Kaco blueplanet 50.0TL3-R User manual

Operating Instruction
nEnglish translation of German original
KACO blueplanet 50.0TL3-
R
These instructions form part of the product and must be carefully read, observed and stored in a place which is freely accessible at all
times.
Authorised electrician
Important safety instructions
RPonly

Legal provisions
The information contained in this document is the property of KACO new energy GmbH. Publication, in whole
or in part, requires the written permission of KACO new energy GmbH.
KACO warranty
For current warranty conditions contact your system integrator. http://www.kaco-newenergy.com
Definitions on product designations
In these operating instructions, the product "blueplanet" is referred to as "device" for ease of reading.
Trademarks
All trademarks are recognised, even if not explicitly identified as such. A lack of identification does not mean
that a product or designation/logo is free of trademarks.
| Legal provisions Operating Instruction
KACO blueplanet 50.0TL3-R
Page 2
EN

Table of contents
1 General information ........................................... 4
1.1 About this document .................................... 4
1.2 More information ......................................... 4
1.3 Layout of Instructions ................................... 4
1.4 Identification................................................. 5
1.5 Warnings on the device ................................ 6
1.6 Target group ................................................. 6
2 Safety ................................................................. 7
2.1 Proper use..................................................... 7
2.2 Protection features....................................... 8
2.3 Functional restrictions .................................. 8
3 Description of the device .................................... 9
3.1 Mode of operation........................................ 9
3.2 Device diagram ............................................. 9
3.3 System layout ............................................... 10
4 Technical data .................................................... 12
4.1 Electrical data ............................................... 12
4.2 General data ................................................. 13
4.3 Environmental data ...................................... 13
5 Transportation and Delivery ............................... 14
5.1 Scope of delivery........................................... 14
5.2 Transporting the device ................................ 14
5.3 Installation tool............................................. 14
6 Assembly and preparation.................................. 15
6.1 Choosing the installation location ................ 15
6.2 Unpacking the device.................................... 16
6.3 Fastening the mount..................................... 16
6.4 Installing and securing the device................. 17
7 Installation ......................................................... 20
7.1 General information ..................................... 20
7.2 Making the electrical connection ................. 20
7.3 Connecting the device to the power grid ..... 20
7.4 Creating equipotential bonding .................... 22
7.5 Connecting the interfaces............................. 22
7.6 Sealing the connection area ......................... 25
7.7 Reading out the reactive power supply ........ 26
7.8 Application - only reactive power supply -
RPO mode .....................................................
27
8 Commissioning ................................................... 28
8.1 Requirements ................................................ 28
9 Configuration and operation................................ 29
9.1 Initial start-up ................................................ 29
9.2 Controls ......................................................... 29
9.3 Quick configuration ....................................... 31
9.4 Menu structure.............................................. 35
9.5 Monitoring the device ................................... 44
9.6 Performing a firmware update ...................... 45
9.7 Access via Modbus......................................... 46
10 Specifications....................................................... 47
10.1 Reactive power control.................................. 47
11 Maintenance and troubleshooting....................... 49
11.1 Visual inspection............................................ 49
11.2 Cleaning ......................................................... 49
11.3 Replacing the fan ........................................... 50
11.4 Shutting down for maintenance /
troubleshooting .............................................
51
11.5 Faults ............................................................. 51
11.6 Fault messages............................................... 52
12 Decommissioning and dismantling....................... 53
12.1 Switching off the device ................................ 53
12.2 Disconnecting connections............................ 53
12.3 Uninstalling the device .................................. 53
12.4 Disassembling the device............................... 53
12.5 Packaging the device ..................................... 53
12.6 Storing the device.......................................... 54
13 Disposal............................................................... 55
14 Service and warranty ........................................... 56
15 Appendix ............................................................. 57
15.1 EU Declaration of Conformity........................ 57
Operating Instruction Table of contents
blueplanet 50.0TL3-RPO_en iii
Reactive power compensation unit
EN

