Kärcher SC 3 Deluxe EasyFix Premium User manual

SC 3 Deluxe EasyFix Premium
97698770 (07/22)

A
9

B C D
E F G
H I J

N O P
Q R

(QJOLVK 
Contents
Safety instructions
Read these safety instructions and the
original instructions before using the de-
vice for the first time. Act in accordance
with them. Keep the two booklets for future reference or
for future owners.
ƔIn addition to the notes in the operating instructions,
you also need to take into consideration the general
safety regulations and accident prevention guide-
lines applicable by law.
ƔWarnings and information notices attached to the
device provide important information for hazard-free
operation.
Hazard levels
DANGER
ƔIndication of an imminent threat of danger that will
lead to severe injuries or even death.
WARNING
ƔIndication of a potentially dangerous situation that
may lead to severe injuries or even death.
CAUTION
ƔIndication of a potentially dangerous situation that
may lead to minor injuries.
ATTENTION
ƔIndication of a potentially dangerous situation that
may lead to damage to property.
General safety instructions
DANGER Ɣ࣯Risk of asphyxiation. Keep pack-
aging film out of the reach of children.
WARNING Ɣ࣯Only use the device for its proper
use. Take into account the local conditions and beware
of third parties, in particular children, when working with
the device. Ɣ࣯Only people who have been instructed on
how to use the device, or have proven their ability to op-
erate it, and have been explicitly instructed to use it,
must use the device. Ɣ࣯Persons with reduced physical,
sensory or mental capabilities and persons lacking ex-
perience and knowledge may only use the appliance if
they are properly supervised, have been instructed on
use of the appliance safely by a person responsible for
their safety, and understand the resultant hazards in-
volved. Ɣ࣯Children must not operate the device. Ɣ࣯Chil-
dren must be supervised to prevent them from playing
with the appliance. Ɣ࣯Keep the device out of the reach of
children when it is connected to the mains or when it is
cooling down.
CAUTION Ɣ࣯Do not use the device if it has
been dropped beforehand, is visibly damaged or if it is
leaking. Ɣ࣯Safety devices are provided for your own pro-
tection. Never modify or bypass safety devices.
Risk of electric shock
DANGER Ɣ࣯Never touch the mains plug and
socket with wet hands. Ɣ࣯Only connect the device to al-
ternating current. The voltage indicated on the type
plate must match the voltage of the power source. Ɣ࣯Do
not direct the steam jet directly onto equipment
contain-ing electrical components, e.g. the interior
space of ov-ens. Ɣ࣯Do not fill the devices with
removable water reservoir directly via the water
connection while they are connected to the mains
power. Use a receptacle for fill-ing. Ɣ࣯Do not use the
device in swimming pools which contain water. Ɣ࣯The
mains plug and extension cable connec-tion must not
be in water. Ɣ࣯Do not clean over floor sockets.
WARNING Ɣ࣯Only connect the device to an
electrical connection which has been set up by a quali-
fied electrician as per IEC 60364-1. Ɣ࣯Only operate the
device in wet rooms, e.g. bathroom, connected to sock-
ets with upstream residual current device. Ɣ࣯Check that
the mains connection cable with mains plug is undam-
aged each time before using the device. To avoid any
possible danger, a damaged mains connection cable
must be immediately replaced by the manufacturer, or
the authorised customer service department or a quali-
fied electrician. Ɣ࣯Do not damage the power supply and
extension cable by running over it, crushing or yanking
it or similar. Protect the power supply cable from heat,
oil and sharp edges. Ɣ࣯Unsuitable electrical extension
cables can be dangerous. Only use electrical extension
cables with a splash guard and a diameter of at least
3x1 mm2.Ɣ࣯Only replace couplings on the power supply
or extension cable with those with the same splash
guard and the same mechanical strength. Ɣ࣯Clean tiled
walls with sockets carefully. Ɣ࣯Disconnect the device
from the mains during longer operating breaks, after use
or before performing any maintenance work. Ɣ࣯Only
carry out servicing work when the mains plug is pulled
and the steam cleaner has cooled down.
Operation
DANGER Ɣ࣯Operation in explosive atmos-
pheres is prohibited. Ɣ࣯When using the device in hazard
zones (e.g. service stations), adhere to the respective
safety regulations.
