KAEL ke-DP01-100A User manual

Digital Protector
Voltage – Current
and
Frequency control
0 -100A
ke-DP01-100A
Phase Sequence Control
Under Voltage Protection
Unbalanced Voltage
Protection
Over Frequency
Protection
Under Frequency
Protection
TRUE RMS
atch Function
VL1,VL2,VL3
VL12,VL23,VL13
IL1,IL2,IL3
Hz
eneral:
In three phase systems, it measures RMS values of AC voltages,
currents and system frequency sensitively. Using up direction button
(Select) phase-neutral voltages and phase-phase voltages monitor
sequentially.
ke-DP01 has many features.
Those are;
- Phase Failure (seq)
- Phase Sequence (seq)
- Over Voltage Protection (o - U)
- Under Voltage Protection (u - U)
- Voltage Unbalance (asymmetry) Protection (unb)
- Over Current Protection (o - C)
- Under Current Protection (u - C)
- Current Unbalance (asymmetry) Protection (ubC)
- Over Frequency Protection (o - F)
- Under Frequency Protection (u - F)
When device is turn on if its adjusted voltages and frequency in its
interval and if phase sequence is correct relay switch on.
If any of error occurred ( except phase failure and phase sequence )
at the end of adjusted time relay switch off its contact. When system
return normal values, at the end of time out relay switch on.
1
2
3
Re
< t-1 t-1
Phase Failure: (u-U)
Before starting system , it controls phase absence then if all phases
exits Normal ED turn on and relay contact switch on. In case of
missing of any 1, 2, 3 phases , Normal ED turn off and relay
switch off its contact .In this case u-U warn appears on display.
VL1
Special Buttons:
L1 L2 L3
VL2
VL3
L1 L2 L3
VL12
L1 L2 L3
VL23
L1 L2 L3
VL13
Select: (Up direction)
when pressing continuously,
screen displays frequency of
system. When button release
device continue to show voltage.
Reset:
If error case although disappeared
then device is not return to normal,
latch-function occurred and it
makes locked device.
Or ock-function (only for currents)
may be occured.
After checking error in system then
restart device with pushing reset
button.
Voltage Unbalanced: (unb)
The phase-phase voltage unbalance limit can be adjusted
between(5% - 20%) . When it exceeds the adjusted limit , the device
switched off its out contact at the end of t-1 delay. In this case unb
warn appears on the screen. For the returning normal state,
asymmetry values should under 20% (hysteresis value). In this case
at the end of t3 time Normal ED turned on and output contact switch
on. If the phase-phase voltage unbalance, return adjusted value
shorter than t-1 time, output relay does not release its contact.
Hysteresis is 20 %.
unb = 000(oFF) protection is disable .
Example: et's say that asymmetry value is set to %15 for a
3 x 380VAC.
In this case, relay contact switch off at (380-(380x0.15))=323 V.
Switch on the contact is performed at 323+(380x%15x%20)= 334V.
(%20 is the hysteresis).
Re
1, 2, 3 2, 3
1
2
3
Phase Sequetion: (Seq)
In case of wrong phase order , Normal ED turned off and relay
contact is not switch on. In this case seq warn appears on the
screen. If phase order is corrected , Normal ED turned on and out
relay switch on.
hys
+ % unb
Vnom
hys
evel
Re
- % unb
t-1 < t-1 t-1
1, 3, 21, 2, 3
r-t r-t
Over Voltage Protection
Under Current Protection
Unbalanced Current
Protection
Over Current Protection
L1 L2 L3
L1 L2 L3
Display Functions:
(Vmax - Vmin)
% unb = x 100 Hys = 380 x (% Asm) x (% 20)
380
AREAS OF OPERATION:
■ In-Elevator motors protection
■ on submersible pump and electric motors protection
■ Resistance in oven with
IMPORTANT: 1 - N is device supply inputs. Thus,the applied 1 – N
voltage must be rated voltage of system . Otherwise normal led makes
flash and the device switched off its output contact.
The measured frequency also must the frequency of the system.
®

V
Re t
t
t-1
(o-U)
(u-U)
r-t t-1 r-t
Umax
Umin
Under Voltage
Over Voltage 1, 2, 3
Normal
Normal
Over and Under Voltage : (o-U),(u-U)
Under voltage (u-U) it can adjusted between Umin= (300 – 370 V).
