BEDIENUNGSANWEISUNG
mit Montageanweisungen
Instructions for use and installation instructions
EEB 10500.0
072533 I71

EEB 6500.0 19
For your information...
You should carefully read the information in this manual before you use your
oven. Here you will find important notes concerning safety and how to use,
look after and service your appliance so that it enjoys a long service life.
Should a fault arise, please first consult chapter “What to do if trouble occurs”.
You can often remedy minor faults yourself and thus save unnecessary service
costs.
Please keep this manual in a safety place and pass it on to new owners for
their information and safety.
The following symbols are used in this operating manual:
[The warning triangle draws your attention to risks to your health or
damage that might be caused to your appliance.
FHere you will find useful hints and information.
Conditions of guarantee
The conditions of guarantee applicable for this product are subject to those
published by the representative in the relevant country.
Details regarding same may be obtained from the dealer from whom the
appliance was purchased. For claims under guarantee the sales receipt must
be produced.
Contents
Your appliance at a glance . . . . . . . . . . . . . . . . . . . . . . . 20
Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Connection and operation
Oven
Before using the appliance for the first time . . . . . . . . . . . 21
Disposing of the packaging and the old appliance
Setting the clock
Initial cleaning
Using your oven. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
General
Controls and displays for the oven
Symbols and operating modes
Heating-up indicator and pilot light
Turning the oven light on and off
Turning the oven on and off
Oven trays
Rack levels:
backmobil®(acc.-no. 600)
Telescopic glide-out shelves (acc.-no. 601)
Fast preheating
Roasting
Recommended temperatures for roasting
Baking
Baking pizza
Tips on the table “Recommended temperatures for baking”
Recommended temperatures for baking
Grilling
Recommended temperatures for grilling
Defrosting
Preserving
The electronic timer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Setting/changing the clock
Setting the alarm time
This is how to programme the switching operations
Changing the setting
When the cooking time is finished
Setting the cooking time 7(switch-off function)
Setting the finish time 8(switch-off function)
Automatic turn-on and shut-off
Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
For all surfaces
Remove caking
Please note the information for the cleaning scraper
The use of oven sprays - information
Enamel
Stainless steel
Glass
Aluminium
Door sealing
Buttons
Removing and installing the oven door
Removing and installing the side racks
Folding heating element down/up
Regenerating the ökotherm®catalyst
What to do if trouble occurs... . . . . . . . . . . . . . . . . . . . . . 31
Replacing the oven lamp
Replacing the door sealing
Rating label. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Installation instructions for fitter. . . . . . . . . . . . . . . . . . . . 32
Electrics
Installation dimensions
Installation in a fitted kitchen

20 EEB 6500.0
12
8
9
11
10
1
H
2
7 8 4
8888
13
H
4
3 6 75
Your appliance at a glance
1 Mode selector
2 Heating-up indicator
3 Temperature control
4 Electronic timer display
5 Control buttons for the electronic timer
6 Mode selector
7 Heating-up indicator
8 Temperature control
9 Control panel
10 Fold-down grill (top heat and grill)
11 Hot air fan
12 Rack levels
13 Oven door
Accessories supplied:
Gridiron
Baking tray (enamel)
Drip pan
Grilling rack with lifter
Accessories available:
Grilling rack with lifter (acc.-no. 125)
Pizza stone (acc.-no. 145)
Gridiron (acc.-no. 124)
Roasting tray (acc.-no. 441)
Baking tray (enamel) (acc.-no. 541)
Drip pan (aluminium) (acc.-no. 542)
Drip pan (acc.-no. 543)
backmobil®(acc.-no. 600)
Telescopic glide-out shelves (acc.-no. 601)
Accessories available
for the telescopic glide-out shelves (acc.-no. 601):
Gridiron, depressed, e.g. for large poultry (acc.-no. 750)
Glass drip pan, suitable only for accessory 750 (acc.-no. 751)

EEB 6500.0 21
Safety instructions
Connection and operation
■ Küppersbusch fitted ovens may only be connected to the corresponding
Küppersbusch fitted hobs by a qualified and authorised fitter.
■ The appliances may only be connected to the mains, maintained and
repaired by a qualified electrician according to valid safety regulations. Work
carried out incorrectly places your safety at risk.
■ Do not put the appliance into operation unless it has been built in!
■ The surfaces of the oven door and the appliance are very hot when in
operation. Always keep children away!
■ Connection leads of electrical appliances may not be placed on the hot
cooking zones or get jammed in the hot oven door.
■ Steam and/or pressure cleaning machines must not be used to clean the
oven! This can damage the unit resulting in risk of personal injury.
■ The appliance is to be used only for the preparation of food in the home.
Oven
■ When carrying out repairs and replacing oven light bulbs, the cooker must
be disconnected from the mains (switch off the fuse or unplug from the
mains).
■ Never store any objects in your oven which could cause a hazard if the oven
is unintentionally switched on.
■ Take special care when working in the hot oven. Use a dish cloth, oven
gloves or similar.
