K&S BASIC KS 1200i User manual

Please, read this manual
carefully before use!
OWNER’S MANUAL
Inverter Generator
KS 1200i
EN

INTRODUCTION
SAFETY INFORMATION 1
Thank you for your purchase of ТМ K&S Basic products. This manual contains a brief description of
safety, use and debugging. More information can be found on the ocial manufacturer’s website in the support
section: ks-power.de/betriebsanleitungen.
You can also go to the support section and download the full version of the manual by scanning the QR code, or on
the website of the ocial importer of K&S Basic products: www.ks-power.de/en.
Manufacturer reserves the right to make alterations into the generators, which may not be reected in this manual.
Pictures and photos of the product may vary from its actual appearance. At the end of this manual, You may nd
contact information which you are free to use in case of any issues occurrence.
All data, specied in this operation manual is the most up to date for the moment of its publishing. The current list of
service centers you can nd at the website of ocial importer: www.ks-power.de/en.
Do not use the generator in rooms with poor ventilation or in conditions of excessive humidity. Do not place the
generator in water or on moist soil. Do not expose the generator to rain, snow, as well as to direct sunlight for a long
time. Place the generator on a at, hard surface, away from ammable liquids/gases (at a minimum distance of 1 m).
Keep unauthorized persons, children, and animals away from work area. Wear safety shoes and gloves.
We care about the environment, therefore, we consider it expedient to save paper andWe care about the environment, therefore, we consider it expedient to save paper and
leave in print a short description of the most important sections.leave in print a short description of the most important sections.
Be sure to read the full version of the manual before getting started!
Failure to follow the recommendations marked with this sign may
lead to serious injury or death of the operator or third parties.
Useful information while operating the machine.
ATTENTION – DANGER!
IMPORTANT!
ELECTRICAL SAFETY 1.1
The generator produces electricity that may lead to an electric shock while neglecting compliance regulations. All con-
necting the generator to the network must be made by certied electrician in accordance with all electrical rules and
regulations. Connect the generator to the protective ground before operation. Wires with damaged or spoiled insulation
should be replaced. You should also replace worn, damaged or rusty contacts.
The device generates electricity. Follow safety precautions
to avoid electric shock.
Using device for other purposes deprives the right for free
warranty.
ATTENTION – DANGER!
IMPORTANT!
Be careful. Do not operate the generator, if you are tired, under
the inuence of drugs or alcohol. Inattention may cause a serious
injury.
ATTENTION – DANGER!
www.ks-power.de/en |1

“ON” MODE“ON” MODE
When the ECON switch is in the “ON” position, the control unit monitors the engine speed, reducing it commensurate
with the connected load. If the engine speed is not enough to generate electricity to provide the load, the control unit
will automatically increase the engine speed.
As a result, fuel consumption is optimized and noise levels are reduced.
“OFF” MODE“OFF” MODE
The ECON switch must be set back to “OFF” when using electrical devices requiring a high starting current, such as a
compressor or submersible pump.
The ECON switch must be set to “OFF” to increase engine speed
to nominal. When connecting multiple power consumers to the
generator, be sure to first connect the one with the highest
starting current, and the device with the lowest starting current
should be connected last.
IMPORTANT!
The ECON switch must be set back to “OFF” when using electrical
devices requiring a high starting current, such as a compressor or
submersible pump.
IMPORTANT!
General view of inverter generators, description of control panels, sGeneral view of inverter generators, description of control panels, safety symbols and description of inscriptionsafety symbols and description of inscriptions
can be found in the full electronic version.can be found in the full electronic version.
PRECAUTIONS WHEN WORKING WITH
GASOLINE GENERATOR 1.2
Do not start the generator operation upon presence of electric load! Disconnect the load before you stop the engine.
Only unleaded gasoline is recommended for the generator. It is forbidden to use kerosene or other
fuel types. Before running the generator, it is necessary to dene the place and means of its emergency stop. Do not
refuel the running generator.
Fuel contaminates the land and groundwater. Do not allow the
leaking gasoline from the tank!
ATTENTION – DANGER!
ECON FUNCTIONECON FUNCTION
1. Start the engine.
2. Set the ECON switch to “ON”.
3. Plug the device into an AC outlet.
4. Make sure the AC indicator light is on.
5. Turn on the electrical device.
FUNCTIONAL DESCRIPTION
OF INVERTER GENERATORS 2
www.ks-power.de/en |2

