Gebrauchs-
und Einbauanweisung
EEB 6550.8
EEBK 6550.8
3172403-000
Instructions for use and installation
Manuel de montage et d’utilisation
Montage- en gebruiksaanwijzingen
EN
FR
NI

EEB 6550.8 27
What you will find here
Read the instructions in this manual carefully before turning on your oven.
Here you will find the most important instructions regarding the safety,
use, care and maintenance of your appliance, so that it will give you
lasting enjoyment.
If your oven becomes damaged at any time, consult the chapter
‘Assistance in the event of malfunction’ before you do anything else. You
may be able to repair small malfunctions yourself and save unnecessary
service costs.
Keep these instructions in a safe place. Give these instructions to new
owners for their information and safety.
The following symbols appear in this manual:
The warning triangle draws attention to health hazards or damage
that may be caused to the appliance.
This indicates advice and instructions.
Contents
Oven features................................................ 28
Control Panel - Sensor keys and instructions .................. 28
Safety Warnings ............................................ 29
Connection and use
Oven
Thermoprobe
Before First Use............................................. 29
Remove packaging and the old appliance
Setting the clock
First cleaning
General oven information ................................. 30
General advice
Shelf levels
Turning the oven light on and off
Oven Use..................................................... 30
General instructions
Turning on the oven
Selecting a conventional cooking setting
Conventional oven cooking functions ................... 32
Shortcut to conventional cooking functions
Automatic cooking
Important information about automatic cooking with recipes
Changing the weight of the food to be cooked
Changing the cooking temperature
Changing/setting the cooking time
Setting the end time
Turning on and off automatically
Oven Switch-Off
Additional settings.......................................... 35
Alarm setting
Stand-by mode
Roasting...................................................... 35
Setting a programme
Turning the roast over
Roasting on the grid shelf
Pot roasting
Roasting with conventional cooking functions
Instructions for automatic cooking recipes
Automatic cooking recipe chart
Suggested roast settings for conventional oven cooking
Thermoprobe and inside temperature function ........ 39
How to insert the thermoprobe correctly
Using the thermoprobe
Suggested temperatures for cooking with the thermoprobe
Semi-automatic cooking with thermoprobe
Slow cooking ................................................ 40
Setting the heat mode/cooking temperature
Suggested settings for slow cooking
Baking with cooking settings.............................. 42
Baking pizza
Instructions for the chart: Suggested baking settings
Suggested baking settings
Grilling
Suggested grill settings
Defrosting
Time chart for defrosting food
Making preserves
Child safety lock ............................................ 45
Turning the child safety lock on / off
Cleaning and care .......................................... 45
For all surfaces
Removing baked-on dirt
Using a scraper to clean
Using an oven spray - instructions
Chrome features
Stainless steel
Enamel
Door glass
Door gasket
Oven door assembly and disassembly
Shelf runner assembly and disassembly
Folding down / away the heating element
Regeneration of the ökotherm® catalyst ............... 47
Regeneration of the ökotherm® catalyst
Assistance in the event of malfunction.................. 48
What to do if….............................................. 48
Maintenance................................................. 48
Changing the oven light
Changing the door gasket
Technical information...................................... 49
Assembly instructions for technical personnel......... 49
Electricity
Measurements for assembly
Assembly in kitchen unit

28 EEB 6550.8
Oven features
1 Control panel
2 Fold down grill (Top heat/Grill)
3 Socket for roasting thermoprobe
4 Hot air fan
5 Shelf levels
6 Oven door
Accessories included:
Grid shelf
Enamel roasting tray
Enamel baking tray
Special accessories:
Pizza stone (acc. No. 145)
Grid (acc. No. 124)
Oven tray (acc. No. 541)
Baking tray (acc. No. 543)
Control Panel - Sensor keys and instructions
The control panel operates all oven settings.
1 Oven power switch.
2 Cooking functions shortcuts.
3 Electronic timer functions.
4 Information display.
5 Menu scrolling and functions selection.
6 Temperature setting with roasting thermoprobe.
7 Conventional cooking functions menu.
8 Automatic cooking functions menu
9 Cooking temperature settings.
10 Food weight settings.

EEB 6550.8 29
Safety Warnings
Connection and use
Only KÜPPERSBUSCH hobs have been manufactured and tested for use
over a KÜPPERSBUSCH oven. Do not use other hobs.
Any handling or repair to the appliance, including replacement of the
feed cable, should be carried out by authorised Technical Service
Personnel using original spare parts. Repairs or handling by others may
damage the appliance or cause malfunctioning that could be hazardous
to your safety.
Do not allow children to come near the oven while in use as it can reach
very high temperatures.
Children should be supervised to ensure they do not play with the
appliance.
This appliance is not for use by persons (including children) with
reduced physical, sensorial or mental capacity, or those lacking
experience and knowledge, except if they have been supervised and
instructed regarding use of the device by a person responsible for their
safety.
Oven
Unplug your oven if it malfunctions.
The oven must always be operated with the door closed.
The manufacturer takes no responsibility for any use of the oven other
than for the home preparation of food.
Only use the oven after it has been installed inside the kitchen unit.
Do not store oil, fats or inflammable materials inside the oven. This may
be dangerous if the oven is turned on.
Do not lean or sit on the open oven door. You could damage it, as well
as endangering your safety.
In order to cook food in the oven, place the tray or grid shelf supplied
with it over the shelf runners inside the oven cavity. The tray and grid
shelf have a system to make their partial outward movement easy for
food handling.
Do not place containers or food on the bottom surface of the oven.
Always use the trays and grid.
Do not pour water on the bottom surface of the oven when in use; this
may damage the enamel.
Open the oven door as little as possible during cooking. This will reduce
power consumption.
Use protective oven gloves when performing operations inside the
oven.
It is normal for condensation to occur on the oven door when cooking
dishes with a high liquid content.
Thermoprobe
Only use the original thermoprobe.
Do not trap the thermoprobe cable in the oven door.
Remove from the oven if it is not being used.
Keep at a minimum distance of 5 cm from the grill and the top
elements.
Before First Use
Remove packaging and the old appliance
Remove packaging and recycle in an environmentally-friendly way.
In Germany, the transport packaging is returned to the store where the
appliance has been purchased. By returning the packaging material, raw
materials are saved and also fewer waste products are generated. Old
appliances still contain valuable material. Leave your old appliance at a
collection point for valuable materials. Old appliances must be rendered
inoperative before disposing of them in order to prevent improper use.
Setting the clock
The clock must be set before first use and after a power failure. Whenever
this occurs, the ‘12.00’ reading will flash on the display.
When you connect your
oven to a power supply,
you will see 12:00 flas-
hing on the display and
the symbols
, and light up.
Touch or on the glass to set the hour. Then touch .
Touch and on the glass to set the minutes. Then touch .
You will then hear a double beep confirming the time is set.
The oven will display the time set and lit up in white.
If you want to change the time:
If the oven is off, turn it on by touching .
Touch .
This symbol
will light up in
red.
If you touch or , you will see the
5 clock functions on the display.