WARNING Ɣ࣯Risk of scalding. Never touch the
steam jet with your hand from a close distance, and do
not direct it at people or animals. Ɣ࣯Danger of scalding
from high water output if you tilt the device more than
30° to the side during use. Only affects SC 1 devices Ɣ࣯Risk
of scalding on the hot steam boiler. Allow the steam boil-
er to cool down before filling it with water. Does not apply
to SC 3 / SC 3 Upright devices Ɣ࣯Risk of scalding. Let the
appliance and accessory parts, particularly the floor
cleaning cloth and the hand cover cool down before
touching them. Ɣ࣯Risk of scalding. Do not use the appli-
ance for cleaning pressure tanks as this poses a burst-
ing and explosion hazard. Ɣ࣯Risk of scalding from the
floor nozzle. Ensure that no part of the body gets under
the floor nozzle. Never operated the floor nozzle without
Safety instructions ............................................... 5
Environmental protection..................................... 7
Accessories and spare parts ............................... 7
Scope of delivery ................................................. 7
Warranty .............................................................. 7
Safety devices ..................................................... 7
Description of the unit.......................................... 7
Initial start-up ....................................................... 8
Installation ........................................................... 8
Operation............................................................. 8
Important application instructions........................ 9
How to use the Accessories ................................ 9
Care and service ................................................. 11
Troubleshooting guide ......................................... 12
Technical data ..................................................... 12

 (QJOLVK
wearing shoes. Ɣ࣯Risk of scalding. Only operate the ap-
pliance once it is fully assembled and functional. Ɣ࣯Risk
of scalding. Let the appliance cool down fully before put-
ting it away.ATTENTION Ɣ࣯Do not fill with any
cleaning agents or other supplements.WARNING
Ɣ࣯Never disconnect accessories from the device while
steam is being expelled. Ɣ࣯Hot water may drip out when
disconnecting accessory parts. Allow the device to cool
down first. Ɣ࣯Never open the maintenance / safety lock
during operation. Allow the device to cool down first.
Ɣ࣯Do not clamp the steam lever / steam key during op-
eration. Ɣ࣯Replace a damaged steam hose immediately
with a steam hose as recommended by the manufactur-
er. Ɣ࣯Do not steam any objects which contain harmful
substances (e.g. asbestos).
CAUTION Ɣ࣯Only operate or store the device
in accordance with the description or figure. Ɣ࣯Check
the device and the accessories, in particular the power
supply cable, safety lock and steam hose, to make sure
it is in proper safe and reliable condition before opera-
tion each time. Do not use the device if it is damaged.
Replace damaged components immediately. Ɣ࣯Only
switch on the device when water is present in the steam
boiler. The device may otherwise overheat, see the
Troubleshooting chapter of the operating instructions.
Ɣ࣯Accidents or damage due to the device falling over.
Before all actions with or on the device, you must make
sure that it is stable.
ATTENTION Ɣ࣯Do not operate the device at tem-
peratures below 0 °C. Ɣ࣯Never leave the device unsu-
pervised while it is connected to the mains. Ɣ࣯Do not use
the appliance as a humidifier or heater. Ɣ࣯Ensure the
room is well ventilated when working with the appliance
and afterwards. Ɣ࣯Protect the device from rain. Do not
store the device outdoors. Ɣ࣯Device damage. Never
pour solvents, liquids containing solvents or undiluted
acids (e.g. detergents, petrol, paint thinner and acetone)
into the boiler/water reservoir. Ɣ࣯Unsuitable water can
block the nozzles or damage the water level indicator.
Do not fill with condensate water from a dryer, collected
rainwater, detergents or additives (e.g. scents). Fill the
water reservoir with a maximum of 1 l / 0,5 l of tap water.
Applies to SC 3 / SC 3 Upright devices only Ɣ࣯Unsuitable wa-
ter can block the nozzles or damage the water level in-
dicator. Do not fill with pure distilled water, condensation
from a dryer, collected rain water, detergents or addi-
tives (e.g. fragrances), use a maximum of 50% distilled
water mixed with tap water.
ƔRemove the water reservoir for filling
a Pull the water reservoir vertically in an upward di-
rection
b Fill the water reservoir vertically with tap water or
a mixture of tap water and a maximum of 50%
distilled water up to the “MAX” marking.
c Insert the water reservoir and press down until it
clicks into place.
ƔFill the water reservoir directly at the device
a Fill tap water or a mixture of tap water and a max-
imum of 50% distilled water up to the “MAX”
marking in the filling hole for the water reservoir.
Applies only to SC 4 and SC 5 devices
Note Ɣ࣯Refilling water
1 Switch off the device.
2 Allow the device to cool down.
3 Unscrew the safety lock.
4 Drain the water completely out of the steam boiler.
5 Fill a maximum of 200 ml distilled water or tap water
into the steam boiler.
