Küppersbusch EDIP 60.0 W Quick setup guide

BEDIENUNGSANWEISUNG
mit Montageanweisungen
Instructions for use and installation instructions
Instructions d´utilisation e avis de montage
Gebruiksaanwijzing en montagehandleiding
Istruzioni di uso e di montaggio
Instrucciones de Uso e Instrucciones de Montaje
Instruções de uso com indicações para montagem
GB
F
NL
I
E
P
G
00 00 00 00
EDIP 60.0 W - EDIP 6400.0E
KÜPPERSBUSCH HAUSGERÄTE AG
Postfach 10 01 32, D-45801 Gelsenkirchen, Küpperbuschstraße 16, D-45883 Gelsenkirchen
Telefon [phone], Telefax (02 09) 4 01-3 03

Dear customer,
We congratulate you on your choice. We are
sure that this modern, functional and practical
article, constructed from highest quality materi-
als, will fully meet your requirements.
Please read all the sections of this INSTRUC-
TION MANUAL before using the extractor for the
first time to be able to obtain its full performance
and to avoid any breakdowns that could arise
from its misuse, also allowing small problems to
be overcome.
Keep this manual. It will always provide useful
information on the extractor and will help other
people to use it.
Safety Instructions
■Before using the extractor for the first time,
you must observe the installation and con-
nection instructions.
■Never pull the cable to unplug the extractor.
Always pull the plug.
■Do not switch on the extractor if the electricity
cable is worn or has cuts or if there are signs
of deterioration around the control panel.
■If the extractor stops working or functions
abnormally, unplug it from the mains and
advise the technical service.
■Do not leave gas burning without a pan
above it under the hood.
■Do not allow grease to accumulate in any
part of the extractor, especially in the filter as
this COULD PRODUCE A FIRE RISK.
■Do not flambé food under the hood.
■Before installing the extractor consult local
rules and regulations in force with respect to
current standards on air and fumes.
■Before connecting the extractor to the mains,
check that both the voltage and the frequen-
cy conform to that shown on the characteris-
tics label of the extractor located inside it.
■Switching on and off must be by means of
an omnipolar switch with minimum separa-
tion between contacts of 3 mm incorporated
into the fixed installation.
■The electrical connection must be made by
means of a flexible cable. It is not allowed to
connect it by means of a rigid conduit.
■The expelled air must not reach a duct that
is used to expel food processor fumes using
energy other than electricity.
■The room must be provided with appropriate
ventilation if the extractor is going to be used
at the same time as other food processing
equipment not using electrical power.
■We recommend the use of gloves and cau-
tion when cleaning the inside of the extractor.
■Your extractor is designed for domestic use
and only for expelling and purifying gases
arising from food preparation. Its use for any
other purpose must be at your own respon-
sibility and may be dangerous.
■You should contact the nearest Qualified
Technical Assistance Service for any repairs
always using original spare parts. Repairs
and modifications carried out by others
could damage the apparatus or cause it to
malfunction, and risking your safety. The
manufacturer cannot be held liable for inap-
propriate use of the apparatus.
Description of the apparatus
AMotor controls that allow three posi-
tions to be selected
BLight switch independent of the motors
CLighting by means of lamps
DFilters located over cooking area, easily
withdrawn for cleaning
EExtractable group that allows a
greater gas capture area
FPossibility of incorporating activated
charcoal filter
G-H Anti return tabs to be located in the
outlet mouth, locating their ends in the
holes provided.
(Fig. 1)
Instructions for use
By pressing the button shown in the figure, you
will be able to control the functions of the
extractor (Fig. 2).
Two achieve better extraction, we recommend
switching on the extractor a few minutes before
starting to cook (3 - 5 minutes) so that the air
flow is continuous and stable when extracting
the fumes.
Likewise, keep the extractor switched on for a
few minutes when cooking is complete to allow
all fumes and odours to be expelled.
Cleaning and maintenance
Before carrying out any cleaning or maintenance
activities, ensure that the extractor is discon-
nected from the mains.
To carry out cleaning and maintenance, follow
the safety instructions.
Filter cleaning
To withdraw the filters from their locations
release the anchoring points. Clean the filter,
either by putting it in the dishwasher (see notes)
or leaving it standing in hot water to simplify the
removal of grease or, if wished, by means of
special sprays (protecting the non metallic
parts). Once clean, leave it to dry.
Notes: cleaning in the dishwasher with aggres-
sive detergents may blacken the surface of
metallic parts, without this affecting its gas
retaining properties.
N.B. The filter must be cleaned at least once a
month depending on how often the extractor is
used. It must be remembered that grease is
deposited in the extractor when cooking,
whether it is switched on or not.
Cleaning of the extractor body
The use of warm (40ºC approx.) soapy water is
recommended. A cloth moistened in this water
is used for cleaning the extractor, paying special
attention to the grids. Afterwards, dry using a
lint-free cloth.
Note:
■Never use metallic scouring pads or abrasive
products that could damage the surface.
■Do not use scrapers with metallic surfaces
such as knives, scissors etc.
Activated charcoal filter
■To install the charcoal filter, the motor
anchorage is made to coincide with the
anchor points of the activated charcoal filter
and turn it clockwise.
■The carbon filter lasts from three to six months
depending on the particular conditions of use.
■The activated carbon filter can neither be
washed nor regenerated. Once it is exhaust-
ed, it must be changed.
■To replace exhausted filters with new ones,
withdraw the old one in the reverse order to
that of installation.
Chaging Bulbs (Mod. A EDIP 60.0W, Fig. 1)
■Remove the filter support to acces the bulbs.
■Take care to disconnect the mains beforehand
and that the bulbs to be replaced are not hot.
■The maximum bulbs power is 40W.
Changing Bulbs (Mod. B EDIP 6400.0E, Fig. 1)
■Remove the embellisher ring by unscrewing
it in anti-clockwise direction, taking care not
to drop it.
■Make sure that the hood has been discon-
nected from the mains supply and that the
bulbs to be replaced are not hot.
■Remove the old bulb and install the new one,
following the bulb manufacturer’s instructions.
■The maximum bulb rating is 40 W, 12 V.
■Replace the embellisher ring by screwing
tightly in clockwise direction.
English
Technical information (Fig. 3)
Dimensions Voltaje Max Power
(mm) Frequency
600x300x185 Refer to Refer to Refer to
(Width x Depth x Height) Characteristics Label Characteristics Label Characteristics Label
Mod.
Typ.
POTENCIA NOM. LAMPARAS
NENNLEISTUNG GLÜHLAMPEN
LAMPS RATE
PUISSANCE LAMPES
POTENCIA NOM. DAS LAMPADAS
2x40 W
XXX – ZZ
Z-000000
N.º de fábric.
Fabrik.-Nr.
Serial No.
Made in European Community - C.I.F.: A-39004932
AA-000000
ELECT.
000…000 V. ~
00 Hz
000 W.