■ Be careful opening the door when the oven is hot: don’t lean over the open
door straight away. As soon as you open the door, hot air and even steam
will spill out through the door opening.
■ The oven door must close well. In the event of damage to the hinges or to
the glass pane, do not use the appliance until it has been repaired and
checked by a qualified person.
■ A damaged door sealing must be replaced. The oven must not be used with
damaged door sealing.
■ Always close the oven door completely when preparing food in the oven.
■ Keep it at a distance of at least 5 cm from the grill and top heat.
Before using the appliance for
the first time
Disposing of the packaging and the old
appliance
Dispose of the transport packaging in such a way that it does not impact on
the environment.
If the appliance is purchased in Germany, the dealer who sold you the
appliance will dispose of the transport packaging for you. Recycling the
packaging saves raw materials and reduces the amount of waste. Disposed
appliances still contain useful materials. Dispose of your old appliance at a
collection point for recycling useful materials. Before disposing of your old
appliance ensure that it cannot be used any longer. This will prevent misuse.
Setting the clock
FThe upper oven will not function until the clock is set.
The clock must be set before the oven is used and whenever power has been
disconnected to the appliance. If the clock needs to be set, you will see “0.00”
flashing in the display.
– Use “+” and “-” to set the right time.
After around 3 seconds, the new time
will be accepted and the display will stop
blinking.
Initial cleaning
– Remove foreign matter and packaging.
– Before preparing food for the first time, the appliance must be cleaned.
Clean the drip pan, gridiron etc. with a damp cloth and a little detergent.
–Heating the oven.
Close the oven door.
Heat up the oven with top heat/bottom heat at 250 °C for 60 minutes.
Air the kitchen well at the same time.

22 EEB 6500.0
Using your oven
General
[Please note the safety instructions on page 21!
[Attention. Risk of overheating! Do not cover the bottom of the oven
with aluminium foil and do not place pots or pans directly on it! This
would cause a build-up of heat that would damage the enamel.
FWhen the oven is in use, it becomes hot. In order to cool the housing,
the cooling fan is switched on as soon as the housing heats up. The
cooling fan continues to run until the housing has cooled down - even
after the appliance has been switched off. The fan noises are normal
running noises and not a fault.
FIf you are cooking a dish in the oven that contains alcohol or yeast, the
Hot air convection, Intensive hot air convection and Pizza Mode will result
in a vinegar smell. If you find the smell disturbing, use one of the other
modes, such as Top/Bottom Heat.
Controls and displays for the oven
Upper oven
A Mode selector
B Heating-up indicator (red)
C Temperature control
Lower oven
D Mode selector
E Heating-up indicator (red)
F Temperature control
Symbols and operating modes
Heating-up indicator and pilot light
The heating-up indicator on the control panel will light up while the appliance
is heating up and will go out as soon as the set temperature has been
reached. It also comes on during operation when the oven is heated to
maintain the temperature you want.
The pilot light lights up when you have selected an operation mode – the oven
is operating.
Turning the oven light on and off
The oven lighting stays on when the mode selector is up – except on position
0. The light stays off when the mode switch is depressed.
The oven light functions regardless of which mode is selected. The light can
also be turned off while the oven is in use. This will save energy and increase
the life of the lamps.
Turning the oven on and off
FThe controls are of the pop-out type and can be countersunk in every
setting. They pop out at a slight press of the finger. No settings can be
made while the controls are countersunk.
Selecting the operating mode:
– Turn the mode selector (the switch on the left) to the right.
Selecting the temperature:
– Turn the temperature control (the 2nd switch from the left) to the right.
Turning the oven off:
– Turn both switches to the “0” position.
Oven trays
Baking trays:
■ Lift slightly when removing.
After baking trays are placed back into the oven, the sloping edge of the
tray must point towards the oven door.
■ Push the drip pan and baking tray with the two slots right at the back into
the oven.
Gridiron:
■ Please ensure that the catches of
the racks always point towards
the back (away from you).
Grilling rack with lifter to insert
in the dripping pan
■ The grilling rack is inserted in the drip
pan. With the lifter you can remove
the grilling rack together with the drip
pan from the oven. Nothing drips and
you can easily serve.
Roasting tray as splash guard for roasting and grilling (accessory)
■ The roasting tray is inserted in the drip pan and prevents the fat from
splashing out of the drip pan.
Switch
symbol
Operating
mode
intended for
0Off
!Lighting
#Cold air
convection
without temperature setting, for gently defrosting and
cooling food.
#Hot air
convection
with temperature setting, for roasting, baking and cooking
on several levels.
$Top heat/
Bottom heat
Preheating,
baking and roasting on one level
-Bottom heat Prebaking very moist cake
.Top heat Browning toppings
*Grilling Grilling small portions. Position the pieces of meat in the
centre of the gridiron.
+Large area
grill
Grilling larger portions such as steaks, fish and sausages,
but also for browning toast dishes and gratins.
0Intensive hot
air convection
Baking large flat cakes with a dry topping (such as a
crumble topping), intensive roasting of large joints and large
poultry such as goose or turkey.
