................................................................15
Powering ON/OFF.................................................................................................................................................15
Selecting Modes....................................................................................................................................................15
Adjusting the Bass................................................................................................................................................15
Adjusting the Volume..........................................................................................................................................15
Adjusting the Sound Eect ...............................................................................................................................16
Adjusting the Brightness....................................................................................................................................16
Setting of the Clock..............................................................................................................................................16
Time Display ...........................................................................................................................................................16
Synchronising the Clock.....................................................................................................................................16
Setting the Alarm Timer .....................................................................................................................................16
Activate and Deactivate the Alarm Timer....................................................................................................17
Setting the Sleep Timer ......................................................................................................................................17
System Reset ..........................................................................................................................................................17
DAB Operation.............................................................................................................................18
Auto Scan.................................................................................................................................................................18
Manual Tuning.......................................................................................................................................................18
Presetting Stations ...............................................................................................................................................18
Recalling a Preset Station...................................................................................................................................19
DAB Display Modes..............................................................................................................................................20
FM Operation ...............................................................................................................................21
Scanning for Radio Stations..............................................................................................................................21
Searching for a Station Automatically...........................................................................................................21
Searching for a Station Manually....................................................................................................................21
Presetting Stations ...............................................................................................................................................21
Recalling a Preset Station...................................................................................................................................21
Compatible Disc Types ................................................................................................................22
RD-D227B_IB_Final190415V6.indd 3 16/04/2019 16:24

CD/MP3 Operation ......................................................................................................................22
Playback ...................................................................................................................................................................22
To Pause Playback.................................................................................................................................................23
To Stop Playback...................................................................................................................................................23
Skipping to Another Track.................................................................................................................................23
Random Playback .................................................................................................................................................23
Repeat Playback....................................................................................................................................................23
Programme Setting..............................................................................................................................................23
USB Operation .............................................................................................................................24
Bluetooth® Operation ..................................................................................................................25
NFC Operation .............................................................................................................................26
AUX Operation.............................................................................................................................26
Maintenance ................................................................................................................................27
Cleaning the Unit..................................................................................................................................................27
Handling Discs.......................................................................................................................................................27
Cleaning Discs........................................................................................................................................................27
Storing Discs...........................................................................................................................................................27
Hints and Tips ..............................................................................................................................28
Product Fiche and Specications ...............................................................................................29
Useful Information and Licences................................................................................................30
RD-D227B_IB_Final190415V6.indd 4 16/04/2019 16:24

Safety Warnings
• Read all the instructions carefully before
using the unit and keep them for future
reference.
• Retain the manual. If you pass the unit
onto a third party make sure to include this
manual.
• Check that the voltage marked on the
rating label matches your mains voltage.
Damage
• Please inspect the unit for damage after
unpacking.
• Do not continue to operate the unit if you
are in any doubt about it working normally,
or if it is damaged in any way - switch o,
withdraw the mains plug and consult your
dealer.
Location of Unit
• The unit must be placed on a at stable
surface and should not be subjected to
vibrations.
• Do not place the unit on sloped or unstable
surfaces as the unit may fall o or tip over.
• The mains socket must be located near the
unit and should be easily accessible.
• This unit is designed for indoor, domestic
use only.
Temperature
• Avoid extreme degrees of temperature,
either hot or cold. Place the unit well away
from heat sources such as radiators or gas/
electric res.
• Avoid exposure to direct sunlight and other
sources of heat.
• Attention should be drawn to the use of
apparatus in moderate climates.
Naked Flames
• Never place any type of candle or naked
ame on the top of or near the unit.
Moisture
• To reduce the risk of re, electric shock or
product damage, do not expose this unit
to rain, moisture, dripping or splashing. No
objects lled with liquids, such as vases,
should be placed on the unit. Do not
operate the unit with wet hands, near water
or other liquid.
• If you spill any liquid into the unit, it can
cause serious damage. Switch it o at the
mains immediately. Withdraw the mains
plug and consult your dealer.
Ventilation
• To prevent the risk of electric shock or
re hazard due to overheating, ensure
that curtains and other materials do not
obstruct the ventilation vents.
• Do not install or place this unit in a
bookcase, built-in cabinet or in another
conned space. Ensure the unit is well
ventilated.
Safety
• Always disconnect the unit from the mains
supply before connecting/ disconnecting
other devices or moving the unit.
• Unplug the unit from the mains socket
before a lightning storm.
Mains Cable
• Make sure the unit or the unit stand is not
resting on top of the mains adapter cable,
as the weight of the unit may damage the
cable and create a safety hazard.
• If the mains cable is damaged it must be
replaced by the manufacturer, its service
agent, or similarly qualied persons in order
to avoid a hazard.
The mains plug is used as
disconnect device, the disconnect
device shall remain readily operable.
Interference
• Do not place the unit on or near appliances
which may cause electromagnetic
interference. If you do, it may adversely
aect the operating performance of the
unit, and cause a distorted picture or sound.
Batteries
• Batteries used in the remote control for this
unit are easily swallowed by young children
and this is dangerous.
• Keep loose batteries away from young
children and make sure that the battery
holder tray is secure in the remote control.
Seek medical advice if you believe a cell has
been swallowed.
• Please dispose of batteries correctly by
following the guidance in this manual.
• Do not expose the battery to direct sunlight
or sources of excessive heat.
• Attention should be drawn to the
environmental aspects of battery disposal.
5
RD-D227B_IB_Final190415V6.indd 5 16/04/2019 16:24