SPECIFICATIONS 3
Model KS 1200i
Voltage, V 230
Maximum power, kW 1.2
Nominal power, kW 1.0
Frequency, Hz 50
Current, A (max.) 5.22
Outlets 1х16А
Engine start Manual
Fuel tank volume, l 3.5
Operating time at 50% load, h 5.5
Noise level Lpa (7m)/Lwa, dB 67/92
Output 12V, A 5.0
Engine model KS 110і
Engine type Gasoline powered one-cylinder, four-stroke
Engine power, hp 2.0
Crankcase volume, l 0.4
Engine volume, cm387
Power output controller AVR
Power factor, cos φ 1
Net dimensions (L*W*H), mm 310*310*380
Gross dimensions (L*W*H), mm 335*330*415
Net weight, kg 13
Protection class IP23M
Nominal voltage tolerance – max. 5%
To ensure reliability and increase the engine service life, peak powers may be slightly limited by circuit breakers.
The optimal operating conditions are ambient temperature of 17-25°C, barometric pressure of 0.1 MPa (760mmHg),
and relative humidity of 50-60%. Under these environmental conditions, the generator can provide maximum perfor-
mance in terms of the declared specications.
In the event of deviations from these environmental indicators, the generator performance may vary.
Please note that in order to preserve the long service life of the generator, continuous loads of more than 80% of the
nominal power are not recommended.
www.ks-power.de/en |3

It is recommended to ground the generator before operating it for the first time. Before starting the device, remember
that the total power of the connected power consumers should not exceed the nominal power of the generator.
OIL LEVEL INDICATOROIL LEVEL INDICATOR
When the oil level falls below the level required for operation, the oil level indicator lights up, and then the engine
stops automatically. The engine will not start until oil is added.
TERMS OF USE
OF INVERTER GENERATOR 4
GENERATOR OPERATION 5
To avoid electric shock due to poor-quality electrical appliances or
improper use of electricity, the generator must be earthed using a
high-quality insulated conductor.
IMPORTANT!
Useful tip: If the engine stalls or does not start, turn the engine
switch to the “ON” position, and then pull the manual starter.
If the oil level indicator flickers for several seconds, add oil and
restart the engine.
IMPORTANT!
Make sure that the control panel, the blinds and the underside of
the inverter are well cooled and protected against the ingress of
small solids, dirt, and water. Improper operation of the cooler can
cause damage to the motor, inverter or alternator.
IMPORTANT!
ENGINE SWITCHENGINE SWITCH
To start the engine, turn the engine switch to the “ON” position. To turn off the engine, turn the engine switch to the
“OFF” position.
AC INDICATORAC INDICATOR
When the generator is running and producing electricity, the AC indicator light is on.
The overload indicator may light up within several seconds
after start-up or when connecting electrical devices requiring a
high starting current, such as a compressor or voltage indicator.
However, this is not a malfunction.
IMPORTANT!
OVERLOAD INDICATOROVERLOAD INDICATOR
The overload indicator lights up when the connected generator is overloaded, the inverter control unit overheats or
the AC output voltage rises.
If the overload indicator goes on, the engine will continue to operate, but the generator will no longer produce
electricity. In this case, you must perform the following steps:
1. Turn off all connected electrical appliances and stop the engine.
2. Reduce the total power of the connected devices until the nominal power of the generator is reached.
3. Check if the vent grid is clogged. Remove excess dirt or debris, if any.
4. After checking, start the engine.
www.ks-power.de/en |4