Installation
To fix the extractor to the kitchen unit the pat-
tern on Fig. 5 is used.
The lower part of the extractor must be located
at a minimum height of 60 cm above the hob for
electric cookers and 65 cm for gas cookers. If
the instructions of a gas cooker indicate a
greater distance these must be observed.
The extractor must be connected to a wall sock-
et with an effective earth.
When the extractor is working at the same time as
other non-electrical cooking equipment, the outlet
air pressure must not exceed 4 Pa (4 x 10-5 bar).
To achieve optimum performance the length of
the outlet hose should not exceed 4 meters, or
include more than two 90º angles (elbows)
Although venting to the outside is recommend-
ed, activated carbon filters may be used, which
allow the gas to be returned to the kitchen
through the outlet pipe.
If you wish to exchange the front for one match-
ing the kitchen units, follow the following
instructions (Fig. 4):
■Withdraw the movable group.
■Remove the screws (T) that support
the front
■Install the new front fixing it with the same
screws that held the old one.
If something does not work
Before seeking technical assistance carry out
the following checks first
English
Defect Possible cause Solution
The extractor does not work
The cable is not connected Connect the mains cable
No current is reaching the plug Revise/repair the
electricity circuit
The extractor does not blow enough or vibrates
Filter saturated with grease Clean or substitute filter
Outlet obstructed Eliminate obstructions
Inadequate air conduit Contact the installer and follow
instructions of this manual
The lamps do not light
Lamp broken Exchange the bulb
Lamp loose Tighten bulb
Special U.K. Requirements
Height above gas hob: 75 mm minimum
NEVER PLACE THE COOKER HOOD OVER AN
EYE-LEVEL GRILL
This appliance must be connectec by a compe-
tent person, using fixed wiring via a DOUBLE
POLE SWITCHED FUSED SPUR OUTLET
Electical connection
We recommend that the appliance is connected
by a qualified electrician, who is a member of the
N.I.C.E.I.C. and who will comply with the I.E.E.
and local regulations.
Should the colour of the wires in the manis lead
for the appliance not correspond with the
coloured markings identifying the terminal in your
spur box proceed as follows:
■The wire which is coloured blur must be con-
nected to the marked N (Neutral) or coloured
Black.
■The wire which is coloured brown must be
connected to the marked L (Live) or
couloured Red.
■Where avialable (see installation), the wire
which is coloured yellow/green must be con-
nected to the market or coloured
Yellow/Green.
If the cooker hood is installed for use above a gas
appliance then the provision vor ventilation must
be in accordance with the Gas Safety (Installation
& Use) Regulations 1984 and the relevant
Building Regulations. Detailed recommendations
are contained in the following British Standard
Codes of Practice BS6172, BS5440 and BS6891
Current Edition.

4
6
1Mod. A
2
5
T
T
T
320
340
4 x Ø8
Ø132
Ø132
559
151
458
598
66
84
214
300
A
B
A
C
Abzug für zwei Motoren Abzug für einen Motor Frontabdeckung der
Dunstabzugshaube
Salida para 2 motores Salida para 1 motor Frontal Campana
Outlet for two motors Outlet for single motor Front of extractor
Sortie pour 2 moteurs Sortie pour 1 moteur Partie frontale de la hotte
Uitgang voor 2 motoren Uitgang voor 1 motor Voorkant afzuigkap
Uscita 2 motori Uscita 1 motore Frontale cappa
d’aspirazione
B C
Saída para 2 motores Saída para 1 motor Frente do exaustor
3
E
A
C
D
B
A
D
Mod. B
E
A
CC
D
B
A
D
F C C F
FC CF
300
24
475
600
559
184
142
Absaugleistung
INiedrig
II Mittel
+Intensiv
Speed
I Low
II High
+Intensive
Vitesse
I Petite
II Grande
+Intensive
Snelheid
I Laag
II Gemiddeld
+Intensief
Velocità
I Bassa
II Alta
+Intensa
Velocidad
I Baja
II Alta
+ Intensiva
I
II
+
Velocidade
I Baixa
II Alta
+ Intensiva
Beleuchtung
Ein / Aus
Light
Switch on / off
Lumière
Allumé / Eteint
Licht
Aan/Uit
Luce
Acceso /
Spento
Luz
Apagado /
Encendido
Luz
Desligar/Ligar
H
G
