Kaysun KPD-35 DR12.1 User manual

IMPORTANT NOTE:
Read this manual carefully before installing or operating your new air conditioning
unit. Make sure to save this manual for future reference.
OWNER'S MANUAL
Duct A6 Type
KPD-35 DR12.1
KPD-52 DR12.1
KPD-71 DR11.1
KPD-90 DR12.1
KPD-105 DR11.1
KPD-125 DR12.1
KPD-140 DR11.1
KPD-160 DR11.1

Table of Contents
Page
0. Safety Precautions ........................................................................................ 4
1. Indoor Unit Parts and Major Functions ....................................................... 6
2. Manual Operations....................................................................................... 8
3. Care and Maintenance ................................................................................. 9
a. Unit Maintenance
b. How to Clean the Air Filter
c. Repairing Refrigerant Leaks
d. Preparation for Periods of Non-use
4. Troubleshooting............................................................................................ 11
a. Common Problems
b. Troubleshooting Tips
c. Error Codes
5. European Disposal Guidelines ..................................................................... 15
Caution: Risk of fire /
flammable materials
WARNING: Servicing shall only be performed as recommended by the equipment manufacturer. Maintenance
and repair requiring the assistance of other skilled personnel shall be carried out under the supervision of the
person competent in the use of flammable refriferants. For more details, please refer to the Information on
Servicing on INSTALLATION MANUAL (This is only required for the unit adopts R-32 Refrigerant).

Page 4 
Thank you for purchasing this air conditioner. This manual will provide you with information on how to operate, maintain,
and troubleshoot your air conditioner. Following the instructions will ensure the proper function and extended lifespan of
your unit.
Please pay attention to the following signs:
Failure to observe a warning may result in serious injuries. The appliance must be installed in
accordance with national regulations.
Failure to observe a caution may result in injury or equipment damage.
WARNING
CAUTION
WARNING
• Ask an authorized dealer to install this air conditioner.
Inappropiate installation may cause water leakage,
electric shock, or fire.
• The warranty will be voided if the unit is not installed
by professionals.
• If abnormal situation arises (like burning smell), turn off
the power supply and call your dealer for instructions to
avoid electric shock, fire or injury.
• Do not let the indoor unit or the remote control get
wet. It may cause electric shock or fire.
• Do not insert fingers, rods or other objects into the air
inlet or outlet. This may cause injury, since the fan may
be rotating at high speeds.
• Do not use flammable sprays such as hair spray,
lacquer or paint near the unit. This may cause fire or
combustion.
• Do not use means to accelerate the defrosting process
to clean, other than those recommended by the
manufacturer.
• The appliance shall be stored in a room without
continuously operating ignition sources (for example:
open flames, an operating gas appliance or an operating
electric heater.
• The appliance shall be stored to prevent mechanical
damage from occurring.
• Be aware that the refrigerants may not contain an odor.
0. Safety Precautions
• Compliance with national gas regulations shall be
observed.
• Keep ventilation openings clear of obstruction.
NOTE: The following information is required for the units
adopt R-32 Refrigerant:
• Do not pierce or burn.
• A warning that the appliance shall be stored in a well-
ventilated area where the room size corresponds to the
room area as specified for operation.
• Any person who is involved with working on or
breaking into a refrigerant circuit should hold a current
valid certificate from industry-accredited assessment
authority, which authorizes their competence to handle
refrigerants safely in accordance with an industry
recognized assessment specification.
• Servicing shall only be performed as recommended by
the equipment manufacturer. Maintenance and repair
requiring the assistance of other skilled personnel shall
be carried out under the supervision of the person
competent in the use of flammable refrigerants.
• If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
people to avoid a hazard.

