USER MANUAL
FLOOR-STANDING SPLIT TYPE
KPV-140 DN10
IMPORTANT
Read this manual carefully before installing or operating your new air conditioning
unit. Make sure to save this manual for future reference. This manual only
describes the outdoor unit of user’s. When using the indoor unit, refer to the user’s
manual of indoor unit.

3
CONTENTS
REGULATIONS REGARDING DISPOSAL
Regulations Regarding Disposal........................................................................................... 3
SAFETY PRECAUTIONS
Warning ............................................................................................................................... 5
Caution ................................................................................................................................ 6
Prior to operation ........................................................................................................................... 7
Operating temperature ......................................................................................................... 7
OPERATING INSTRUCTIONS
Product overview .................................................................................................................. 8
Unit control panel ................................................................................................................ 9
Airflow direction control........................................................................................................ 11
Operation tips ...................................................................................................................... 12
CARE AND MAINTENANCE
Cleaning the indoor unit....................................................................................................... 14
Cleaning the air outlet ......................................................................................................... 14
Cleaning the air inlet grille and air filter............................................................................... 14
TROUBLESHOOTING TIPS
Troubleshooting tips............................................................................................................. 16
! CAUTION
Contact an authorized service technician for repair or maintenance of this unit. Contact the installer
for installation of this unit.
The air conditioner is not intended for use by young children or invalids without supervision. Young
children should be supervised to ensure that they do not play with the air conditioner. If the power
cord is to be replaced, replacement work shall be performed by authorized personnel only.
Installation work must be performed in accordance with the national wiring standards by authorized
personnel only.
This appliance can be used by children aged from 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe way and understand the
hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall
not be made by children without supervision.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
Do not operate your air conditioner in a wet room such as a bathroom or laundry room.

4
REGULATIONS REGARDING DISPOSAL
The follow contents apply to the countries of Europe.
DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of
such waste separately for special treatment is necessary.
It is prohibited to dispose of this appliance in domestic household waste. For
disposal, there are several possibilities:
A) The municipality has established collection systems, where electronic waste can
be disposed of at least free of charge to the user.
B) When buying a new product, the retailer will take back the old product at least
free of charge.
C) The manufacture will take back the old appliance for disposal at least free of
charge to the user.
D) As old products contain valuable resources, they can be sold to scrap metal
dealers.
Wild disposal of waste in forests and landscapes endangers your health when
hazardous substances leak into the ground-water and find their way into the
food chain.

SAFETY PRECAUTIONS
5
To prevent injury to the user or other people and property damage, the following instructions must be
followed. Incorrect operation due to ignoring of instructions may cause harm or damage. The
seriousness is classified by the following indications.
! WARNING
This symbol indicates the possibility of serious injury.
! CAUTION
This symbol indicates the possibility of injury or damage to property .
Meanings of symbols used in this manual are as shown below .
Never do this.
! Always do this.
!
WARNING
! Connect with the power
properly.
Otherwise, it may cause electric
shock or fire due to excess heat
generation.
! Do not modify power cord
length or share the outlet
with other appliances
It may cause electric shock or
fire due to heat generation.
Do not operate or stop the
unit by switching on or off
the power.
It may cause electric shock or fire
due to heat generation.
Do not operate with wet
hands or in damp
environment.
It may cause electric shock.
Do not damage or use an
unspecified power cord.
It may cause electric shock or fire.
Do not direct airflow at
room occupants only.
This could damage your health.
! Always ensure effective
earthing.
Do not allow water to run
into electric parts.
! Always install circuit
breaker and a dedicated
power circuit.
No earthing may cause electric
shock.
! Disconnect the power if
strange sounds, smell, or
smoke comes from it.
It may cause fire and electric
shock.
! Use the correctly rated
breaker or fuse.
There is risk of fire or electric
shock.
It may cause failure of machine
or electric shock.
Do not drink water drained
from air conditioner.
It contains contaminants and
could make you sick.
Do not use the power cord
close to heating appliances.
It may cause fire and electric
shock.
No installation may cause fire
and electric shock.
Do not open the unit
during operation.
It may cause electric shock.
Do not use the power cord near
flammable gas or combustibles, such
as gasoline, benzene, thinner, etc.
It may cause an explosion or fire.
! Ventilate room before operating air
conditioner if there is a gas leakage from
another appliance.
It may cause explosion, fire and, burns.
Do not disassemble or modify unit.
It may cause failure and electric shock.