6 Insert the safety lock.
Applies only to SC 1 devices Ɣ࣯Refilling water
1 Switch off the appliance.
2 Allow the appliance to cool down.
3 Unscrew the safety lock.
4 Drain the water completely out of the steam boiler.
5 Fill a maximum of 1 l distilled water or tap water into
the steam boiler.
6 Insert the safety lock.
Applies only to SC 2 devices
For upright machines
WARNING Ɣ࣯Risk of scalding. Only operate
the appliance on even, horizontal surfaces. Do not lay
the appliance on its side during operation. Do not use
the appliance above head height or horizontally e.g. to
clean walls, work surfaces or windows. Applies to SC
3 Upright only
CAUTION Ɣ࣯In order to guarantee stability,
place the device on a firm, flat surface. Ɣ࣯Do not carry
the device when performing cleaning work.
Care and service
CAUTION Ɣ࣯Have repair work carried out by
the authorised customer service only.
Descaling the steam boiler
Does not apply to SC 3/SC 3 upright devices
CAUTION Ɣ࣯Never screw the safety lock onto
the device while descaling. Ɣ࣯Do not use the steam
cleaner while there is descaler in the boiler.
ATTENTION Ɣ࣯The descaler may corrode sensi-
tive surfaces. Work carefully when filling and emptying
the steam cleaner with descaler.
ATTENTION Ɣ࣯Do not use vinegar or similar
agents.
Steam cleaner accessories
(Depending on equipment)
Iron
WARNING Ɣ࣯Risk of scalding. Do not direct
the steam jet at people or animals. Ɣ࣯Risk of burns on
hot steam pressure iron and hot steam jet. Alert other
people to the hazard. Ɣ࣯Do not touch any electrical ca-
bles or combustible objects with the hot steam pressure
iron. Ɣ࣯Have the damaged mains cable replaced imme-
diately by an authorized customer service/qualified
electrician. Ɣ࣯Children over the age of 8 and persons
with reduced physical, sensory or mental capabilities, or
those with a lack of experience and knowledge, are only
allowed to use the appliance if they are properly super-
vised, have been instructed with respect to using the ap-
pliance safely by a person responsible for their safety,
and understand the resultant dangers involved. Ɣ࣯Chil-
dren must not play with the appliance. Ɣ࣯Children may
only perform cleaning work and user maintenance un-
der supervision.
CAUTION Ɣ࣯Do not use the steam pressure
iron if it has been dropped, has visible damage or is
leaking. Ɣ࣯Do not leave the steam pressure iron unat-
tended while it is connected to the mains. Ɣ࣯Before the
water reservoir (of the steam cleaner) is filled with water,
the mains plug must be pulled out of the socket. Ɣ࣯You
must only operate or set down the steam pressure iron

English 7
on a stable surface.●When placing the steam pres-
sure iron on its stand, make sure that the stand is stable.
●Repair work on the device may only be carried out by
authorized customer service.
Steam turbo brush
CAUTION
●Longer periods of use of the steam turbo brush may
lead to poor blood circulation in the hands due to vi-
bration. In case of symptoms, e.g. tingling in the fin-
gers, cold fingers, take a break. A general period of
use cannot be set, because this depends on several
influencing factors:
●Personal tendency to suffer from poor circulation
(frequently coldfingers, tingling sensation in the fin-
gers).
●Holding the device too tightly hindering blood circu-
lation.
●Continuous operation is more harmful than opera-
tion interrupted by work breaks.
You should consult a doctor if using the steam turbo
brush regularly and for lengthy periods of time, and in
the event of repeated occurrences of symptoms such
as tingling in the fingers or cold fingers.
Environmental protection
The packing materials can be recycled. Please
dispose of packaging in accordance with the en-
vironmental regulations.
Electrical and electronic appliances contain valu-
able, recyclable materials and often components
such as batteries, rechargeable batteries or oil,
which - if handled or disposed of incorrectly - can
pose a potential threat to human health and the environ-
ment. However, these components are required for the
correct operation of the appliance. Appliances marked
by this symbol are not allowed to be disposed of togeth-
er with the household rubbish.
Notes on the content materials (REACH)
Current information on content materials can be found
at: www.kaercher.com/REACH
Accessories and spare parts
Only use original accessories and original spare parts.
They ensure that the appliance will run fault-free and
safely.
Information on accessories and spare parts can be
found at www.kaercher.com.
Scope of delivery
The scope of delivery for the appliance is shown on the
packaging. Check the contents for completeness when
unpacking. If any accessories are missing or in the
event of any shipping damage, please notify your deal-
er.
