KDS POWER RC-6S User manual

KDS POWER RC-6S manual
KDS POWER RC-6S manual
SHENZHEN KDS MODEL TECHNOLOGIES CO.,LTD
DIGITAL CHARGER & DISCHARGER
www.kdsmodel.com

Tel: [phone] 84006652
FAX: [phone]
http:// www.kdsmodel.com
SHENZHEN KDS MODEL TECHNOLOGIES CO.,LTD

1
Introduction
Thank you for purchasing the RC-6S LiPo Balance Charger. This product is a rapid charger
with a high performance microprocessor and specialized in operating. Please read this entire
operating manual completely and attentively before using this product, as it covers a wide range
of information on operating and safety. Or please do use this product in company with a specialist!
Specifications
Operating voltage range: DC11.0~18.0Volt
AC to DC adaptor(DC11.0 ~18.0V|5A)
Circuit power Max. charge power 50w
Max. discharge power5w
Charge current range: 0.1~5.0A
Discharge current range: 0.1~1.0A
Current drain for balancing Li-po: 300mAh\cell
NiCd \NiMH battery cell count: 1~15cell
li-ion\Polymer cell count:1~6 series
Pb battery voltage: 2V~20V
Weight: 260g(Net Weight)
Dimensions: 117×85.5×30mm
Introduction

2
Optimized operating software
RC-6S features the so-called AUTO function that set the feeding current during the process of
charging or discharging. Especially for Lithium batteries, it can prevent the overcharging which
may lead to an explosion due to the user's fault. It can disconnect the circuit automatically and alarm
once detecting any malfunction. All the programs of this product were controlled through two way
linkage and communication, to achieve the maximum safety and minimize the trouble. All the settings
can be configured by users!
Internal independent lithium battery balancer
RC-6S employs an individual-cell-voltage balancer. It isn't necessary to connect an external
balancer for balance charging.
Balancing individual cells battery discharging
During the process of discharging, RC-6S can monitor and balance each cell of the battery
individually. Error message will be indicated and the process will be ended automatically if
the voltage of any single one cell is abnormal.
Adaptable to various type of Lithium battery
RC-6S is adaptable to various types of Lithium batteries, such as Li-ion,LiPo and the mew
LiFe series of batteries.
Fast and storage mode of lithium battery
Purposes to charge Lithium battery varise, ' fast’ charge reduce the duration of charging, whereas
“store”state can control the final voltage of your battery, so as to store for a long time and
protect useful time of the battery.
SPEC IAL FEATURES
SPECIAL FEATURES

3
Maximum safety
Delta-peak sensitivity: The automatic charge termination program based on the principle of the
Delta-peak voltage detection. When the battery's voltage exceeds the threshold, the process will
be terminated automatically.
Automatic charging current limit
You can set up the upper limit of the charging current when charging your NiCd or NiMH battery;
it is useful for the NiMH battery or low impedance and capacity in the “AUTO” charging
mode.
Capacity limit
The charging capacity is always calculated as the charging current multiplied by time. If the
charging capacity exceeds the limit, the process will be terminated automatically when you set the
maximum value.
Temperature threshold
The battery's internal chemical reaction will cause the temperature of the battery to rise. lf the
temperature limit is reached, the process will be terminated.
*This function is available by connecting optional temperature probe, which is not included
in our package.
Processing time limit:
You can also limit the maximum process time to avoid any possible defect.
Input power monitoring
To protect the car battery used as DC input power from being damaged, its voltage keeps being
monitored. lf it drops below the lower limit, the process will be ended automatically.
Data store\load
The maximum five batteries' data can be stored for users' convenience .You can keep the data
pertaining to program setting of the battery of continuous charging or discharging. Users can
call out these data at any time without any special program setting.
SPECIAL FEATURES

4
Cyclic charging/discharging
1 to 5 cyclic and continuous process of charge > discharge or discharge > charge is
operable for battery refreshing and Balancing to stimulate the battery’s activity.
Input power cable
11-18V DC Lcd screen
output charge lead 4mm
banana plug
banana lead sockets
JST-XH prots
scroll through the Main Menu
stop any charge processes
Alter values
See the status of individual
cells in balance charge mode
Alter values
See the status of individual
cells in balance charge mode
SPECIAL FEATURES

