KAP Trader PCM 5.0 TDC3 User manual

INSTRUCTION
MANUAL
CONTACT
W kaptrader.com
E [e-mail]
A (05854) A-912 RM Tera-tower2, 201
Songpa-Dearo, Songpa-gu, Seoul, Korea
F ([phone]
DATA.
Video Interface and Wireless CarPlay & Wired Android Auto
PCM 5.0 TDC3
2021.04.28
VW TOUAREG ONLY INTERFACE

INSTRUCTION MANUAL
CAR COMPATIBILITY SHEET
BRAND MODEL SCREEN YEAR
Volkswagen Touareg
15˝ 2019~
9.2˝ 2018~

INSTRUCTION MANUAL
COMPONENT
▶Warning
Please contact your dealer if any component is missing.
▶Warning
Please contact your dealer if any component is missing.
KPLAY KPLAY POWER CABLE HDMI CABLE
MIC WIFI/BLUETOOTH
ANTENNA AUX CABLE
INTERFACE POWER CABLE LVDS CABLE
A/V CABLE RGB NAVI CABLE OSD BOARD

INSTRUCTION MANUAL
INTERFACE SPEC
1KPLAY INPUT
•Wireless APPLE CARPLAY
•Wired APPLE CARPLAY
•Wired ANDROID AUTO
•USB storage media
2INPUT
•1 x DIGITAL RGB IN (HDMI PORT)
•1 x ANALOG RGB IN (7PIN)
•2 x CVBS AUDIO/VIDEO IN
•1 x CVBS FRONT CAM IN
•1 x CVBS REAR CAM IN
•1 x LVDS IN CAMMAND SYSTEM
3OUTPUT
•2 x CVBS VIDEO OUT
•1 x CVBS AUDIO OUT
•1 x LVDS OUT OPERATION
5POWER
•Input Power : 8VDC ~ 24VDC
•Consumption Power : 12Watt, Max
6SWITCH INPUT MODE
•Possible to select CAR model while switching mode by DIP S/W
•By button on the Commander in the car via CAN
4TOUCH
•VIRTUAL ANALOG TOUCH (4PIN)
•UART DIGITAL TOUCH

INSTRUCTION MANUAL
EXTERNAL DEVICE SPECIFICATIONS
3 4 5 6
7 8 9 10 11
2LVDS IN 1LVDS OUT
5PROGRAM 6LED
7POWER/CAN 8RESISTIVE TOUCH 9DIGITAL RGB 10 ALNALOG RGB
11 AUDIO/VIDEO
Interface error
check
4PIN Touch
REAR CAMERA IN
FRONT CAMERA IN
DVB-T or DVD IN
CVBS OUT
1 2
4IMAGE 3DIP SWITCH
OSD connection
NAVI IN

INSTRUCTION MANUAL
DIP SWITCH SETTING
PIN FUNCTION
INFORMATION
▲OFF ▼ON
1NAVIGATION USE Do not use
2AV1 (DVB-T) USE Do not use
3AV2 (DVD) USE Do not use
4No function
5
Car Type
6
7
8
ON 1ON 1
2 2
3 3
ON 5 6 7 8
VOLKSWAGEN (2019)
Touareg -15"
ON 5 6 7 8
VOLKSWAGEN (2019)
Touareg -9.2"

INSTRUCTION MANUAL
No PORT INFORMATION
1POWER
/CAN
2TOUCH
3RGB
NAVI
No. Color Signal Assignment No. Color Signal Assignment
1Red ACC 2
3Brown REAR DET 4Blue FRONT DET
5White CAN LOW 6Purple CAN HIGH
7Blue CAN LOW 8Red CAN HIGH
9Green CAN LOW 10 Orange CAN HIGH
11 12 Red REAR VCC
13 Red FRONT VCC 14
15 Black GND 16
CONNECTOR PIN ASSIGNMENT
1 3 5 7 9 11 13 15
2 4 6 8 10 12 14 16
1 2 3
No. Color Signal Assignment
1Red Y-
2Green X-
3Blue Y+
4White X+
1 2 3 4
No. Color Signal Assignment
1Red R DATA
2Green G DATA
3Blue B DATA
4White SYNC
5Black GND
6Green DVB-T IR
7 Orange DVD IR
1 2 3 4 5 6 7
1
2
3

