JVC CS-G1210 User manual

Subwoofers
drvn Series Subwoofers
400W
RMS
1400W
Peak Power
✹High Response
(High-Compression Urethane Surround)
High-Compression Urethane Surround allows
woofers to produce a more linear excursion
resulting in more bass output.
Dual Voice
Coil
Single Voice
Coil
The drvn Series subwoofers deliver dynamic sound with more aggressive-looking design. The dual voice coil CS-GD1210 comes
with a large magnet for powerful sound, while the butyl rubber surround provides strong deep bass. The CS-G1210 features
superior sound in the most audible range with quick-responding high-compression urethane surround.
Key Benefits
CS-GD1210
12” (30cm) Dual Voice Coil Subwoofer Unit
✹High Sound Pressure
(Butyl Rubber Surround)
Butyl Rubber Surround allows long-throw
linearity with control and stability at the
excursion limits.
CS-G1210
12” (30cm) Subwoofer Unit
250W
RMS
1200W
Peak Power
Sound Dynamics
Design
Sound Dynamics
Design
Strong &
Deep Bass
Strong &
Deep Bass
CS-GD1210
CS-G1210
Butyl Rubber
Surroound
Strong &
Quick Bass
Strong &
Quick Bass
CS-GD1210 CS-G1210
High-Compression
Urethane Surround

NTK-0929-19
Key Specifications
CS-GD1200 CS-G1200
Size 12” (30 cm) 12” (30 cm)
Power Handling Capacity (Peak) 1400W 1200W
Power Handling Capacity (RMS) 400W 250W
Sensitivity 86.5dB/W.m 87.5dB/W.m
Frequency Response 20 - 2,000Hz 25 - 2,500Hz
Impedance 4Ω+ 4Ω(Dual Input) 4Ω
Fs 39.8Hz 41Hz
Qts 0.837 0.961
Vas 1.23 ft3 1.77 ft3
Magnet Mass 62.6 oz 39.0 oz
Hole Cutout Diameter Dia. 10 31/32” (278 mm) Dia. 10 31/32” (278 mm)
Mounting Depth 5 25/32” (146.4 mm) 5 13/32” (136.6 mm)
Weight (NET) 5.1kg (11.3 lbs.) 3.7kg (8.2 lbs.)
✹Cutaway View
Dimensions
Recommended Enclosure Size
(CS-GD1210/G1210)
0.75-1.5 cu/ft
(1 cu/ft recommended)
Sealed Type
1-1.8 cu/ft
(1.2 cu/ft recommended)
Ported Type
Recommended System
CS-GD1210 CS-G1210
or
CS-VS608 CS-VS608
Front
Rear
Front
Rear
CS-V6938 CS-V6938
KS-AX3204
drvn Series Subwoofers
KW-AV71BT
KS-AX3201D
CS-GD1210
13 inch (330 mm)
12-1/16 inch (306 mm)
7/32 inch (5.2 mm) x 8 HOLES
21/32 inch (16.6 mm)
5-25/32 inch (146.4 mm)
6-5/32 inch
(156 mm)
10-29/32 inch (276.5 mm)
CS-G1210
13 inch (330 mm)
12-1/16 inch (306 mm)
7/32 inch (5.2 mm) x 8 HOLES
21/32 inch (16.6 mm)
5-13/32 inch (136.6 mm)
10-29/32 inch (276.5 mm)
5-17/32 inch
(140 mm)
CS-GD1210
3D Structure and Sputtering
Olefin Diaphragm
Aggressive Design Gasket
Butyl Rubber Surround
Pulp Cone
High Linearity Spider
Dual Voice Coil
Long Stroke and Vented Pole Yoke
Large Strontium
Magnet 62.6 oz