1 General information
1.1 About this document
WARNING
Improper handling of the device can be hazardous!
1. You must read and understand the operating instructions in order to install and use the device safely!
Other applicable documents
During installation, observe all assembly and installation instructions for components and other parts of the system.
These instructions also apply to the equipment, related components and other parts of the system.
Storing the documents
These instructions and other documents must be stored near the system and be available at all times.
– The current version of the operating Instructions can be downloaded from www.kaco-newenergy.com.
English translation of German original
This document has been produced in several languages. The German-language version is the original version. All other
language versions are translations of the original version.
This document is valid for the following types of device from firmware version V5.63 onwards
Modules [KACO art. no.] KACO blueplanet 50.0 TL3 M1 WM OD IIGR [ 1001601 ]
1.2 More information
Links to more detailed information can be found at www.kaco-newenergy.com
Document title Document type
Technical data sheet Product flyer
Remote access via web interface Application note - operation
Modbus protocol
RS485 protocol reactive power control
Application note
SunSpec Information Model Reference
SunSpec Information Model Reference KACO
Excel files for software version with application note “Mod-
bus protocol” under https://kaco-newenergy.com/down-
loads/
Software package Files for current software
EU Declaration of Conformity
Country-specific certificates
Certification for specific subassembly
Certificates
1.3 Layout of Instructions
1.3.1 Symbols used
General hazard Fire and risk of explosion
Electrical voltage Risk of burns
Earthing - ground conductor
1 | General information Operating Instruction
KACO blueplanet 50.0TL3-R
Page 4
EN

1.3.2 Safety warnings symbols guide
DANGER
High risk
Failure to observe this warning will lead directly to serious bodily injury or death.
WARNING
Potential risk
Failure to observe this warning may lead to serious bodily injury or death.
CAUTION
Low-risk hazard
Failure to observe this warning will lead to minor or moderate bodily injury.
CAUTION
Risk of damage to property
Failure to observe this warning will lead to property damage.
1.3.3 Additional information symbols
NOTE
Useful information and notes
Information that is important for a specific topic or objective, but that is not safety-relevant.
1.3.4 Symbols for instructions
↻Prerequisite for use
1. Carry out the next step
2. Additional action sequence
ðInterim result of the action
ðEnd result
1.4 Identification
You will find the name plate with the following data for service and other require-
ments specific to installation on the right side panel of the product:
– Product name
– Part no.
– Serial number
– Date of manufacture
– Technical data
– Disposal information
– Certification marking, CE marking.
KACO new energy
Carl-Zeiss-Straße 1
74172 Neckarsulm
Made in Germany
KACO blueplanet 50.0 TL3 M1 WM OD IIGR
Part number 1001601
Serial number 50.0TL01XXXXXX Year Q4 / 19
Input Vmax PV / lsc PV (max) / Inom PV NA - RPO Mode
V-MPP at Pnom / V- range NA - RPO Mode
Output
Nominal voltage
220 V / 380 V (3/N/PE)
230 V / 400 V (3/N/PE)
240 V / 415 V (3/N/PE)
Voltage range continuous operation 176 V - 276 V (Ph-N)
Current (maximum continuous) 3 x 76,5 A
Frequency range 42 Hz - 68 Hz
Output
Power
Rated power 50 000 var
Reactive power cos phi 0-100% Snom 0 ind/cap
Environ-
ment Temperature range - 20°C ... + 60°C
Protection class / Ingress protection I / IP65
ARC fault circuit protection none
Interface protection according to country
specific requirements, details see manual
No galvanic separation / UTILITY-INTERCONNECTED
Fig.1: Name plate
Operating Instruction General information | 1
KACO blueplanet 50.0TL3-R Page 5
EN