Pizza mode Baking bread, pizzas and moist cakes, making preserves.
H H
ABC DEF

EEB 6500.0 23
Rack levels:
You have 8 levels in the side racks. The rack levels are numbered from 0 to 7
from the bottom up. For example, the drip pan can be inserted into rack level 0.
Side racks:
Rack level 0 is the lowest
possible level.
backmobil®(acc.-no. 600)
The backmobil®replaces the shelf
racks in your oven and can be
completely pulled out like a trolley.
It can be removed from the oven
and dismantled for cleaning pur-
poses.
If your oven is equipped with a
backmobil®, please read the in-
structions enclosed with it.
Telescopic glide-out shelves (acc.-no. 601)
are oven rails available as acces-
sories which replace the side
racks and make working in a hot
oven more easy. Trays or gridirons
are placed on the glide-out
shelves. They can be pulled out
singly and independently of each
other.
If your oven is fitted with glide-out
shelves, please read the
instructions enclosed with them.
Fast preheating
FDo not insert food for roasting or baking into the oven until fast preheating
is over and the oven has been set to the normal mode of operation.
FWith the Pizza mode the empty oven can be preheated in a relatively
short time.
– Close the oven door.
– Set the mode selector switch to Pizza mode .
– Set the temperature you want. The heating-up indicator comes on.
– As soon as the heating-up indicator goes off, set the mode you want.
– Put the food into the oven.
Roasting
FUse the drip pan and the gridiron.
■ You should only cook meat or fish in the oven if they weigh more than 1 kg.
■ The roasting time depends on the type of meat you are roasting, the quality
and on the thickness of the joint.
To measure the joint, lift it slightly as it collapses under its own weight.
■ The roasting time for meat with a layer of fat can be as much as twice as
long as usual.
■ If you are cooking several small pieces of meat or small poultry in the oven,
the cooking time increases by about 10 min. per piece. The roasting time
for a chicken is, for example, about 60 min., for 2 chickens 65 to 75 mins.
FBe absolutely certain to observe the notes on the rack levels!
Rack levels (count from bottom!):
Roasting on the gridiron
■ You can cook large roasts directly in the drip pan or on the gridiron with
the drip pan inserted underneath (e.g. turkey, goose, 3-4 chickens or
knuckles).
■ Turn the roast after 2/3 of the cooking time unless you are using the hot
air convection mode # .
Roasting in a pan (oven)
FSelect Intensive hot air convection 0at 180-200 °C.
■ You should roast lean types of meat in the roasting pan with the lid closed
(e.g. roast of veal or marinated beef, braised beef or deep-frozen meat).
The meat remains juicier that way.
■ You can use any type of pan (stainless steel, enamelled, cast iron or glass)
which does not have plastic or wooden handles.
■ If you use an earthenware cooking pot, study the manufacturer's
instructions.
We recommend the following procedure:
– Rinse out the pan with water or grease it lightly.
– After preparing the meat (adding spices), place it into the pan. Put the lid
on the pan and place the pan onto the rack in the cold oven.
– Select Intensive hot air convection 0and set the temperature to between
180 and 200 °C.
Prepare the sauces in the usual way.
Intensive hot air convection 0 Drip pan: rack level 0
Gridiron: rack level 1 or 2
Hot air convection #Drip pan: rack level 1
Gridiron: rack level 2 or 3
Top heat/bottom heat $Drip pan: rack level 1
Gridiron: rack level 2

24 EEB 6500.0
Recommended temperatures for roasting
The recommended temperatures for the preferred operating modes have
been highlighted.
Baking
Hot air convection #
FNo need to preheat the oven - baking is possible on several levels
simultaneously.
Rack levels:
1 tray: 2nd rack level from the bottom
2 trays: 2nd and 5th rack levels from the bottom
3 trays: 2nd, 4th and 6th rack levels from the bottom
4 trays: 0th, 2nd, 4th and 6th rack levels from the bottom
■ If you are baking several cakes in baking tins, about 5 to 10 minutes
additional baking time will be needed for each baking tray.
■ Remove the baking trays individually, depending on how well browned the
cakes are.
■ Bake using hot air convection #at a temperature of 160 °C if there are
no instructions for baking by hot air convection in your recipe.
■ Important: When cakes with a moist fruit topping are being baked, the
development of humidity is particularly high. You should bake no more than
two cakes at the same time.
Top heat/bottom heat $
FPreheating - baking on one level
■ Preheat the oven by pizza mode , and when the temperature has been
reached, set the oven back to Top heat/bottom heat $
■ Baking tins made of black metal and aluminium are particularly suitable.
Intensive hot air convection 0
FNo need to preheat the oven - baking on one level
■ Only for large flat cakes with a dry topping, such as a crumble topping.
Pizza mode
FBaking on one level
■ for moist cakes
■ for pizzas: preheat the oven with a baking tray or a pizza stone (accessory)
■ for bread: preheat the oven
Baking pizza
FSelect the Pizza mode at 250 °C.