5
LITHIUM POLYMER BALANCE CHARGE PROGRAM CONNECTION DIAGRAM
This diagram shows the correct way to connect your battery to the RC-6S charger while
charging in the balance charge program mode only.
Warning:
Failure to connect as shown in this diagram will damage this charger.
The main battery leads must be
connected along with the balance lead
connector as shown before charging
your battery.
Warning:
If using crocodile clips as shown in
above diagram, make sure they are
unable to touch together!
！
LITHIUM POLYMER BALANCE CHARGE PROGRAM CONNECTION DIAGRAM
！

6
These warnings and safety notes are particularly important. Please follow the instructions for
maximum safety; otherwise the charger and the battery can be damaged or at worst it can cause
a fire.
Never leave the charger unattended when it is connected to its power supply. lf any
malfunction is found, TERMINATE THE PROCESS AT ONCE and refer to the operation
manual.
Keep the charger well away from dust, damp, rain, heat, direct sunshine and vibration.
Never drop it.
The allowable input voltage is 11-18V DC.
This charger and the battery should be put on a heat-resistant,noninflammable and
nonconductive surface. Never place them on a car seat, carpet or similar. Keep all the
inflammable volatile materials away from operating area.
Make sure you know the specifications of the battery to be charged or discharged to ensure it
meets the requirements of this charger. If the program is set up incorrectly, the battery and
charger may be damaged. It can cause fire or explosion due to overcharging. This warranty is
not valid for any damage or any damage or subsequent damage arising as a result of a misuse or
failure to observe the procedures outlined in this manual.
WARNING AND SAFETY NOTES
！
！
！
！
！
！
WARNING AND SAFETY NOTES

7
NiCd / NiMH
Voltage level: 1.2V\cell
Allowable fast charge current: 1C-2C(depends on the performance of cell)
Discharge voltage cut off level: 0.85V\cell (NiCd), 1.0V\cell ( NiMH)
Li-ion voltage level: 3.6V\cell
Max. charge voltage: 4.1V\cell
Allowable fast charge current: 1C or less
Min. discharge voltage cut off level: 2.5V\cell or higher
Lipo Voltage level: 3.7V\cell
Max. charge voltage: 4.2\cell
Allowable fast charge current: 1C or less
Discharge voltage cut off level: 3.0V\cell or higher
LiFe Voltage level: 3.3v\cell
Max. charge voltage: 3.6V\cell
Allowable fast charge current: 4C or less
Discharge voltage cut off level: 2.0V\cell or higher
Pb Voltage level: 2.0V\cell
(Lead-acid) Max. charge voltage: 2.46V\cell
Allowable fast charge current: 0.4C or less
Discharge voltage cut off level: 1.75V\cell or higher
WARNING AND SAFETY NOTES

8
To avoid short circuit between the charge lead, always connect the charge cable to the
charger first, then connect the battery. Reverse the sequence when disconnecting.
Do not connect more than one battery pack to this charger at any one time.
Never attempt to charge or discharge the following types of batteries.
A battery pack which consists of different types of cells (including different manufacturers)
A battery that is already fully charged or just slightly discharged.
Non-rechargeable batteries (Explosion hazard).
Batteries that require a different charge technique from NiCd, Nimh, Lipo or Gel cell (Pb, Lead
accid).
A faulty or damaged battery.
A battery fitted with an integral charge circuit or a protection circuit.
Batteries installed in a device or which are electrically linked to other components.
Batteries that are not expressly stated by the manufacturer to be suitable for the currents the
charger delivers during the charge process.
warning and safety notes

9
Please bear in mind the following points before commencing
charging.
Did you select the appropriate program suitable for the type of battery you are charging?
Did you set up adequate current for charging or discharging?
Have you checked the battery voltage? Lithium battery packs can be wired in parallel and in
series, i. e. a 2 cell pack can be 3.7V(in parallel)or 7.4V(in series).
Have you checked that all connections are firm and secure? Make sure there are no
intermittent contacts at any point in the circuit.
Charging
During charge process, a specific quantity of electrical energy is fed into the battery.
The charge quantity is calculated by multiplying charge current by charge time. The
maximum permissible charge current varies depending on the battery type or its
performance, and can be found in the information by the battery manufacturer. Only batteries
that are expressly stated to be capable of quick-charge are allowed to be charged at rates
higher than the standard charge current.
Connect the battery to the terminal of the charger: red is positive and black is negative. Due
to the difference resistance of cable and connector, the charger can not detect resistance of
the battery pack, the essential requirement for the charger to work properly is that the charge
lead should be of adequate conductor cross-section, and high quality connectors which are
normally gold-plated should be fitted to both ends.
Always refer to the manual by the battery manufacturer pertaining to charging methods,
recommended charging current and charging current and charging time. Especially, the
Lithium battery should be charged according the charging instruction provided by the
manufacturer strictly.
Attention should be paid to the connection of Lithium battery especially.
Do not attempt to disassemble the battery pack arbitrarily
warning and safety notes