Over voltage (o-U) it can adjusted between Umax=(390 – 460 V).
If the voltage drops below the adjusted under voltage limit, when u-U
shows on the screen and device switch off its output contact end of the
t-1 time Normal ED turned on .In this case u-U warn appears on the
screen.
If the voltage exceed the adjusted over voltage limit, Normal ED
turned off and output relay switch off. In this case o-U warn appers on
its screen.
Hysteresis is 6 V.
I(A)
Re t
t
Sdt d-t r-t d-t r-t
o-C
u-C
%hYS
%hYS
2.6 Asymmetric Current Protection:
It can be set by the user between 5% and 40%. It controls the
asymmetric that may occur in the current of the three phases. That
may occur when one of the phases' voltage is low and the other one
is high. That may cause asymmetric current in the motor's bobbin.
This way the motor's bobbin is protected. Furthermore it protects the
motor from missing phase or a possible unplugged or cut wiring.
If the unbalance between the phases' current exceeds the adjusted
value the switch off occurs after t-1 delay.
If the current unbalance exceed the adjusted value, Normal ED
turned off and output relay switch off. In this case ubC warn appears
on its screen.
This function can be disable if ubC value = 000 (oFF)
Over and Under Current : (o-C),(u-C)
Under Current (u-C)
Over Current (o-C)
When the current of the protected system goes below the adjusted
value it switches off its output contact after d-t delay.
Normal ED turn off and relay switch off its contact .In this case
u-C warn appears on display.
When any current passing through any phase of the protected system
exceeds the adjusted value the device switches off its output contacts
after a proper time (d-t).Normal ED turn off and relay switch off its
contact .In this case o-C warn appears on display.
NOTE: Under current protection set value with its hysteresis must not
overlap with over current protection set value with its hysteresis or, the
under current protection set value must not be higher than the over
current protection set value.
VOC
OC
r-t r-t
Re t
t
t-2
(o-F)
(u-F)
r-t t-2 r-t
55 Hz
45 Hz
Under Frequency
Over Frequency 1, 2, 3
Normal
Normal
f(Hz)
Start delay time: Sd-t
It can be set between 1 and 60 seconds.It is used to prevent the switch
off from occurance because of the motor's inrush current.
This function can be disable if Sd-t value = 000 (oFF)
Return Time : r-t
it shows the delay time that device will wait to switch on its output relay
when failure ends after a switch off. It can be set between 0,5 and 99,9
seconds.
Very Over Current Coefficient : VOC (Current Very Sudden Switch
Off Protection)
It can be set by the user between 2,1 and 6.
When the current value exceeds the adjusted value within the start
delay time, the device switches off, its output contact immediately.
Very Over Current value = (o – C) x (VOC)
This function can be disable if VOC = 000 (oFF)
Over Current Coefficient : OC (Current Sudden Switch Off Protection)
It can be set by the user between 1,1 and 2.
When the current value exceeds the adjusted value without the start
delay time, the device switches off, its output contact immediately.
Over Current value = (o – C) x (OC)
This function can be disable if OC = 000 (oFF)
Over and/or Under Frequency Protection : ( 40 – 70 Hz )
Under Frequency be able to set between(u-F) = 40 Hz ...[(o-F) -0,4]
Over Frequency be able to set between (o-F) =[(u-F) + 0,4]...70 Hz
If required , it can be set only under frequency or only over frequency
protection as well as both of protection can be disabled.
If o-F = 55 Hz and u-F = oFF set, device works as over
frequency protector only. (if system frequency above 55 Hz, under
screen displays o-F warning and end of time t-2 relay switch off its
output contact )
if o-F = oFF and u-F = 45 Hz set , device works as under
frequency protector only . (if system frequency below 45 Hz, under
screen displays u-F warning and end of time t-2 relay switch off its
out contact.)
if o-F = oFF and u-F = oFF set, frequency protection is disabled.
LOCKIN FUNCTION :
It can be controlled by two parameters. ocking time and
ocking counter. If the number of opening reaches the adjusted
locking counter withing the adjusted locking time then device
switch off its contact and locks its functions until the user
pressed Reset button.
If the locking counter is adjusted to oto then this function is
disable and device never locks itself.
