Kbs Quadrovino qv12 Operator's manual

Stand 08/2014

Bedienungsanleitung

Sektkühl-Bilderrahmen

. .

QV12

EXPO SRL Strada Antica di None, 14

10092 Beinasco Torino ( Italia )

P.IVA 08909180013 Rea 1009634

MANUFACTURER EEC DECLARATION OF CONFORMITY

Hereby declares that the products Are in compliance with the following directive

2006/42/CEE

With reference to harmonised standard

EN 60335 – 1

USER INSTRUCTIONS MANUAL

. GENERAL NFORMAT ONS

We thank you for choosing our product . We ask you to please read these instructions carefully and to store them in a suitable place for easily

consultation. Observe a indicated warnings to ensure proper equipment operation.

The manufacturer declines all responsibility for malfunctions caused by a failure to observe directions. All packaging materials utilised are ecological and

recyclable. Please dispose properly of packaging. MALTIMENTO

. D SPOS NG OF USED EQU PMENT

n accordance with art.13 of Legislative Decree of 25 July 2005, n.151 “ mplementing Directives 2002/95/CE, 2002/96/CE and 2003/108/CE, concerning

the reduction of the use of hazardous substances in electrical and electronic equipment, as well as waste disposal".

The cross-out wheeled bin on the product or packaging or in the manual means that at the product end of life, it must be taken for separate collection.

Differentiated refuse collection of this product at the end of life is organised and managed by the manufacturer. The user desiring to rid him/herself of

this equipment must contact the manufacturer and follow the system arranged for separate collection at the end of life.

Adequate differentiated refuse collection in having the product recycled, treated and disposed of ecologically helps avoid possible negative effects on the

environment and health and supports the recycling of materials of which the equipment is made. Unlawful disposal of this product by the user will entail

fines foreseen by the current regulations.

. TECHN CAL NFORMAT ONS

To ensure maximised functioning, the equipment shou d be arranged in a we -aerated area without excessive moisture which is far from heat

sources, avoiding exposure to direct sun ight and keeping equipment c ean from dust or other sediments.

Any damage or defects caused by failure to respect these norms are not covered by the guarantee and are not in any way the responsibility of the

manufacturer. t is also recommended to place the machine in order to enable the use when lighting conditions are “NORMAL” (quantified in 200 LUX)

E.D. 2006/42/EECERTENZE

. SAFETY WARN NGS

ELECTRIC SYSTEM

Fist of all check that the voltage supply corresponds to the one shown on the product data plate located on the back of the product .

A tolerance of +/- 6 % is allowed. t is very important to check the voltage level also during equipment operation, keeping in mind that vo tage ower

than the a owed to erance can cause serious damage to the system. Damage caused by a failure to observe the information in this paragraph is not

covered in any way by the guarantee.

nsert the supplied regulatory plug in a mono phase socket equipped with earthing. This socket must be permanently accessible to allow for equipment

disconnection at any time. Insta ation earthing is not on y a safety standard but is a so ob igatory by aw. The manufacturer dec ines a

responsibi ity whenever this accident prevention standard is not respected.

Do not insert more than one plug at the same time in the same outlet using multiple outlets.

Do not spray any liquids or flammable gas directly inside or outside the cellar when the plug is inserted in the outlet.

OTHER SAFETY INFORMATION

The machine was designed and manufactured with reference to standards and were taken where possible all available security precautions, but still

hypothetical residual risk:

•

Beware of protruding corners and edges, that can cause cuts

•

The on and off all the moving parts is automatic. All moving parts are protected and in areas difficult to reach, it is recommended to disconnect power

before performing maintenance and clearing All moving parts are protected and in areas difficult to reach, it is recommended to disconnect

power before performing maintenance and clearing

•

Vacation time: f the appliance will not be used for several months, remove all items and turn off the appliance

•

before proceeding with cleaning and maintenance is recommended to disconnected the appliance and wait a few minutes

( n compliance with E.D. 2006/42/EEC)

. NSTALLAT ON

The QUADRO V NO has been designed to be hung on the wall. t is necessary to fix two hooks on the wall by using the correct plugs for the type of wall

where they will be placed ( perforated brick , concrete, drywall etc. ..) and depending on the load that can support ( indicated on the different types of

plugs) . The manufacturer disclaims any liability with regard to the product installation .

The distance (D ) that is the distance to which the plugs must be placed is indicated in the following drawing . The height ( H 1 ) as indicated in the

diagram refers to the holes for the plugs and it is the suggested (this may be different according to specific needs) . The height (H 2 ) refers to the power

socket position.

•Hang the QuadroVino by inserting the hooks into the cuts placed in the back of the case.

•nsert the plug into the socket ( see safety electrical system )

. ADJUSTMENT, USE AND OPERAT ON