1.5 Warnings on the device
A warning sticker is affixed to the device. Read the warnings carefully.
Do not remove the sticker. If the sticker is missing or is illegible, please contact a
KACO representative or distributor.
– Article number: 3009476
Fig.2: Warning sticker
1.6 Target group
All activities described in the document may only be carried out by specially trained personnel with the follow-
ing qualifications:
– Knowledge about how an inverter functions and operates
– Knowledge about how a reactive power compensation unit functions and operates.
– Knowledge of the Modbus specifications
– Knowledge of the SunSpec Modbus specifications
– Training in the handling of hazards and risks during the installation and operation of electrical devices and
systems.
– Education concerning the installation and start-up of electrical units and plants.
– Knowledge of applicable standards and directives.
– Knowledge and adherence to this document with all safety notices.
1 | General information Operating Instruction
KACO blueplanet 50.0TL3-R
Page 6
EN

2 Safety
DANGER
Lethal voltages are still present in the connections and cables of the device even after the device
has been switched off and disconnected!
Severe injuries or death may occur if the cables and/or terminals/busbars in the device are touched.
üOnly appropriately qualified and authorised electricians are permitted to open and uninstall the device.
üComply with all safety regulations and current technical connection specifications of the responsible power
supply company.
1. Switch off the grid voltage by turning off the external circuit breakers.
2. Secure the device against reconnection.
The electrician is responsible for observing all existing standards and regulations. The following applies:
– Keep unauthorised persons away from the device and/or system.
– Ensure operational safety by providing proper grounding, conductor dimensioning and appropriate protection against
short circuiting.
– Observe all safety instructions on the product and in these operating instructions.
– Switch off all voltage sources and secure them against being inadvertently switched back on before performing visual
inspections and maintenance.
– When taking measurements on the live device:
– Do not touch the electrical connections
– Remove all jewellery from wrists and fingers
– Ensure that the testing equipment is in safe operating condition.
– Modifications to the surroundings of the device must comply with the applicable national and local standards.
2.1 Proper use
The RPO device is designed exclusively for the reactive power compensation. During this period, the device is
activated by a control system.
The device is built using state-of-the-art technology and in accordance with the recognized safety rules. Never-
theless, improper use may cause lethal hazards for the operator or third parties, or may result in damage to the
product and other property.
The device is intended for indoor and outdoor applications and may only be used in countries for which it has
been approved or for which it has been released by KACO new energy and the grid operator. 1
Operate the device only with a permanent connection to the public power grid. The country and grid type se-
lection must be commensurate with the respective location and grid type.
The requirements of the grid operator must be met for grid connection to take place. The permission of the rel-
evant authorities may also be required in order to secure authorisation to connection to the grid.
The name plate must be permanently attached to the product and must be in legible condition.
NOTE:In addition to the parametrised preset data, it is also possible to apply a static setting.
Any other or additional use is not considered proper or intended use and can lead to an annulment of the
product guarantee. This includes:
– Use of a distribution system that is not described (grid type)
– Mobile use
– Use in rooms where there is a risk of explosion
– Use in direct sunlight, rain or a storm or other harsh environmental conditions
– Outdoor use in environmental conditions that exceed the limits stated in the technical specifications > [See
section4.3}Page13].
1
Operating Instruction Safety | 2
KACO blueplanet 50.0TL3-R Page 7
EN

– Operation outside the specification intended by the manufacturer
– Device modification
– Standalone mode
2.2 Protection features
The following monitoring and protection functions are integrated in the device:
– RCMU (Residual Current Monitoring Unit)
– Device temperature monitoring system
– EMC filter to protect the inverter from high-frequency grid interference
– Grid-side varistors grounded to earth to protect the product against burst and surge pulses
– Anti-islanding detection according to the current standards.
2.3 Functional restrictions
Note the following device-specific restrictions:
– It is not possible to connect PV modules or strings to the device.
– The device must not receive broadcast commands from the controller of the PV inverter. This device
should only receive commands from an external controller/regulator (control system/SCADA)- RPO react-
ive power requirements.
– For reliable operation, an automatic re-start of the device will take place regularly (on Sunday 12:00
o'clock).
2 | Safety Operating Instruction
KACO blueplanet 50.0TL3-R
Page 8
EN