30 EEB 6550.8
When you have
chosen
the time setting
function
, touch .
You will then see the current time on
the display.
Touch or on the glass to set the hour .
Touch and on the glass to set the minutes .
You will then hear a double beep confirming the time is set.
First cleaning
– Remove packaging and accessories from the oven.
– Before preparing food for the first time, the appliance must be
cleaned.
Clean the inside of the oven, oven trays, grease tray, grid shelf etc. with
a damp cloth and a little dishwashing detergent.
– Heat the oven.
Close the oven door.
Heat the oven to 200° C with top and bottom heat for 60 minutes.
Ensure the kitchen is well ventilated while doing this.
General oven information
General advice
Follow the safety warnings given previously!
Caution, Danger of overheating! When using the oven, do not cover
the bottom with aluminium foil or place pots, frying pans or the like
inside. If this happens, the oven will overheat, causing damage to the
enamel.
The oven becomes hot when in use. The cooling fan turns on when
the oven overheats. The cooling fan will remain on until the oven has
cooled down, even after the appliance has been turned off. The noises
made by the fan are normal and do not mean that it is damaged.
When preparing a dish with alcohol or yeast with settings that use hot
air, there may be a vinegary smell. If the smell is unpleasant, use a
function that does not include the fan, such as top/bottom heat.
The electronic clock features Touch-Control technology. To operate,
simply touch the glass control symbols with your fingertip. The touch
control sensitivity continuously adapts to changing conditions. Make
sure that the glass surface of the control panel is clean and free of any
obstacles when turning on the oven.
If the clock does not respond correctly when you touch the glass,
you will need to turn off the oven for a few seconds and then turn it
back on after a few seconds. Doing this causes the sensors to adjust
automatically so that they will react once more to fingertip control.
Shelf levels
Model EEB6550.8
There are 8 shelf runners
on the sides. They are
numbered 1 to 8 from the
bottom up.
Model EEBK 6550.8
There are 5 shelf runners on
the sides. The shelf levels
are numbered 1 to 5 from
the bottom up.
Shelf runners
Shelf level 1 is the lowest shelf.
Turning the oven light on and off
The inside light will go on:
When the oven door is open. If the door is not closed after a certain
amount of time, the light will turn off to reduce power consumption.
When any cooking function is set. The light will turn off after a certain
time.
If you want to turn the light on during cooking, touch . If you keep your
finger on for a few seconds, the light will stay on for the duration of
the cooking. To turn the light off, touch again.
Oven Use
General instructions
In some settings the fan turns itself on and off; this does not mean it
is damaged.
Turning on the oven
To cook with your oven, touch . You will
then see the different oven use options lit up in
white.
Shortcut to the most common
cooking functions: These controls
provide immediate access to the
most frequently used cooking functions.

EEB 6550.8 31
: Electronic Clock Settings. These let you programme timer
functions for use with your oven.
, and .
: Conventional oven cooking functions. This enables you to select
any cooking function by combining different heat sources.
: Automatic cooking recipe settings. Simply put the food into the
oven and indicate its weight on the display; the oven will cook it for you
automatically.
If you do not set any function or recipe, the oven will turn itself off
again, showing the current time and in white.
Selecting a conventional cooking setting
Turn the oven on by touching .
Touch , which will light
up on the control panel.
will change to red. Touch or
to set one of the following cooking
functions. (See Conventional oven
cooking functions below).
When you have set the desired function, touch .
You will hear a double beep confirming the chosen function has been
set. The oven will begin cooking and in most cases you will see the
following information on the display:
The set function, the pre-programmed
cooking temperature for that function
and the clock or timer function if any
have been set.
If you wish to change the cooking function, press and follow the
above instructions.
During cooking will flash, indicating that the oven is transmitting
heat to the food.
After the thermostat is turned off the first time, you will hear a sound
indicating that pre-heating has finished.

