Kamado Space KETTLE ADD-ON V1.6 User manual

KETTLE ADD-ON
ASSEMBLY MANUAL
PRODUCT: KAMADOSPACE KETTLE ADD-ON
PRODUCT VERSION: V1.6
INSTRUCTIONS VERSION: KSI/2022/1.6.1

KamadoSpace Kettle Add-on assembly manual version KSI/2022/1.6.1
Thank you for purchasing
We wish you the best
grilling experience
Team
2

KamadoSpace Kettle Add-on assembly manual version KSI/2022/1.6.1
TABLE OF CONTENTS
WARNINGS AND IMPORTANT SAFEGUARDS 4
NOTES BEFORE STARTING 5
STEP 1: UNBOX COMPONENTS 6
STEP 2: ASSEMBLE THE KETTLE ADD-ON COMPONENTS 8
3

KamadoSpace Kettle Add-on assembly manual version KSI/2022/1.6.1
WARNINGS AND IMPORTANT SAFEGUARDS
⚠Make sure to follow the assembly instructions.
⚠It is recommended to use gloves when assembling or moving the unit, to avoid injuring the
fingers.
⚠Exercise caution when handling the unit. DO NOT transport it to another location without
removing the grill first.
⚠Engage the brakes when the table is not being moved.
⚠Regularly check all nuts, screws and bolts to make sure they are tight and secure.
IMPORTANT: Place wooden blocks under the table when checking the wheels, to avoid any injuries.
⚠Ensure the metal runners are not in contact with water, grease or other liquids.
⚠Keep the unit protected under the roof, KamadoSpace cover or other suitable material. Damage
due to excessive water is not covered by the warranty.
⚠Use stainless steel polisher and a sponge for any rust stains you may notice. It is not
recommended to use abrasive cleaning tools.
⚠DO NOT use pressure washer on the unit.
⚠You may need to remove salt build-up if you reside in a location near the sea or the ocean.
4

KamadoSpace Kettle Add-on assembly manual version KSI/2022/1.6.1
NOTES BEFORE STARTING
Important - Please read these instructions fully before starting the
assembly!
● Make sure you have the correct worktop. Cutout should be not less
than 22 inches (575 mm).
● Make sure you have all the components listed on page Nr. 6 and 7.
● Do not stand or put weight on the parts, this could cause damage.
● Keep children and animals away from the work area, small parts
could choke if swallowed.
● Make sure you have enough space to lay out the parts before
starting.
● Scan the QR code on your mobile camera to be taken to video
tutorials and mobile instructions or go to our website
(https://kamadospace.eu/instructions).
Need assistance?
Send us a Facebook message (fb.com/kamadospace) or email us at
[email protected]
5

KamadoSpace Kettle Add-on assembly manual version KSI/2022/1.6.1
STEP 1: UNBOX COMPONENTS
Component
Quantity
1
Grill platform
1
2
Feets
3
3
Back stiffening element (bar)
1
4
Stiffening element
2
6

KamadoSpace Kettle Add-on assembly manual version KSI/2022/1.6.1
5
Lid holder
1
7

KamadoSpace Kettle Add-on assembly manual version KSI/2022/1.6.1
STEP 2: ASSEMBLE THE KETTLE ADD-ON
COMPONENTS
Take out the standard Infinite
Island grill platform from your
Island.
Leave the stainless steel grill
platform from the main Island
packaging as a spare part. You
won’t need it while using Kettle,
but we suggest keeping it in
case you ever decide to switch
to a ceramic kamado type grill.
Remove the ashtray and its
cover.
8

KamadoSpace Kettle Add-on assembly manual version KSI/2022/1.6.1
Take off the worktop. If your
worktop is not 22”, you can still
keep it if you ever want to revert
back to the old grill.
Take out the platform by lifting
the left side to a 45° angle and
pull it out from the slots on the
right.
Remove the back stiffening
element (bar) from the grill
platform by twisting it to a 45°
angle and pulling it away.
Note: The back bar will have a
shorter lip.
9

KamadoSpace Kettle Add-on assembly manual version KSI/2022/1.6.1
Replace the old back bar with a
new back bar from the Kettle
add-on box.
Put hooks into the slots on the
back bar at a 45° angle and
twist it into place.
Note: Make sure that the hooks
on the back are facing the same
way as the front bar.
Attach the 2 stiffening bars from
the Kettle add-on box.
Insert the hooks into the slots at
a 45° angle and push the
stiffening bars down.
The platform should look like
this.
10

KamadoSpace Kettle Add-on assembly manual version KSI/2022/1.6.1
Put the platform back into the
table.
Insert the hooks into the slots
on the right side at a 45° angle
and push down the platform
until it sits on the position clips.
Attach the worktop and insert
the ashtray back onto the grill
platform.
Put the new grill platform, from
the Kettle add-on box, on the
platform.
Note: Longer lip as well as a
single slot for the legs goes to
the back.
11

KamadoSpace Kettle Add-on assembly manual version KSI/2022/1.6.1
Take the Kettle lid holder out of
the add-on box and unscrew the
two bolts that are holding it
together.
Note: Do not lose the screws.
Slide the top part of the holder
onto the worktop ensuring that it
is facing the left side of the
table.
Insert the bottom part of the
holder beneath the worktop and
align it with the screw slots on
the top part.
12

KamadoSpace Kettle Add-on assembly manual version KSI/2022/1.6.1
Screw in the two screws from
the top to fix the lid holder to the
worktop.
Take the 3 legs from the Kettle
add-on box and insert them into
the slots on your Kettle grill.
Note: The plastic parts at the
bottom should be facing down.
With the legs attached, lower
the Kettle grill into the Island
through the cutout.
Note: One leg should be in the
back of the table and the other
two - in the front.
13

KamadoSpace Kettle Add-on assembly manual version KSI/2022/1.6.1
Align the plastic spikes on the
legs with the slots on the grill
platform until the grill stands in
its place.
Congrats!
It is ready for use.