Supervision
• Children should be supervised to ensure
that they do not play with the unit and the
remote control.
• Never let anyone especially children push
anything into the holes, slots or any other
openings in the case - this could result in a
fatal electric shock.
Class 1 Laser Product
This unit utilises a laser. Use
of controls, adjustments or
performance of procedures
other than those specied
herein may result in hazardous radiation
exposure.
• Before moving the unit, ensure the disc tray
is empty.
• Always remove the disc when the unit is
not in use.
• Failure to do so will risk severely damaging
the disc and the unit.
• Do not stack devices, heat from other
devices may aect the performance of the
unit.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning ash with arrowhead
symbol, within an equilateral triangle, is
intended to alert the user to the
presence of uninsulated“dangerous
voltage” within the unit’s enclosure that
may be of sucient magnitude to
constitute a risk of electric shock.
The exclamation point within an
equilateral triangle is intended to alert
the user to the presence of important
operating and maintenance (servicing)
instructions in the manual
accompanying the unit.
Service
• To reduce the risk of electric shock, do not
remove screws. The unit does not contain
any user-serviceable parts. Please leave all
maintenance work to qualied personnel.
• Do not open any xed covers as this may
expose dangerous voltages.
Maintenance
• Ensure the unit is fully unplugged from the
power supply before cleaning.
• Do not use any type of abrasive pad or
abrasive cleaning solutions as these may
damage the unit’s surface.
• Do not use liquids to clean the unit.
CLASS 1
LASER PRODUCT
• This equipment is a Class II or double
insulated electrical appliance. It has
been designed in such a way that it
does not require a safety connection
to electrical earth.
~ AC voltage: This symbol indicates that the
rated voltage marked with the symbol is AC
voltage.
DC voltage: This symbol indicates that the
rated voltage marked with the symbol is DC
voltage.
6
RD-D227B_IB_Final190415V6.indd 6 16/04/2019 16:24

Unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so
according to local regulations.
The following items are included:
Main Unit Remote Control Mains Cable
Instruction Manual 3.5mm to RCA Stereo
Audio Cable
USB Connecting Cable
1
CD
INFO
/SCAN
DAB BT
INTRO
SLEEP
TIMER
BASS
REPEAT
ALBUM/PRESET
2 3
4 5
7 8 9
DIMMER CLOCK
EQ
6
VOL VOL
0PROG
SHUFFLE
FMUSB
CLEAR
PAIR
FMST/MONO
AUX
Instruction
Manual
Thank you for purchasing your new product.
We recommend that you spend some time reading this instruction manual
in order that you fully understand all the operational features it oers. You
will also nd some hints and tips to help you resolve any issues.
Read all the safety instructions carefully before use and keep this
instruction manual for future reference.
• If items are missing, or damaged please contact Partmaster (UK only). Tel: [phone] for assistance.
• If you require additional assistance:
For UK, please call our UK Call Centre on 0344 561 1234.
For Ireland, please call our Ireland Call Center on 1 890 818 575.
7
RD-D227B_IB_Final190415V6.indd 7 16/04/2019 16:24