3 Description of the device
3.1 Mode of operation
The device has been developed specifically for the provision of reactive power.
To implement reactive power control at the grid connection point, the control system reads the measured re-
active power at the grid connection point.
If the actual value is different to a specified value, additional reactive power can be ordered from this device, in
this way the reactive power at the grid connection point can be compensated or the device operates according
to static specifications.
3.2 Device diagram
3
5
6
1
2
4
7
Fig.3: Device diagram
1 Housing 5 Interfaces / cable feed-through
2 Housing door 6 Communication - USB port / cable feed-
through
3 Status indicator with display and operator
panel
7 AC connection / cable feed-through
4 Mount with fan
3.2.1 Interfaces
You can configure the interfaces and the web server in the Settings menu. The device has the following inter-
faces for communication and remote monitoring.
Ethernet interface
The Ethernet interface can be used by a connected control system for reactive power specification on RPO
devices.
The local web server can be used to configure the device and perform updates.
RS485 interface
The RS485 interface can be used by a connected control system for reactive power specification on RPO
devices.
USB interface
The USB connection of the device is a type A socket. It is located on the communication circuit board. The USB
connection is specified to draw 500 mA of current.
Operating Instruction Description of the device | 3
KACO blueplanet 50.0TL3-R Page 9
EN

Use the USB interface to read out stored operating data, load software updates or device configurations using a
FAT32-formatted USB stick.
3.3 System layout
3.3.1 Use with a PV system
Modbus/
TCP
Status
Modbus/
TCP
Modbus/
TCP
Modbus/
TCP
1
2
3
4
5
6
7
Default Q
RPO-Gerät
Fig.4: System overview - control via Modbus TCP
RS485
RS485
RS485 RS485 RS485 RS485
RS485
RS485
Status
RS485
Set value Q
RPonly
Actual value Q
12
3
4
5
6
7
Fig.5: System overview - control via RS485
1 PV generator with inverter 5 Measurement equipment
2 RPO device 6 Medium-voltage transformer
3 Power distribution 7 Grid connection point
4 Control system - centralised/decentralised system
for monitoring the system, visualisation, control
and regulation
3 | Description of the device Operating Instruction
KACO blueplanet 50.0TL3-R
Page 10
EN

3.3.2 Use without a PV system
Modbus/
TCP
Modbus/
TCP
Measured
Values
Status
Set Value
Status
RPOnly
5
4
2
3Grid
Fig.6: System overview - control via Modbus without a PV system
Digital I/O
to Modbus
Grid
Status
Set Value
RPOnly
Measured
Values
Modbus
/ Sunspec 4 Din
2
3
4
5
Fig.7: System overview - control via digital IO
1 Data logger 4 Control system - centralised/decentralised system
for monitoring the system, visualisation, control
and regulation
2 RPO device 5 Measurement equipment
3 AC sub-distribution
Operating Instruction Description of the device | 3
KACO blueplanet 50.0TL3-R Page 11
EN

4 Technical data
4.1 Electrical data
Output levels
Rated power @ rated voltage in Volts 50.0 kvar [@220V];
50.0 kvar [@230V];
50.0 kvar [@240V]
Rated voltage 240 / 415 V [3/N/PE];
230 / 400 V [3/N/PE];
220 / 380 V [3/N/PE]
Voltage range: continuous operation 176 V - 276 V (Ph-N);
305 V - 480 V (Ph-Ph)
Rated current 3x 69.6 A [@415V];
3x 72.2 A [@400V];
3x 76.0 A [@380V]
Max. continuous current 3 x 76.5 A
Contribution to peak short-circuit current
(îp)
136.11 A
Initial short-circuit alternating current (Ik"
first single period effective value)
77.93 A
Inrush current 1.21 A [RMS (20ms)]
Rated frequency / Frequency range / 50/60 Hz / 42 - 68 Hz
Reactive power 0-100 % Snom
cos phi range 0
Number of feed-in phases 3
Distortion factor (THD) < 1,6 %
Max. voltage range (up to 100 s) 520V [Ph-Ph]
AC overvoltage protection no
General electrical data
Max. efficiency 98.5 %
European efficiency 98.1 %
Transformer unit no
Protection class/overvoltage category I / III (AC)
Grid monitoring Country-specific
Distribution system TN-C-System, TN-C-S-System, TN-S-System, TT-System
4 | Technical data Operating Instruction
KACO blueplanet 50.0TL3-R
Page 12
EN

