SERVICE MANUAL
COPYRIGHT © 2003 VICTOR COMPANY OF JAPAN, LIMITED No.52113C
2003/10
COLOR TELEVISION
52113C200310 AV-27F734/SA, AV-27F734/ZA
AV-32F734/YA, AV-32F734/ZA
Supplementary
OUTLINE
HOW TO IDENTIFY MODELS
The following items for the AV-27F734/ASA, AV-27F734/AZA, AV-32F734/AYA, AV-32F734/AZA model were
changed partly from AV-27F704/ASA, AV-27F704/AZA, AV-32F704/AYA, AV-32F704/AZA model.
Therefore, this service manual describes only the items which differ from those of the AV-27F704/ASA, AV-
27F704/AZA, AV-32F704/AYA, AV-32F704/AZA model
service manual.
For details other than those described in this manual, please refer to the AV-27F704/ASA, AV-27F704/AZA,
AV-32F704/AYA, AV-32F704/AZA model service manual (No.52113, 2003/6) (No.52113B, 2003/8).
Since new models are added for sales in general merchandising store, we have issued the SERVICE MANUAL
for AV-27F734/ASA, AV-27F734/AZA, AV-32F734/AYA, AV-32F734/AZA.
MODEL NO.
AC 120V 60Hz
W
TV SCREEN SIZE : DIAGONAL
INCHES
CHASSIS NO.
MANUFACTURED
SERIAL NO.
VIDEO EQUIPMENT
4C43
ME
AV-27F734
or AV-32F734
SA or ZA or YA
DISTINGUISH NAME
MODEL NAME
A suffix “SA”, “YA” and “ZA” are added to the serial No. under at the Rating label.
BASIC CHASSIS
GJ2

1-2 (No.52113C)
DIFFERENCE LIST
AV-27F734 and AV-32F734 are the model to which the "BBE" were added to AV-27F704 and AV-32F704.
USING P.W. BOARD (Page 3-3)
EXPLODED VIEW PARTS LIST (Page 3-3)
PRINTED WIRING BOARD PARTS LIST [AV-27F734/SA]
MAIN P.W. BOARD ASS’Y (Page 3-6)
PRINTED WIRING BOARD PARTS LIST [AV-27F734/ZA]
MAIN P.W. BOARD ASS’Y (Page 3-12)
P.W.B ASS'Y Name AV-27F704/ASA AV-27F734/SA DESCRIPTION
MAIN P.W.B SGJ-1503A-M2 SGJ-1531A-M2 Non compatible
AV SELECTOR P.W.B SGJ-5501A-M2 SGJ-5502A-M2 Non compatible
P.W.B ASS'Y Name AV-27F704/AZA AV-27F734/ZA DESCRIPTION
MAIN P.W.B SGJ-1504A-M2 SGJ-1532A-M2 Non compatible
AV SELECTOR P.W.B SGJ-5501A-M2 SGJ-5502A-M2 Non compatible
P.W.B ASS'Y Name AV-32F704/AYA AV-32F734/YA DESCRIPTION
MAIN P.W.B SGJ-1501A-M2 SGJ-1533A-M2 Non compatible
AV SELECTOR P.W.B SGJ-5501A-M2 SGJ-5502A-M2 Non compatible
P.W.B ASS'Y Name AV-32F704/AZA AV-32F734/ZA DESCRIPTION
MAIN P.W.B SGJ-1505A-M2 SGJ-1534A-M2 Non compatible
AV SELECTOR P.W.B SGJ-5501A-M2 SGJ-5502A-M2 Non compatible
Ref. No. PARTS No. PARTS NAME DESCRIPTION
AV-27F734/ASA
AV-27F734/AZA AV-27F734/SA AV-27F734/ZA
100 LC10878-006C-A LC10878-009A-A FRONT CABI ASSY Silver
Ref. No. PARTS No. PARTS NAME DESCRIPTION
AV-32F734/AYA AV-32F734/YA
100 LC11048-008D-A LC11048-011A-A FRONT CABI ASSY Silver
Ref. No. PARTS No. PARTS NAME DESCRIPTION
AV-32F734/AZA AV-32F734/ZA
100 LC11048-008D-A LC11048-011A-A FRONT CABI ASSY Silver
T502 QQR1414-001 QQH0140-002 FB TRANSF Change
Ref. No.
PARTS No.
PARTS NAME DESCRIPTIONAV-27F704/ASA AV-27F734/SA
SGJ-1503A-M2 SGJ-1531A-M2
IC201 TM8812CSDNG4RR3 TM8812CSDNG4UC1 IC(MCU)
C004 QETN0JM-477Z QETN1CM-108Z E CAPACITOR
Ref. No.
PARTS No.
PARTS NAME DESCRIPTIONAV-27F704/AZA AV-27F734/ZA
SGJ-1504A-M2 SGJ-1532A-M2
IC201 TM8812CSDNG4RR3 TM8812CSDNG4UC1 IC(MCU) Change

