KARUIZAWA KHE2016 User manual

Ceramic Heater
User Manual
MODEL: KHE2016
*Before operating the appliance, please read this
manual and all the safety instructions thoroughly and
retain it for future reference.

CONTENT
PAGE
SAFETY INSTRUCTION
1
PRODUCT FEATURES
3
PARTS DESCRIPTION
3
OPERATION INSTRUCTION
4
MAINTENANCE INSTRUCTION
7
SPECIFICATION
7
WARRANTY
8

1
SAFETY INSTRUCTION
1. To avoid electric shock, fire or injury, please read the user manual carefully before using the
appliance and keep it for future reference.
2. This appliance is for household use only. Please use suitable power source. (Please refer to
SPECIFICATION)
3. Never immerse the appliance in water or other liquids.
4. Do not use the appliance under direct sunshine.
5. Please turn off the appliance when not in use otherwise it may result in danger.
6. Please turn off the appliance and unplug the socket when unattended otherwise it may result in
danger.
7. Keep the appliance away from children.
8. This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
9. Children of less than 3 years should be kept away unless continuously superivsed.
10. Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided
that it has been placed or installed in its intended normal operating position and they have been
given supervision or instruction concerning use of the appliance in a safe way and understand the
hazards involved. Children aged from 3 years and less than 8 years shall not plug in, regulate and
clean the appliance or perform user maintenance.
11. With any indication of damage or malfunction, please stop using the appliance immediately to
avoid hazards. Take it to the authorized service center for repair. Do not attempt to repair or
change any parts by yourself.
12. If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid hazards.
13. Please turn off and unplug the appliance before cleaning or maintenance.
14. Clean the surface of the appliance with dry cloth. Do not use corrosive detergent or solvent to
clean. Do not swash the appliance with water.
15. Please turn off and unplug the appliance when not in use. Make sure the power is off before
pulling out the plug and do not pull the cord.

2
16. When the appliance is not in use for a prolonged period, please turn it off, unplug it, pack it well
and store it in dry cool place.
17. Forbid to put flammable and explosive objects around the appliance, and do not use the appliance
in an environment full of flammable gas and powder. Keep away from any fire and heat sources.
18. Please put the power cord in the right place in order to avoid tripping the appliance over.
19. Do not put any objects on the appliance and put the appliance immediately below a socket-outlet.
20. Do not touch the air outlet when operating.
21. Please keep the air inlet and the air outlet unblocked to minimize the risk of fire or malfunction.
22. Do not let the power cord touch or near the air outlet. It will damage the insulation layer of wires.
23. Please operate the appliance on a firm and level desk or floor. Do not use the appliance in the
immediate surroundings of a bath, a shower or a swimming pool.
24. Ensure no water or raindrop leaks into the appliance in order to avoid electric shock. Do not put
flammable objects or wet clothes on the air outlet in order to avoid short circuit or fire.
25. Please do not place the air inlet or the air outlet near to curtains or walls when operation because
it will block the air current and cause fire. The appliance should be installed at minimum distant
of 10 cm from the wall or other obstacles.
26. Please do not insert any objects into the air inlet or the air outlet in order to avoid electric shock.
27. After a period of operation, abnormal noise and uneven air volume may appeared because of dust
blocking the airflow. It will disappear after cleaning the back net.
WARNING: In order to avoid overheating, do not cover the appliance with anything,
especially flammable materials, such as clothes or paper.
CAUTION: In order to avoid hazards due to inadvertent resetting of the thermal cutout,
this appliance must not be supplied through an external switching device, such as timers,
programmers, separate remote-control system or connected to a circuit that is regularly
switched on and off by the utility.
CAUTION: Some parts of this product can become very hot and cause burns. Particular
attention has to be given where children and vulnerable people are present.

3
PRODUCT FEATURES
2 heating power options: High (1800W) / Low (900W)
LED display
ECO function
Oscillation function
Room temperature setting: 15〬C to 30〬C
Timer off: 1-12 hours
Overheat protection
Tip-over protection
PARTS DESCRIPTION
①Control panel
②Front cover
③Base
④Handle
⑤Back net
⑥Power switch
➁
➀
➂
➃
➄
➅

4
CONTROL PANEL
Note: The fan of the heater will keep operating for 1 minute after switching off the appliance to
cool down the internal components.
ON/OFF Button
+ Button
LED Display
Timer Button
- Button
Oscillation Button
Mode Button
ON indicator
High heating indicator
Timer indicator
ECO indicator
Low heating indicator
Oscillation indicator

