KAEL DP01-72 User manual

Digital Protector
Voltage – Current
and
Frequency control
DP01-72
Phase Sequence Control
Under Voltage Protection
Unbalanced Voltage
Protection
Over Frequency
Protection
Under Frequency
Protection
TRUE RMS
Latch Function
VL1,VL2,VL3
VL12,VL23,VL13
IL1,IL2,IL3
Hz
Ge eral:
In three phase systems it measures RMS values of AC voltages
currents and system frequency sensitively. Using up direction button
(Select) phase-neutral voltages and phase-phase voltages monitor
sequentially.
DP01-72 has many features.
Those are;
- Phase Failure (seq)
- Phase Sequence (seq)
- Over Voltage Protection (o - U)
- Under Voltage Protection (u - U)
- Voltage Unbalance (asymmetry) Protection (u b)
- Over Current Protection (o - C)
- Under Current Protection (u - C)
- Current Unbalance (asymmetry) Protection (ubC)
- Over Frequency Protection (o - F)
- Under Frequency Protection (u - F)
When device is turn on if its adjusted voltages and frequency in its
interval and if phase sequence is correct relay switch on.
If any of error occurred ( except phase failure and phase sequence )
at the end of adjusted time relay switch off its contact. When system
return normal values at the end of time out relay switch on.
L1
L2
L3
Re
< t-1 t-1
Phase Failure: (u-U)
Before starting system it controls phase absence then if all phases
exits Normal LED turn on and relay contact switch on. In case of
missing of any L1 L2 L3 phases Normal LED turn off and relay
switch off its contact .In this case u-U warn appears on display.
VL1
Special Butto s:
L1 L2 L3
VL2
VL3
L1 L2 L3
VL12
L1 L2 L3
VL23
L1 L2 L3
VL13
Select: (Up direction)
when pressing continuously
screen displays frequency of
system. When button release
device continue to show voltage.
Reset:
If error case although disappeared
then device is not return to normal
latch-function occurred and it
makes locked device.
Or Lock-function (only for currents)
may be occured.
After checking error in system then
restart device with pushing reset
button.
IMPORTANT: L1 - N is device supply inputs. Thus the applied L1 – N
voltage must be rated voltage of system . Otherwise normal led makes
flash and the device switched off its output contact.
The measured frequency also must the frequency of the system.
Voltage U bala ced: (u b)
The phase-phase voltage unbalance limit can be adjusted
between(5% - 20%) . When it exceeds the adjusted limit the device
switched off its out contact at the end of t-1 delay. In this case u b
warn appears on the screen. For the returning normal state
asymmetry values should under 20% (hysteresis value). In this case
at the end of t3 time Normal LED turned on and output contact switch
on. If the phase-phase voltage unbalance return adjusted value
shorter than t-1 time output relay does not release its contact.
Hysteresis is 20 %.
u b = 000(oFF) protection is disable .
Example: Let's say that asymmetry value is set to %15 for a
3 x 380VAC.
In this case relay contact switch off at (380-(380x0.15))=323 V.
Switch on the contact is performed at 323+(380x%15x%20)= 334V.
(%20 is the hysteresis).
Re
L1 L2 L3 L2 L3
L1
L2
L3
Phase Sequetio : (Seq)
In case of wrong phase order Normal LED turned off and relay
contact is not switch on. In this case seq warn appears on the
screen. If phase order is corrected Normal LED turned on and out
relay switch on.
hys
+ % unb
Vnom
hys
Level
Re
- % unb
t-1 < t-1 t-1
L1 L3 L2L1 L2 L3
r-t r-t
Over Voltage Protection
Under Current Protection
Unbalanced Current
Protection
Over Current Protection
L1 L2 L3
L1 L2 L3
Display Fu ctio s:
(Vmax - Vmin)
% unb = x 100 Hys = 380 x (% Asm) x (% 20)
380
AREAS OF OPERATION:
■ In-Elevator motors protection
■ On-pump and electric motor
■ Resistance in oven with
®