Warranty
The warranty conditions issued by our relevant sales
company apply in all countries. We shall remedy possi-
ble malfunctions on your appliance within the warranty
period free of cost, provided that a material or manufac-
turing defect is the cause. In a warranty case, please
contact your dealer (with the purchase receipt) or the
next authorised customer service site.
(See overleaf for the address)
Safety devices
CAUTION
Missing or modified safety devices
Safety devices are provided for your own protection.
Never modify or bypass safety devices.
Symbols on the device
(according totype of appliance)
Pressure controller
In case of inadmissibly high pressure in the event of a
fault, a safety valve relieves the pressure into the at-
mosphere.
Fuse
The fuse prevents the device from overheating. If the
device overheats, the fuse disconnects the device from
the power supply.
Before re-commissioning the device, contact the re-
sponsible KÄRCHER Customer Service.
Description of the unit
The maximum amount of equipment is described in
these operating instructions. Depending on the model
used, there are differences in the scope of delivery (see
packaging).
For the illustrations, refer to the graphics page.
Illustration A
1Decalcification cartridge
2On/Off switch
3Reduced steam volume
4Indicator light (red) - replace decalcification car-
tridge.
5Maximum steam volume
6Accessory storage area
7Park bracket for floor nozzle
8Carrying handle
9Mains connection cable with mains plug
10 Steam gun
11 Steam lever
12 Unlocking button
13 Child lock
14 Steam hose
15 Spotlight nozzle
16 Round brush
17 ** Round brush (large)
18 ** Power nozzle
Risk of burns, surface of appliance be-
comes hot during operation
Risk of scalding from steam
Read operating instructions

19 Crevice brush
20 Manual nozzle
21 Microfibre cover for manual nozzle
22 Extension tubes (2 x)
23 Unlocking button
24 Floor nozzle
25 Hook and loop fastener
26 Microfibre floor cloth (1 x)
27 ** Carpet glider
28 ** Microfibre floor cloth (2 x)
** optional
Initial start-up
ATTENTION
Device damage due to calcification
The decalcification cartridge only works properly if you
adjust the device to the local water hardness before op-
erating it for the first time.
Set the device to the local water hardness.
Set the device to the current water hardness before us-
ing it in an area with a different water hardness (e.g. af-
ter a move)
1. Insert the decalcification cartridge into the opening
and push it so that it is firmly in place.
Illustration B
2. Set the water hardness, see chapter Setting the wa-
ter hardness.
Installation
Installing accessories
1. Push the open end of the accessory onto the steam
gun so that the unlocking button on the steam gun
engages.
Illustration C
2. Push the open end of the accessory onto the spot-
light nozzle.
Illustration D
3. Connect the extension tubes to the steam gun.
a Push the 1st extension tube onto the steam gun
so that the unlocking button on the steam gun en-
gages.
The connection pipe is connected.
b Push the 2nd extension tube onto the
1st extension tube.
The connection pipes are connected.
Illustration E
4. Push the accessory and / or the floor nozzle onto the
free end of the extension tube.
Illustration F
The accessory is connected.
Disconnecting accessories
1. Move the child lock back.
The steam lever is locked.
2. Push the unlocking button and pull the parts apart.
Illustration G
Operation
Filling water
The water reservoir can be filled at any time.
ATTENTION
Damage to the device
Unsuitable water can block the nozzles or damage the
water level indicator.
Do not use condensation from the clothes dryer for fill-
ing.
Do not use collected rain water for filling.
Do not use cleaning agents or other additives (e.g.
scents) for filling.
1. Fill the water reservoir with a maximum of 1 l of tap
water.
Illustration H
Switching on the device
ATTENTION
Device damage due to incorrectly set water hard-
ness
The decalcification cartridge only works properly if the
device is adjusted to the local water hardness. The de-
vice may calcify if the water hardness is set incorrectly.
Adjust the device to the local water hardness before first
operation, see chapter Setting the water hardness.
Note
When steaming for the first time after removing and re-
inserting the decalcification cartridge, the steam jet may
be weak or irregular, and individual drops of water may
be expelled. The device requires a short running-in pe-
riod in which the decalcification cartridge fills with water.
The steam volume that is expelled increases constantly
until the maximum steam volume has been reached af-
ter approx. 30 seconds.
1. Place the device on a firm surface.
2. Connect the mains plug into a socket.
3. Press the On/Off switch.
4. The LED strip is in fading red.
5. The LED strip lights up in a constant green after ap-
prox.30 seconds.The device is ready for use.