USB R AUX LAC~
Rear View
1 2
Product Overview
Front View
1. Display
2. Remote Sensor
Receive signals from the remote control.
3. Speakers
4. CD Tray
5. USB Socket
6. AUX L/R Sockets
7. AC~ Socket
Connect the mains cable to the mains socket.
3 34
65 7
8
RD-D227B_IB_Final190415V6.indd 8 16/04/2019 16:24

SOURCE
SCAN
VOL– VOL+
1. NFC Sensor
2. Aerial
3. Button
Switch the unit between the On and
STANDBY mode.
4. SOURCE Button
Switch between DAB, USB, AUX, BT,
FM and DISC mode.
5. Button
Open or close disc compartment.
6. Button
• Press to skip backwards to the
beginning of the track or to the
previous track in DISC, USB and BT.
• Press and hold to fast reverse the
current track in DISC and USB mode.
• Select the previous preset station.
• Press to search for a radio station
going backwards through accessible
radio frequencies in FM and DAB
mode.
• Press and hold to perform an auto
search in FM mode.
7. /SCAN Button
• Play/pause/resume playback.
• Press to conrm a selection.
• Press to perform auto scan for radio
stations in FM and DAB mode.
• Press and hold to enter MANUAL
TUNE in DAB mode.
8. Button
• Press to skip to the next track in DISC,
BT and USB mode.
• Press and hold to fast forwards the
current track in DISC and USB mode.
• Select the next preset station.
• Press to search for a radio station
going forwards through accessible
radio frequencies in FM and DAB
mode.
• Press and hold to perform an auto
search in FM mode.
9. VOL– Button
Decrease the volume level.
10. VOL+ Button
Increase the volume level.
3 4 5 6 7 8 9 10
21
Top View
9
RD-D227B_IB_Final190415V6.indd 9 16/04/2019 16:24

1. Button
Switch the unit between the ON and
STANDBY mode.
2. SOURCE Buttons
Switch between CD/USB, DAB/FM,
BT or AUX mode.
3. INFO Button
Display DAB radio station
information.
4. INTRO Button
Play the rst 10 seconds of a
soundtrack in DISC mode.
5. /CLEAR Button
• Stop playback in USB and DISC
mode.
• In STANDBY mode, press and hold
to enter CLOCK SYNC MENU.
• In FM/DAB mode, press to exit
preset menu/programming menu/
manual tune menu.
• In FM/DAB mode, press and hold
to clear all preset stations.
6. ALBUM/PRESET / Buttons
• Navigate up/down through.
• Select a previous/next preset
station (DAB: see p.18-19; FM:
see p.21).
• Adjust the time.
• Skip to the previous/next album.
7. Numeric keypad (0-9) Buttons
• Select a track number for playlist
in DISC, FM, DAB and USB mode.
8. DIMMER Button
Adjust the display brightness.
9. Button
Open or close disc compartment.
10. SHUFFLE/FM ST/MONO Button
• In CD/USB mode, randomly play
back CD or music tracks.
• In FM/DAB mode, press to switch
between STEREO or MONO mode.
Remote Control
1
C D
INFO
/SCAN
DAB BT
INTRO
SLEEP
TIMER
BASS
REPEAT
ALBUM/PRESET
2 3
4 5
7 8 9
DIMMER CLOCK
E Q
6
VOL VOL
0PROG
SHUFFLE
FMUSB
CLEAR
PAIR
FM ST/MONO
AUX
3
4
2
5
1
6
7
8
9
10
10
RD-D227B_IB_Final190415V6.indd 10 16/04/2019 16:24

11. REPEAT Button
Select repeat play mode in DISC and
USB mode.
12. Button
Mute or resume the sound.
13. /SCAN Button
• Play/pause/resume playback.
• Press to conrm a selection.
• Press to perform auto scan for radio
stations in FM and DAB mode.
• Press and hold to enter MANUAL
TUNE in DAB mode.
14. / Buttons
• In DISC/BT/USB mode: Search
backward/forward within a track/
disc.
• In DISC/USB mode: Press and hold
to fast reverse/forwards within a
track.
• In FM mode: Search radio station
manually, press and hold the button
to search automatically.
• Navigate to select an item on a
menu screen (DAB).
15. VOL+/VOL– Buttons
Increase/Decrease the volume level.
16. EQ Button
Select the preset equaliser.
17. BASS Button
Turn the bass ON or OFF.
18. SLEEP/TIMER Button
Set the sleep/alarm timer.
19. CLOCK Button
• In STANDBY mode, press and hold
to activate clock setup.
• Display current clock
20. PROG Button
• Programme soundtracks (see p.23).
• Preset radio stations (DAB: see
p.18-19; FM: see p.21).
1
C D
INFO
/SCAN
DAB BT
INTRO
SLEEP
TIMER
BASS
REPEAT
ALBUM/PRESET
2 3
4 5
7 8 9
DIMMER CLOCK
E Q
6
VOL VOL
0PROG
SHUFFLE
FMUSB
CLEAR
PAIR
FM ST/MONO
AUX
16
17
18
19
20
12
11
13
14
15
11
RD-D227B_IB_Final190415V6.indd 11 16/04/2019 16:24