– If you use a pizza stone (special accessory), the pizza gets a particularly
crispy base. Preheating time: at least 30 min.!
Read the instructions enclosed with the pizza stone.
Basic recipe for pizza
250 g of flour, 20 g of yeast, 1/8 l of lukewarm water, 3 tablespoons of (olive)
oil, salt.
Baking pizza on a baking tray
– Make a yeast dough out of the specified ingredients.
– Allow the dough to rise for approx. 30 minutes until it has doubled in size.
– Then knead the dough for a few minutes and allow it to prove for another
15 minutes.
– Preheat the oven (Pizza mode at a temperature of 250 °C).
– Grease the baking tray.
If you are making small round pizzas, insert the baking tray into the oven
now and preheat it as well.
– Roll out the dough, place on a baking tray and form an edge.
– Add any topping you want quickly so that the dough does not become moist.
–Small pizzas: Put topped dough onto the preheated baking tray.
– Place the baking tray in rack level 0.
– Bake for approx. 8 - 12 minutes in Pizza mode , at 250 °C.
Baking pizzas on the pizza stone
– Prepare the pizza dough as described above.
– Place the pizza stone on the gridiron and insert at rack level 0.
– Preheat the oven in Pizza mode and at a temperature of 250 °C.
– Place the dough onto the floured lifter and add toppings quickly so that the
dough does not become moist. The topped pizza must not lie too long on
the lifter as otherwise the dough no longer slides off.
– When preheating is over, push the pizza off the lifter onto the hot pizza
stone.
– Bake for approx. 8 - 12 minutes in Pizza mode , at a temperature of
250 °C.
Tips on the table “Recommended temperatures
for baking”
The table on page 25 contains a selection of cakes etc., the necessary
temperatures, cooking times and rack levels.
■ Temperatures are generally given in ranges as they depend on the
composition of the dough, the quantity and the shape.
■ We recommend you to set the lower temperature value the first time and
only select a higher temperature if necessary, e.g. if you want more
browning or the baking time is too long.
■ If you do not find any specific temperatures for your own recipes, use a
similar cake in the table given as a reference.
■ Height differences of the food can result in different degrees of browning at
the start of the baking process. In this case please do not change the
temperature setting. Differences in browning are offset during the course of
baking.
Type of meat Hot air
convection
#
Top heat/
bottom heat
$
Intensive hot
air convection
0
Roasting time
Temperature in °C per cm of the
thickness of the
joint in mins.
Joint of beef 160 170-190 18
Roast beef 180 200-220 180-200 8-10
Fillet 180 200-220 180-200 8
Veal 160 170-190 160-180 12
Roast pork 160 170-190 160-180 12-15
Smoked loin of pork 160 170-190 160-180 8
Shoulder of pork 160 170-190 160-180 12-15
Roast pork with
crackling
160 170-190 160-180 12-15
Game 160 170-190 15
Wild boar 160 170-190 15
Fillet of game 180 200-220 180-200 8-10
Mutton 150-160 170-190 15
Duck 160 170-190 160-180 12
Goose 160 170-190 160-180 12
Chicken 160 180-200 160-180 8*
Turkey 160 200-220 160-180 12
Fish 160 200-220 8
*whole chicken 45 - 60 min.

EEB 6500.0 25
Recommended temperatures for baking
The recommended temperatures for the preferred operating modes have been highlighted. Please note the tips on p. 24!
Grilling [Always close the oven door when grilling!
FSet the operating mode Grill * for small portions or Large area grill +
Type of cake or biscuit Hot air convection #Top heat/bottom heat $Intensive hot air convection 0
Pizza mode Baking time
rack level Temperature in °C rack level Temperature in °C rack level Temperature in °C in minutes
Cake mixture
Ring cake 2 150-160 1 170-180 50-65
Tin cake 2 150-160 1 170-190 50-70
Madeira cake 2 150-160 1 160-180 60-70
Gateaux and flans 2 150-160 1 170-180 40-60
Flan bases 2 170-180 2 180-200 20-30
Fine fruit flans 2 150-160 1 170-180 2 150-160 45-60
Small biscuits 2 150 2 170-180 15-30
Large flat cakes:
with a dry topping 2 150-160 2 180-190 2 0150-160 25-35
with a moist topping 2 160-170 2 170-180 2 160-170 35-50
Kneaded dough
Flan bases 2 170-180 2 180-200 25-35
Cheese cake 2 140-150 1 160-170 2 140-150 70-90
Small bisquits 2 140-150 2 180-190 15-35
Large flat cakes:
with a dry topping 2 150-160 2 180-190 2 0150-160 25-35
with a moist topping 2 160-170 2 170-180 2 160-170 30-50
Leavened dough
Ring cake 2 150-160 1 175-180 40-65
Yeast cake 2 150-160 2 175-180 40-50
Rich sweet bread (preheated) 2 150-160 2 175-180 50-70
Small biscuits 2 140-150 2 180-200 15-30
Large flat cakes:
with a dry topping 2 150-160 2 175-180 2 0150-160 30-40
with a moist topping 2 160-170 2 170-180 2 160-170 30-50
Sponge cake
Gateaux and flans 2 150-160 2 175-180 30-40
Rolls 2 170-180 2 180-200 12-25
Biscuits made with white of egg
Meringue 2 80-90 2 100-120 80-120
Cinnamon stars 2 100-120 2 120-140 20-40
Macaroons 2 100-120 2 120-140 20-50
Other doughs
Puff pastry 2 170-180 2 190-210 15-30
Puff pastry made with leavened
dough 2170-180 2 190-210 30-40
Puff pastry made with curd
cheese 2160-180 2 180-200 30-40
Choux pastry 2 170-180 2 190-210 30-40
Dough made with curd cheese
and oil 2150-160 2 170-180 30-40
Honey cake 2 140-150 2 170-180 20-35
Bread and pizza
Leaven and bread made with
yeast (preheat: 230 °C,
prebake: 10 min., 230 °C)
2 180 1/2 160 50-65
Bread made with yeast/white
bread. 2180 2 200 2 180 30-50
Pretzels (preheat: 230 °C) 2 200 2 220 15-20
Pizza (preheat: 250 °C) 0250 8-12

26 EEB 6500.0
for large portions.