32 EEB 6550.8
Top/bottom heat This function is for use when baking cakes where the heat should be even to give a
spongy texture.
Top heat For when you need to heat food gently. Plate warming.
Bottom heat Heat only comes from lower part. Suitable for warming dishes or letting dough or
similar products rise.
Grill and bottom heat
(EEBK6550.8 only) Ideal for roasts. This setting can be used with any size cuts of meat.
Grill Toasting and browning. This setting allows the surface to be cooked without affecting the inside
of the food. Suitable for flat foods such as steaks, ribs, fish and open toasted sandwiches.
Larger surface grill For toasting larger surfaces than possible with the Grill setting, in addition to greater
toasting power for faster food browning.
Fan-forced hot air
For even roasting and simultaneous surface browning. Ideal for mixed grills.
Perfect for bulky pieces such as poultry and game. The meat should be placed
on the grid shelf with the tray below to collect meat juices.
Turbo fan with top and bottom heat Suitable for roasts and cakes. The fan spreads the heat evenly throughout the inside of
the oven to reduce cooking time and temperature.
Hot air
The fan distributes the heat coming from an element located at the back of the oven. As
a result of the evenly distributed temperature, food can be cooked on two levels at the
same time.
Pizza mode Ideal for cooking pizzas and baking pies, fruit tarts and sponge cakes.
Defrosting See corresponding section
Food warming
This function provides the right level of heat to keep prepared food warm in the oven
until you are ready to serve. The interior temperature of the oven varies in this setting
between 50 and 80° C. Meat can be kept warm at 60° C inside the oven. Large cuts of
meat can be warmed for 1 to 2 hours, and smaller cuts for 30-40 minutes.
Symbol Cooking function Suitable for
Conventional oven cooking functions
There are many conventional oven cooking functions and they are described below.
The door must be closed during use with Grill, Larger surface grill or fan-forced hot air.

EEB 6550.8 33
Shortcut to conventional cooking functions
When you turn the oven on (by
touching ), you have shortcuts to
the following cooking functions, which
will be lit up in white:
Touch the symbol for the
desired cooking function.
You will hear a double beep confirming the function has been set. The
oven will begin cooking and in most cases you will see the following
information on the display:
The programmed function, the
pre-programmed cooking temperature
for that setting and the clock or timer
function if any have been set.
is an automatic cooking recipe. If you want to change it, please
consult the next section.
Automatic cooking
Touch to turn the oven on.
Touch . This will light up in red.
The display will show the diffe-
rent automatic cooking recipes
available with the oven:
Touch and to select the desired recipe. Then touch
the symbol.
You will hear a double beep confirming your setting and the display will
show the following information:
The symbol for the chosen recipe and
its automatic cooking temperature are
shown. The pre-programmed weight for
this option flashes.
Touch or to change the weight of the food.
Touch to accept the selection.
You will hear a double beep confirming the programmed recipe. The oven
will begin cooking and you will see the following information on the display:
The symbol for the chosen recipe, the
automatic cooking temperature and
calculated cooking time will be shown.
Important information about automatic cooking
with recipes
When you select a recipe and enter a weight, the oven automatically cal-
culates the temperature and cooking time needed, but these values can
be changed. Cooking time starts from a cold oven unless pre-heating
has been specifically indicated.
It is very important to select the correct food weight so that the ingre-
dients will be properly cooked.
When cooking with a thermoprobe, the oven will determine the cooking
temperature only. The cooking time will depend on the temperature
setting programmed for the thermoprobe.
With roasting programmes, after a certain time has passed the oven will
advise you that the joint of meat should be turned over. When it is time
to do this, the oven will beep.
You will also see on the display
until you have turned the roast over. If
you do not turn the roast over, the oven
will continue cooking according to the
programmed automatic cooking recipe.
For white bread, rye bread, thin-crust and thick-crust pizza base
recipes, the oven should be pre-heated first. In this way the oven will
be at the ideal temperature for the best results. Pre-heating is not
needed for the other recipes.
Follow these instructions when cooking with these recipes:
– Set the recipe first. The oven will begin pre-heating.
Do not put the food into the oven until the signal is given.
– During pre-heating, the symbol of the programmed recipe and the
symbol will flash on the display.
– When the set temperature is reached, the oven will beep. You can now
put the food into the oven.
– The oven will continue to beep until you put the food in.
– The food will be cooked automatically according to the recipe settings.
Changing the weight of the food to be cooked
If you wish to change the food weight, the cooking time or tempe-
rature may change automatically according to the parameters of the
programmed recipe. To change the weight of the food:
Touch . This will light up in red.
The display will show and the
weight of the food to be cooked
according to the recipe you have
programmed.
Touch and to change the weight.
Touch . The two beeps you hear after that will confirm the new
weight has been set.

34 EEB 6550.8
Changing the cooking temperature
The cooking temperature is pre-programmed for all cooking functions.
It is only possible to adjust the temperature within a predetermined range
when using the automatic cooking function. The temperature can be freely
selected for conventional cooking functions in a range between 50° C
(no temperature adjustment) and 250° C.
If you want to change the cooking temperature:
Touch . This will light up in red.
You will see the symbol and the set
temperature for this cooking function
on the display.
Touch and to set the new cooking temperature.
Touch . The two beeps you hear after that will confirm the new
temperature has been set.
Changing/setting the cooking time
The cooking time is pre-programmed for the automatic cooking recipes
but can be changed. There is no pre-programmed time for conventional
cooking functions.
Touch . This will light up in red.
If you touch or , you will see
the 5 clock functions on the display:
cooking time, end time, alarm, setting
the clock and stand-by mode.
When you have selected the cooking
time function, , touch . You will
see and the 0:00 reading on the display.
Touch or to set the cooking
time. Touch . You will hear a double
beep and see and the programmed
cooking time.
When the programmed cooking time has finished, the oven will switch
itself off, an alarm will sound briefly and and will start flashing.
Touch to stop the alarm. The oven will display the current time and
lit up in white. The oven is now off.
Setting the end time
The end time is when the oven turns off.
You can combine the cooking time and the end time. See “Turning on
and off automatically”.
Touch . This will light up in red.
If you touch or , you will see
the 5 clock functions on the display:
cooking time, end time, alarm, setting
the clock and stand-by mode.
Touch or to select the end time
setting , followed by . You will
see and the current time on the
display.
Touch or to set the end time.
Touch . You will hear a double beep
and see and the cooking time.
When the programmed end time is reached, the oven will switch itself
off, an alarm will sound briefly and and will start flashing.
Touch to stop the alarm. The oven will display the current time and
lit up in white. The oven is now off.
Turning on and off automatically
If you wish to use the oven at a later time, the cooking time and end
time can be combined. The cooking start time, when the oven turns on
automatically, is programmed as a combination of both settings and
cannot be set on its own.
Example:
It is 8:00 and at 13:00 I want to remove a roast from the oven that will
take 90 minutes to cook.
Enter 1:30 as the cooking time, following the instructions explained in
the section “Setting the cooking time”.
Then, change the end time from 9:30 to 13.00, following the instruc-
tions “Setting the end time”.
The settings are automatically accepted.
Set the conventional cooking or automatic cooking function. Put the
food for roasting in the oven.
The oven will turn on at 11:30 and will finish cooking at 13:00.
Oven Switch-Off
Touch . The oven is off. You will be able to see the correct time and the
symbol in white on the display.