Replace the Remote Control Battery
Operating Your Remote Control
When you rst time use remote control, remove
the protective tab to activate the remote control
battery.
1. Pull out the battery tray.
2. Remove the old battery
3. Replace new CR2025 battery into the battery
tray with correct polarity as indicated.
4. Insert the battery tray back into the slot.
Handling the Remote Control
• Take care of your ngernails when you slide and pull the battery release tab.
• Do not drop the remote control.
• Do not allow anything to impact the remote control.
• Do not spill water or liquid on the remote control.
• Do not place the remote control on a wet object.
• Remove the battery from the remote control when not in use for a long period of time, as corrosion or
battery leakage may occur and result in physical injury, and/or property damage, and/or re.
• When the battery is exhausted, the remote control will not function.
• Small button cell batteries such as the one used in the remote control are easily swallowed by young
children and this is dangerous. Keep loose button cells away from young children and make sure that
the battery is secure in the remote control. Seek medical advice if you believe a battery cell has been
swallowed.
12
RD-D227B_IB_Final190415V6.indd 12 16/04/2019 16:24

Remote Control Operation Range
• The remote control sensor on the front unit is
sensitive to the remote control’s commands up
to a maximum of 5 metres away and within a
maximum of a 40° arc.
• Please note that the operating distance may
vary depending on the brightness of the room.
Wall Mounting
1. Remove the screws from the main unit.
1
CD
INFO
/SCAN
DAB BT
INTRO
SLEEP
TIMER
BASS
REPEAT
ALBUM/PRESET
2 3
4 5
7 8 9
DIMMER CLOCK
EQ
6
VOL VOL
0PROG
SHUFFLE
FMUSB
CLEAR
PAIR
FMST/MONO
AUX
20° 20°
Max. 5 m
2. Fix the two screws (not included) onto the wall. They should be parallel to each other.
The distance between the two screws should be 121 mm.
121 mm
13
RD-D227B_IB_Final190415V6.indd 13 16/04/2019 16:24

Connections
Using the AUX Connection
Use a 3.5mm to RCA stereo audio cable to connect an auxiliary equipment to the main
unit’s AUX L/R sockets.
USB R AUX LAC~
Auxiliary Equipment
3.5mm to RCA stereo audio cable
(Included)
3. Leave a 5 mm gap between the wall and the screw’s
head. Lift the unit with the attached wall brackets over
the heads of the screws and slot into place.
5 mm
25-30 mm
USB R AUX LAC~
Use a RCA stereo audio cable (not included) to connect an auxiliary equipment to the main
unit’s AUX L/R sockets.
Auxiliary Equipment
RCA stereo audio cables
(Not included)
The wall where the unit is to be installed must be capable of long-
term support of the total load of the unit. Measurements should
also be taken to ensure sucient strength to withstand the force
of earthquakes, vibrations and other external forces. Incorrect
installation can cause the unit to fall and cause injury.
14
RD-D227B_IB_Final190415V6.indd 14 16/04/2019 16:24