Illustration I
Regulating the steam volume
The expelled steam volume is regulated by pressing the
steam volume button. Two different steam volume but-
tons are available:
Illustration R
Note
The maximum steam volume is always selected when
the device is switched on.
1. Press the steam lever after setting the steam vol-
ume.
2. Before starting cleaning, point the steam gun at a
cloth until steam is expelled evenly.
Topping up the water
If there is a water shortage, the LED strip rapidly flashes
red.
Maximum steam volume
Reduced steam volume
No steam - child lock
Note
In this position, the steam lever cannot
be operated.

(QJOLVK 
For constant steam output, the water has to be topped
up through the cover of the decalcification cartridge.
When topping up the water, the decalcification cartridge
remains secured in the device.
Note
The device is equipped with dry-run protection for the
pump. If the pump runs dry for a longer period, e.g. be-
cause the decalcification cartridge is not correctly in-
serted, the pump switches off and the red water
shortage indicator light flashes.
To be able to operate the device again, the device has
to be switched off and back on again. In the process,
you must make sure that the cartridge has been insert-
ed correctly and there is enough water in the water res-
ervoir.
1. Fill the water reservoir with a maximum of 1 l of tap
water through the cover of the decalcification car-
tridge.
The LED strip lights up in a constant green.
Interrupting operation
In order to save energy, we recommend that you switch
off the device for breaks in operation of longer than 20
minutes.
1. Press the On/Off switch.
Switching off the device
1. Press the On/Off switch.
Illustration J
The device has been switched off.
2. Press the steam lever until no more steam flows out.
Illustration K
The steam boiler is depressurised.
3. Move the child lock back.
The steam lever is locked.
4. Remove the mains plug from the socket.
ATTENTION
Device damage due to water putrefaction
If the device is not put into operation for more than 2
months, the water in the reservoir may putrefy.
Drain the water reservoir before breaks in operation.
5. Remove the decalcification cartridge from the de-
vice.
Illustration L
Storing the device
1. Hang the floor nozzle in the park bracket.
Illustration M
2. Connect the extension tubes to the large mounts for
accessories.
3. Connect a manual nozzle and spotlight nozzle to
each extension tube.
4. Wrap the cable and place it in the accessory storage
area.
5. Place the small round brush and power nozzle in the
accessory storage area.
6. Put the steam hose in the accessory storage area.
Illustration N
7. Store the device in a dry location that is protected
from frost.
Important application instructions
Cleaning the floor areas
We recommend sweeping the floor or vacuum cleaning
it before using the appliance. In this way the floor will be
cleared of dirt and loose particles before the wet clean-
ing.
Freshening up textiles
Prior to using the appliance, always check the compati-
bility of the textiles at a concealed point: Steam down
the textile, allow it to dry and then check it for any
change in colour or shape.
Cleaning coated or painted surfaces
ATTENTION
Damaged surfaces
Steam can loosen wax, furniture polish, plastic coatings
or paint and edge band from edges.
Do not direct the steam at glued laminated edges as the
edge band may loosen.
Do not use the appliance for cleaning unsealed wood or
parquet floors.
Do not use the appliance for cleaning painted or plastic
coated surfaces such as kitchen or living room furniture,
doors or parquet.
1. To clean these surfaces, steam a cloth briefly and
use it to wipe over the surfaces.
Glass cleaner
ATTENTION
Glass breakages and damaged surfaces
Steam can damage sealed points of the window frame
and, at low outside temperatures, lead to tension on the
surface of window panes and hence to glass breakages.
Do not direct the steam at sealed points on the window
frame.
At low outside temperatures, heat up the window panes
by gently steaming the full surface of the glass.
zClean the window area with a manual nozzle and
cover. To remove the water, use a squeegee or wipe
the surfaces dry.
How to use the Accessories
Steam gun
The steam gun can be used for the following applica-
tions without accessories:
ƔFor removing slight creases from the hanging cloth-
ing items: Steam the clothing item from a distance of
10-20 cm.
ƔFor wiping damp dust: Steam a cloth briefly and use
it to wipe over the furniture.
Spotlight nozzle
The spotlight nozzle is suitable for cleaning areas, joins,
fittings, drains, sinks, WCs, blinds or radiators that are
difficult to access. The closer the spotlight nozzle is to
the soiled area, the greater the cleaning efficiency will
be as the temperature and steam volume are at their
highest at the nozzle opening. Larger lime deposits can
be treated before steam cleaning with a suitable deter-
gent. Allow the detergent to soak in for
approx. 5 minutes and then steam it off.