4.2 General data
General data
Display Graphical display 240 x 128 pixels + LEDs
Controls / management 4-way button + 2 buttons
Menu language DE; EN; FR; IT; ES; PL; NL; PT; CZ; HU; SL; TR; RO
Interfaces 2 x Ethernet, USB, RS485, 4 optional digital inputs/outputs, error relay (30V
potential free contact); 4-DI
Potential-free relay no
DC switch / AC switch no / no
Cooling temp. controlled fan
Number of fans 2
Noise emission 61 db(A)
Housing material Alu
H x W x D 760 mm x 500 mm x 425 mm
Weight 71 kg
Certification No special country-specific approvals because no PV device - CE declaration
in appendix
4.3 Environmental data
Environmental conditions
Max. installation height 3000m (derating from 2000m)
Installation distance from coast >2,000 m
Ambient temperature from -20 °C to +60 °C
Power derating from +50 °C
Protection rating (KACO installation loca-
tion)
IP65
Relative humidity, non-condensing (in op-
eration)
100 %
Pollution degree inside the enclusure 2
Pollution degree outside the enclusure 3
Item number 1001601
Name on nameplate KACO blueplanet 50.0 TL3 M1 WM OD IIGR
Operating Instruction Technical data | 4
KACO blueplanet 50.0TL3-R Page 13
EN

5 Transportation and Delivery
Every product leaves our factory in perfect electrical and mechanical condition. Special packaging ensures that
the devices are transported safely. The shipping company is responsible for any transport damage that occurs.
5.1 Scope of delivery
– Reactive power compensation unit
– Mount
– Mounting kit + 1 insulating tube (for interface cables)
– Manual [manual]
Check the equipment included
1. Inspect the device thoroughly.
2. Immediately notify the shipping company in case of the following:
– Damage to the packaging that indicates that the device may have been damaged.
– Obvious damage to the device.
3. Send a damage report to the shipping company immediately.
4. The damage report must be received by the shipping company in writing within six days following receipt
of the device. We will be glad to help you if necessary.
5.2 Transporting the device
CAUTION
Hazard due to impact; risk of breakage to the device!
1. Pack the device securely for transport.
2. Transport the device using the intended carrying handles of the packaging box.
3. Do not expose the device to any shocks.
For safe transportation of the product, use the hand recesses in the carton.
Packaging Folding cardboard box
Height x width x depth 818x591x537 mm
Total weight 79 kg
Fig.8: Transporting the device
5.3 Installation tool
The codes given in the table below are used in all usage instructions for assembly/installation/maintenance and
disassembly for the tools and tightening torques being used.
Code (s) Shape of the
connector
W External hexagon
A Internal hexagon
T Torx
S Slot
Tab.1: Key and description of tool codes
Outer contour
Tightening torque
Spanner size or number
Nm
Fig.9: Form pattern
5 | Transportation and Delivery Operating Instruction
KACO blueplanet 50.0TL3-R
Page 14
EN

6 Assembly and preparation
6.1 Choosing the installation location
DANGER
Risk of fatal injury due to fire or explosions!
Fire caused by flammable or explosive materials in the vicinity of the device can lead to serious injuries.
1. Do not mount the inverter in potentially explosive atmospheres or in the vicinity of highly flammable ma-
terials.
CAUTION
Property damage due to gases that have an abrasive effect on surfaces when they come into contact with
ambient humidity caused by weather conditions.
The device housing can be seriously damaged due to gases in combination with air humidity resulting from weather con-
ditions (e.g. ammonia, sulphur).
1. If the device is exposed to gases, the installation must be carried out at observable locations.
2. Perform regular visual inspections.
3. Immediately remove any moisture from the housing.
4. Ensure adequate ventilation at the installation location.
5. Immediately remove dirt, especially on vents.
6. Failure to observe these warnings may lead to device damage which is not covered by the manufacturer warranty.
NOTE
Access by maintenance personnel for service
Any additional costs arising from unfavourable structural or installation conditions will be billed to the cus-
tomer
Installation space
– As dry as possible, climate-controlled, the waste heat must be dissipated away from the device.
– Unobstructed air circulation.
– Close to the ground, accessible from the front and sides without requiring additional resources.
– Protected on all sides against direct weather exposure and sunlight (thermal heating) in outdoor areas. Implementa-
tion where necessary via constructional measures, e.g. wind breaks.
– For easy operation during installation, ensure that the display is slightly below eye level.
Installation surface
– Must have adequate load-bearing capacity
– Must be accessible for installation and maintenance
– Must be made out of heat-resistant material (up to 90 °C )
– Must be flame resistant
– Minimum clearances to be observed during installation: [See figure 13 [}Page17]
Operating Instruction Assembly and preparation | 6
KACO blueplanet 50.0TL3-R Page 15
EN

