Kalee KL-7012 Guide

Assembly Manual & User’s Guide
Battery Operated Ride-On Vehicle
Item No.: KL-7012
Mercedes-Benz M-Klasse W 166
Adult Assembly Required
This manual contains important information which will help you to assemble
the unit includes safety instructions.Please keep this manual for future purpose
WARNING:
Please read this manual carefully before assembly and use.
Mercedes-Benz M-Klasse W 166 is registered trademark owned and licensed by Mercedes-Benz Accessories Gmbh.
Manufactured by Kalee Children’s Products Co., Ltd., www.mercedes-benz.com

Age: 3 years and up
Maximum Capacity: 40kgs / 88 lbs
Speed: 2.2-2.8mph
Battery Type: Sealed lead-acid rechargeable, 12Volt 7Ah
Charging time: Always charge the battery for 8-10 hours before first use
and when recharging is needed. Never charge for more
than 20 hours.
Power input for Charger: A/C 100-240 Volts, 60Hz
Power output to Battery: DC 14Volts, 1000mA
Vehicle / Battery Specifications:
WARNING:
Use the toy only on flat surfaces, such as sidewalks, driveways or
playgrounds. Never ride the vehicle in dangerous places such as busy
streets, roads or highways.
Never use/ride/play near swimming pools or other bodies of water.
Never ride the vehicle in muddy or sandy areas. Never ride in hilly
areas or on steep slopes. This vehicle was made to operate on dry
leveled ground.
Never ride in the dark or in dimly lit areas.
Clean the vehicle only with a damp cloth and never submerge vehicle
in water or spray with water directly from a hose.
Do not exceed the recommended weight limit of 40 kgs / 88 lbs.
To avoid suffocation of children please destroy all plastic bags after
assembly of the vehicle.
If vehicle is equipped with a forward / reverse switch, never press
this switch while vehicle is in motion. Always stop the vehicle before
switching directions.
1.
2.
3.
4.
5.
6.
7.
8.
2
9. This toy should be used with caution since skill is required to avoid
falls or collisions causing injury to the user or third parties.
10. The charger used for the vehicle are to be regularly examined for
damage to the cord, plug, enclosure and other parts, and in the event
of such damage, they must not be used until that damage had been
repaired.
11. The toy should be used with caution since skill is required to avoid
falls or collisions causing injury to the user or third parties.

CHARGING CAUTIONS:
- The charger is not a toy. Do not allow children to play with the charger or
to recharge the battery.
- Turn the power switch to “OFF” when charging.
- Before the first use, you should charge the battery for 8-10 hours. Do not
charge the battery for more than 20 hours to avoid overheating the charger.
- It is normal for the charger to feel warm during charging. If the charger
feels very hot, stop charging, unplug the charger and check the battery and
charger.
- Use the charger in a dry location only and store in a dry location when
not in use.
- Regularly check the charger, battery and their connectors for excessive
wear or damage each time you charge the battery. If damage or excessive
wear is detected, do not use the charger or the battery until you have
replaced the worn or damaged part.
WARNING - Risk of fire. Do not by pass fuse. Replace only
with the correct amperage fuse.
BATTERY SAFETY WARNING:
- Only use the battery and charger supplied by the manufacturer.
- Do not connect the battery terminals directly together. This will cause
the battery to short-circuit.
- Never short-circuit the battery terminals or modify the electrical
system. Alterations may cause a fire resulting in serious injuries.
- Do not mix old and new batteries or batteries of different types.
- Remove batteries during long periods of non-use. Always remove
batteries from the product. Dispose of batteries safely. Do not dispose
of batteries in fires. The batteries may explode or leak.
- If removable, rechargeable batteries are used, they are only to be
charged under adult supervision.
- Recharge the battery fully before storage, then charge it every 3
months to extend the life of the battery.
3
Caution:
This ride on vehicle is equipped with a built-in thermal circuit breaker.
The thermal circuit breaker is a self-resetting safety device which
automatically “trips” and shuts down the operation of the vehicle if it is
overloaded or the driving conditions are too severe. Once the circuit
breaker has tripped it will automatically reset itself after approximately
25 seconds and allow the rider to resume normal operation.
Caution:

Part List:
No. Description Qty
How to assemble the vehicle:
1 Body 1 pc
2 Charger 1 pc
3 Radio line 1 pc
4 Rearview Mirror 1 pairs
● Attach the Rearview Mirror (#4) onto
the windshield of the vehicle.
●
●
●
The vehicle is shipped with the battery
unplugged. It must be connected before
the first use.
The battery is located in the seat
compartment of the body.
Unscrew the prefixed screw on the back
of the seat with screwdriver(not included).
Connect the red cable to the Thermal
Circuit Breaker device.
Place the seat and tighten the screw with
screwdriver.
●
●
Thermal Circuit Breaker Device
Connect the red cable
to the thermal circuit
breaker device
2

Operation of the Vehicle:
1. Make sure the battery is fully charged and the
red plug is connected to the battery plug under
the seat.
2. Locate the direction switch to the right of the
steering wheel. Push the direction switch to “F”
and press the accelerator pedal, vehicle will move
forward. Headlights come on while vehicle is
moving forward.
3. To stop the vehicle remove foot from accelerator
pedal. When stopped pull the direction switch to
“B”, then press the accelerator pedal, vehicle will
move backward. The taillight will come on while
moving backward.
5. MP3 Plug-in: Plug in MP3 to play music. Audio Line
(#3) included with the car.
4. Steering Wheel: Press the buttons in the middle
for different driving sounds.
5
Charging the Battery:
● The socket for charging the battery is
located near the seat.
● Connect the charger plug into the DC jack,
then plug the charger into a household outlet.
● Charge the battery for 8-10 hours. Never
charge more than 20 hours.
● When the battery is fully charged, unplug the
charger and store it in a cool and dry place.
F/R Switch
MP3 Insert
Pedal Switch
Power Switch