1. Slide the spotlight nozzle onto the steam gun.
Illustration C
Round brush (small)
The small round brush is used for cleaning stubborn dirt.
Stubborn dirt can be removed more easily by brushing.
ATTENTION
Damaged surfaces
The brush may scratch sensitive surfaces.
It is not suitable for cleaning sensitive surfaces.
1. Fit the round brush to the spotlight nozzle.
Illustration D

 (QJOLVK
Round brush (large)
The large round brush is suitable for cleaning large
rounded surfaces, e.g. wash basin, shower tray, bath
tub, kitchen sink.
ATTENTION
Damaged surfaces
The brush may scratch sensitive surfaces.
It is not suitable for cleaning sensitive surfaces.
1. Fit the large round brush to the spotlight nozzle.
Illustration D
Power nozzle
The power nozzle is used for cleaning dirt and for blow-
ing down corners, on joints, etc.
1. Install the power nozzle onto the spotlight nozzle as
suitable for the round brush.
Illustration D
Crevice brush
1. The crevice brush is used for cleaning narrow gaps
e.g. window recess and cranks in the walls.
Illustration D
Manual nozzle
The manual nozzle is used for cleaning small areas that
can be washed down, shower cubicles and mirrors.
1. Push the manual nozzle onto the steam gun accord-
ing to the spotlight nozzle.
Illustration C
2. Pull the cover over the manual nozzle.
Floor nozzle
The floor nozzle is used for cleaning washable wall and
floor coverings e.g. stone floors, tiles and PVC floors.
ATTENTION
Damage due to build-up of steam
Heat and moisture can lead to damage.
Check the heat resistance and steam effect on an in-
conspicuous area using a minimal volume of steam pri-
or to use.
Note
Detergent residue or care emulsions on the surface to
be cleaned can lead to streaks during steam cleaning,
which will disappear however once these have been
used several times.
We recommend sweeping the floor or vacuum cleaning
it before using the device. In this way the floor will be
cleared of dirt and loose particles before the wet clean-
ing commences. Work slowly on surfaces that are heav-
ily soiled so that the steam has longer to take effect.
1. Connect the extension tubes with the steam gun.
Illustration E
2. Push the floor nozzle onto the extension tube.
Illustration F
3. Fasten the floor cleaning cloth to the floor nozzle.
a Place the floor cleaning cloth with the hook and
loop fastener strips pointing upwards on the floor.
b Place the floor nozzle onto the floor cleaning
cloth, applying slight pressure.
Illustration O
The floor cleaning cloth will stick to the floor nozzle
of its own accord due to the hook and loop fastener.
Removing the floor cleaning cloth
1. Place one foot on the bottom corner of the floor
cleaning cloth and lift the floor nozzle up.
Illustration O
Note
Initially, the floor cleaning cloth's hook and loop fastener
strip is very strong and cannot be removed from the
floor nozzle easily. After the floor cleaning cloth has
been used several times and washed, it is easier to re-
move from the floor nozzle and it has reached the opti-
mum adhesion.
Parking the floor nozzle
1. Hang the floor nozzle in the park bracket during
breaks in work.
Illustration M
Carpet glider
The carpet glider is used for freshening up carpets.
ATTENTION
Beware of damaging the carpet glider and carpet
Contamination on the carpet glider, as well as heat and
moisture penetration, can result in the carpet being
damaged.
Prior to the application, also check the heat resistance
and impact of steam on the carpet at an insignificant
spot using as small an amount of steam as possible.
Observe the cleaning instructions from the carpet man-
ufacturer.
Prior to using the carpet glider, make sure that the car-
pet has been vacuumed and that stains have been re-
moved.
Prior to application and following operating pauses, re-
move any possible water accumulation (condensate) in
the appliance by means of evaporating the condensate
into a drain (without floor cleaning cloth / with accesso-
ries).
Only use the carpet glider with a floor cleaning cloth on
the floor nozzle.
Steam clean with a weak steam stage when using the
carpet glider.
In order to prevent too much moistening and to avoid
the risk of damage due to temperature effects, do not di-
rect the steam continuously onto one spot (maximum
5 seconds).
Do not use the carpet glider on deep-pile carpets.
Fastening the carpet glider to the floor nozzle
1. For fastening the floor cleaning cloth to the floor
nozzle, please refer to chapter Floor nozzle.
Illustration O
2. Using a little force, allow the floor nozzle to slide into
the carpet glider and engage there.