Set the temperature control to *. Exception: With larger roasts it is
better to select a temperature between 200 and 250 °C so that the roast
does not burn.
Switch setting for Grill *: Switch setting for Large area grill +:
– Preheat the oven for 5 to 10 min.
– Place the food on the gridiron.
– Push the drip pan into the 2nd or 3rd rack level and the gridiron into the
rack level as per the table.
– Select Grill * or Large area grill +.
– Set temperature control to *.
– Close the oven door.
Recommended temperatures for grilling
Defrosting
FSet the operating mode to Cold air convection #(Hot air convection
without temperature setting) and do not countersink the mode selector
so that the oven interior stays illuminated. The oven slightly heats up via
the lighting - perfect for a mild defrosting.
FWhen defrosting ready to serve meals please follow the instructions of
the producer.
– Remove the frozen food from the packaging, place it in a dish and insert
into the oven with the rack on the third rack level from the bottom.
– Set the mode selector to #and the temperature control to “0” (resp. the
instructions of the producer).
Preserving
[Attention! Do not use jars with twist-off®lids if the latter have been
already in use. The jars could otherwise smash under certain
circumstances!
FConventional preservative jars with a rubber ring and glass lid or standard
jars with a twist-off®lid (only with new lid) are suitable.
Metal cans are unsuitable.
FDo not pour water into the drip pan! A lot of steam would emerge from
the vapour opening and you could burn yourself on it! Place a container
of water in the drip pan, not on the bottom of the oven!
FSelect Pizza mode .
■ Only use fresh food and prepare according to the usual recipes.
■ Prepare no more than 6 preserving jars with a capacity of 1 litres at one
time.
■ Only use jars of the same height and fill 3/4 full with the same contents.
■ The jars should not touch each other.
– Place the drip pan on the 1st rack level from the bottom.
– Set 1 cup with water in the drip pan.
– Select Pizza mode at 160 °C and observe preserving process.
After 10 to 20 minutes (jars with a capacity of 1 l) the liquid in the jars will
start to bubble, usually in the jar on the front right first.
Fruits
– Then switch off the oven and keep the jars in the closed oven for another
30 min. (approx. 15 min if preserving very sensitive fruit such as
strawberries.)
Vegetables and meat
– When the liquid starts to bubble, turn the oven down to 100 °C and
continue to heat for a further 60 to 90 minutes.
– Then switch off the oven and keep the jars in the closed oven for another
30 min.
Dish Rack
level
Grill Large area grill
1st side 2dside 1st side 2dSide
in minutes
Pork chops/Escalope 6 6-8 4-6 8-9 5-7
Fillet of pork 5 10-12 8-10 12-13 8-10
Sausages 6 6-8 4-6 8-10 5-7
Shashlik 4 7-8 5-6 8-10 7-10
Rissoles 4 8-10 6-8 10-15 10-12
Beef steak 6 4-6 3-5 6-7 4-6
Slices of liver 6 3-4 2-3 4-5 3-4
Escalope of veal 5 5-7 4-5 7-8 5-6
Veal steak 5 6-8 4-6 8-9 5-6
Mutton chops 5 8-10 6-8 10-11 7-8
Lamb chops 5 8-10 6-8 10-11 7-8
Half a chicken 3 10-12 8-10 14-15 10-11
Fillet of fish 6 6-7 4-5 7-8 5-6
Trout 4 4-7 3-6 8-11 5-6
Toast 5 2-3 2-3 2-3 2-3
Toasted sandwiches 4 6-8 6-8

EEB 6500.0 27
The electronic timer
As well as providing a short-time alarm for reminders, the electronic timer
controls the oven in several other ways. You can use it to set the cooking time
and the finish time. All functions are available in any mode or temperature
selection.