EEB 6550.8 35
Additional settings
Alarm setting
You can set an alarm on your oven, even if it is not being used.
Touch . This will light up in red.
If you touch or , you will see
the 5 clock functions on the display:
cooking time, end time, alarm, setting
the clock and stand-by mode.
Touch the alarm setting, , followed
by . You will see the symbol and
the 0:00 reading on the display.
Set the time for the alarm to sound by
touching or . Touch . You will
hear a double beep and see and the
set alarm time on the display.
When the set time is reached, an alarm will sound and and will
start flashing. Touch to stop the alarm.
Stand-by mode
This mode permits you to choose between having the display on (showing
the time) or off (stand-by, with nothing displayed). When the display is
off, touching any part of the glassed front will bring up the clock again,
and will light up. When the oven is turned off, the display will gradua-
lly turn itself off.
Touch . This will light up in red.
If you touch or , you will see
the 5 clock functions on the display:
cooking time, end time, alarm, setting
the clock and stand-by mode.
Touch , followed by . The display
will then show the two options for this
function, (display off) and
(display on).
Touch or to set the desired function. Touch . You will hear a
double beep confirming the chosen function has been set.
Roasting
Use of the thermoprobe is recommended. The cooking time is deter-
mined by the thermoprobe, making its design ideal for roasting.
Setting a programme
1. Setting an automatic cooking recipe
The temperature is determined from the weight of the roast. The cooking
time is also determined if you intend to roast without the thermoprobe.
Both values are pre-programmed but can be changed (see previous
sections).
Before using the thermoprobe, set the weight.
Or
2. Setting a conventional cooking function
Each cooking function is associated with a pre-programmed temperature.
This temperature can be changed. You can set the cooking time and end
time. If you use the thermoprobe, you can set the cooking start time and
the oven temperature.
Turning the roast over
With the conventional cooking functions, the joint of meat must be
turned over after about 2/3 of the cooking time has passed so that it
browns evenly. If using a hot air function, you do not need to turn the
roast.
For automatic cooking recipes, once approximately 70% of the time has
passed, an alarm will sound so to alert you that the roast needs turning
over.
Roasting on the grid shelf
Use tray and grid shelf.
Large roasts can be prepared directly on the tray or on the grid shelf
with the tray below (e.g. turkey, goose, 3-4 chickens or pork hocks).
We recommend that when cooking fish this way, it should be standing
on the tray (in its swimming position). In this way, it will not need to
be turned, it does not fall apart as easily and is cooked more evenly. If
the fish does not stand upright by itself you can place it over a bed of
vegetables or over a coffee cup. Put the cup upside-down on the tray
and cover it with the fish so that it is inside the gut opening.
Pot roasting
Lean cuts of meat roast better in a covered casserole (e.g. veal that is
pot roasted or stewed in vinegar; beef or frozen meat stew). The meat
will be juicier.
You can use any type of pot or casserole (steel, enamelled, cast iron or
glass) provided it does not have wooden or plastic handles and that it is
heat-resistant.

36 EEB 6550.8
If you use an earthenware casserole, read the manufacturers instruc-
tions. The following is recommended:
– Rinse the pot or casserole with water or use a little oil or fat.
– Seal the prepared (dressed) meat in a pan on the hob.
– Place it in the pot or casserole. Cover with the lid and place it in the
cold oven on the grid shelf.
Set the automatic cooking recipe or the turbo fan with top heat function,
or , at 180-200° C.
Roasting with conventional cooking functions
When roasting with the thermoprobe the cooking time is automatically
determined, therefore the following instructions do not need to be
followed.
The settings and information in the charts refer to a cold oven unless
otherwise specified.
The cooking time of the roast depends on the type, quality and height of
the meat.
As the weight of the meat makes it fall, carefully press the sides of the
piece with both hands in order to determine its height. Instructions are
provided in the chart “Roasting with heat settings”
The cooking time for meat with a layer of fat may increase to twice the
length.
If roasting several small pieces of meat or small birds in the oven, the
cooking time should be increased by about 10 minutes per piece. For
example, the roasting time for one chicken is approximately 60 mins.
Two chickens will need between 65 and 75 mins.
Shelf levels (count from the bottom up):
As a general rule: The bigger the roast the lower the grid shelf should be
in the oven.
For larger roasts:
Hot air + grill or : Tray: Shelf level 1
Grid shelf: Shelf level 2
Hot air : Tray: Shelf level 1
Grid shelf: Shelf level 2
Top/bottom heat : Tray: Shelf level 1
Grid shelf: Shelf level 2
Instructions for automatic cooking recipes
The settings and information in the charts refer to an oven that has
not been preheated unless otherwise specified.
The roasting settings automatically adapt to the weight of the food to
be cooked, for this reason it is important to set the weight directly
after selecting the setting and before modifying the cooking time,
the cooking temperature or the inside temperature (see previous
sections).
If using an automatic cooking recipe
The roasting programmes are designed for one piece of meat or fish up to
7cm thick and without a layer of fat. Enter the correct weight and modify
the recipe, taking into account:
If there are several pieces, the cooking time will need to be extended.
If there is one piece thicker than 7cm and weighing less than 3kg, the
cooking time should be increased by 10 minutes for each centimetre
with respect to the pre-programmed value.
If there is one piece weighing more than 3 kg, the cooking time
corresponds to the predetermined value, as the differences balance out
throughout the pre-programmed cooking time.