Page 5 
CAUTION
• Do not touch the air outlet while the swing flap is in
motion. Fingers might get caught or the unit may break
down.
• Do not inspect the unit by yourself. Ask an authorized
dealer to perform the inspection.
• To prevent product deterioration, do not use the air
conditioner for preservation purposes (storage of food,
plants, animals, works of art, etc.).
• Do not touch the evaporator coils inside the indoor
unit. The evaporator coils are sharp and may cause
injury.
• Do not operate the air conditioner with wet hands. It
may cause electric shock.
• Do not place items that might be affected by moisture
damage under the indoor unit. Condensation can occur
at a relative humidity of 80%.
• Do not expose heat-producing appliances to cold air
or place them under the indoor unit. This may cause
incomplete combustion or deformation of the unit due
to the heat.
• After long periods of usage, check the indoor unit to see
if anything is damaged. If the indoor unit is damaged, it
may fall and cause injury.
• If the air conditioner is used together with other heating
devices, thoroughly ventilate the room to avoid oxygen
deficiency.
• Do not climb onto or place objects on top of the
outdoor unit.
• Do not operate the air conditioner when using fumigant
insecticides. The chemicals may become layered with
the unit and endanger those who are hypersensitive to
chemicals.
• Do not let children play with the air conditioner.
• Do not operate the air conditioner in a wet room (e.g.
bathroom or laundry room). This can cause electrical
shock and cause the product to deteriorate.
• This appliance can be used by children aged from 8
years and above and people with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Cleaning
and user maintenance shall not be made by children
without supervision.

Air inlet
Air outlet
Electric control cabinet
Air filter (on some models)
Drain hose
Refrigerant connecting pipe
Page 6 
1. Indoor Unit Parts and Major Functions
Unit Parts
Fig. 1.1
Operating Conditions
Use the system under the following temperatures for safe and effective operation. If the air conditioner is used under
different conditions, it may malfucntion or become less efficient.
FOR OUTDOOR UNITS WITH AUXILIARY ELECTRIC HEATER
When outside temperature is below 0°C (32°F ), we strongly recommend keeping the unit plugged in at all time to ensure
smooth ongoing performance.
COOL Mode HEAT Mode DRY Mode
Indoor Temperature 17°C - 32°C
(62°F - 90°F)
0°C - 30°C
(32°F - 86°F)
10°C - 32°C
(50°F - 90°F)
Outdoor Temperature
0°C - 50°C
(32°F - 122°F)
-15°C - 24°C
(5°F - 76°F)
0°C - 50°C
(32°F - 122°F)
-15°C - 50°C
(5°F - 122°F)
(low temperature
cooling models)

Closing curtains during heating also helps
keep the heat in
Doors and windows should be kept closed
Page 7 
Features
• Default Setting
When the air conditioner restarts after a power failure,
it will default to the factory settings (AUTO mode,
AUTO fan, 24ºC (76ºF)). This may cause inconsistencies
on the remote control and unit panel. Use your remote
control to update the status.
• Auto-Restart (some models)
In case of power failure, the system will immediately
stop. When power returns, the Operation light on the
indoor unit will flash. To restart the unit, press the ON/
OFF button on the remote control. If the system has
an auto restart function, the unit will restart using the
same settings.
Energy Saving Tips
• DO NOT set the unit to excessive temperature levels.
• While cooling, close the curtains to avoid direct sunlight.
• Doors and windows should be kept closed to keep cool or warm air in the room.
• DO NOT place objects near the air inlet and outlet of the unit. This will reduce the efficiency of the unit.
• Set a timer and use the built-in SLEEP/ECONOMY mode if applicable.
• If you don't plan to use the unit for a long time, remove the batteries from the remote control.
• Clean the air filter every two weeks. A dirty filter can reduce cooling or heating efficiency.
• Adjust louvers properly and avoid direct airflow.
• Louver Angle Memory Function (Optional)
Some models are designed with a louver angle
memory function. When the unit restarts after a
power failure, the angle of the horizontal louvers will
automatically return to the previous position. The angle
of the horizontal louver should not be set too small as
condensation may form and drip into the machine. To
reset the louver, press the manual button, which will
reset the horizontal louver settings
• Refrigerant Leak Detection System (some
models)
In the event of a refrigerant leak, the LCD screen will
display "EC" and the LED indicator light will flash.

Manual button LED display
Operation indicator Infrared receiver
Timer indicator Alarm indicator
PRE-DEF
(pre-heating/defrost)
indicator
Page 8 
2. Manual Operations
This display panel on the indoor unit can be used to operate the unit in case the remote control has been misplaced or is
out of batteries.
Fig. 2.1
• MANUAL button: This button selects the mode in the following order: AUTO, FORCED COOL, OFF.
• FORCED COOL mode: In FORCED COOL mode, the Operation light flashes. The system will then turn to AUTO after
it has cooled with a high wind speed for 30 minutes. The remote control will be disabled during this operation.
• OFF mode: When the panel is turned OFF, the unit turns off and the remote control is re-enabled.