INSTRUCTION MANUAL
EXTERNAL DEVICE SPECIFICATIONS
1 2 3
4 5 6 7 8
1DIP SWITCH 2DIGITAL 3POWER
4USB 5MICROPHONE 6RESISTIVE TOUCH 7SPEAKER
8WIFI/BLUETOOTH ANTENNA
4PIN TouchSmartphone
USB storage

INSTRUCTION MANUAL
KPLAY CONNECTOR PIN ASSIGNMENT
1 2 3
No PORT INFORMATION
1DIP
SWITCH
2POWER
3TOUCH
No. Color Signal Assignment
1Red ACC
2Black GND
1 2
1 2 3 4
1
2
3
No FUNCTION
1800x480
Resolution
21280x480
Resolution
ON 1 2
ON 1 2
▶Warning
DIP switch No. 2 has no function
No. Color Signal Assignment
1Black Y+
2Green X+
3White Y-
4Red X-

INSTRUCTION MANUAL
KPLAY CONTROL
MAIN SCREEN
1 2 3 4
1APPLE CARPLAY 2ANDROID AUTO 3USB MEDIA 4SETTINGS
VIDEO
MUSIC
IMAGE
Wireless
Cable
Cable
Apple CarPlay –800 x 480
Apple CarPlay –1280 x 480
Android AUTO –800 x 480
Android AUTO –1280 x 480

INSTRUCTION MANUAL
KPLAY CONTROL
SETTINGS
No INFORMATION SELECTION FUNCTION
1Language
settings Languages You can change the language of the settings screen
2Connection
settings
Auto Phone
Connect
(Only for wired
connection)
Activation Automatically launch Android AUTO or Apple CarPlay
when smartphone is connected
Disabled Charge only when connecting a smartphone, select icon
to launch Android AUTO or Apple CarPlay
Driver Position
Left Use when driver's position is left
Right Use when driver's position is right
Wireless
Carplay
Activation Connect Apple CarPlay wirelessly
(Bluetooth)
Disabled Used to wire Apple CarPlay
Use touch on
Android Auto
Activation Touch is available when running Android Auto
Disabled Touch not available when running Android Auto
Link Type
Android Android Auto
Carlife do not select
(Update Coming Soon)
3Firmware
Information
Reset Factory reset
Sys Update Update firmware using USB
1
2
3
1
2
3

INSTRUCTION MANUAL
KPLAY CONTROL
MEDIA CONTROL
KPLAY
TOUCH SPK ANT
POWER DIGITAL DIP_S/W
MICUSB
APPLE
CARPLAY
Smartphone
connection
Connect AUX to your car and use KPLAY's microphone
No INFORMATION Can be used CONTROL NOTICE
1Apple
CarPlay
Wireless
connection
Use all
Apple CarPlay
Functions
•AUX
•MIC
•TOUCH
•Multiple connections are not supported
•Only one device can be connected
unconditionally
Cable
Connection
2Android
AUTO
Cable
Connection
Use all
Android AUTO
Functions
3USB Media Connection Music, Photo,
Video
USB Media
ANDROID
AUTO
or

INSTRUCTION MANUAL
KPLAY CONTROL
iPhone Wireless connection -Connection method
1. Activate Wireless Carplay in KPLAY Settings
Menu
(If Wireless Carplay is enabled, you cannot
connect by wire)
2. Choose CarPlay-BT in Bluetooth on iPhone
3. PIN Number “0000” enter 4. “Allow” select
5. “Use CarPlay” select
(Once connected, Bluetooth will be
disconnected and connected via Wi-Fi)
6. Enjoy CarPlay!
In KPLAY on iPhone
on iPhoneon iPhone
on iPhone In KPLAY