DC FUSEDC FUSE
The DC protector automatically switches to “OFF” when the current of the operating electrical device is higher than the
rated current. To use this equipment again, turn on the DC fuse again by pressing the “ON” button.
FUEL TANK CAPFUEL TANK CAP
Remove the fuel tank cap by turning it counterclockwise.
FUEL TANK CAP AIR VENTFUEL TANK CAP AIR VENT
The fuel tank cap is equipped with an air choke control knob for venting and stopping the fuel supply. The air choke
control knob must be returned to the “ON” position. This will allow fuel to enter the carburetor and engine to start.
When the generator is not in use, turn the air choke control knob to the “OFF” position to stop the fuel supply.
GROUND TERMINALGROUND TERMINAL
The ground terminal forms a ground line to prevent electric shock. If the electrical appliance is grounded, the
generator must also be grounded.
CHECKING THE FUEL LEVELCHECKING THE FUEL LEVEL
1. Unscrew the fuel cap and check the fuel level in the tank.
2. Fill the fuel tank to the fuel filter level.
3. Tighten the fuel cap securely.
4. For closed models, open the air intake valve on the fuel tank cap.
Recommended fuel:Recommended fuel: unleaded gasoline.
Fuel tank volume:Fuel tank volume: see specifications table.
CHECK BEFORE GETTING STARTED 6
If the DC fuse turns off, reduce the load of the connected electrical
device. If the DC protector turns off again, stop operation and
contact your nearest Könner & Söhnen service center.
IMPORTANT!
Wipe up spilled fuel immediately with a clean, dry, soft cloth, as
the fuel may harm painted surfaces or plastic parts.
IMPORTANT!
Use only unleaded gasoline. Using leaded gasoline can cause
serious damage to the inside of the engine.
IMPORTANT!
CHECKING THE OIL LEVELCHECKING THE OIL LEVEL
The generator is transported free of motor oil. Do not start the engine
until it is filled with sufficient amount of motor oil.
1. Unscrew the oil dipstick and wipe it out with a clean cloth.
2. Insert the dipstick without screwing it in.
3. Check the oil level by a mark on the oil dipstick.
4. Add oil if its level is below the mark on the oil dipstick.
5. Screw on the dipstick.
Recommended motor oil:Recommended motor oil: SAE 10W-30, SAE 10W-40.
Recommended motor oil grade:Recommended motor oil grade: API Service SG type or higher.
Motor oil quantity: Motor oil quantity: see specifications table.
FILL TO HEREFILL TO HERE
www.ks-power.de/en |5

Before starting the engine,Before starting the engine, make sure that the power rating of power consumers matches that of the generator. Do
not exceed the nominal power of the generator. Do not connect any devices before you start the engine!Do not connect any devices before you start the engine!
GETTING STARTED 7
Do not change the controller settings in terms of the amount of
fuel or speed governor (this adjustment was made at the factory).
Otherwise, this may result in changes in the engine operation or
its failure.
IMPORTANT!
In the power supply mode, the generator should operate no longer
than 15 minutes in the range from nominal to maximum power.
ATTENTION – DANGER!
COMMISSIONING
In the first 20 operating hours of the generator, the following requirements should be met:
1. During commissioning, do not connect power consumers, the power of which exceeds 50% of the nominal
(operating) power of the device.
2. After commissioning, be sure to change the oil. It is better to drain oil while the engine is still hot after operation
to ensure quick and complete oil draining.
Before starting to use the generator, connect the ground wire to
the ground terminal.
IMPORTANT!
Useful tip: to ensure long-term operation of the generator engine,
it is important to observe the following tips:
- Before connecting the load, allow the engine to run for 1-2 minutes to warm it up.
- When disconnecting the load after lengthy operation, do not turn off the generator. Allow the
generator to run idle for 1-2 minutes so that it cools down.
IMPORTANT!
Do not connect two or more devices at a time. The start-
up of many devices requires high power. Devices should
be connected one at a time according to their power rat-
ing. Do not connect any power consumers within the rst
2 minutes after the generator has been started.
ATTENTION – DANGER!
DISCONNECT ALL DEVICES BEFORE STOPPING THE GENERATOR!
Do not stop the generator if it has any devices connected to it. This may disable the generator or devices connected
to it!
ENGINE START
Do not connect any power consumers to the generator before you start the engine. Turn the ECON switch to the “OFF”
position. Turn the air choke control knob to the “CLOSE” position. Turn the fuel valve handle to the “ON” position
(OPEN). Set the engine switch to “ON”. Pull the manual starter until a slight resistance is felt, then pull it toward you
relatively sharply. Slowly turn the manual starter by hand, do not release it abruptly. When starting the generator,
hold the generator by the carrying handle to prevent the generator from falling. Slowly turn the air choke control knob
to the “OPEN” position and then warm up the engine for 1-2 minutes. If the engine does not start, check the oil level.
Before turning on the connected device, check that the ECON switch is in the “OFF” position.
www.ks-power.de/en |6