(No.52113C)1-3
PRINTED WIRING BOARD PARTS LIST [AV-32F734/YA]
MAIN P.W. BOARD ASS’Y (Page 3-17)
PRINTED WIRING BOARD PARTS LIST [AV-32F734/ZA]
MAIN P.W. BOARD ASS’Y (Page 3-22)
PRINTED WIRING BOARD PARTS LIST
AV SELECTOR P.W. BOARD ASS'Y (Page 3-9)
Ref. No.
PARTS No.
PARTS NAME DESCRIPTIONAV-32F704/AYA AV-32F734/YA
SGJ-1501A-M2 SGJ-1533A-M2
IC201 TM8812CSDNG4RR3 TM8812CSDNG4UC1 IC(MCU) Change
Ref. No.
PARTS No.
PARTS NAME DESCRIPTIONAV-32F704/AZA AV-32F734/ZA
SGJ-1505A-M2 SGJ-1534A-M2
IC201 TM8812CSDNG4RR3 TM8812CSDNG4UC1 IC(MCU) Change
Ref. No.
PARTS No.
PARTS NAME DESCRIPTION
AV-27F704/ASA
AV-27F704/AZA
AV-32F704/AYA
AV-32F704/AZA
AV-27F734/SA
AV-27F734/ZA
AV-32F734/YA
AV-32F734/ZA
SGJ-5501A-M2 SGJ-5502A-M2
IC5151 --- NJM2150AD IC Addition
R5151 --- NRSA63J-223X MG RESISTOR Addition
R5152 --- NRSA63J-223X MG RESISTOR Addition
R5153 --- NRSA63J-223X MG RESISTOR Addition
R5154 --- NRSA63J-223X MG RESISTOR Addition
R5156 --- NRSA63J-0R0X MG RESISTOR Addition
R5158 --- NRSA63J-0R0X MG RESISTOR Addition
R5159 --- NRSA63J-103X MG RESISTOR Addition
C5015 QETN1HM-106Z QBTC1CK-106Z E CAPACITOR
C5026 QETN1HM-335Z QBTC1CK-335Z E CAPACITOR
C5151 --- QENC1HM-105Z BP E CAPACITOR Addition
C5152 --- QENC1HM-105Z BP E CAPACITOR Addition
C5153 --- NCB31HK-222X C CAPACITOR Addition
C5154 --- NCB31HK-222X C CAPACITOR Addition
C5155 --- NCB31HK-473X CHIP C CAPACITOR Addition
C5156 --- NCB31HK-473X CHIP C CAPACITOR Addition
C5157 --- QETN1HM-106Z E CAPACITOR Addition
C5158 --- QETN1HM-106Z E CAPACITOR Addition
C5159 --- QETN1EM-476Z E CAPACITOR Addition
C5160 --- NCB31EK-104X C CAPACITOR Addition
D5504 --- MTZJ9.1C-T2 Z DIODE Addition
C5504 QETN1HM-106Z QENC1CM-106Z E CAPACITOR

(No.52113C)
AV & MULTIMEDIA COMPANY VIDEO DISPLAY CATEGORY 12, 3-chome, Moriya-cho, kanagawa-ku, Yokohama, kanagawa-prefecture, 221-8528, Japan
VICTOR COMPANY OF JAPAN, LIMITED
WPC
Printed in Japan
PACKING PARTS LIST (Page 3-32)
Ref. No.
PARTS No.
PARTS NAME DESCRIPTION
AV-32H704/AZA
AV-27F704/AZA
AV-32F704/AYA
AV-32F704/AZA
AV-27F734/SA
AV-27F734/ZA
AV-32F704/YA
AV-32F704/ZA
9 RM-C1252G-1H RM-C1251G-1H REMOCON Change
10 LCT1339-001A-A LCT1506-001A-A INST BOOK Change
12 BT-52006-2Q --- WARRANTY CARD Delete
