Karakoram Prime Splitboard System Quick setup guide

Patented US8469372B2, US8733783B2 and Patents Pending
2x Bindings (L and R)
4x Solid-Ride Plates
2x Tour Modes
2x Toe Attachments
6x
M6x10mm Buttonhead Screw
Tour Mode
4x for Flip-Speed Riser
6x extra for Tour Mode with thin core boards
M6x10mm Flathead Screw
8x
Ride Mode
M6x7mm Buttonhead Screw
4x
Toe Attachments
Heel Attachments
M6x14mm Buttonhead Screw
4x
10x
M6x8mm Buttonhead Screw
2x Dual-Speed Risers
with Heel Lockdown
2x Heel Attachments
Prime Splitboard System
Assembly and Use Instructions
Tools:
-M4 Allen Wrench
(Binding Hardware, Interfaces)
-M3 Allen Wrench (Highback Fwd Lean, Heel Lever Size Adjustment)
-Cresent Wrench or 8 mm socket
(Heel Lever Size Adjustment)
Hardware:
Size Chart:
Small: 6-8
Medium: 8.5-11
Large:11.5-13
Women's: W6-W8
Scan QR Code for
video instructions or visit
www.splitboardbindings.com
PAGE 1 OF 6
Prime Instructions_A04

M6x10mm Buttonhead Screw
Use M6x8mm Buttonhead
for thin core boards
Production Splitboard Installation
1.
2.
M6x10mm Flathead Screw
8x
.5in
.5 in
Center
4x
M6x8mm Buttonhead
Screw
6x
PAGE 2 OF 6
Prime Instructions_A04

M6x14mm Buttonhead Screw
4x
Heel Attachments
Toe Attachments
M6x7mm Buttonhead Screw
4x
10° 20° 30°
Toe Attachment
Heel
Attachment
R
3.
Tighten Toe Attachment to 1.
desired angle
(hash marks in 5° increments)
Leave Heel Attachment loose 2.
Mount Binding to align Heel Attachment 3.
Tighten screws on Heel Attachment 4.
PAGE 3 OF 6
Prime Instructions_A04

SMALL POSITION
LARGE POSITION
Only adjust if binding is too tight to
mount to Ride Mode or if binding is
loose on ride mode.
!
Loosen Toestay screws 1.
Adjust Toestay fore/aft as desired 2.
Tighten Toestay screws 3.
5. Binding Adjustment
22°
11°
10°
11°
0°
0°
4a. Binding Size Adjustment- PRIME SL
Size Setting:
S: 6-7
M:8.5-9.5
L: 11.5
W: W6-W7
Size Setting:
S: 7-8
M:9.5-11
L: 12-13
W: W7-W8
Forward Lean Adjustment:
Bindings come set
at 11°/18° fwd lean
USE 4b. for Prime-X
and X-Carbon
PAGE 4 OF 6
Prime Instructions_A04

LARGE POSITION
SMALL POSITION
(Bindings come in this position)
To shift bindings to LARGE POSITION:
Remove six Forward Screws A.
Loosen two Rear Screws B.
Slide Heelstay forward C.
Shift Toestay forward D.
Reinstall Forward Screws in LARGE POSITION E.
Tighten all Screws F.
Forward Screws
Rear Screw
(Under rubber pad)
Heelstay
Toestay
4b. Binding Size Adjustment- PRIME-X and X-Carbon
PAGE 5 OF 6
Prime Instructions_A04

V
Toe Pins
0° Rise
Heel Lock
Slide basket
under here
Short 12° Rise
Tall 20° Rise
Prime Splitboard System Use Instructions
Attach binding to Ride 2.
Mode, aligning Toe Pins and
Ride Mode Toe Attachment
Close Heel Lever and Safety 3.
Ride Mode:
Open Heelcup Lever 1.
Dual-Speed Riser:
Operation:
Slide basket of ski pole under tall riser to flip up 1.
Flip riser to short position or long position with tip of ski pole 2.
Lower riser by pushing on tall riser towards tail of ski 3.
Heel Lock Operation:
Flip Heel Lock up 1.
Close Heelcup Lever to 2.
engage pins with Heel Lock
PAGE 6 OF 6
Prime Instructions_A04