Illustration P
3. Start cleaning the carpet.
Removing the carpet glider from the floor nozzle
CAUTION
Beware of burns to your feet
The carpet glider can heat up during the steaming pro-
cess.
Do not operate or remove the carpet glider bare-footed
or using open sandals.
Only operate or remove the carpet glider using suitable
footwear.
1. Press the strap on the carpet glider downwards us-
ing your toecap.
2. Lift the floor nozzle upwards.
Illustration P

(QJOLVK 
Care and service
Draining the water reservoir
ATTENTION
Device damage due to water putrefaction
If the device is not put into operation for more than 2
months, the water in the reservoir may putrefy.
Drain the water reservoir before breaks in operation.
1. Press the On/Off switch.
The device has been switched off.
2. Pull the mains plug out of the socket.
3. Remove the accessories from the accessory hold-
ers.
4. Remove the decalcification cartridge from the de-
vice.
5. Drain the water reservoir.
Illustration Q
Replacing the decalcification cartridge
ATTENTION
Device damage and shortened service life
If the replacement intervals (indicator light) for the de-
calcification cartridge are not observed, there is a risk of
device damage and the service life of the device may be
shortened.
Observe the replacement intervals (indicator light).
Note
The replacement intervals depends on the local water
hardness. Areas with hard water (e.g. III/IV) have a
higher replacement interval than areas with soft water
(e.g. I/II).
Indicator lamp at end of the run time
The "decalcification cartridge indicator light " indicates
when the decalcification cartridge has to be replaced:
ƔThe indicator light flashes 2 hours before the run
time expires.
ƔThe indicator light flashes more quickly 1 hour be-
fore the run time expires.
ƔOnce the run time for the decalcification cartridge
has expired, the indicator light and the LED strip
light lights up in continuously red and the pump
switches off automatically in order to prevent device
damage.
Inserting the decalcification cartridge
ATTENTION
Device damage
There is a risk of damage to the device if the used de-
calcification cartridge is re-used.
Work carefully in order to prevent mixing up the cartridg-
es.
Note
When steaming for the first time after removing and re-
inserting the decalcification cartridge, the steam jet may
be weak or irregular, and individual drops of water may
be expelled. The device requires a short running-in pe-
riod in which the decalcification cartridge fills with water.
The steam volume that is expelled increases constantly
until the maximum steam volume has been reached af-
ter approx. 30 seconds.
1. Press the Off switch.
The device has been switched off.
2. Remove the decalcification cartridge.
3. Insert the new decalcification cartridge.
4. Press the On switch.
The device is switched on.
5. Press and hold the Maximum steam volume and
Reduced steam volume buttons at the same time
until the "Replace decalcification cartridge" goes
out. This means that the reset is complete.
6. Allow the device to heat up.
7. Press and hold the steam lever for approx. 30 sec-
onds to vent the decalcification cartridge.
Setting the water hardness
ATTENTION
Device damage due to calcification
Without a decalcification cartridge, the device may cal-
cify if the water hardness is set incorrectly.
Always work with a decalcification cartridge.
Set the device to the local water hardness.
Set the device to the current water hardness before us-
ing it in an area with a different water hardness (e.g. af-
ter a move).
Note
Your water board or municipal utilities authority can pro-
vide information on hardness of tap water.
The water hardness setting is stored until a new setting
(e.g. after a move) is made. The device is set to the
highest water hardness (level IV) in the factory. The de-
vice indicates the set water hardness with flash pulses.
Water hardness levels and flash pulses
Note
The anti-calcification effect of the decalcification car-
tridge is activated as soon as the device is filled with wa-
ter and put into operation. Lime in the water is absorbed
by the granulate in the decalcification cartridge. Addi-
tional descaling is not required.
Note
The granulate in the cartridge can discolour on contact
with water due to the mineral content in the water, which
is no cause for concern and has no negative effects on
the device, cleaning work or the functionality of the car-
tridge.
Note
Do not pause for longer than 15 seconds when setting
as the device will otherwise be set automatically to the
last selected water hardness or the highest water hard-
ness set during initial start-up.
1. Make sure that the device is switched off.
2. Press the ON/OFF button and hold it for 6 seconds.
Illustration R
3. The decalcification cartridge indicator light flashes
and signals the current water hardness setting with
the number of pulses.
4. Press the Reduced steam volume button repeatedly
to set the lower water hardness level.
5. Press the Maximum steam volume button repeated-
ly to set the higher water hardness level.
6. Release the Reduced/Maximum steam volume but-
ton.