Fig. 3.2
Fig. 3.1
Page 9 
3. Care and Maintenance
Safety Precautions
• Contact an authorized service technician for repair or
maintenance. Improper repair and maintenance may
cause water leakage, electrical shock, or fire, and may
void your warranty.
• Do not substitute a blown fuse with a higher or lower
amperage rating fuse, as this may cause circuit damage
or an electrical fire.
• Make sure the drain hose is set up according to the
instructions. Failure to do so could cause leakage and
result in personal property damage, fire and electric
shock.
• Make sure that all wires are connected properly. Failure
to connect wires according to instructions can result in
electrical shock or fire.
Unit Maintenance
BEFORE CLEANING OR MAINTENANCE
• Always turn off your air conditioning system and
disconnect the power supply before cleaning or
maintenance.
• Do not use chemicals or chemically treated cloths to
clean the unit.
• Do not use benzene, paint thinner, polishing powder
or other solvents to clean the unit. They can cause the
plastic surface to crack or deform.
• Do not wash the unit under running water. Doing so
creates an electrical hazard.
• Do not use water hotter than 40ºC (104ºF) to clean
the front panel. This can cause the panel to become
deformed or discolored.
• Clean the unit using a damp, lint-free cloth and neutral
detergent. Dry the unit with a dry, lint-free cloth.
How To Clean The Air Filter
The filter prevents dust and other particles from entering
the indoor unit. Dust buildup can reduce the efficency of
the air conditioner. For optimum efficiency, clean the air
filter every two weeks or more frequently if you live in a
dusty area. Replace the filter with a new one if it's heavily
clogged and cannot be cleaned.
WARNING: DO NOT REMOVE OR CLEAN
THE FILTER BY YOURSELF
Removing and cleaning the filter can be dangerous.
Removal and maintenance must be performed by a certified
technician.
NOTE: In households with animals, you will have to
periodically wipe down the grille to prevent animals hair
blocking air flow.
1. If the unit you purchased is a rear ventilated one, take
off the filter in the directions indicated by the arrows in
the following diagram.
2. If the unit you purchased is a descensional ventilated
model, take off the filter in the directions indicated by
the arrows in the following diagram.

Fig. 3.3
Fig. 3.4
Page 10 
3. Remove the air filter.
4. Clean the air filter by vacuuming the surface or washing
in warm water with mild detergent.
A. If using a vacuum cleaner, the inlet side should face
the vacuum.
Repairing Refrigerant Leaks
WARNING
• If the refrigerant leaks, turn off the air conditioner and
any combustible heating devices, ventilate the room
and call your dealer immediately. Refrigerant is both
toxic and flammable. Do not use the air conditioner
until the leak is repaired.
• When the air conditioner is installed in a small room,
measures must be taken to prevent the refrigerant
concentration from exceeding the safety limit in the
event of refrigerant leakage. Concentrated refrigerant
causes a severe health and safety threat.
Refrigerant Leak Detection System (some models)
In the event of a refrigerant leak, the LCD screen will display
"EC" and the LED indicator light will flash.
Preparation For Periods Of Non-Use
Maintenance after Extended Non-Use
1. Remove any obstacles blocking the vents of both the
indoor and outdoor units.
2. Clean the air filter and the front grille of the indoor unit.
Reinstall the clean, dry air filter in its original position.
3. Turn on the main power switch at least 12 hours prior
to operating the unit.
Storing the Unit While Not in Use
1. Run the appliance on FAN mode for 12 hours in a warm
room to dry it and prevent mold.
2. Turn off the appliance and unplug it.
3. Clean the air filter according to the instructions in the
previous section. Reinstall the clean, dry filter before
storing.
4. Remove the batteries from the remote control.
B. If using water, the inlet side should face down and
away from the water stream.
5. Rinse the filter with clean water and allow it to air-dry.
Do not let the filter dry in direct sunlight.
6. Reinstall the filter.