Display: Time, alarm time (actual value in each case)
Lamps, showing that the oven is switched on.
Lamps (for each selector button/function)
Heating-up indicator
Selector buttons: 7Cooking time
8Finish time
4Alarm time
Adjust: +/- for altering the values of all functions.
Temperature control
Mode selector
Setting/changing the clock
– Push simultaneously “7” and
“8”, until the time in the display
flashes.
– Adjust as required using “+”/“-”.
– Wait for the display to stop flashing. The
time will then be accepted, and the dot
in the centre of the hour and the
minutes will flash every second.
Setting the alarm time
You can use the alarm on its own, without effecting the oven.
–Press“
4 ”. The lamp will flash. The
display will read “0.00”.
– Use “+”/“-” to set the timer in minutes
and seconds.
– Start the timer with “4” or wait until the
lamp stops flashing. You will see in the
display the time remaining until the
buzzer sounds.
An acoustic signal is generated when the
alarm time has elapsed.
– Press any button to stop the buzzer. The display will show the normal clock
again.
This is how to programme the switching
operations
1. Selecting the operation:
– Press the selector button for the operation you wish to use. The lamp above
the button you have pressed will start to flash and a number will appear in
the display.
2. Altering/adjusting the operation:
– Adjust the value shown, using “+” and “-”.
3. Starting the operation:
If you do not press another button for 3 seconds, the operation will commence
automatically and the lamp will stay on all the time.
FYou can reduce the time by pressing a selector button:
- the previously selected button confirms the input and starts the operation.
- another button confirms the input and selects the new operation you have
chosen.
4. Setting the oven functions (switching functions only):
–Use
to select the mode and to select the temperature.
If you wish, you can set the temperature and mode before programming the
timer.
Changing the setting
If you wish to alter a setting you have made – even if the operation is running
– push the appropriate button again and use “+”/“-” to change the value in
the display.
When the cooking time is finished
the oven will switch off and “End” will
appear in the display. A warning signal will
sound. Both of the lamps next to the
display will stop flashing.
– Press any selector button to stop the alarm buzzer.
The display will show the normal clock again. The oven starts again.
– Turn the temperature control and the mode selector switch to “0”.
7 8 4
8 888
H
2
3
4
65
1

28 EEB 6500.0
Setting the cooking time 7(switch-off function)
The oven switches itself off when the pre-set time has elapsed.
–Press“
7”: the lamp will flash and
“0.00” will appear in the display.
– Use “+”/“-” to set the cooking time
in hours and minutes.
After approx. 3 secs. the timer will start
and the lamp will stay on continuously.
The display will show the time remaining.
Both lamps will flash alternately.
– Set the temperature and mode.
Setting the finish time 8(switch-off function)
Use this function if you want the oven to switch off automatically after a certain
time.
–Press“
8”: the lamp will flash and
“0.00” will appear in the display.
– Use “+”/“-” to set the desired switch-off
time.
After approx. 3 secs. the timer will start
and the lamp will stay on continuously.
The display will show the time remaining.
Both lamps will flash alternately.
– Set the temperature and mode.
Automatic turn-on and shut-off
If you wish use the oven’s time-delay feature, you may pre-select both cooking
time and finish time. The automatic start time itself cannot be specified, but
this is derived from both settings.
FIt is impossible to set a finish time before the start time: you will hear a
buzzer and the value in the display will not change. If you wish to shorten
the cooking time you have set, do this first before you reset the finish
time.
Example:
It is 8:00 and you wish to have your roast ready at 13:00. The roast needs to
be cooked for 90 minutes.
Change the cooking time “7” from 0.00 to 1.30. Then change the finish
time “8” from 9.30 to 13.00.
Once the times have been accepted, “Auto” will appear in the display and the
oven will switch on at 11:30 and off at 13:00.
This is how to set the automatic switch-on and switch-off:
– Press “7”: the lamp will flash and
“0.00” will appear in the display.
– Use “+”/“-” to set the cooking time
in hours and minutes.
(For example: 90 minutes)
– Press “8” to confirm the input and
select the finish time. The display will
show a time (finish time if the oven is to
switch on right away).
– Use “+” to set the finish time.
After approx. 3 secs. the lamps will
stay on continuously. The display will
show “Auto” until the oven switches
on.
– Set the temperature and mode.
– The oven will automatically switch on at
the specified time and both lamps next to
the display will flash alternately. The time
remaining until switch-off will be shown
in the display.

EEB 6500.0 29
Cleaning and care
You should carefully read this chapter before you use your appliance the first
time. If cleaned correctly and looked after regularly the appliance will remain
beautiful and clean for many years. Here you will find tips concerning the
careful cleaning and of the individual surfaces and how to look after them.
For all surfaces
[Steam and/or pressure cleaning machines must not be used to clean the
appliance! This can damage the unit resulting in risk of personal injury.
[Risk of burning! Make sure the appliance has cooled down before
cleaning.
[Please note the instructions of the cleaning agents.
Clean the appliance each time you use it. Not removed dirt will burn into the
surface the next time you switch it on and these incrustations can often not
be removed anymore.