TO STOP THE ENGINE, PROCEED AS FOLLOWS:
1. Disconnect all devices connected to the generator, then disable the ECON mode.
2. Allow the generator to operate at idle for 3 minutes for the alternator to cool down.
3. Set the engine switch to OFF.
4. Turn the fuel valve to the “OFF” position.
Detailed description of operation in AC mode can be found in the full electronic version of the manual.Detailed description of operation in AC mode can be found in the full electronic version of the manual.
The manufacturer shall not be liable for any damage caused by
failure to perform maintenance work.
IMPORTANT!
- If the generator often operates at high temperature or high load, the oil should be replaced
every 25 operating hours.
- If the engine often runs in dusty or other harsh conditions, clean the air filter every 10 operating hours.
- If you missed the maintenance time, perform it as soon as possible to save the generator engine.
MAINTENANCE 8
This manual compliance! You can find a list of service center addresses on the website of exclusive importer:
www.ks-power.de/en.
TECHNICAL MAINTENANCE WORKS
Unit
Action
At each start
First month
or 20 operating
hours
Every 3 months
or 50 operating
hours
Every 6 months
or 100 operating
hours
Every year
or 300 operating
hours
Motor oil
Level check
Replacement
Air lter
Check
Cleaning
Spark plug
Cleaning
Replacement
Fuel tank
Level check
Cleaning
Fuel lter Replacement
www.ks-power.de/en |7

RECOMMENDED OILS 9
Upon oil level decrease it is necessary to add the required quantity in order to provide the correct generator opera-
tion. It is necessary to check the oil levels according to technical maintanance schedule.The detailed description of oil
lling and draining can be found in the full version of the manual.
Use oils designed for four-stroke cycle vehicle engines
SAE10W-30, SAE10W-40. Motor oils with other viscosity levels,
may be used only if the average air temperature in your region
does not exceed the limits of the temperature range, specified
in the table.
000CC
10W-30, 10W-40
4040303020201010-10-10-20-20
AIR FILTER TECHNICAL MAINTENANCE 10
Air filter cleaning is to be performed each 50 hours of the generator operation (every 10 hours in unusually dusty
conditions).
CLEANING THE FILTER:CLEANING THE FILTER:
1. Open the clips on the upper cap of the air lter.
2. Remove the sponge ltering element.
3. Remove all dirt deposits inside the hollow case
of the air lter.
4. Thoroughly wash the ltering element in warmsoapy
water.
5. Dry the sponge lter.
6. Dry ltering element is to be moistened by
machine oil and excess oil is to be squeezed out.
SPARK PLUGS TECHNICAL MAINTENANCE 11
DAMPER AND FLAME ARRESTER
MAINTENANCE 12
Spark plug has to be intact, without soot deposits and to have a correct gap.
SPARK PLUG VERIFICATION:SPARK PLUG VERIFICATION:
1. Remove the cap from the spark plug.
2. Remove the spark plug by means of a corresponding spanner.
3. Examine the spark plug. If is is shattered – it is necessary to replace it.
Recommended replacement spark plugs – F7TC.
4. Measure the gap. It has to be within range 0.7-0.8 mm.
5. In case of repeated use, the spark plug has to be cleaned by means of a metal brush.
After that – set the correct gap.
The engine and damper will get very hot after the generator has been started. Do not touch the engine or damper
with any part of your body or clothing during inspection or repair until they have cooled down.
Remove the screws and then pull the protective cover towards you. Loosen the bolts and remove the cover, screen
and ame arrester of the damper. Descale the screen and ame arrester of the damper with a wire brush.Inspect
the screen and ame arrester of the damper. Replace them if they are damaged. Replace the ame arrester. Replace
the screen and cover of the damper. Replace the cover and tighten the screws.
Match the protrusion of the flame arrester to the hole in the
pipe damper.
IMPORTANT!
www.ks-power.de/en |8

