JVC HR-A35U User manual

PROG.
CHECK
PROG.
TV operation – Press and hold
TV button, then press POWER,
TV CH +/–, VOL +/–, TV/VCR
POWER
TV
12 3
45
0
AUX
6
78
DAILY 9 WEEKLY
DISPLAY
TV/VCR
SP/EP
CANCEL
START
REW FF
PLAY
REC
MENU
OK
STOP
TV CH +
TV CH –
TV
+ VOL
TV
VOL –
PAUSE
STOP DATE CH
C.RESET OSD
ENTER TIMER
1
2
4
3
SHUTTLE PLUSSHUTTLE PLUS
LP20034-020
–+
QUICK START*
A GUIDE TO EASY SET UP AND USE
CHECK
PACKAGE
CONTENTS
1
1
The Path To Enjoyment
Starts Here . . .
Dear Customer,
Thank you for purchasing
this JVC Video Cassette
Recorder.
SET CLOCK
AND
TUNER
3
3
SITUATE AND
CONNECT
VCR
2
2
5
5
4
4RECORD
A
PROGRAM
PLAY BACK
A
TAPE
1
1MAKE SURE THAT YOUR PACKAGE
CONTAINS:
* Please refer to the HR-A55U/35U’s instruction manual for
more detailed information.
4
4WATCH A RECORDED PROGRAM
MONO/Hi-Fi/SUPER VHS
VIDEO CASSETTE RECORDERS
UPrinted in Malaysia
1298 IYV*MW*PJ
COPYRIGHT © 1999VICTOR COMPANY OF JAPAN, LTD.
VIDEO CASSETTE
RECORDER
12 3
45
0
6
7 8 9
1
2
4
3
–+
LPT0188-002A
* You can use the available buttons on the remote control or on the VCR.
1Load a cassette with the label facing out and the window facing up.
2Press REW or FF (remote) to find program start point.
3Press PLAY to start playback.
4Press STOP (remote) or STOP/EJECT (VCR), then press STOP/EJECT to remove the
cassette.
b–INSTANT TIMER RECORDING
a–BASIC RECORDING
5
5RECORD A PROGRAM
* You cannot perform ITR using the remote control.
1Press REC to start recording.
2Press REC to engage ITR. “0:30” appears in the VCR display.
3To extend duration in increments of 30 minutes, press REC as many times as necessary.
* You can use the available buttons on the remote control or on the VCR.
1Load a cassette as above.
2Press CH, or press the appropriate NUMBER keys (remote) and press ENTER (remote),
to select the recording channel.
3Press SP/EP (remote) to set the recording speed.
4Press REC and PLAY together (remote) or REC (VCR) to start recording.
5Press PAUSE to stop recording temporarily, and press PLAY to resume.
6Press STOP or STOP/EJECT, then press STOP/EJECT to remove the cassette.
SP P
VCR
POWER
SP VCR
MENU
CH OK
REC
REW PLAY FF
PAUSESTOP/EJECT
VIDEO AUDIO
POWER
SP VCR
MENU
CH OK
REC
REW PLAY FF
PAUSESTOP/EJECT
VIDEO (MONO)L—AUDIO—R
HR-A55U
POWER
HR-A35U
POWER
REC
PLAY
RF CABLE (F-TYPE)
“AA” BATTERY x 2
INFRARED
REMOTE
CONTROL
UNIT
PLAY
POWER
CH +/–
PLAY
FF (Fast-Forward)
PAUSE
TV/VCR
SP/EP
ENTER
STOP
NUMBER
STOP/EJECT
PAUSE
REC
CH 䊱䊲
STOP/EJECT
PAUSE
REC
CH 䊱䊲
HR-A35U
HR-A55U
REW (Rewind)

a–BASIC ANTENNA/CABLE CONNECTION
SITUATE AND CONNECT YOUR
NEW VCR
2
2b–CATV CONVERTER CONNECTION
PLUG & PLAY
3
3SET YOUR VCR'S CLOCK AND
TUNER
1Place the VCR on a stable, horizontal
surface.
2Disconnect your antenna or cable line
from your TV.
3Connect your antenna to your VCR.
4Connect your VCR to your TV.