5
OPERATION INSTRUCTION
Power Switch
Connect the power plug to the correct socket outlet.
Press the power switch to the “I” position, you will hear a “beep” sound, and the LED display will be
on. The heater is ready to use. Press the power switch to the “O” position to turn off the power of the
heater.
ON/OFF Button ( )
Press the ON/OFF button, the heater will start operation at high heating power. The high heating
indicator will be on, and the LED display will show the pre-setting temperature 30∘C. Press the
ON/OFF button again, the heater will be off in 1 minute.
Mode Button ( )
Press the mode button to change the high heating/low heating/ECO mode during operation, the
indicators will be on according to the selection.
ECO Mode
When the room temperature is lower than 20∘C, the high heating mode will be on; when the room
temperature is 20∘C or higher than 20∘C, the low heating mode will be on.
Temperature Setting (Not applicable in ECO mode)
Press the “+” or “-” button to adjust the temperature with the range of 15-30〬C during operation.
The temperature will be added or reduced by 1〬C for each press of the “+” or “-” button. After
completing the setting, the display will be flashing for 10 seconds and the set temperature will be
shown.
Note: If the room temperature reaches the set temperature, the heater will be OFF. Once the
room temperature is lower than the set temperature for around 3-4〬C, it will be ON again.

6
Oscillation Button ( )
Press the oscillation button to activate the oscillation function. The oscillation indicator will be on.
Press the button again, the oscillation function will be stopped and the oscillation indicator will be off.
Timer Button ( )
Press the timer button during operation, the display will show “00”. The timer indicator will be on.
Press the timer button again to set the auto timer off. The timer will be added 1 hour for each press of
the timer button. After completing the setting, the display will be flashing for 10 seconds and the set
temperature will be shown. The timer setting range is 1-12 hours.

7
CLEANINGAND MAINTENANCE
1. Please turn off, unplug and cool down the appliance before cleaning or maintenance.
2. Clean the surface of the appliance with dry cloth. Do not use corrosive detergent or
solvent to clean. Do not wash the appliance with water.
3. Use vacuum cleaner to remove any dusts on the air inlet/outlet.
SPECIFICATION
Model No.
KHE2016
Product name
Ceramic Heater
Rated Voltage/Frequency
220-240V~, 50Hz
Rated Power
Low (900W) / High (1800W)
Dimensions (WxHxD)
215 x 120 x285 mm

8
WARRANTY
1. The product has 1 year warranty from the date of purchase.
2. The warranty shall not apply:
A. to any product subjected to misuse, alteration, act of God, improper handling, improper
transport, improper testing or unauthorized repair;
B. to cosmetic problems or defects which result from normal wear and tear under ordinary
use yet not affecting the performance or use of the product;
C. if the product is disassembled or altered;
D. to any packing, transportation, export / import tax or any related expenses.
3. CUSTOMER MUST PRESENT THE SALES INVOICE OR RECEIPT FOR 1 YEAR
WARRANTY SERVICES.
4. Please bring along the product and sales invoice or receipt to our services center for warranty
services during office hour:
Address : Unit A, 20/F, Yip Shing Industrial Centre, No.19, Yip
Shing Street, Kwai Chung.
Service Hotline : [phone]
Service Hours:
Monday-Friday :9:00am - 6:00pm
Saturday :9:00am - 4:00pm
Sunday & Public Holiday :Closed
NOTES
This appliance must be plugged into a specific 220-240V socket. Please make sure the plug is
fully plugged-in before use. Do not use any adapter or extension cord.
This appliance is a high energy consumption product, please do not use with other high energy
consumption product into the same supply socket.
THE APPLIANCE IS FOR HOUSEHOLD USE ONLY.
ENVIRONMENT
Do not throw away the appliance with the normal household waste at the end of its life, but hand it
in at an official collection point for recycling. By doing this, you help preserving the environment.
IMPORTANT NOTICES
IN NO EVENT SHALL OUR COMPANY OR THE SUPPLIER BE LIABLE TO YOU OR ANY
OTHER PARTY FOR ANY DIRECT, INDIRECT, GENERAL SPECIAL, INCIDENTAL,
CONSEQUENTIAL, EXEMPLARY OR OTHER DAMAGES ARISING OUT OF THE USE OR
INABILITY TO USE THE PRODUCT (INCLUDING, WITHOUT LIMITATION, DAMAGES FOR
INJURY, LOSS OF PROPERTY, BUSINESS PROFITS, BUSINESS INTERRUPTION) OR FROM
ANY BREACH OF WARRANTY, EVEN IF OUR COMPANY OR SUPPLIER HAS BEEN
ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. IN NO CASE SHALL OUR COMPANY
OR SUPPLIER’S LIABILITY EXCEED THE AMOUNT YOU PAID FOR THE PRODUCT.
Specifications, designs and dimensions are subject to change without prior notice.