EEB 6550.8 37
Automatic cooking recipe chart
Your oven offers the possibility of cooking with the following recipes. You only need to set the desired recipe, specify the weight of the food to be
cooked and put it in the oven.
There is no need to worry about anything else; the oven will cook it for you, with perfect results.
Available recipes are shown below:
SYMBOL
Chicken –
poultry ---- According to weight
According
to weight 0.5 – 10Kg Chicken, duck, turkey, goose etc.
Chicken/poultry
thighs and
drumsticks
---- According
to weight
According
to weight 0.5 – 2Kg Chicken/duck thighs and drumsticks
Veal ---- According
to weight
According
to weight 0.5 – 6Kg Veal, meatloaf, stuffed roast
Pork ---- According
to weight
According
to weight 0.5 – 10Kg Pork, suckling pig
Beef - lamb ---- According
to weight
According
to weight 0.5 – 5Kg Beef, lamb, veal shin
Chops/steak ---- According
to weight
According
to weight 0.5 – 4Kg Beef or pork chops/steak, roast beef
Fish ---- According
to weight
According
to weight 0.5 – 5Kg Varied fish
Cakes in
moulds
Fruit pie
Cakes
White bread YES 160-190° C According
to weight 0.5 – 2Kg
---- 150-180° C ---- ------ Sponge cakes
---- 150-180° C 50 min ------ Fruit filling
---- 140-170° C 70 min ------ Cupcakes, muffins,
cheesecake
Rye bread
Wholemeal
bread
Melted cheese
toppings
Thick-crust
pizza
Thin-crust pizza YES
YES 200-260° C 12 min ------
---- 160-190° C 40 min ------ Vegetables, pasta, potatoes
with melted cheese
160-190° C According
to weight 1 – 3Kg
YES 160-190° C According
to weight 1 – 4Kg
RECIPES PREHEATING TEMPERATURE COOKING TIME WEIGHT RANGE DISHES

38 EEB 6550.8
Meat type
Roast veal 160 170-190 160 160 18
Roast beef 180 200-220 180 180-200 8-10
Steak 180 200-220 180 180-200 8
Rosé veal 160 170-190 160 160-180 12
Recommended
roasting setting
Temperature in °C
Hot air Top/bottom heating
Grilling
Fan-forced
hot air
Cooking time
Per cm meat height
in mins.
Roast pork 160 170-190 160 160-180 12-15
Baked pork chops 160 170-190 160 160 8
Pork shoulder 160 170-190 160 160-180 12-15
Roast pork with crackling 160 170-190 160 160-180 12-15
Game 160 170-190 160 15
Wild boar 160 170-190 160 15
Game steak 180 180-200 180 180-200 8-10
Lamb 150-160 170-190 160 15
Duck 160 170-190 160 160-180 12
Goose 160 170-190 160 160-180 12
Chicken 160 180-200 160 160-180 8*
Turkey 160 180-190 160 160-180 12
Fish 160 200-220 8
*whole chicken 45-60 minutes
Suggested roast settings for conventional oven cooking

EEB 6550.8 39
Thermoprobe and inside
temperature function
The thermoprobe measures the inside temperature of the food being roas-
ted. When the temperature detected by the probe has reached a set value,
the roast is perfectly cooked: not too dry or too rare, but ‘just right’.
Cooking continues until the inside temperature of the roast has rea-
ched the corresponding temperature. This is the reason why it cannot
be set or adjusted. Cooking time can vary depending on the size and
type of meat, the roasting temperature and the programmed cooking
function.
The thermoprobe can be used with all cooking functions.
How to insert the thermoprobe correctly
Pierce the pointed tip of the thermoprobe horizontally through one side
into the middle of the food to be roasted.
Insert the thermoprobe fully to the handle.
The tip must not be resting close to fat or bone, or inside a hollow
cavity (e.g. in poultry).
Take care when preparing poultry that the thermoprobe does not come
into contact with any bones.
Using the thermoprobe
Put the dressed roast with the inserted thermoprobe into the oven.
Plug the thermoprobe pin into
the socket located at the top
left-hand side of the oven.
When you plug the probe in, the display
will show the symbol and the
recommended cooking temperature will
flash.
If you want to change the recommended temperature, touch and
. Touch .
Select a cooking function or automatic cooking recipe.
During cooking, the display will show
and the temperature currently
measured by the thermoprobe,
alternating with the selected
temperature.
When the inside temperature of the roast reaches the temperature you
have programmed it for, the oven will turn off, an alarm signal will
sound for a few seconds and will blink.
Touch to stop the alarm. The roast is just right and ready to serve.
If you wish to modify the thermoprobe temperature setting at any
time during cooking, touch . You can then change the temperature
setting using and . Touch . You will hear a doble beep
confirming the change has been made.
Suggested temperatures for cooking with
the thermoprobe
Dish
Beef
Rare roast beef/fillet steak 40-45
Medium roast beef/fillet steak 50-55
Well done roast beef/fillet steak 60-65
Other roast cuts 80-85
Pork
Pork fillet 65-70
Roast pork/ham 80-85
Rib roast/pork hock 80-85
Pork loin 75-80
Chops on the bone 70
Spareribs 65-70
Meatloaf 70-75
Veal
Roast veal 70-75
Roast veal kidney 75-80
Veal shin 80-85
Game
Game meat 75-80
Loin 60-70
Rare fillet 40-45
Medium fillet 50-55
Well done fillet 60-65
Roast lamb 80-85
Stuffed meat 70-75
Poultry 85-90
Fish 70-80
Inside temperature
in °C
Semi-automatic cooking with thermoprobe
This function can be used to set the cooking start time. Once the thermo-
probe has detected the selected temperature, the oven will turn off.
You will not be able to set the cooking time because this is determined by
when the pre-programmed temperature inside the meat is measured by
the thermoprobe.

