Karat CEDAR K-31147X User manual

TWO-PIECE TOILET WITH SEAT
K-31147X
CEDAR
Specied Model
Features
• Vitreous china
• Elongated bowl
• Includes gentle close seat
• Includes polished chrome trip lever
• Siphonic wash-down flushing system
• 3.75 liter per flush
• 305 mm rough-in for S-trap
• 702 x 374 x 762 mm
Codes/Standards Applicable
Specied model meets or exceeds the following:
• ASME A112.19.2/CSA B45.1
• TIS 792-2554
Page 1/2
1363727-X4-A
Call Center:
0-2700-9299
kohler.com
Model Description Color/Finished
K-31147X-S Cedar two-piece toilet, S-trap with elongated gentle close seat WK: Diamond White
Product Diagram
Technical Information
Installation Notes
Install this product according to the installation guide.
Fixture:
Conguration two-piece, elongated
Water per flush 3.75 liter
Passageway 51 mm
Water area 140 x 117 mm
Water depth from rim 201 mm
Seat post hole centers 140 mm
Included Components:
Bowl K-17286K
Tank K-20985X-LT
Tank cover 1340773-SP
Elongated gentle close seat K-98101X
Dimensions are approximate.
Unit: mm
Note: The recommended dimension for installation can be adjusted according to user preferences and layout.
1/2" Supply
C
L of Outlet
Front of bowl
305
380
130
200
470
282 350
265
158
358
376
140
13 184
702
374
762



1/2"
ดานหนาโถสุขภัณฑ

305
380
130
200
470
282 350
265
158
358
376
140
13 184
702
374
762

K-31147X



• 
•
•
•
•
•
•
•


•
•

1363727-X4-A
ูก้าัมัน์/Call Center: 0-2700-9299
kohler.com





 
 
 
 



 
 
 
 
 
  
  



©2021 Kohler Co.
1061234-X2-H
ข้อสังเกต:



NOTE: Do not recommend to apply with white
cement or high lime content to install this toilet.
The expansion of cement due to a rise in
temperature may make the toilet crack or cause
damage. Kohler is not responsible for any damage
cased by installation with the use of cement.
ข้อสําคัญถึงผู้ติดตั�ง! 

ข้อสังเกต: อุปกรณ์สําหรับการติดตั�งบางชิ�น

ข้อสังเกต:


CAUTION: Turn on the water and allow water
to flow through the supply pipe to flush the
system of any debris before connecting fill valve.
ข้อควรระวัง:

IMPORTANT NOTICE TO INSTALLERS!:
Please leave these instructions for the
consumer. Please retain for future reference.
NOTE: Some installation parts might not be
provided.
NOTE: The toilet pictured in the installation
steps may differ from the model being installed.
Installation and Care Guide
ขอแนะนําการติดตั้งและการดุแลรักษา
K-2960X, K-6357X, K-12240K
K-12449K, K-12449X, K-17386K
K-17386X, K-17475X, K-31147X
K-37389X, K-45311X, K-98118X
K-98121X, K-99292X, K-99294X
K-22630X
Do not overtighten!
อย่าขันแน่นจนเกินไป!
1/2"
Supply Hose

Adapter
15/16" to 1/2"
(Optional Part)
Make the center of anchoring holes and
waste pipe on the floor.
Insert anchors. Install the bowl on the floor.
Connect supply and turn on the water.
Flush several times and check for leaks.
Turn the tank upside down and
place the gasket to the tank.
Install the tank onto the bowl.
Install the tank lid and the seat.
1
4 5 6
2 3


 





305
3/8"
Anchor
 Bolt/
Nut/
Sleeve/

Anchor/ 
* อุปกรณ์ประกอบอาจไม่รวมอยู่ในชุดสุขภัณฑ์
The component is not include in the product


 
 


 
 
 
 
 
    
 




 
 

   
 

 
 
 
 

 
 
 

 


 