L-t : Locking Time ( 001 – 060 min. )
It is well know the frequently occurring faults may damage
system. For that the device when number of faults reaches the
adjusted locking number within this locking time. This way the
system is protected and user has chance to investigate the
problem.
L-C : Locking Counter ( oto , 001 – 010 piece )
The number of faults allowed within the period -t. If number of
faults exceeds this adjusted counter value device locks itself.
In this case (- - -) warn appears on its screen. User must press
Reset button then the fault passes in order to unlock the device.
If L- C is set to oto then this property is disabled.
V
Re
t
t
(o-U)
(u-U)
r-t
Over Voltage
1. Error 1, 2, 3
Normal
Normal
- C (number of lock) = 2 piece
- t (lock time) = 3 min. if select ;
t-1 t-1 r-t
Pushed to Reset button
and ock have reseted.
ocked occurred
< 3 minutes
Over Voltage
2. Error
®

SET
SET
ACCESSIN PARAMETER MENU:
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
SET
+
SET
SET
Push the SET button
during 3 seconds.
SET
Return time
( r - t )
return time from error
00,5 – 99,9 (sec.)
Locking Counter
(L - C)
[oto, (001–010 pieces)]
oto: function is disabled
Locking Time
(L – t )
001 – 060 (minutes)
quit
Return from
VOLTA E Menu
Return from
CURENT Menu
Over Voltage
( o – U)
phase - phase
390 - 460 (V)
oFF:function is disabled
Under Voltage
( u – U)
phase - phase
300 - 370 (V)
oFF:function is disabled
Unbalance for Voltage
( unb )
0,05 – 0,40
(5% - 40% )
oFF:function is disabled
Delay Time for Voltage
( t - 1)
00,1 – 99,9 (sec.)
Delay Time for Frequency
( t - 2)
00,1 – 99,9 (sec.)
Over Frequency
( o – F )
[(u-F) + 0,4] ≤...≤ 70 Hz
oFF:function is disabled
Under Frequency
( u – F )
40 Hz ≤...≤ [(o-F) – 0,4]
oFF:function is disabled
Accessing
Voltage
Parameter
Accessing
Current
Parameter
Over Current
( o – C)
oFF:function is disabled
ysteresis Value
( hYS )
00.3(3%) – 0.50 (50%)
Delay Time for Current
( d - t)
(0,1 – 60 sec.)
Start Delay Time
( Sdt )
(0,1 – 60 sec.)
oFF:function is disabled
Very Over Current
Coefficient
(VOC)
VOC = 2,1 - 6,0
oFF:function is disabled
Under Current
( u – C)
oFF:function is disabled
Unbalance for Current
( unb )
0,05 – 0,40
(5% - 40%)
oFF:function is disabled
Over Current
Coefficient
(OC)
OC = 1,1 - 2,0
oFF:function is disabled
_
+
_
+
_
+
_
+
_
+
_
+
_
+
_
+
_
+
_
+
_
+
_
+
_
+
_
+
_
+
_
+
_
+
_
SET
Lock :
ocking function for
currents.
on : function is inabled
oFF: function is disabled
+
_
®

ATTENTION !!!
- Clean the device using dry dust cloth after turned off device.
- Read and follow the instruction on this manual and attached label.
58mm
32mm
48mm
90mm
36mm
45mm
62mm
53mm
Connection :
TECHNICAL INFORMATION:
Rated Voltage (Un) : 220Vac ( 1-N)
Operating Range : (0,8-1,1) x Un
Frequency : 50 / 60 Hz
Supply Power Consumption : < 4VA
Current Transformer Ratio : X / 5A
Current Measurement Range : 0 - 100 Amp AC
Voltage Measurement Range : (Phase-Phase)10 - 500 Vac, 45 - 65Hz
: (Phase-Neutral )10 - 300 Vac, 45 - 65Hz
For power supply( 1 - N) 176V – 242V
Voltage Measurement
Power Consumption : <1VA (for one phase)
Measurement Sensitivity : %1±1 digit
Contact Current : Max. 3A / 240Vac
Device Protection Class : IP 20
Connector Protection Class : IP 00
Temperature : - 5 °C .... + 50 °C
Connection Type : To connection rail in electrical panel
Dimension :
L3
N
1A1A 1A
L2
L1
oad
18
16
15
N
Fault
lamp
100A
100A
100A
®