SAFETY PRECAUTIONS
6
!
CAUTION
When the air filter is to be
removed, do not touch the
metal parts of the unit.
It may cause an injury.
Do not clean the air
conditioner with water.
Water may enter the unit and
degrade the insulation. It may
cause an electric shock.
!
Ventilate the room well
when used together
with a stove, etc.
An oxygen shortage
may occur.
When the unit is to be
cleaned, switch off, and turn
off the circuit breaker.
Do not clean unit when power
is on as it may cause fire and
electric shock, it may cause
an injury.
Stop operation and close
the window in storm or
hurricane.
Operation with windows
opened may cause wetting
of indoor and soaking of
household furniture.
Do not put a pet or house
plant where it will be
exposed to direct air flow.
This could injure the pet or
plant .
Do not place obstacles
around air-inlets or inside
of air-outlet.
It may cause failure of
appliance or accident.
Do not use for
special purposes.
Do not use this air
cond itioner to preserve
preci sion devices, food,
pets, plants, and art
objects.
It may cause deterioration of
quality, etc.
Turn off the main power
switch when not using
the unit for a long time.
It may cause failure of
product or fire.
Do not use strong detergent
such as wax or thinner. Use
a soft cloth for cleaning.
Appearance may be
deteriorated due to change
of product color or
scratching of its surface.
Do not place heavy object on the
power cord and take care so that
the cord is not compressed.
There is danger of fire or
electric shock.
Ensure that the installation bracket of
the outdoor appliance is not damaged
due to prolonged exposure.
If bracket is damaged, there
is concern of damage due to
falling of unit.
Use caution when unpacking
and installing. Sharp edges
could cause injury.
Always insert the filters
securely. Clean filter
once every two weeks.
Operation without filters
may cause failure.
If water enters the
unit, turn the unit off
and disconnect the
power, contact a
qualified service
technician.

SAFETY PRECAUTIONS
7
Prior to operation
1. Contact an installation specialist for installation.
2. Make sure the unit is grounded efficiently.
3. Do not use a damaged or non-standard power cord.
4. Do not share the same outlet with other appliances.
5. Do not use an extension cord.
6. Do not start/stop operation by shutting off the power supply.
Usage
1. Exposure to direct airflow for an extended period could be hazardous to your health.
Do not expose occupants, pets, or plants to direct airflow for extended periods of time.
2. Due to the possibility of oxygen deficiency, ventilate the room when used together with stoves or
other heating devices.
3. Do not use this air conditioner for non-specified special purposes (e.g. preserving precision
devices, food, pets, plants, and art objects). Usage in such a manner could harm such property.
Cleaning and maintenance
1. Do not touch the metal parts of the unit when removing the filter. Injuries can occur when handling
sharp metal edges.
2. Do not use water to clean inside the air conditioner. Exposure to water can destroy the insulation,
leading to possible electric shock.
3. When cleaning the unit, first make sure that the power and circuit breaker are turned off.
Service
For repair and maintenance, contact your authorized service dealer.
Operating temperature
Mode
Temperature
Cooling operation
Heating
operation
Drying operation
Room temperature
17ºC~32ºC/62ºF~90ºF
0ºC~30ºC
/32ºF~86ºF
17ºC~32ºC/62ºF~90ºF
Outdoor temperature
0ºC~50 ºC /32ºF~122ºF
-15ºC~ 24ºC
/5oF~76oF
0ºC ~50ºC /32oF~122oF
(-15ºC ~50ºC /5ºF~122ºF:
For the models with low
temperature cooling system)
CAUTION:
1. If air conditioner is used outside of the above conditions, certain safety protection features may
come into operation and cause the unit to function abnormally.
2. Room relative humidity less than 80%. If the air conditioner operates in excess of this figure,
the surface of the air conditioner may attract condensation. Please set the vertical air flow louver
to its maximum angle (vertically to the floor), and set HIGH fan mode.
3. Optimum performance will be achieved within this operating temperature.

8
Product Overview
Indoor unit
1 Air outlet
2 Operation panel
3 Horizontal airflow control louver
4 Vertical airflow control louver
5 Remote controller holder (on some models)
6 Air inlet (2 sides)
Outdoor unit
7 Drain pipe, vent pipe
8 Connection cable
9 Connection pipe
10 Refrigerant pipe port
11 Air outlet
1 3
4
2 11
5
10
6 9
8
7
NOTE All the pictures in this manual are for explanation purpose only.
They may be slightly different from the air conditioner you
purchased (depend on model). The actual shape shall prevail.
NOTE: This manual does not include Remote Controller Operations, see the
<<Remote Controller Instruction>> packed with the unit for details.

9

10
O P E R A T I N G I N S T R U C T I O N S
Unit Control Panel
Room Temp
/Set Temp
/Set Timer display
Fan speed operation display
Indicators
Auto operation display
Cooling operation display
Dry operation display
Heating operation display
Fan operation display
Vertical airflow display (optional)
Horizontal airflow display
Sleep operation display
Turbo operation display (optional)
Off timer operation display
On timer operation display
Lock operation display
Operation buttons
1 ON/OFF button: Operation starts when this button is pressed and stops when you press the
button again.
2 MODE button: Press this button to select the appropriate operating mode. Each time the button
is pressed, the operation mode is shifted in the direction of the arrow:
AUTO COOL DRY HEAT (for cooling & heating models only) FAN ONLY
Mode indicators illuminate under the different mode settings.
Auto: Automatically choose the operation mode by sensing the difference between the
actual ambient room temperature and the set temperature on the remote controller. The fan
speed is automatically controlled.
Cool: Enables you to enjoy the cooling effect at you preferred setting temperature
(Temperature range: 17ºC~30ºC).
Dry: Enables you to set the desired temperature at low fan speed which provides you with
the dehumidifying surroundings (Temperature range: 17ºC~30ºC). In Dry mode, you cannot
select Fan speed and Sleep mode.
Heat: Permits heating operation (For cooling & heating models only)
(Temperature setting range: 17ºC~30ºC)
Fan only: Permits fan operation without cooling or heating. In this case, however, the setting
temperature is not displayed and you cannot adjust the set temperature.
