Katie Barnes Training Academy KB PORTABLE E-FILE User manual

KB PORTABLE E-FILE
INSTRUCTION MANUAL

CONTENTS
Control box
Hand piece
Hand piece lid
Connection cable
Charging cable
Cleaning cloth
Control box storage
Hand piece storage
Bit storage
Storage box

On, off, pause button1.
On, off, pause button 1.
3. Connector 2. Forward / Reverse
7. Dial speed
regulation
4. Hand piece
5. Hand piece lid
3. Connector
8. USB-C socket
9. USB socket 3. Connector
6. Display screen

Input
voltage
Battery
voltage
Battery
capacity
Wattage
Torque
Speed
DC5V 2A
DC7.4V
4000mA
35W
2.8Nm
up to 40,000RPM
DIMENSIONS
LENGTH
20mm
141mm
PRODUCT DETAILS
LENGTH
BATTERY
Charge time: 1.5 - 2 hours from empty
Battery life: 6 - 8 hours (after full charge)
May arrive with no charge and needs
charging before use.

On off, pause button
Hold down for 2 seconds to turn on.
If this does not turn on, check charge.
Will show speed on 6. display screen.
It will display the last used speed after power on.
Press once for 1 second whilst on to pause.
Press again to resume. Will resume the paused speed.
Hold down for 2 seconds to turn off.
This will be turned off when the screen no longer has a
display. If it shows a display, it will only be paused.
The default rotation is forward "F" when power on. To change
this, press the "R" button to change the rotation direction to
Reverse. Use forward for right handed, reverse for left handed.
1.
2. Forward / reverse direction
3. Connector
Connects the hand piece to the control box. Remove cable
connection when not in use.
4. Hand piece
Remove safety piece - this is just for travel. Twist to left once until
you hear a click all the way to the padlock to open chuck. Place
your efile bit. Twist to the right once until you hear a click to close
the chuck. Make sure the dot lines up with the padlock symbol.
open locked

5. Hand piece lid
Remove lid, replace when not in use. Do not force on.
6. Display screen
Will display the speed and battery life. Will display with last used
speed after power on. Has a memory function.
If power grid flashes, the e-file is out of power and needs
charging. It will arrive with no power.
If the power grid displays a full grid, the battery is fully charged.
Will also display direction rotation.
7. Dial speed regulation
Turn the dial clockwise to increase the speed, turn
counterclockwise to decrease the speed.
8. USB-C Socket
Place USB-C into the USB-C socket and the USB into powersource
to charge your e-file. This can be any USB power source including
power bank, mains plug, laptop and so on. The KB Portable E-File
doesn't come with a mains plug to allow for it to be used and
powered internationally.
9. USB Socket
USB allows you to power or charge an external device from your e-
file such as smartphone, KB Glow, USB light.

PRECAUTIONS
Do not lift and manoeuvre the e-file from the dial - this can
cause damage to the dial. Clean the hand piece before use.
Do not push a bit in with dust on the opening.
Replace the lid when not in use.
Do not disassemble the hand piece.
Do not work in wet or humid environment.
Do not use when charging.
Make sure that your bit is securely fastened into the chuck
before turning on.
Do not force bits in.
Do not try and force bits out or bend.
When the machine is in use, do not change or remove bits
without first pausing or turning off.
Do not touch rotating parts with your hand.
Do not force lid into the storage slot.
Take care when opening the storage box whilst e-file and
hand piece is being stored in storage slots. Always hold
and support when opening.
Do not clean with liquid solutions - keep clean with dust
cloth, canned air.
Do not submerge the handpiece in water.
Avoid water.
Do not use damaged wires.
Do not charge unattended.
Do not charge for longer than necessary.
If a bit is stuck in the chuck, do not try to prise it out.
If dropped or damaged get the machine checked by a
professional or get in contact with us before trying to rectify
yourself.

During use
Place the e-file control box into the designated slot at a 90 degree angle. Do not angle
the e-file too far back otherwise it will be top heavy.
Use storage box when not in use.
The control box, hand piece and wires should be stored inside the storage
box when not in use for best protection.
When not in use
STORING YOUR E-FILE
Place the handpiece in the lid.
Hold the lid at a 90 degree angle, twist left, then twist right and the lid will slot in.
This is to keep it secure.
You can put the lid in first, then your hand piece.
twist left twist right

WARRANTY
The warranty is limited to the valid warranty period under
normal use.
If the machine has a fault within one year from the date of
purchase, your machine will be replaced or repaired,
whichever is applicable to the fault.
You must provide proof of purchase to validate the
warranty.
WARRANTY EXCLUSIONS
Unauthorised maintenance, dismantling, misuse, damage,
drops, knocks, liquid injection and modification.
The issue arises from improper use and care.
The serial number or any other certification has been
altered.
It is not used and maintained in accordance to the
manufacturers instructions.
Damage caused by force majeure but not limited to flood,
fire, lightening.
Theft or loss.
Cannot prove purchase.
Has been purchased second hand or third party.
The following invalidate your warranty and a replacement or
repair will be your responsibility:

For any queries, concerns or warranty requests, contact:
[email protected]
Katie Barnes Tool Range
C/O Montague Storage LTD
Montague Road
Warwick
CV34 5LW