40 EEB 6550.8
You should be present when the cooking finishes as the roast is just
right for serving. If you leave the roast in the oven, it will continue to
cook with the heat inside the oven and the result will not be as ideal.
To set this function, connect the thermoprobe.
Touch . This will light up in red.
If you touch or , you will see
the 5 clock functions on the display.
When you have programmed the
cooking start time, , touch . You
will see and the current time on the
display.
Touch or to programme the
cooking start time. Touch . You will
hear a double beep. You will see
and the programmed cooking time.
The oven will stay off.
At the set time, the oven will turn on and cook the food.
When the inside temperature of the roast reaches the temperature you
have programmed it for, the oven will turn off, an alarm signal will
sound for a few seconds and will blink.
Touch to stop the alarm. The oven is now off.
The roast is just right and ready to serve.
Slow cooking
Cooking at low temperatures leaves the meat especially tender, even
though it takes longer to cook. The meat can be ready to eat longer
without drying out.
Suitable for tender cuts of veal, beef, pork and lamb. It is also suitable
for chicken, turkey, duck and goose breasts (boneless).
It is not suitable for game and horse meat. Lengthy cooking of these
types of meat produces a typically strong smell.
– Remove the fat and skin before preparation (except duck breast).
– Seal the meat in a pan or pot on both sides (also both ends).
As a general rule the longer you seal the meat the shorter the time you
will need for cooking. Seal thicker cuts of meat longer than thinner
pieces. The length of the cuts of meat does not influence the time
needed to seal the meat.
Setting the heat mode/cooking temperature
– Heat the oven with the grid shelf and roasting tray for 20 minutes so
that the temperature on the inside of the oven is even.
– Select the hot air, , heat mode. Alternatively, you can choose
top/bottom heat, .
– Set the temperature and cooking time according to the chart.
As a general rule, cook thicker cuts of meat at 80°C and thinner cuts
at 70°C.
– Do not cover the meat while cooking, even if using small pieces of
meat.
Do not use the thermoprobe. It is not reliable enough for this style
of cooking. Slow cooking means the juice from the meat does not
remain inside but it is distributed evenly throughout the piece.
– You can carve the meat immediately after cooking; it does not need to
stand for a time as in the case of conventional cooking.
You may keep the meat warm in the oven at 60°C. The thicker cuts of
meat for approximately 1-2 hours, and thinner pieces for 30-40 mins.

EEB 6550.8 41
Meat type
Pork
Steak 400-600 g 5 60-90 80
Pork fillet 800-1,000 g 7 90-105 80
Ham 1,000-1,500 g 10-12 230-250 80
Chops 800-1,000 g 8-10 120-140 80
Spareribs 1,000-1,500 g 10-12 120-150 80
Beef
Steak 700-1,200 g 5-9 100-140 80
Rib steak 1,500-1,800 g 10-12 150-180 80
Roast beef 700-1,800 g 10-12 120-180 70
Silverside, beef knuckle 1,500-2,000 g 10-12 200-230 80
Skirt steak 1,500-1,800 g 10-15 150-200 80
Veal
Steak 500-800 g 5-6 90-110 80
Veal fillet 1,000-1,500 g 8-10 110-120 80
Silverside, veal knuckle 1,500-1,800 g 10-12 140-160 80
Lamb
Lamb loin chops 400-600 g 3-5 60-80 70
Leg of lamb
(boned) 2,000-2,500 g 10-12 200-250 70
Poultry
Chicken breast 400-600 g 3-4 50-60 70
Duck breast 400-600 g 4-5 70-80 70
Weight Sealing (mins) Cooking time (mins) Temperature
Suggested settings for slow cooking