6.2 Unpacking the device
CAUTION
Risk of injury caused by excessive physical strain
Lifting the device, for transport, relocation and assembly, can result in injuries (e.g. back injuries).
1. Only lift the device using the openings provided.
2. The device must be transported and installed by at least 2 persons.
DETAIL Z4:1
Z
2
1
3
4
5
6
Fig.10: Open the package Fig.11: Setting the device upright
Legend
1 Cover 4 Base
2 Side section - upper 5 Side section - lower
3 Clamp (4x) 6 Cardboard packaging with mount and mounting kit
↻The device is transported to the installation location.
1. Remove the plastic band from the pallet and packaging.
2. Pull the clamp off the packaging.
3. Pull the hood upwards to remove it and place the cardboard packaging to one side together with the mount and ac-
cessories.
4. Set the unit with base and side sections upright.
5. Remove the top side section and base from the device.
ðIf the unit is in the correct installation position: Proceed with the installation of the mount.
6.3 Fastening the mount
WARNING
Hazard when using unsuitable fixing materials!
If unsuitable fixing materials are used, the device could fall and persons in front of the device may be seriously
injured.
1. Use only fixing materials that are suitable for the mounting base. The fastening materials supplied are only
to be used for masonry and concrete.
2. Only install the device in an upright hanging position.
6 | Assembly and preparation Operating Instruction
KACO blueplanet 50.0TL3-R
Page 16
EN

1
2
3
4
5
6
7
111 mm
A
A
C
B
D
Fig.12: Minimum clearances for wall mounting
**
**
8
1
400 mm
250 mm
600 mm
1150 mm
Fig.13: Wall mounting
Key
1 Mount 5 Screw for securing purposes (1x)
2 Fixings for mounting [S12 – Ø 12mm/ 90mm] 6 Bracket to prevent device displacement
3 Lock washer 7 Marking as installation aid
4 Screws for mounting (5x) [SW 13 / [See sec-
tion6.3}Page16]]
8 Seating recess
A Minimum clearance: 120 mm (without device370
mm )
recommended distance400 mm (without device 550
mm *)
C Minimum clearance: 500 mm
B Minimum clearance: 300 mm D Recommended clearance: 550 mm
↻Cardboard packaging with mount and mounting kit removed from the packaging and opened.
1. Mark the mounting position on the wall surface according to the position of the mount by drawing a line.
2. Mark the positions of the drill holes using the slot in the mount.
.NOTE:The minimum clearances between two devices, or the device and the ceiling or floor have
already been taken into account in the diagram.
3. Fix the mount to the wall using suitable mounting fixtures from the mounting kit.
.NOTE:Make sure that the mount is oriented correctly.
ðProceed with the installation of the device.
6.4 Installing and securing the device
CAUTION
Risk of injury from improper lifting and transport.
If the device is lifted improperly, it can tilt and result in a fall.
1. Always lift the device vertically using the openings provided.
2. Use a climbing aid for the chosen installation height.
3. › Wear protective gloves and safety shoes when lifting and lowering the device.
Operating Instruction Assembly and preparation | 6
KACO blueplanet 50.0TL3-R Page 17
EN