10
Please get highlighted that Lithium battery packs can be wired in parallel and in
series. In the parallel connection, the battery's capacity is calculated by multiplying
single battery's capacity by the number of cell with total voltage stay the same. The
voltage's imbalance may cause fire or explosion. Lithium battery is recommended
to charge in series.
Discharging
The main purpose of discharging is to clean residual capacity of the battery ,or to
reduce the battery' voltage to a defined level. The same attention should be paid to
the discharging process as charging. The final discharge voltage should be set up
correctly to avoid deep-discharging.Lithium battery can not be discharged to lower
than the minimum voltage, or it will cause a rapid loss of capacity or a total failure
.Generally, Lithium battery doesn't need to be discharged. Please pay attention to
the minimum voltage of Lithium battery to protect the battery.
Some rechargeable batteries have a memory effect. If they are partly used and recharged
before the whole charge is accomplished, they remember this and will only use that part of
their capacity next time. This is a ‘memory effect' It is said that NICd and NiMH batteries
are suffering from memory effect .NiCd has more memory effect than NiMH.
Lithium batteries are recommended to be discharged partially rather than fully
discharged. Frequent full discharging should be avoided if possible. Instead, charge the
battery more often or use a battery of larger capacity. Full capacity cannot be used until it
has been subjected to 10 or more charge cycles. The cyclic process of charge and
discharge will optimize the capacity of battery pack.
warning and safety notes

11
Program select
Lithium Battery
Program select
Lithium Battery
Start
Enter INC
EDC
INC
EDC
INC EDC
Start
Enter
Start
Enter
Start
Enter
Start
Enter
Start
Enter
Program select
NiMH Battery
Program select
Nicd Battery
Program select
Pb Battery
Program select
Save Data
Program select
Load data
User Set
program LiXX V.Type
Chg > Dchg
Waster time
Save Data
Pb
Discharge
NiCd
Discharge
NiMH
Disch a r g e
LiXX Balance
LiXX
Discharge
Load data
Safety Timer
Start
Enter
INC
EDC
INC
EDC
INC
EDC
INC
EDC
INC
EDC
INC
EDC
INC
EDC
INC
EDC
INC
EDC
INC
EDC
INC
EDC
INC
EDC
INC EDC
LiXX
Fast Charge
LiXX
Fast Charge
LiXX
Fast Charge
LiXX
Fast Charge
LiXX
Fast Charge
LiXX
Fast Charge
LiXX
Fast Charge
Input power low
Cut-off
Key Beep
Buzzer
Capacity
Cut-off
Temp Cut-off
USB Enable
MoCd D.peak
Sensitivity
NiCd D.Peak
Sensitivity
LiPo/LiLo/LiFe
Chk Time
As default this charger will be set to
typical user settings when it is
connected to a 12V battery for the
first time. The screen displays the
following information in sequence
and the user can change the
parameter on each screen.
If you need to alter the parameter
value in the program, press
“Start/Enter”key to make it blink
then change the value with “INC” or
“DEC” key. The value will be stored
by pressing “ Start/Enter” key once.
warning and safety notes

LiFe
V.TYPE 3.3V
LiPO/LiIo/LiFe
CHK Time 10 min
NiNH Sensitivity
D.Peak Default
NiCd Sensitivity
D.Peak Default
USB/Temp Select
Temp cut-off 80C
USB/Temp Seledt
USB Enabled
DE C I N C DE C I N C
DE C I N C DE C I N C
DE C I N C DE C I N C
DE C I N C DE C I N C
DE C I N C D EC I N C
The screen shows the nominal voltage of Lithium battery. There
are three kinds of Lithium battery: LiFe (3.3V),Lilo (3.6V) or LiPo
(3.7V). This information is of critical importance that you have to
check the battery carefully to make sure it is set up correctly. If it
is different from correct value, explosion can occur during charge
process.
To avoid from erroneous setting by users, RC-6S detects the cell
count of Lithium battery automatically at the beginning of charge
or discharge process. But battery that is deep-discharged can’t
be detected correctly. To avoid this error, the time term can be set
to verify the cell count by the processor. Normally, 15 seconds
are enough to detect the cell count correctly. You need to extend
the time term limit for the battery of large capacity. But the charge
or discharge process may come to an end if you set too long time
limit for the battery of small capacity. This may cause fatal error.
You have to extend the time term if the processor process.
Otherwise, default value is recommended to use.
This shows the trigger voltage for automatical charge termination
of NiMH and NiCd battery. the valid value ranges from 5 to 20 mV
per cell. Setting the trigger voltage higher brings a danger of
overcharging; whereas setting it lower brings a possibility of
premature termination. Please refer to the technical specification
of the battery. (NiCd default:12mV, NiMH default:7 mV)
12
WARNING AND SAFETY NOTES