V
Re t
t
t-1
(o-U)
(u-U)
r-t t-1 r-t
Umax
Umin
Under Voltage
Over Voltage L1 L2 L3
Normal
Normal
Over a d U der Voltage : (o-U),(u-U)
Under voltage (u-U) it can adjusted between Umin= (300 – 370 V).
Over voltage (o-U) it can adjusted between Umax=(390 – 460 V).
If the voltage drops below the adjusted under voltage limit when u-U
shows on the screen and device switch off its output contact end of the
t-1 time Normal LED turned on .In this case u-U warn appears on the
screen.
If the voltage exceed the adjusted over voltage limit Normal LED
turned off and output relay switch off. In this case o-U warn appers on
its screen.
Hysteresis is 6 V.
I(A)
Re t
t
Sdt d-t r-t d-t r-t
o-C
u-C
%hYS
%hYS
2.6 Asymmetric Curre t Protectio :
It can be set by the user between 5% and 40%. It controls the
asymmetric that may occur in the current of the three phases. That
may occur when one of the phases' voltage is low and the other one
is high. That may cause asymmetric current in the motor's bobbin.
This way the motor's bobbin is protected. Furthermore it protects the
motor from missing phase or a possible unplugged or cut wiring.
If the unbalance between the phases' current exceeds the adjusted
value the switch off occurs after t-1 delay.
If the current unbalance exceed the adjusted value Normal LED
turned off and output relay switch off. In this case ubC warn appears
on its screen.
This function can be disable if ubC value = 000 (oFF)
Over a d U der Curre t : (o-C),(u-C)
Under Current (u-C)
Over Current (o-C)
When the current of the protected system goes below the adjusted
value it switches off its output contact after d-t delay.
Normal LED turn off and relay switch off its contact .In this case
u-C warn appears on display.
When any current passing through any phase of the protected system
exceeds the adjusted value the device switches off its output contacts
after a proper time (d-t).Normal LED turn off and relay switch off its
contact .In this case o-C warn appears on display.
NOTE: Under current protection set value with its hysteresis must not
overlap with over current protection set value with its hysteresis or, the
under current protection set value must not be higher than the over
current protection set value.
VOC
OC
r-t r-t
Re t
t
t-2
(o-F)
(u-F)
r-t t-2 r-t
55 Hz
45 Hz
Under Frequency
Over Frequency L1 L2 L3
Normal
Normal
f(Hz)
Start delay time: Sd-t
It can be set between 1 and 60 seconds.It is used to prevent the switch
off from occurance because of the motor's inrush current.
This function can be disable if Sd-t value = 000 (oFF)
Retur Time : r-t
it shows the delay time that device will wait to switch on its output relay
when failure ends after a switch off. It can be set between 0 5 and 99 9
seconds.
Very Over Curre t Coefficie t : VOC (Current Very Sudden Switch
Off Protection)
It can be set by the user between 2 1 and 6.
When the current value exceeds the adjusted value within the start
delay time the device switches off its output contact immediately.
Very Over Current value = (o – C) x (VOC)
This function can be disable if VOC = 000 (oFF)
Over Curre t Coefficie t : OC (Current Sudden Switch Off Protection)
It can be set by the user between 1 1 and 2.
When the current value exceeds the adjusted value without the start
delay time the device switches off its output contact immediately.
Over Current value = (o – C) x (OC)
This function can be disable if OC = 000 (oFF)
Over a d/or U der Freque cy Protectio : ( 40 – 70 Hz )
Under Frequency be able to set between(u-F) = 40 Hz ...[(o-F) -0 4]
Over Frequency be able to set between (o-F) =[(u-F) + 0 4]...70 Hz
If required it can be set only under frequency or only over frequency
protection as well as both of protection can be disabled.
If o-F = 55 Hz and u-F = oFF set device works as over
frequency protector only. (if system frequency above 55 Hz under
screen displays o-F warning and end of time t-2 relay switch off its
output contact )
if o-F = oFF and u-F = 45 Hz set device works as under
frequency protector only . (if system frequency below 45 Hz under
screen displays u-F warning and end of time t-2 relay switch off its
out contact.)
if o-F = oFF and u-F = oFF set frequency protection is disabled.
LOCKING FUNCTION :
It can be controlled by two parameters. Locking time and
Locking counter. If the number of opening reaches the adjusted
locking counter withing the adjusted locking time then device
switch off its contact and locks its functions until the user
pressed Reset button.
If the locking counter is adjusted to oto then this function is
disable and device never locks itself.
L-t : Locki g Time ( 001 – 060 min. )
It is well know the frequently occurring faults may damage
system. For that the device when number of faults reaches the
adjusted locking number within this locking time. This way the
system is protected and user has chance to investigate the
problem.
L-C : Locki g Cou ter ( oto 001 – 010 piece )
The number of faults allowed within the period L-t. If number of
faults exceeds this adjusted counter value device locks itself.
In this case (- - -) warn appears on its screen. User must press
Reset button then the fault passes in order to unlock the device.
If L- C is set to oto then this property is disabled.
V
Re
t
t
(o-U)
(u-U)
r-t
Over Voltage
1. Error L1 L2 L3
Normal
Normal
L- C (number of lock) = 2 piece
L- t (lock time) = 3 min. if select ;
t-1 t-1 r-t
Pushed to Reset button
and Lock have reseted.
Locked occurred
< 3 minutes
Over Voltage
2. Error