䡲Antenna Splitter 䡲Antenna Splitter
䡲VHF/UHF Antenna Mixer
䡲RF Cable 䡲300-75 ohm Matching
Transformer
●CONNECTORS WHICH ARE OR MAY BE REQUIRED:
CABLE TV LINE Note:
Exact connector positions and names may differ.
ANT. IN
RF OUT
VHF/UHF
VHF
VHF
UHF
UHF
UHF ONLY
VHF ONLY
SEPARATE VHF/UHF
COMBINED VHF/UHF Back of VCR (example only) Back of TV (example only)
RF CONNECTION
5After completing the basic connections:
●If you’re using a Cable Box, . . .
. . . go to 2b (CATV CONVERTER
CONNECTION) .
●If you’re using an AV connection, . . .
. . . go to 2c (AUDIO/VIDEO
CONNECTIONS).
●If you’re using an RF connection, . . .
. . . go directly to 3(PLUG & PLAY).
INOUT
ANT. IN
RF OUT
CATV Input
From
Cable
Box
To TV
Cable
Box
TV
VCR
With this connection you can view/record any
cable channel including scrambled channels to
which you have subscribed.
INOUT
ANT. IN
RF OUT
CATV Input
From VCR
Cable
Box
To TV
TV VCR
With this connection, you can view one
scrambled cable channel while recording
another unscrambled channel.
To watch TV with this type of connection
1Press TV/VCR on remote to engage VIDEO
mode.
2Tune TV to VCR output channel
(3, 4 or AV mode).
3Tune VCR to Cable Box output channel.
4Select desired channel on Cable Box.
•You can only view the channel you’re
recording.
•You cannot change channels with the
VCR remote control.
To watch TV with this type of connection
1Press CH or NUMBER keys to select desired
channel for recording.
2Press TV/VCR to engage TV mode.
3Tune TV to Cable Box output channel.
4Select desired channel on Cable Box.
•You cannot record scrambled channels.
•To play back a tape, you must tune the Cable
Box to the VCR output channel.
c–AUDIO/VIDEO CONNECTIONS
To Listen To VCR Sound Through A
Component Stereo Audio System,
Connect As Shown
AV connection methods differ from one type
of VCR to another. First, for any TV and VCR
type, connect your VCR to your TV using RF
connection. Then make AV connections
following one of the methods pictured to the
right.
After making the connections, go to 3 (PLUG
& PLAY)
.
MONAURAL VHS VCR 佡AV TV
VIDEO OUT
AUDIO OUT
VIDEO IN
AUDIO IN
SUPER VHS VCR 佡AV STEREO TV WITH S-VIDEO
INPUT TERMINALS
VIDEO IN
S-VIDEO IN
VIDEO OUT
S-VIDEO OUT
R
AUDIO INAUDIO OUT
L
R
L
Hi-Fi VHS VCR 佡AV STEREO TV
VIDEO INVIDEO OUT
R
AUDIO INAUDIO OUT
L
R
L
AMP
VIDEO OUT
AUDIO OUT
R
L
VCR TV
Monaural deck owners:
Connect to VCR's AUDIO
OUT
The VCR's clock and tuner channels are set automatically when the VCR is plugged into the AC
outlet.
If you use a cable box, Plug & Play will not function; set the clock and tuner channels manually.
(墌pg.11 – 15 of the HR-A55/35U’s instruction manual)
1
Plug the VCR into the
AC outlet.
2
Don’t press any buttons on the VCR or remote
during auto setup.
3
“AUTO” blinks while the VCR automatically
sets the clock using information provided by
the local PBS channel.
NOTES:
●If the time displayed in is incorrect, perform the Semi-Auto or Manual Clock Set procedure
(refer to page 12 or 13 of the HR-A55U/35U’s instruction manual). Auto channel set has already
taken place, and is not affected.
●There are some PBS channels that do not transmit clock setting data. If your antenna cable is
properly connected and “– – : – –” is displayed, perform the Manual Clock Set procedure (refer
to page 13 of the HR-A55U/35U’s instruction manual). Auto channel setting has not yet taken
place, so please also perform the “Set Receivable Channels” procedure (refer to page 14 of the
HR-A55U/35U’s instruction manual).
5
4
During auto channel setting, the channel
numbers are displayed as they are scanned and
set. Receivable channels are automatically
assigned to CH buttons, and non-receivable
channels are skipped.
5
When setting is complete, the VCR displays the
current time. You can now use your VCR.