There is a 3-pin port on the left of the charger used as USB interface or temperature
sensor port. If the screen displays temperature, you can use the optional temperature
probe to connect to the surface of the battery. If it is set as the USB port, you can connect
the charger to your PC through the optional USB cable to monitor the charging process
through optional software. The maximum temperature of the battery can be set during
the charge process. The process will be terminated automatically to protect battery once
the temperature of battery reaches this value. This feature is accomplished through
temperature probe (optional).
The battery becomes warm after cycles of charge/discharge process. The
program will insert a time delay after each charge/discharge process to
allow the battery enough time to cool down before beginning next cycle of
charge/discharge process. The valid value ranges from 1 to 60 minutes.
When the charge process starts, the integrated safety timer starts to run
simultaneously. If error detected or the termination circuit can not detect
overcharging. Please refer to the below statement to calculate the timer
you set.
The program provides maximum capacity protection function. If the Delta-
peak voltage can not be detected or the safety timer times out, the
charge process will stop automatically, when the battery reaches the
use-set maximum charge capacity.
The beep to confirm user’s operation sounds every time a button is
pressed. The keep or melody sounds at various times during operation to
confirm different mode change. These functions can be switched on or
off.
This function monitors the voltage of the input battery used to power this
charge. If the voltage is lower than user-set value, the program will end
forcibly to protect the input battery.
LiFe
V.TYPE 3.3V
DEC I N C
DEC I N C
DEC I N C
LiFe
V.TYPE 3.3V
DEC I N C
DEC I N C
DEC I N C
LiFe
V.TYPE 3.3V
DEC I N C
DEC I N C
DEC I N C
LiFe
V.TYPE 3.3V
DEC I N C
DEC I N C
13
WARNING AND SAFETY NOTES

14
Safe timer calculation
When charging NiCd or Nimh batteries, divide the capacity by current, then divide
the result by 11.9, set this number of minutes as the value for safety timer setting. If
the charger stoppied at this time threshold, about 140% of the capatity will have
been fed into the battery.
For example:
Capacity Current Safety Time
2000mAh 2.0A (2000/2.0=1000)/11.9=84 minutes
3300mAh 3.0A (3300/3.0=1100)/11.9=92 minutes
1000mAh 1.2A (1000/1.2=833)/11.9=70 minutes
Lithium (LiIo/LiPo/LiFe) program
The program is only suitable for charging/discharging Lithium-polymer batteries
with a nominal Voltage of 3.3/3.6/3.7V/cell. Different batteries have different charge
technique. There are two methods termed as constant voltage and constant
current. The charge current varies according to battery capacity and specification.
The final voltage is very important; it should precisely match the voltage of the
battery: LiPo is 3.6V, LiLo is 4.1V, and LiFe is 3.6V. The current and voltage of the
battery should be correctly set.
When you want to change the values of parameters, please press START/ENTER
key to make it blink and then use DEC or INC to change the value. Then press
START/ ENTER key again to store the value.
SAFE TIMER CALCULATION

The left side of the first line shows the type of battery you
choose.The value on the left of the second line of the charger is
current user set. After setting the current and voltage, press
process. (charge current: 0.1-5.0A, voltage:1-5V)
This displays the number of cells you set up and the processor
detects. “R”shows the number of cells detected by the charger
and “S” is the number of cells set by you at the previous screen.
If both numbers are identical you can start charging by press
START/ENTER button. If not, press BATTERY/STOP button to
go back to previous screen to carefully check the number of
cells of the battery pack before going ahead.
This screen shows the real-time status during charge process.
Press BATTERY/STOP key once to stop the charge process.
Charging lithium battery in the balance mode
This function is for balancing the voltage of Lithium-polymer battery cells while charging.
In the balance mode, the battery needs to have a balance lead to connect the individual
port at the right side of the charger. And you need to connect the battery’s out put plug to
the output of charger.
Charger in this mode is different from the normal modes, because the built-in processor
monitors voltage of individual cell and control input current fed into each cell to normalize
the voltage.
LiPo BALANCE
2.0A 11.1V (3S)
DE C I N C
15
DE C I N C
R:3SER S:3SER
CONFIRMC(ENTER)
Batt Type
Stop
Start
Enter ‘>3 seconds’
Li3S 1.2A 12.59V
BAL 022:43 00682
Start
Enter
Number
of cells
Charging
time
Battery
Voltage Charged
capacity
Charging
current
SAFE TIMER CALCULATION