SET
SET
ACCESSING PARAMETER MENU:
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
+
SET
SET
Push the SET button
during 3 seconds.
SET
Return time
( r - t )
return time from error
00 5 – 99 9 (sec.)
Locking Counter
(L - C)
[oto (001–010 pieces)]
oto: function is disabled
Locking Time
(L – t )
001 – 060 (minutes)
quit
Retur from
VOLTAGE Me u
Retur from
CURENT Me u
Over Voltage
( o – U)
phase - phase
390 - 460 (V)
oFF:function is disabled
Under Voltage
( u – U)
phase - phase
300 - 370 (V)
oFF:function is disabled
Unbalance for Voltage
( u b )
0 05 – 0 40
(5% - 40% )
oFF:function is disabled
Delay Time for Voltage
( t - 1)
00 1 – 99 9 (sec.)
Delay Time for Frequency
( t - 2)
00 1 – 99 9 (sec.)
Over Frequency
( o – F )
[(u-F) + 0 4] ≤...≤ 70 Hz
oFF:function is disabled
Under Frequency
( u – F )
40 Hz ≤...≤ [(o-F) – 0 4]
oFF:function is disabled
Accessing
Voltage
Parameter
Accessing
Curre t
Parameter
Current transformer
Primer value
Ct Ct
000 001
005 – 000 A
( 5 – 1000 ) A
Over Current
( o – C)
oFF:function is disabled
ysteresis Value
( hYS )
00.3(3%) – 0.50 (50%)
Delay Time
for Current ( d - t)
(0 1 – 60 sec.)
Start Delay Time
( Sdt )
(0 1 – 60 sec.)
oFF:function is disabled
Very Over Curre t
Coefficie t
(VOC)
VOC = 2 1 - 6 0
oFF:function is disabled
Under Current
( u – C)
oFF:function is disabled
Unbalance for Current
( u b )
0 05 – 0 40 (5% - 40%)
oFF:function is disabled
Over Curre t
Coefficie t
(OC)
OC = 1 1 - 2 0
oFF:function is disabled
_
+
_
+
_
+
_
+
_
+
_
+
_
+
_
+
_
+
_
+
_
+
_
+
_
+
_
+
_
+
_
+
_
+
_
+
_
SET
Lock :
Locking function for
currents.
o : function is inabled
oFF: function is disabled
+
_

ATTENTION !!!
- Clean the device using dry dust cloth after turned off device.
- Read and follow the instruction on this manual and attached label.
Co ectio :
TECHNICAL INFORMATION:
Rated Voltage (Un) : 230Vac (L1-N)
Operating Range : (0 8-1 1) x Un
Frequency : 50 / 60 Hz
Supply Power Consumption : < 4VA
Current Transformer Ratio : X / 5A
Current Measurement Range : (for seconder current)
0 05 - 6 Amp AC
Voltage Measurement Range : (Phase-Phase)10 - 500 Vac 45 - 65Hz
: (Phase-Neutral )10 - 300 Vac 45 - 65Hz
For power supply(L1 - N) 176V – 242V
Voltage Measurement
Power Consumption : <1VA (for one phase)
Measurement Sensitivity : %1±1 digit
Contact Current : Max. 3A / 240Vac
Device Protection Class : IP 20
Connector Protection Class : IP 00
Temperature : - 5 °C .... + 50 °C
Connection Type : To front panel tap
Dimensions : 72x72x80 mm :
L3
N
1A1A 1A
L2
L1
Load
X/5
X/5
X/5
18
16
15
Fault
lamp
N L1 L2 L3 18 15 16
k3 I3 k2 I2 k1 I1
3 A / 240Vac
Other KAEL Controllers manuals
Popular Controllers manuals by other brands

DIG
DIG 400A Series instruction manual

flamco
flamco LogoTronic HIU V2 operating instructions

Harman Kardon
Harman Kardon CITATION 5.0 Quick start instructions

Sunlight Supply
Sunlight Supply TITAN CONTROLS Helios 5 instruction manual

Roger
Roger MC16 operating manual

EUROSTER
EUROSTER 11M Operation and assembly manual