Hardness
range
°dH mmol/l Number
of flash
pulses
Interval
between
flash
pulses
I Soft 0-7 0-1.3 1x 4 seconds
II Medium 7-14 1.3-2.5 2x
III Hard 14-21 2.5-3.8 3x
IV Very
hard
>21 >3.8 4x

The flash pulse for the set water hardness is indicat-
ed.
7. Repeat the process as necessary until the desired
water hardness level has been achieved.
Note
When the steam volume is pressed, the flash pulse for
the water hardness level is not indicated.
8. Press and hold the ON/OFF button for 4 seconds to
save the setting for the water hardness level. The
decalcification cartridge indicator light lights up.
Care of accessories
(Accessories - depending on scope of delivery)
Note
The micro fibre cloths are not suitable for dryer.
Note
When washing the cloths, observe the instructions on
the washing tag. Do not use any liquid softeners as this
will affect the ability of the cloths to pick up dirt.
1. Wash the floor cleaning cloths and covers at a max.
temperature of 60 °C in the washing machine.
Troubleshooting guide
Malfunctions often have simple causes that you can
remedy yourself using the following overview. When in
doubt, or in the case of malfunctions not mentioned
here, please contact your authorised Customer Service.
WARNING
Risk of electric shock and burns
Trying to eliminate faults while the appliance is connect-
ed to the mains or has not yet cooled down is always
dangerous.
Remove the mains plug.
Allow the appliance to cool down.
The LED strip flashes red
The dry-run protection for the pump is activated.
1. Switch the device off and back on again.
2. Make sure that the decalcification cartridge has
been inserted correctly and there is sufficient water
in the reservoir.
No water in the water reservoir.
1. Top up the water reservoir, see chapter Topping up
the water.
The steam lever cannot be pressed
The steam lever is locked with the child lock.
Move the child lock forward.
The steam lever is released.
No / little steam although there is water in the reser-
voir
The decalcification cartridge has not been inserted or
has been inserted incorrectly.
Insert the decalcification cartridge or insert it cor-
rectly.
The decalcification cartridge has been removed while
topping up the water.
Leave the decalcification cartridge in the device
when topping up.
New decalcification cartridge has been inserted.
Press and hold the steam lever continuously.
The full steam output is reached after approximately
30 seconds.
Red “Replace decalcification cartridge” indicator
light lights up / flashes
The run time of the decalcification cartridge ends early.
Insert the new decalcification cartridge and reset the
maintenance indicator, see chapter Replacing the
decalcification cartridge.
The maintenance indicator was not reset after replace-
ment of the decalcification cartridge.
Press and hold the Maximum steam volume and
Reduced steam volume buttons at the same time
until the “Replace decalcification cartridge” indicator
light goes out after inserting the decalcification car-
tridge, see chapter Replacing the decalcification
cartridge.
The LED strip is in constantly red and no steam al-
though there is water in the reservoir
Run time for the decalcification cartridge has expired
Insert the new decalcification cartridge and reset the
maintenance indicator, see chapter Replacing the
decalcification cartridge.
The maintenance indicator is not reset after replace-
ment of the decalcification cartridge.
Press and hold the Maximum steam volume and
Reduced steam volume buttons at the same time
until the indicator light of "Replace decalcification
cartridge" goes out after inserting the decalcification
cartridge, see chapter Replacing the decalcification
cartridge.
Technical data
Subject to technical modifications.
SC 3 De-
luxe
EasyFix
Premi-
um
Electrical connection
Voltage V 220 -
240
Phase ~
Frequency Hz 50 - 60
Protection class IPX4
Protection category I
Performance data
Heating capacity W
Maximum operating pres-
sure
MPa
Heating-up time Sec-
onds
Continuous steaming g/min
Maximum steam blast g/min
Filling quantity
Water reservoirl
Dimensions and weights
Weight (without accesso-
ries)
kg
Length mm
Width mm
Height mm
1
1900
0.35
30
40
100
1.0
3.3
361
250
282

(QJOLVK 

advantages.
vielen Vorteilen.
avantages.
Registre su producto y aproveche de muchas ventajas.
Bewerten Sie Ihr Produkt und sagen Sie uns Ihre Meinung.
Rate your product and tell us your opinion.
Évaluer votre produit et dites-nous votre opinion.
Reseñe su producto y díganos su opinión.
www.kaercher.com/welcome
www.kaercher.com/dealersearch
Alfred Kärcher SE & Co. KG
Alfred-Kärcher-Str. 28-40
71364 Winnenden (Germany)
Tel.: [phone]
Fax: [phone]
DANKE!
THANK YOU!
MERCI! GRACIAS!
!