16
The value on the left side of the second line sets the charge
current. The value on the right side of the second line sets the
battery pack’s voltage. After setting current and voltage, press
START/ENTER for more than 3 seconds to start the process.
This displays the number of cells you set up and the processor
detects. ”R” shows the number of cells detected by the charger
and “S” is the number of cells set by you at the previous screen. If
both numbers are identical you can start charge by press
START/ENTER button. If not, press BATTTYPE/STOP button to go
back to previous screen to carefully check the number of cells the
battery pack before going ahead.
This screen shows the real-time status during charge process.
Press BATTTYPE/STOP key once to stop the charge process.
Individual Cell connection diagram (pin-assignment of 8 - pin)
1 cell
2 cell
3 cell
4 cell
5 cell
6 cell
1 cell
2 cell
3 cell
4 cell
5 cell
6 cell
Li P o 1s
Li P o 2s
Li P o 4s
Li P o 3s
1s
2s
3s
top v i e w
top v i e w
LiPo BALANCE
2.0A 11.1V (3S)
DE C I NC DE C I NC
R:3SER S:3SER
CONFIRMC(ENTER)
Batt Type
Stop
Start
Enter ‘>3 seconds’
Li3S 2.0A 12.59V
BAL 022:43 00682
Start
Enter
Number
of cells
Charging
time
Suppiled
capacity
Current
voltage
battery
Charging
current
Li P o 6s
Li P o 5s
in d iv id u al
bal.port
in d iv id u al
bal.port
Charging of lithium battery

17
LiPo FAST CHG
2.0A 11.1V (3S)
DE C I N C DE C I N C
Batt Type
Stop
Start
Enter ‘>3 seconds’
R:3SER S:3SER
CONFIRMC(ENTER)
Li3S 2.0A 12.59V
BAL 022:43 00682
Number
of cells
Elapsed
time
Supplied
capacity
Charged
Voltage
battery
Charging
current
Storage control of lithium battery
This function is for charging/discharging batteries which are not used at once. This
program is designed for charging or discharging of batteries of specific original state.
They are classified by types:3.75V LiIo,3.85V LiPo and 3.3V LiFe. The program will begin
to discharge if the original state of the battery exceeds voltage level of storage.
Fast charging of Lithium battery
Charging current will become lower when it progress to the end
of charging. A specific CV process will be reduced to end the
charging process earlier. In fact, the charging current will goes
to 1/5 when the charging process comes to 1/10. Charging
capacity will be a little smaller than normal charging, but
charging time will be shortened accordingly.
You can set up the charging current and voltage of the battery
pack. Press START/ENTER key to display voltage confirmation.
Then press START/ENTER key again to confirm and begin to
charge.
This screen shows the real-time status of “fast charging”. Press
BATTTYPE/STOP key once to stop the charge process.
Fast charging of Lithium battery

18
LiPo STORAGE
2.0A 11.1V (3S)
DEC INC DEC INC
Batt Type
Stop
Start
Enter ‘>3 seconds’
Li3S 2.0A 12.59V
BAL 022:43 00682
Number
of cells
Elapsed
time
Supplied
capacity
Current
voltage
battery
Charging
current
LiPo DISCHARGE
2.0A 11.1V (3S)
DE C I N C DE C I NC
Batt Type
Stop
Start
Enter ‘>3 seconds’
Li3S 2.0A 12.59V
BAL 022:43 00682
Number
of cells
Elapsed
time
Battery
voltage
Discharged
capacity
Discharge
current
At this screen, you can set up the current and voltage of the
battery park. Charging and discharging will make the batteries
come to the voltage level of “storage” state.
This screen shows the real-time status charging. Press
BATTTYPE/STOP key once to stop the charge process.
Discharging of lithium battery
The value of discharge current on the left can not exceed 1C,
and the value on the right can not be under the voltage
recommended by the manufacturer to avoid deep discharging.
Press START/ENTER for more than 3 seconds to start
charging.
This shows the real-time status of discharging, you can press
BATTTYPE/STOP key to stop discharging.
STORAGE CONTROL OF LITHIUM BATTERY