Connecting to the Mains Supply
• This unit is designed to operate with an AC
power supply.
• Connecting the unit to any other power source
may cause damage to the unit. Unwind the
mains cable to its full length. Connect the
mains plug to a mains socket. Make sure the
mains plug is fully inserted into the mains socket. The unit is now connected and ready
to use.
• To switch the unit o completely, unplug the mains plug from the mains socket.
Ensure all connections are connected before connecting to the mains power socket.
USB R AUX LAC~
To the mains
socket
General Operation
Powering ON/OFF
When you rst connect the unit to the mains socket, the unit will be in STANDBY mode.
• Press the Standby button on the unit or the remote control to switch the unit on.
• Press the Standby button on the unit or the remote control to switch the unit back to
STANDBY mode.
• Disconnect the mains plug from the mains socket if you want to switch the unit o
completely.
Selecting Modes
Press the SOURCE button repeatedly on the unit to switch between FM, DISC, USB, AUX,
BT and DAB mode. The selected mode will show on the display. Alternatively press the CD/
USB, DAB/FM, AUX and BT button on the remote control to select the desired mode.
• The eco-friendly technology saves power by switching the device to STANDBY mode when there is no
input signal (or weak input signal) in USB/AUX/BT and when CD is not playing (No disc, Stop or Pause)
for over 15 minutes.
• Please turn the unit o completely to save energy when not in use.
Adjusting the Bass
Press the BASS button on the remote control repeatedly to select BASS ON or BASS OFF.
Adjusting the Volume
• Press the VOL+/VOL– button on the unit or remote control to adjust the volume.
• If you wish to turn the sound o, press the MUTE button on the remote control. Press
the MUTE button again or press the VOL +/VOL – button on the remote control.
15
RD-D227B_IB_Final190415V6.indd 15 16/04/2019 16:24

Adjusting the Sound Eect
Press the EQ button the remote control repeatedly to select Pop, Classic, Jazz or Rock for
your desired sound eect.
Adjusting the Brightness
Press the DIMMER button to select the brightness level.
Setting of the Clock
Manual Setting of the clock can only be done in STANDBY mode.
1. In STANDBY mode, press and hold the CLOCK button on the remote control until the
hour digits are ashing.
2. Press the button on the remote control to adjust the hour digits while ashing, then
press the CLOCK button to conrm, then the minute digits will ash.
3. Press the button to adjust the minute digits while ashing, then press the CLOCK
button on the remote control to conrm.
4. Press /SCAN button to select 12-hour or 24-hour mode.
5. Each activated state will be cleared if any buttons are not pressed in about 15 seconds.
Time Display
When in ON mode, press the CLOCK button to show the current time on the display for a
few seconds.
Synchronising the Clock
When in STANDBY mode, press and hold /CLEAR button to synchronise the clock.
Press the button on the remote control to select below options:
• RADIO: Only synchronize with the RDS radio station.
• OFF: Turn o clock synchronisation.
Press button to conrm.
Setting the Alarm Timer
The clock must be correctly set for the timer to operate correctly.
1. In STANDBY mode, press and hold the SLEEP/TIMER button on the remote control
until the hour digits ash on the display.
2. Press the button on the remote control to adjust the hour digits, and then press the
SLEEP/TIMER button to conrm. The minute digits will ash on the display.
3. Press the button on the remote control to adjust the minute digits, and then press
the SLEEP/TIMER button to conrm, the tuner timer will ash on the display
4. Press the button on the remote control to select BUZZER, DISC, FM, DAB, or USB
mode, and then press the SLEEP/TIMER button to conrm, the display will show the
volume level.
5. Press the button on the remote control to adjust the volume, and then press the
SLEEP/TIMER button on the remote control to conrm,“ ”will show on the display.
16
RD-D227B_IB_Final190415V6.indd 16 16/04/2019 16:24

Activate and Deactivate the Alarm Timer
• After setting the alarm timer, press the SLEEP/TIMER button on the remote control to
view the alarm settings.
• The alarm is active when “ ” is shown on the display.
• When the alarm rings, press button to turn o the alarm.
• To deactivate the alarm, press the SLEEP/TIMER button twice. The “ ” will disappear
on the display. Press the SLEEP/TIMER button twice again to activate the alarm timer.
Setting the Sleep Timer
Use the sleep timer to turn the system o after a certain number of minutes in play mode.
By setting the sleep timer, you can fall asleep to music and know that your system will turn
o by itself rather than play all night.
1. When in ON mode, press the SLEEP/TIMER button on the remote control repeatedly
to view the dierent sleep timer settings. The number of minutes shown will display in
this sequence:
SLEEP 90 SLEEP 60
SLEEP 00 SLEEP 15
SLEEP 30
2. The system is now set to turn o after the number of minutes you have set. The
display will show“SLEEP #”, e.g. “SLEEP 30” means the unit will switch itself o after 30
minutes, “SLEEP 10”means the unit will switch itself o after 10 minutes, and so on.
3. Press the SLEEP/TIMER button to show the reminding time till the unit switches o
minutes and return back to previous screen.
4. To cancel the sleep timer press the SLEEP/TIMER button repeatedly until“SLEEP 00”
shows on the display.
System Reset
There may be times when you need to reset your unit back to the factory settings especially
when you have moved house. If you experience reception problems you may want to reset
and try again. If you move to another part of the country and pick up the local and national
DAB/FM stations in that area, your previously tuned channels may no longer be available.
1. When in FM or DAB mode, press and hold the /CLEAR button on the remote control.
2. The display will show “CLEAR“, and then all the stored stations will be cleared.
17
RD-D227B_IB_Final190415V6.indd 17 16/04/2019 16:24