 
Symptoms Recommended Action
1.Poorush. A. Adjustthetankwaterleveltomatchthewaterline.
B. Fullyopenthewatersupplyshut-ovalve.
C. Clearobstructionsfromthetrapway,jet,orbowlrimholes.
D. Clearobstructionsfromthewasteline.
2.Noush. A. Reconnectthechaintothetripleverorushvalve.
B. Adjustthechainassemblytoremoveexcessiveslack.
3.Thellvalve
turnson/oby
itselfwithout
thetoiletbeing
ushed,orit
runs,allowing
watertoenterthe
tank.
A. Adjustthechainforproperslacksothesealisnotheldotheush
valveseat.
B. Cleanorreplacetheapperifitisworn,dirty,ormisalignedwith
theushvalveseat,oriftheushvalveseatisdamaged.Replace
theushvalvesealorushvalve.
C. Cleanthellvalveseatandseatwasherofdebris,orreplacethe
piston/seatwasherassembly.
D. Removethetankandtightentheushvalvenutifushvalvegasket
isleaking.Donotovertighten.Ifleakagecontinues,replacethegasket.
E. Replacethellvalveifthevalveoatsinks.
F. Adjustthetankwaterlevelifitistoohigh.
4.Tanktakes
excessivetime
toll.
A. Fullyopenthewatersupplyshut-ovalve.
B. Checktheexiblesupplyline(ifapplicable)forakink.Removethe
kink.
C. Cleanthevalveinlet,valvehead,orsupplyline.Flushthelines.
5.Thereisexcessive
noisewhenthe
tankislling.
A. Partiallyclosethewatersupplyshut-ovalveifthewaterpressure
tothetoiletistoohigh.Checkthetoiletperformancefollowingany
suchadjustment.
B. Removedirtorobstructionsfromthevalvehead.Flushthelines.

KARAT Limited Warranty

Care and Cleaning Troubleshooting
  
 
   
   
   
  
  

•  
•  
•  
  
  

 
  


   






 
     


For best results, keep the following in mind when
caringforyourproduct:
• Carefullyreadthecleanerproductlabeltoensure
thecleanerissafeforuseonthematerial.
• Alwaystestyourcleaningsolutiononaninconspicuou s
areabeforeapplyingtotheentiresurface.
• Wipe surfaces clean and rinse completely with
waterimmediatelyaftercleanerapplication.Rinse
and dry any overspray that lands on nearby
surfaces.
• Donotallowcleanerstositorsoakonthesurface.
•Useasoft,dampenedspongeorcloth.Neverusean
abrasivematerialsuchasabrushorscouringpad
tocleansurfaces.
• Becarefulnottoleavestainingmaterialsincontact
withthesurfaceforextendedperiodsoftime.
• Theidealcleaningtechniqueistorinsethoroughly
and blot dry any water from the surface after
eachuse.
 

•

•
 

• 
 

•
• 

•
• 

Kohler (Thailand) Public Company Limited warrants to the original products,
whicharepurchasedfromauthorizeddistributorsanddealerswithinKingdomof
Thailandonly,tobefreeofdefectsinmaterialandworkmanship.
Withinthebelowmentionedperiodsfromthedateofpurchase,Kohler(Thailand)
PublicCompanyLimitedwillatitselection,repair,replaceormakeappropriate
adjustment where company’s inspection discloses any such defect occurring in
normalusageandmaintenancebutisnotresponsibleforlaborcharges,removal
charges,installation,orotherincidentalorconsequentialcosts.Innoeventshall
theliability ofKohler(Thailand) PublicCompany Limitedexceedthe purchase
priceoftheproduct.
 • Barewaremadefromvitreouschina LifetimeLimitedWarranty
 • Tanktrimsandaccessories One(1)Year
 • Toiletseatandcover One(1)Year
ThislimitedwarrantyDOESNOTCOVERthedefectordamagefrommisuseor
abuse of products, wrong installation, accidents, natural disasters such as re,
ood,orearthquake.Consumersareresponsibleforthecostofservicepartsand
servicefeeforsuchcases.
Toensurecontinuousproductqualityandperformance,aswellasproductdurability
and lifetime, without any damage to the product, consumers should purchase
anduseonlygenuineservicepartsandafter-salesservicesfromKohler(Thailand)
PublicCompany Limitedor company’sauthorized servicecenters,distributors,
ordealersonly.
Toobtainwarrantyservice,pleasecontactyourdealersorcontacttheKOHLER
CallCenter,togetherwithproofofpurchaseat:
CallCenter,Kohler(Thailand)PublicCompanyLimited
16thFloor,JasmineCityBuilding,2SoiSukhumvit23,SukhumvitRoad
Waana,Bangkok10110
Tel:0-2700-9299Email:[email protected]
Remarks:
1. There may be variation in color delity between catalog images and actual
products.
2. Kohler(Thailand)PublicCompanyLimitedreservestherighttomakechangesin
productcharacteristics,packaging,oravailabilityatanytimewithoutnotice.
COPYRIGHT©2018BYKOHLER(THAILAND)PUBLICCOMPANYLIMITED.
WARNING: Risk of property or product
damage.Donotusein-tankcleanersinyour
toilet. Products containing chlorine (calcium
hypochlorite) can seriously damage ings
inthetank.Thisdamagecancauseleakage
andpropertydamage.
 

 

  