42 EEB 6550.8
Baking with cooking settings
Hot air
Preheating is not required – you can bake different things on different
levels at the same time.
Shelf levels:
1 tray: shelf level 2 from bottom
2 trays: shelf levels 1 and 4 from the bottom
When baking several flat sponges or cakes in moulds the baking time is
extended by 5-10 minutes per tray.
Take out the trays individually, start with the more golden cakes first.
Bake with hot air at 160° C when the recipe that you are following
does not give instructions for hot air.
NB: For cakes garnished with moist fruits, the level of humidity will be
particularly high. Bake only one cake at a time.
Top/bottom heat
Baking on one shelf
Preheating: -Select the heating mode «Hot air/Bottom heat» .
Blackplate and aluminium baking moulds are particularly suitable for
this function.
Fan-forced hot air or
No preheating required – bake on one shelf
Only for flat cakes with dry garnish e.g. cake with a layer of sugar.
Pizza Mode
Bake on one shelf
for moist cakes
for pizza: preheat
for bread: preheat
Baking pizza
Select the baking setting
– When a pizza stone (special accessory) is used, the pizza crust will turn
out be extra crisp. Preheating time: 30 mins minimum!
Follow the instructions that come with the pizza stone.
Basic pizza recipe
250 g flour, 20 g yeast, 125 ml warm water, 3 soup spoons of oil (olive),
salt.
Baking pizza on the oven tray
– Make leavened dough with the ingredients specified.
– Leave the dough to stand until the volume has doubled (approximately
30 minutes).
– Knead the dough for a few minutes and leave to stand for a further 15
minutes.
– Start the oven setting , the oven will preheat.
– Grease the oven tray.
If baking a small round pizza, put the tray in the oven to preheat too.
– Roll out the dough, place it on the oven tray and shape an edge.
– Cover the dough with the topping of your choice but do so quickly so
that the dough does not become too moist.
– Small pizzas: place the pizza bases on the preheated tray.
– Place the tray on shelf level 1 after the alarm sounds.
– After the door is closed, the 12-minute programme will start.
Baking the pizza on the stone
– Prepare the pizza dough as described above.
– Place the pizza stone on the grid shelf and put it on shelf level 1.
– Preheat the oven with heating mode at 250°C for 30 mins.
– Place the dough on the floured pizza shovel and quickly cover it with the
topping so that it does not become too moist. The topped pizza should
not be on the pizza shovel for too long as the dough may stick to it.
– Once the oven is preheated, push the pizza from the shovel onto the
stone.
– Bake for 8-12 mins without changing the settings.
Instructions for the chart: Suggested baking
settings
The chart below features a selection of cakes and pastries with the
required temperatures, cooking times and shelf level for each case.
In most cases, the temperature range is specified given that the
temperature depends largely on how the dough is made, the quantity
and the mould used.
We recommend that at the start you use the lower temperature and only
choose the higher temperature if necessary, e.g. if you require a more
intense golden colour or if the baking time is too long.
If you cannot find instructions for a specific recipe, use instructions for
a similar cake or pastry.
Differences in the height of the food can result in differences in the
level of brownness. In such cases the temperature setting should not
be changed. Any difference in the brownness will even out during the
baking process.

EEB 6550.8 43
Cakes and pastries
Sponge cake recipe
Flat sponge cake in mould 1 150-160 1 170-180 50-65
Cake in mould 1 150-160 1 170-190 50-70
Fruit cake 1 150-160 1 160-180 60-70
Flat sponge cake 2 150-160 1 170-180 40-60
Sponge base 2 170-180 2 180-200 20-30
Fruit-garnished flat sponge 2 150-160 1 170-180 2 150-160 45-60
Cupcakes 2 150 2 170-180 15-30
Large flat sponge (oven tray)
Dry coating 2 150-160 2 180-190 2
150-160 20-35
Moist garnishing 2 160-170 1 170-180 2
160-170 35-50
Recommended
baking setting
Hot air Top/bottom heat Fan-forced hot air
Pizza Mode Cooking time
Height Setting Height
Temperature in °C
Height
Temperature in °C
Height
Temperature in °C
In mins
Shortcrust pastry
Pie base 2 170-180 2 180-200 25-35
Baked cheesecake 1 140-150 1 160-170 2
140-150 70-90
Small pastries 2 140-150 2 180-190 15-35
Large flat pies
Dry garnishing 2 150-160 2 180-190 2
150-160 25-35
Moist garnishing 2 160-170 1 170-180 2
160-170 30-50
Leavened dough
Pie in mould 1 150-160 1 175-180 40-65
Brioche 2 150-160 2 175-180 40-50
Christmas loaf (preheat) 1 150-160 1 175-180 50-70
Small pastries 2 140-150 2 180-200 15-30
Large flat pies
Dry garnishing 2 150-160 2 175-180 2
150-160 30-40
Moist garnishing 2 160-170 1 170-180 2
160-170 30-50
Sponge cake recipe
Flat sponge cake 2 150-1690 2 175-180 30-40
Swiss rolls 3 170-180 2 180-200 12-25
Meringue base recipes
Meringues 2 80-90 2 100-120 80-120
Cinnamon stars 2 100-120 2 120-140 20-40
Almond meringue biscuits 2 100-120 2 120-140 20-50
Other types of pastry
Pastry 2 170-180 2 190-210 15-30
Puff pastry 2 170-180 2 190-210 30-40
Cottage cheese pie 2 160-180 2 180-200 30-40
Choux pastry 2 170-180 2 190-210 30-40
Cottage cheese pie with oil 2 150-160 2 170-180 30-40
Honey pastry 2 140-150 2 170-180 20-35
Bread and Pizza
Sourdough bread
(preheat: 230°C,
preheat: 10 min at 230°C) 1 180 1 180 1
180 70
Leavened bread /
White bread (preheat) 1 180 1 200 1
180 30-60
Savoury bread rolls / German-style
pretzels (preheat: 230°C 3 200 3 220 15-20
Pizza (preheat: 250°C) 1 250 8-12
Suggested baking settings
The values for the modes that should preferentially be used are highlighted.