Use a damp cloth or a soft sponge with warm water containing a small amount
of detergent to clean light amounts of dirt from the surface. Always wipe off
the surface completely with cold water to remove cleaning agents residues
which could cause discolouring and stains. Wipe dry afterwards.
FYou can find information in the following paragraphs concerning the
individual surfaces and parts and how to remove heavy dirt.
FVSR O-FIX-C is perfect for the cleaning of glass ceramic, enamel and the
coated inside of the door. You can obtain this cleaning agent from
KÜPPERSBUSCH customer service.
Do not use any
- aggressive or bleaching cleaning agents containing for example active
oxygen, chlorine or corrosive components.
- abrasive or aggressive cleaning or scouring agents such as steel wool,
soap-impregnated steel wool, metal or plastic sponges or similar agents
with an abrasive surface.
Remove caking
Heavy dirt should first be soaked – best with a wet cloth. Afterwards it is easier
to remove the dirt.
Please note the information for the cleaning
scraper
[Caution! Risk of cutting! The blade of the cleaning scraper is very sharp!
Always keep the cleaning scraper flat on the
surface and push the caking away.
[Do not scratch the surface with the edge of
the scraper and take care not to damage the
sealings with the edge.
The use of oven sprays - information
[Pease follow the instructions of the manufacturer. Oven sprays damage
aluminium, lacquered surfaces and plastic!
[Do not spray into the opening of the ventilator at the backplate! The
ökotherm®catalyst will be destroyed if oven spray is used.
For environmental reasons you should not use oven spray at all. If you
nevertheless want to use it, only spray it in the oven interior and on enamel
baking trays.
Enamel
Oven interior, front, baking trays, drip pan, enamel hobs
Some plastic sponges with abrasive side can be used. Some products do
however contain grains in the abrasive side of the sponge which can cause
scratches.
Carefully try out the sponge on a small surface!
FA cleaning scraper for glass ceramic surfaces is suitable for removing
heavy dirt.
FTo thoroughly clean your appliance we recommend the use of VSR O-
FIX-C. Oven spray may be used.
Stainless steel
Stainless steel door front, control panel, telescopic glide-out shelves
(acc. No. 601), backmobil (acc. No. 600)
[Stainless steel is very sensitive to scratches!
Do not use a cleaning scraper!
[Remove any deposits of calcium or any spots of grease, and starch as
soon as possible, or stains will appear!
For the cleaning a cleaning agent for stainless steel can be used.
We recommend to clean once a week stainless steel surfaces with an usual
cleaning agent for stainless steel. This will create a protective film protecting
the stainless steel surface from discolouring.
Glass
Inside of the door – coated glass
[If possible, oven spray should not be used as it can cause the destruction
of the coated glass surface when used frequently.
A cleaning scraper for glass ceramic surfaces is suitable for removing heavy
dirt.
FTo thoroughly clean your appliance we recommend the use of VSR O-
FIX-C or glass detergent.
Door front, control panel
FClean the oven front with warm water containing a small amount of
detergent, with a damp cloth o a soft sponge. Do not use glass cleaning
agents.
Aluminium
Door ledges and handles in aluminium, baking tray (acc. No. 543)
[Aluminium is very sensitiv to scratches and oven spray spray causes
damage!
Do not use a cleaning scraper!
Door sealing
FThe door sealing should be removed when cleaning the oven to avoid
that dirt can collect under the sealing. See page 31 “Replacing the door
sealing".
If necessary the sealing can be cleaned with detergent or washing-up liquid.

30 EEB 6500.0
Buttons
Clean the buttons with warm water containing a small amount of detergent,
with a damp cloth o a soft sponge.
Removing and installing the oven door
Removing the oven door
– Open the oven door as wide as it will
go.
– Fold forward the clamps on the door
hinges.
– Take hold of the oven door on the
both sides and close it almost
completely.
– Gently lift the door and pull the
hinges forward away from the door
opening.
Reassembling the oven door
– Take hold of the oven door on both
sides and push the hinges into the
relevant holes on the oven. The hinge
will click into place.
– Slowly open the oven door full.
– Fold back the clamps on the door
hinges.
– Close the oven door.
Removing and installing the side racks
Removing the side racks.
– Loosen the screws.
– Remove the slot-in racks.
Installing side racks
– Insert side racks and tighten down in
front.
Folding heating element down/up
Folding heating element (top
heat/grill) down
– Open lock and fold heating element
down.
Folding heating element up
– Fold heating element up and close
again with the lock.
Regenerating the ökotherm®catalyst
– Set the mode selector to Hot air convection $ .
– Set the temperature control to ”*” and
– Heat the empty oven for 60 minutes.

EEB 6500.0 31
What to do if trouble occurs...
[Repairs may only be carried out by a qualified technician!
You can deal with some problems that occur yourself. First check whether
there has been any operating error. Repairs during the guarantee period are
not free of charge, when they are caused by operating errors or non-
observance of the following instructions:
Replacing the oven lamp
[Caution: Danger of electric shock! Before you open the cover of the
oven lamp the appliance has to be disconnected from the electricity
supply: Switch off the fuse or pull out the mains plug!