Maintaining your vehicle:
It is a parents responsibility to check main parts of the vehicle before
use. Regularly examine the vehicle for potential hazards, such as the
battery, charge cable, cord and plug. Ensure screws are tightened. If
there are any damages, the vehicle must not be used until these
damages have been properly repaired or replaced.
Occasionally use a lightweight oil to lubricate moving parts such as
the wheels and steering linkages.
Keep the vehicle in an upturned position, do not overturn or incline it.
It is recommended to store the vehicle indoors when not in use. If
stored outdoors, the vehicle needs to be covered by a tarp for
protection against weather elements.
This toy should be kept away from fire. Keep the vehicle away from
sources of heat, such as stoves and heaters. Plastic parts may melt.
While charging ensure all flammable liquids are well away from the
vehicle.
ADULTS ONLY to recharge the battery after each use. Recharge the
battery at least once a month when the vehicle is not being used.
Use a soft, dry cloth to clean vehicle.
DO NOT use any chemical liquids to clean the plastic surface of the
vehicle.
DO NOT wash the vehicle with soap and water.
DO NOT drive the vehicle in rainy or snowy weather. Water will
damage the motor, electric system and battery.
When not in use all electrical sources should be turned off. Press the
power switch to the "OFF" position to turn the power off. Also
disconnect the battery connection under the seat.
Please do not change the structure of this product and circuit system.
DO NOT use the vehicle for other purposes except riding.
●
●
●
●
●
●
●
●
●
●
●
●
6

WARNING:
To reduce the risk of injury, adult supervision
is required.
Never use on roadways, near motor vehicles,
on or near steep inclines or steps, swimming
pools or other bodies of water. Always wear
shoes and never allow more than 1 rider.
WARNING:
Contains small parts, sharp points and
sharp edges. Adult assembly required.
WARNING:
Choking Hazard! Contains small
parts. Not for children under 3 years old! WARNING:
This toy is unsuitable for children under
3 years due to its maximum speed.
WARNING:
Not to be used in traffic.
Safety Precautions:
1. While riding, adult supervision is required at all times.
2. Always wear a helmet when riding.
3. Do not ride near roads or on the footpath.
4. It is not recommended to drive the vehicle on wet surfaces or on
slopes greater than 15 degrees.
5. It is recommended to ride this vehicle on smooth surfaces only.
6. Do not use this vehicle outdoors when it is raining.
7. Make sure you come to a complete stop before changing directions
from forward to reverse.
8. Don't allow children to operate the charger or play with the battery.
9. Clean the vehicle with a dry cloth only.
10. Please follow the correct weight and age limits allowed to driver
this vehicle.
11. It is prohibited to change the circuit or add other electric parts.
12. Adults must teach their children about safe driving procedures.
13. Please turn the power off when not in use.
14. Check the seat to ensure it has been fitted and secured with a bolt
before driving.
15. Inspect all wires and connections of the vehicle perodically.
16. Charging the battery should only be done by adults.
17. Charging plug is located the bottom of the vehicle.
18. In order to avoid accidents, please ensure the vehicle is safe before
driving.
19. Do not let any child touch the wheels or be near them when the
vehicle is moving.
7

8
BOM List:
1. Body
2. Seat
3. Steering wheel
4. Door knob
5. Rear Bumper A
6. Rear Light
7. 14. Rear turning light
(Left & Right)
8. Rear Wiper
9. Empennage A
10. Rear Light receptacle
(Left & Right)
11. Rear Light cover
12. Rear Bumper Bracket
13. Empennage
15. Rear Bumper
16. Rear Windshield
17. Rear Bumper B
18. Rear Windscreen
19. Rear Wheel
20. Rearview Mirror Right
21. 23. Front Radiator A
(Right & Left)
22. Bonnet
24. Front Wheel
25. Front Bumper
26. Front Radiator B
27. Front Bumper A
28. Front Radiator C
29. Front Dadiator D
30. Front Light Cover
(Left & Right)
31.36. Front Light receptacle
(Left & Right)
32. Front Bumper Adornment
33. Front Wiper A
34. F/R Switch board
35. Push-to-start switch
37. Front Turning Light
(Left & Right)
38. Rearview Mirror Left
39. Front Windshield
40. Front Windscreen
41. Front Bumper Bracket
42. Dash Board A
43. Dash Board B
44. Front Wiper B

1. If vehicle fails to move:
a) Make sure the battery wires are connected properly.
b) Recharge the battery, if necessary.
c) Check the fuse and replace if damaged.
2. If vehicle runs slowly:
a) Recharge the battery.
3. If the battery can not recharged:
a) Battery or charger may be damaged. Replace if necessary.
Trouble-Shooting:
9
Made in China
You can help protect the environment! Please
remember to respect the local regulaons:hand in the
non-working electrical equipments to an appriate
waste disposal center.
If you have any missing or damaged parts or need assembly assistance,
please contact our service center directly. Do not return this product to the retailer,
they do not stock replacement parts.
Support Website: http://support.bigtoysusa.com
Support Phone: [phone]