DAB Operation
To listen to the tuned stations press the button. Each time you press the
button, you will skip to the previous or next stored station (including primary and
secondary station). The unit will display the station name.
Auto Scan
The auto scan will search for all DAB Band III channels. After the scan has nished, the rst
alphanumerically found station will be automatically selected.
1. Press the /SCAN button on the remote control to start Auto Scan. The display will
show “SCANNING“ and then “SCAN ##”that indicates the progress of the scan and the
amount of stations that have been found so far.
2. Once the scan has nished, the unit will display the total number of stations have been
found. All the stations that have been found will be stored automatically.
To explore the found stations, press the button to the selected station.
You may press and hold the /CLEAR button to clear the previously tuned stations before running
an auto scan.
Manual Tuning
As well as the auto tune function, you can manually tune the receiver. This can help you
when aligning your aerial or when adding stations that were missed while auto tuning.
1. Press and hold the /SCAN button to select Manual tune, the display will now show
“Manual tune”.
2. Press the button to cycle through the DAB channels, which are frequency from
5A to 13F.
3. After your desired channel number is selected, press the /SCAN button to conrm.
The display will show “TUNING”.
4. The unit will start to scan.
Presetting Stations
You can store up to 20 of your favourite DAB stations to the memory. This will enable you to
access your favourite stations quickly and easily.
1. To store a preset, you must rst be listening to the station that you would like to save.
2. Press PROG button on the remote control. The display will show “## Empty”, and the
preset number will ash.
3. Press button on the remote control to select your desired station preset number.
4. Press the PROG button to conrm your station, the display will show “SAVED”.
18
RD-D227B_IB_Final190415V6.indd 18 16/04/2019 16:24

Recalling a Preset Station
1. Once you have saved a station to one of the preset buttons, you can recall it by pressing
the button on the remote control to select your desired preset number.
2. Preset number and station name will show on the display to indicate the preset station
you are listening to. Press /SCAN button on the unit or remote control to conrm.
The stored stations will be saved into the memory and power o will not erase it. Storing a new station in
a preset location will erase the previously stored station in that location.
19
RD-D227B_IB_Final190415V6.indd 19 16/04/2019 16:24

DAB Display Modes
Every time you press the INFO button on the remote control, the display will cycle through
the following display modes.
Station Name
Ensemble Name
Clock
Date
DLS
Programme Type
Channel Number
Frequency
Stereo/Mono
Bit Rate
Signal Strength
Station Name
When a radio station is received, the name of that station will
be displayed.
Ensemble Name
A Ensemble/multiplex is a collection of radio stations that
are bundled and transmitted on one frequency. There are
national and local multiplexes. Local ones contain stations
that are specic to that area.
DAB – unlike normal radio, groups together several radio
stations and transmits them on one frequency.
Clock
The broadcaster (Radio station) provides clock information
automatically. If the information is not available, the display
will show the incorrect time.
Date
The broadcaster (Radio station) provides date information
automatically. If the information is not available, the display
will show the incorrect date.
DLS (Dynamic Label Segment)
Dynamic label segment is a scrolling message that the
broadcaster may include with their transmissions. The
message usually includes information, such as programme
details etc.
Programme Type
This describes the “Style” or “genre” of music that is being
broadcast e.g. “Rock” or “Classical”.
Channel Number
DAB digital radio can be broadcast on a wide number of
frequencies.
Frequency
The frequency of the present station will be displayed.
Stereo/Mono
The display will show the audio mode (Stereo or Mono) of
the current station.
Bitrate
The display will show the digital audio bit rate being received.
Signal Strength
The display will show a slide bar to indicate the signal
strength, the stronger the signal, the longer the bar will be from
left to right.
20
RD-D227B_IB_Final190415V6.indd 20 16/04/2019 16:24