[The lamps become very hot after being in use for some time. Therefore,
the lamps should be changed when they have cooled down!
Type: 25 W, 230/240 V, socket: E14
Important: temperature resistant up to 300 °C!
You can obtain these lamps from KÜPPERSBUSCH customer service or from
your dealer.
Changing the light bulb:
– Unscrew the shelf rack.
– Carefully lever out the glass
cover with a screwdriver.
– Remove the damaged light
bulb and put the new one in.
– Reinstall the glass cover.
Replacing the door sealing
[Do not use the oven with damaged or missing door sealing!
If the sealing is damaged or cannot be cleaned anymore it has to be replaced.
You can obtain a new sealing from KÜPPERSBUSCH customer service.
Removing the sealing
– To remove the sealing gently pull
each corner out.
Fitting the new sealing
– Clasp one corner after the other into the oven front.
Take care not to deform the hooks!
Rating label
Always indicate the data provided on the rating label when calling in customer
service or ordering spare parts.
The rating label for the oven is located on the
right-hand side strip and is visible when the
oven door is open.
– Make a note of this information in case you
have to consult our customer service.
Fault Cause Remedy
Not possible to switch off the
oven.
Electronic component
defective.
Disconnect fuse, call
customer service.
Oven does not heat up. Fuse defective. Check and replace fuse, if
necessary.
Is the mains plug in
the wall socket?
Plug the mains plug into the
wall socket
Oven temperature
control or mode
selector has not been
switched on.
Set oven temperature control
or mode selector as required.
Electronic timer
flashing – the clock
has not yet been set.
Set the clock. See page 21.
Oven light no longer works. Lighting defective. Replace the oven lamp.
Glass of oven door broken. Switch off the appliance,
call customer service.
Door sealing damaged. Replace the door sealing.
Strong smells from oven in
spite of ökotherm®catalyst.
ökotherm®catalyst
must be regenerated.
Heat the empty oven by
intensive hot air convection
at 275 °C for 60 min.
Strong vinegar smell when
preparing.
Baking with sour
dough or with yeast,
food containing alcohol
and using a fan-
assisted mode.
Use a mode without fan-
assistance, e.g., top heat/
bottom heat.
Fruit juice or protein stains
on enamelled parts.
Moist cake or meat
juices.
Harmless changes in the
enamel, cannot be remedied.
Production-no. oven:
Model designation oven

32 EEB 6500.0
Installation instructions for fitter
■ Only KÜPPERSBUSCH built-in hobs were designed and tested for use above
a Küpperbusch fitted oven. No other hobs may be used.
■ Statutory regulations and the connection specifications issued by the local
power apply company must be strictly observed.
■ Switch off the appliance by means of these safety devices before connecting
up the oven, carrying out repair work or replacing the oven light bulb.
Disconnect the appliance from the mains, disconnect fuse.
■ It must not be possible to touch components which are insulated under
operating conditions.
■ The earth wire must be so long that if the mains lead cleat fails, the live
wires of the connecting cable are subjected to tension before the earth wire.
■ The unit is ready to plug in and may be connected only to a properly
installed protected socket. Installing and wiring a socket or replacing the
connection cable should only be performed by an electrician and in
observance of the relevant regulations.
■ If the socket is inaccessible after the installation, safety regulations require
that an all-polo isolator with a contact opening of at least 3 mm be used
on the installation side.
■ The socket for plugging in the unit must be outside the installation space.
■ Built-in kitchen fixtures must be temperature resistant to 100 °C. This
applies especially to veneers, plastic coatings, adhesives and varnishes.
Adjacent cabinetry front must be temperature resistant to at least 70 °C.
■ The unit must be installed absolutely horizontal on a level, solid base. The
base must not be allowed to sag.
■ If the cupboard element is not attached to the way, screw on using an
ordinary bracket.
Electrics
[WARNING! This appliance must be earthed!
Built-in cooker Permanent connection by means of a cooker socket.
Hob Connected via the cooker connection strip.
Circuit diagram for the various mains ratings is illustrated on the
back wall of the appliance.
Total rating at 230 V: max. 7.0 kW, of which
one oven: 3.5 kW,
at 235 V: max. 7.3 kW, of which
one oven: 3.6 kW
Electrical connection Permanent connection: 400 V 3 N ~50 Hz
Connection 3 N ~Fuse current 16 A
Connection 2 N ~Fuse current 16 A
Connection 1 N ~Fuse current 32 A
Connection 3 x 230 V Fuse current 25 A
Connection cable Use H 05 RR-F or H 07 RN-F.
Cable length At least 2 m
Installation dimensions
Installation in a fitted kitchen
Installing the appliance
– Push the oven right into the cupboard alcove. Do not jam the cooker
connection!
Fastening the appliance
– Open the oven door and fix the
screws supplied at an angle through
the cupboard.
1022
1033
1025
