KaiDeng WVC Modem User manual

WIFI-MODEM transfers the data from the inverter to KDM server via the internet,the client can manage the data sending and
receiving,the power statistics and the error of the machine running state,whitch greatly improvers the stability of the system.
Support all wvc series micro inverter
Can be used by PC,mobile and PAD.
Check the data by day,month or year
Easy to use
Support local interview and remate control
Dual antenna transceiver design
433MHz+Wifi double modules Choose APP or Web
433MHz
Communication
Running Mode
Cloud
WIFI
Communication
⑥433MHz antenna
⑦WIFI antenna
Diagram of indicator and connector
①Power lamb(bright)
②Working station indicator(blink)
③Network connection signal(bright)
④Sending data(blink)
⑧Reset
⑤receiving data(blink)
⑨Power input port
⑨
① ② ③④⑤
⑥⑦
⑧⑥
⑦
Front Back
KDM Server WIFI-MODEM PV array
WIFI-MODEM
50/60Hz
10Watt
0.35KG
160×100×32mm
433MHz+WIFI
Transmission distance
Waterproof
1000M(open range)
IP23
automatic shift 120/230V
G.W.
Size
Input Voltage range
Input frequency range
Max Output Power
Communication mode
Parameter
Brief configuration interface,made the installation easier
and faster
WiFi-Router
WIFI
Communication
Remark: One MODEM can monitor 46 WVC inverters or 92 Solarbox at the same time.
Each Modem can monitor 46pcs micro inverters
or 92 SolarBox at the same time.

Connect the 433MHz antenna
Connect the power
Connect the WiFi antenna
WiFi-Modem Installation guide(WiFi only)
Tighten the two antennas of the Modem in order, then connect the power cord and power it on.
Ready to work
Check if there is a sticker on the back of the Modem. If there is no label or the code is unclear, please contact the
manufacturer; the location of the label is as shown below (copy the 8-digit code for backup)
Model
Front Back
Prepare a toothpick (or any replacement that can be inserted into the reset hole)
Install the App client on the mobile phone (the first time the mobile phone APP is installed, you will be prompted to
open the positioning function. For details, please follow the mobile phone prompts)
Authorized GPS

APP Phone Settings：
A) Please visit our company's official website to download the
kaideng-app.apk app and install it on your Android phone, then
click the Kaideng app to enter the login interface, then click the
collector to initialize.As shown in Figure 1:
Figure 1 Figure 2
B) As shown in Figure 2, click the red circle to select HF-A11x_AP in
the AP SSID of the collector, click thecompany WiFi SSID to select the
WiFi network name in your home, and enter the password in the WiFi
password.
The WiFi name of the
Selected module
Select the WiFi hotsp
-ot in use
Enter WiFi password
C) After all are entered, first select the drop-down menu of the
mobile phone and long press the network to select the HF-A11x_AP
connection, as shown in Figure 3, and close the data connection of
the mobile phone, as shown in Figure 4:
Figure3Figure4
Note: Because HF-A11x_AP is not connected to the Internet, the
Android phone will automatically disconnect the network, which
will make our initialization unsuccessful. Please find the automatic
switching functionin the Android phone's system settings and turn
it off.
D) After all are entered, first select the drop-down menu of the
mobilephone and long press the network to select the HF-A11x_AP
connection, as shown in Figure 3, and close the data connection of
the mobile phone, as shown in Figure 4:
Figure5Figure6
E) Most smartphones automatically select a network. When the
connected network pops up and there is no Internet access signal,
be sure to choose to keep connected to ensure that the initialization
is carried out smoothly, as shown in Figure 5, and the initialization is
completed at the last point, as shown in Figure 6 As shown.
Figure7
Computer Settings：
A) Click on the computer to connect to the WiFi network of HF-A11x_AP
as shown in Figure 8, open the browser in the computer, enter the IP
address: 10.10.100.254, enter in the name: admin, enter in the password
field: admin.
Figure8
Figure9
1、Select STA mode on Mode Selection, as shown in Figure 10:
2、Click Search on the STA Interface Setting to search the network as shown
in Figure 11:
3、Select your own network in the searched network list as shown in
Figure 12:
4、Click Search on the STA Interface Setting to search the network ,
and enter the password in the Pass Phrase and click Apply, as shown
in Figure 13:
Figure12
Figure13
Figure10 Figure11
5、In Application Setting, select Mode as Client> enter Port 1234>
enter Server Address 47.115.28.119> click Apply to confirm as shown
in Figure 14:
Figure14
6、Restart the device in Device Management to complete the settings
as shown in Figure 15:
Figure15
As Shown in Figure 9:
KD
KAIDENG ENERGY
App Setting

Use of APP：
Please visit our company's offici
-al website to download the kai
-deng-app.apk app and install it
on your Android phone, then cli
-ck the Kaideng app to enter the
login interface, click to register a
new account, then click to log in
to the power station interface
and click Add Power Station As
shown on the right.
Please enter each item related to the
power station, select "No" in the opt
i-on of whether there is an electric b
-ox, fill in the number in the bar code
behind the collector in the option of
the collector, enter "1" in the calcula
-tion ratio, the other according to
the actual Just enter.
Address information
"No" must be entered here
Found behind the collector
"1" must be entered here
Fill in the actual installed
capacity
Click here to complete
Add the inverter to the inverter addition
page, enter the inverter code in the Inve
-rter Code field, and then click Single Add
to complete the addition of the inverter,
as shown on the left.
Enter the code of the inverter
Click add
The added inverter
The pictures on the right are "In
-verter Data Detail Page" and "I
-nverter List Page". To view the
data details of a single inverter,
click the icon in the inverter list
to open the inverter data Details.
Immediately monitor your power plant and keep track of your power plant data：
KD
KAIDENG ENERGY
WVC Series micro inverter