FUEL FILTER 13
1. Remove the fuel tank cap and fuel lter.
2. Clean the lter with gasoline.
3. Wipe the lter and replace it.
4. Replace the fuel tank cap.
Make sure that the fuel tank cap is tight.
Never use gasoline while smoking or in the immediate vicinity of
an open flame.
IMPORTANT!
STORAGE 14
GENERATOR DISPOSAL 15
WARRANTY SERVICE TERMS 16
Storage room has to be dry and free from dust deposits. Storage room also has to be locked away from children and
animals. It is recommended to store and use the generator at temperature of -20°С to +40°С. Avoid direct sunlight,
rain on the generator. Information on long-term storage and transportation can be found in the full version of the
manual.
To prevent environment damage generator should be separated from ordinary waste. Please recycle it in the safest
way, passing it to special place for disposal.
Potential faults and troubleshooting methods, as well as average device capacities can be found in the full versionPotential faults and troubleshooting methods, as well as average device capacities can be found in the full version
of the manual.of the manual.
The international manufacturer warranty is 1 year. The warranty period starts from the date of purchase.
In cases when warranty period is longer than 1 year according to local legislation please contact your local
dealer. The Seller which sells the product is responsible for granting the warranty. Please contact the Seller for
warranty. Within the warranty period, if the product fails because of defects in the production process, it will
be exchanged on the same product or repaired.
The warranty card should be kept throughout the warranty period. In case of warranty card loss, a second
one will not be provided. The customer must provide the warranty card and buyer`s check during request
for repair or exchange. Otherwise, the warranty service will not be provided. The warranty card, attached to
the product during sale, should be correctly and fully completed by the retailer and customer, signed and
stamped. In other cases, warranty is not considered as valid.
Provide clean product to the service center. Parts, that must be replaced, are the property of the service center.
www.ks-power.de/en |9


Deutschland:
DIMAX International GmbH
Deutschland, Hauptstr. 134,
51143 Köln,
www.ks-power.de
Polska:
DIMAX International
Poland Sp.z o.o.
Polen, Warczawska, 306B
05-082 Stare Babice,
www.ks-power.pl
Україна:
ТОВ «Техно Трейд КС»,
вул. Електротехнічна 47,
02222, м. Київ, Україна
www.ks-power.com.ua
Россия:
ТД «Рус Энержи К&С»
129090, г.Москва, про-
спект Мира, д.19, стр.1,
эт.1, пом.1, комн.6б, офис
99В
www.ks-power.ru
CONTACTS
Table of contents
Other K&S BASIC Inverter manuals
Popular Inverter manuals by other brands

Quantum Harvest
Quantum Harvest 2500 Series owner's manual

Advanced Energy
Advanced Energy AE 600 user manual

SEW-Eurodrive
SEW-Eurodrive MOVIDRIVE system product manual

HiQ Solar
HiQ Solar TrueString TSXL380-8k-VN Installation & operator's manual

DeWalt
DeWalt DXGNI 2500 instruction manual

Teledyne
Teledyne T3AFG5 Series user manual