INSTRUCTION MANUAL
KPLAY CONTROL
If your iPhone fails to connect
Forget Bluetooth history
1. Make sure Siri is active
2. Delete the Bluetooth and CarPlay records as shown below,
3. disable and re-enable WiFi and Bluetooth, then try to connect again.
Forget CarPlay History
▶Warning
Due to the nature of the wireless connection, sometimes the connection is not working
properly
If you follow the same procedure as above, but the connection is not working properly,
reboot KPLAY and iPhone and try again

INSTRUCTION MANUAL
KPLAY CONTROL
If your Android Phone fails to connect
▶Warning
Android Auto may not run even if the cable is not broken
If you follow the same procedure as above, but the connection is not working properly,
reboot KPLAY and iPhone and try again
ANDROID AUTO APP Download
1. Check if your smartphone has ANDROID AUTO application
2. Replace the cable
Changing the cable

INSTRUCTION MANUAL
FIRMWARE UPDATE
1. Add the firmware file provided in root folder
* of the USB
3. Select 'Sys Update' from the Settings menu
2. Connect USB to the KPLAY board with the
update file. The USB media will be scanned
automatically
Press the Home button on the top right
corner of the USB Media screen and select
the Settings menu
4. After the device reboots, check the
message and wait for the update to complete.
firmware files
Root folder
*Root folder : Top-level folder without adding folder
▶Warning
If USB with firmware is connected, the update will be performed every time the device is
rebooted

INSTRUCTION MANUAL
BUTTON CONTROL
CHANGE MODE TO INTERFACE SCREEN
VIEW
BUTTON OPERATION FUNCTION
VIEW LONG PRESS OEM screen to interface screen
Interface screen to the OEM screen
▶Warning
Screen change sequence : OEM > NAVI > AV1 > AV2 > OEM

INSTRUCTION MANUAL
PARKING CONTROL
FrontCam Rcv Option
1FrontCam-RcvOpt : ON (1 -30s)
MENU Option NAVI
Config FronrCam-RcvOpt 30s
Option
Screen
Parking
OEM or
Interface Screen
REAR
Camera
Screen
FRONT
Camera
Screen
OEM or
Interface
Screen
Displays the front camera
screen for the set time
(1 -30second)
2FrontCam-RcvOpt : OFF (0s)
MENU Option NAVI
Config FronrCam-RcvOpt 0s
Option
Screen
Parking
OEM or
Interface Screen
REAR
Camera
Screen
FRONT
Camera
Screen
OEM or
Interface
Screen

INSTRUCTION MANUAL
PCM5.0 TDC3
POWER/CAN TOUCH DIGITAL NAVI A/V
LED IMAGE DIP_S/WPROGRAM LVDS-IN LVDS-OUT
HDMI
No.1 -▲OFF
CONNECTION DIAGRAM
KPLAY
ON 1 2 3 4 5 6 7 8
ON 12
KPLAY
POWER DIGITAL DIP_S/W
USB MIC TOUCH SPK ANT
MENU Option NAVI
Config NAVI-RGB DIGITAL-KPLAY
Option DVB-T (DMB)
Image DVD
Screen RearCam
Parking FrontCam
MENU Option NAVI
Config NAVI-COM KPLAY
Option Reset
Screen
Parking
※Please set in the OSD menu
ON 12
Speaker Microphone
WiFi/BT
Antenna
Smart
Phone
800x480
1280x480
HDMI

INSTRUCTION MANUAL
Touch Cursor To Calibrate
+ Touch
Touch and hold for 10 seconds
INSTALL MANUAL
KPLAY TOUCH
KPLAY
POWER DIGITAL DIP_S/W
USB MIC TOUCH SPK ANT
HDMI
HDMI
MENU Option NAVI
Config NAVI-COM KPLAY
Option Reset
Screen
Parking
※TOUCH CALIBRATION (IN KPLAY)
Touch and hold anywhere on the screen for 10 seconds
Touch in the center of the "+" icon
PCM5.0 TDC3
POWER/CAN TOUCH DIGITAL NAVI A/V
LED IMAGE DIP_S/WPROGRAM LVDS-IN LVDS-OUT