NOTE
Power reduction due to heat accumulation!
If the recommended minimum clearances are not observed, the device may go into power regulation mode
due to insufficient ventilation and the resulting heat build-up.
1. › Observe minimum clearances and provide for sufficient heat dissipation.
2. All objects on the device housing must be removed during operation.
3. › Ensure that no foreign bodies prevent heat dissipation following device installation.
1
24
3
Fig.14: Lift the device using the opening
N
O
5
4
Fig.15: Insertion aid in mount
Key
1 Opening 4 Marking for insertion into mount
2 Centre of gravity 5 Outer contour of the mount
3 Warning sign (attachment prohibited)
Lifting and installing the unit
↻The mount has been installed.
1. Lift the device using the side recesses. Observe the device's centre of gravity!
.NOTE:Do not lift the device by the lid or cover!
2. Suspend the device in the mount using the recess on the rear of the device. ( [See figure 13 [}Page17]).
.NOTE:Keep in mind that the lower marking on the housing must protrude over the upper outer con-
tour of the mount. Ensure that the upper marking is flush with the upper edge of the outer contour
when lowering the device. The outer contour of the mount must be flush with the outer contour of
the housing.
3. Insert the screw provided into the lug of the mount and secure the device to prevent it from being lifted off [ T30 /
2 Nm]. ( [See figure 12 [}Page17]).
.NOTE:Alternatively: At this point, the screw described above can be replaced by a special screw as
anti-theft protection.
ðDevice is installed. Proceed with the electrical installation.
6 | Assembly and preparation Operating Instruction
KACO blueplanet 50.0TL3-R
Page 18
EN

CAUTION
Property damage as a result of condensation
During pre-assembly of the device, moisture can penetrate into the interior via the dust-protected threaded connections.
The resulting condensate can cause damage to the device during installation and start-up.
üKeep the device closed during pre-assembly and do not open the connection area until you perform installation.
1. Seal off the screw connections using sealing covers.
2. Prior to installation, check the inner area for condensation and if necessary, allow it to dry sufficiently before installa-
tion.
3. Immediately remove any moisture from the housing.
Operating Instruction Assembly and preparation | 6
KACO blueplanet 50.0TL3-R Page 19
EN

7 Installation
7.1 General information
7.2 Making the electrical connection
NOTE
Select conductor cross-section, safety type and safety value in accordance with the following basic
conditions:
Country-specific installation standards; power rating of the device; cable length; type of cable installation; local
temperature
7.2.1 Requirement for supply lines and fuse
AC-side
Max. conductor cross-section 95 mm² (AL or CU)
Max. cable cross-section (without wire sleeves) 95 mm²
Min. cable cross-section in accordance with local installation standards
Length of insulation to be stripped off 25 mm
Tightening torque 10 Nm
Connection type Screw terminal
Ground conductor connection M8
Ground conductor connection tightening torque 10 Nm
Fuse protection for installation provided by customer min. 100 A / max.125 A
Fitting for AC connection M63
Cable diameter for cable fitting 32 - 42 mm
Torque for cable fitting 20 Nm
7.3 Connecting the device to the power grid
7.3.1 Prepare the grid connection
TN-S-System, TN-C-S-System, TT-System
↻A connection cable with 5 wires is provided on the device.
↻Nominal grid voltage matches the VAC nom name plate details.
1. Unfasten the cable fitting for the AC connection [ W_68].
2. Remove the outer cladding of the AC cables.
3. Push an M8 cable lug onto the PE line.
4. Remove the cover of the AC filter using the 4 screws[ T_15].
5. Unscrew the screws on the contact bridge and remove the contact bridge[
_T20].
6. Insert the AC cables through the cable fitting into the connection area.
7. Strip the AC lines [approx. 25 mm].
ðMake the grid connection.
1
4
2
3
Fig.16: 5-core connection
1 Cover
2 Screws for contact bridge
3 Contact bridge
4 Earthing bolt
7 | Installation Operating Instruction
KACO blueplanet 50.0TL3-R
Page 20
EN