44 EEB 6550.8
Grilling
Grill with the oven door closed only.
Select heating mode .
Set the temperature to 250°C.
In the case of large cuts, it is better to select a temperature between
200 and 250°C so that the meat does not burn.
– Heating mode .
– Preheat the oven for 5 mins.
– Put the food for grilling on the grid shelf.
– Place the tray on shelf level 1 or 2 counting from the bottom; place the
grid shelf on the shelf level specified in the chart.
– Close the oven door.
Suggested grill settings
Defrosting
The defrost function works by means of a 2-level system of hot air. HI is
for meats in general and LO is for fish, cakes, pastries and bread.
1. When you select the function
(follow the instructions in “Selecting
a conventional cooking function”), the
display will show:
Type of meat
Pork chops 4 10-12 8-10
Belly pork 4 12-15 8-10
Pork fillet 4 10-12 8-10
Filleted liver 5 5-6 4-5
Grill
Side 1.
In minutes
Side 2.
Height
Bratwurst 4 8-10 6-8
Meat skewer 3 9-11 7-8
Beef steak, rare 5 6-7 5-6
Beef steak, medium 5 7-9 6-7
Veal steak 4 8-10 7-8
Lamb chop 4 7-8 6-7
Chicken thighs 3 15-18 10-12
Half chicken 3 18-20 10-12
Fish fillet 5 6-7 4-5
Trout 3 5-7 4-6
TToast 5 2-3 2-3
Open toasted sandwich 4 6-8
The times shown in the chart are suggested. The time needed for
defrosting will depend on the ambient temperature, weight of the food
and how deeply frozen it is.
Making preserves
Caution If using jars with twist-off® lids, do not use the same lid twi-
ce. This could lead to the jars smashing under certain circumstances
if used too often.
Suitable containers for preserves are clip top jars with a rubber
sealing ring or ordinary containers with twist-off® lid (with a new lid
only).
Metal tins are not suitable.
Do not spill water in the tray. Too much steam would suddenly escape
when the oven door is opened. Place a cup with water in the baking
tray, not in the bottom of the oven.
Food Type LO level
Bread 1/2 kg 35 min
Cake 1/2 kg 25 min
Fish 1/2 kg 30 min
Fish 1 kg 40 min
Chicken 1 kg 75 min
Chicken 1.5 90 min
Steak 1/2 kg 40 min
Mincemeat 1/2 kg 60 min
Mincemeat 1 kg 120 min
HI level
Weight
Temperature Weight Temperature
2. Touch or to select the HI or LO defrosting levels. Touch .
3. You will then hear 2 beeps confirming your setting.
When defrosting, remember:
Food should be removed from its packaging and placed on the oven
tray or on a dish.
Defrost large cuts of meat or fish by placing them on the grid shelf with
a tray underneath to collect any liquid.
Meat and fish do not need to be completely thawed before cooking. It is
enough for the surface to be soft to enable it to be seasoned.
Food should always be cooked after defrosting.
Do not refreeze defrosted food.
Time chart for defrosting food.
See the following chart for defrosting times and temperature levels.

EEB 6550.8 45
Select Pizza Mode .
Only use fresh produce and prepare according to the usual recipes.
Make no more than 6 jars holding 1 litre each.
Use the same size jars. Fill them to ¾ their capacity with the same
content.
Do not let the jars touch each other.
– Place the baking tray on shelf level 1 counting from the bottom.
– Put a cup filled with water in the baking tray.
– Set to Pizza mode at 160° C and observe the preserving process.
After 10 to 20 minutes, the liquid in the first jars begins to pearl,
normally first of all in the front right jar.
Fruit
– Next, turn off the oven and leave the jars to stand for 30 mins. (approx.
15 mins with delicate fruit such as strawberries) inside the closed oven.
Vegetables and meat
– When the liquid pearls, reduce to 100° C and continue to cook for 30 to
60 mins.
– Next, turn off the oven and leave the jars to stand for 30 mins.
Child safety lock
The child safety lock protects the oven against settings being changed
accidentally, and offers additional protection for small children.
When the child safety lock is active, it is only possible to turn the oven
off. It is not possible to change the settings or to turn on the oven.
Turning the child safety lock on / off
Turning the child safety lock on:
First turn on the oven by touching , if it is off.
Next, touch
and at the same time.
You will hear 1 prolonged beep and see on the display. The oven
is locked.
If the glass fronted panel is touched at any time, will be displayed,
indicating the oven is locked.
Turning the child safety lock off:
Touch and at the same time.
You will hear 1 prolonged beep. The oven is unlocked.
Cleaning and care
Please read this chapter before using the appliance for the first time.
If it is cleaned as it should be and regularly cared for, the oven should
stay beautiful and as good as new for many years. Here is a series
of instructions that allow you to care for and clean all of the surfaces
thoroughly, without damaging them.
For all surfaces
Do not use steam and/or pressure cleaning devices on the oven. The
appliance could become damaged and may create a situation where
there is danger of death.
Danger of burning Leave the appliance to cool until you can touch it
with your hand before cleaning it.
Follow the instructions for all cleaning products.
Clean the appliance after each use. Stains or baked-on food that have not
been removed may burn the next time the appliance heats up. Often, these
types of stains or dirt cannot be removed without leaving marks.
If there are light stains, clean the surfaces with a cloth, brush or soft
sponge and hot water and some dishwashing detergent. Rinse with cold
water so that there is no detergent left which might decolour the surface
or cause more stains. Dry with a cloth immediately after.
Here are some instructions for more difficult-to-remove stains concer-
ning the different surfaces and elements.
VSR 0-FIX-C is ideal for cleaning glass-ceramic, enamel and the sur-
face of the inside of the door. This cleaning powder can be purchased
from the KÜPPERBUSCH after-sales service.
Never clean with:
– aggressive products or bleaches that contain active oxygen, chlorine or
other corrosive ingredients.
– cleaning products that can cause scratches, such as abrasive agents,
steel wool, soapy steel wool, hard brushes, metal scourers, plastic
sponges or sponges with a surface that scratches (scouring side).
Removing baked-on dirt
Baked-on dirt has to be softened first of all. The best way is by using a
damp cloth. The dirt can then be removed more easily.
Using a scraper to clean
Careful! Danger of cutting! The scraper blades are very sharp.
Always use the scraper at a low angle to the surface and for pushing the
baked-on dirt.
