Keeler 1941-P-1368 User manual

PLEASE READ AND FOLLOW THESE INSTRUCTIONS CAREFULLY
LITHIUM DOUBLE CHARGER 1941-P-1368
LITHIUM MINI CHARGER 1941-P-1341

Keeler Lithium Chargers & Handles
Carefully read this Instruction Section before using your Keeler product.
For your own safety and that of your customers observe all cautionary
information provided in this section. The following information is intended
to highlight potential safety hazards that can be associated with misuse, or
damage.
Warning
This product must not be used in the presence of ammable gases.
Do not disassemble or modify the battery. There are no serviceable
parts inside.
Do not dispose of battery in re, Do not puncture.
Do not use a battery that is deformed, leaking, corroded or visually
damaged.
If the product emits a strange odour, heat, or smoke, stop use and
disconnect from mains. The continued use of a damaged product or part may
cause injuries.
Do not immerse the unit in any liquid
Do not use unit if damaged and periodically visually inspect for signs of
damage.
Only Keeler Lithium handles i.e. with a red base can be used in the Keeler
Lithium Charger. Do not try to insert a Keeler handle with a blue base into
the Keeler Lithium Chargers. Refer to Keeler handle and bulb identication.
Caution
Remove dry cell batteries before prolonged periods of storage.
Use only Keeler rechargeable battery Pt. Nos. EP39 18918
Charge only using Keeler chargers Pt. Nos 1941-P-5289, Double Charger
1941-P-5326, Mini Charger
Do not mix battery types.
Do not charge battery in any environment where the temperature may exceed
40oC or fall below 0oC.
Keep out of reach of children.
Do not t into damaged electrical supply outlet.
!

For indoor use only (protect from moisture)
To prevent condensation from forming, allow instrument to come to room
temperature before use.
When connecting instrument heads to handles check that voltage of the bulb
in the instrument corresponds with the voltage of the handle.
Ensure that the control is in the off position when the examination has been
completed.
When replacing Lithium cell, turn handle off and insert new cell. Replace
bottom cap, and place handle into charging well.
Environmental
Dispose of battery in line with local regulations on recycling of batteries.
Tape over battery contacts to avoid short circuiting during disposal.
Li-ion batteries contain no toxic heavy metals, such as mercury, cadmium or
lead.
Keeler Handle & Bulb Identication
Keeler handles & bulbs are colour coded to allow you to distinguish between
a dry cell battery handle (2.8V) and a lithium handle (3.6v). The handles
are colour coded as follows:
Blue Base = 2.8v for dry cell batteries
Red Base = 3.6v for Lithium batteries
Please ensure when replacing bulbs that the voltage corresponds to the
handle voltage.
Inserting/Replacing Batteries
Unscrew battery cap, insert batteries and replace battery cap as shown in
Fig 1.
2xAA (LR6-AM3-MN 1500) LINER SLEEVE
BLUE
RED
EP39-18918
Fig. 1
Always ensure that the handle rheostat is turned off before fitting an
instrument head or changing a bulb.
If a short curcuit occurs, reactivate the battery by placing the handle in the
charger until the LED flashes.
This is a built in protection device to protect the battery from damage.

Charging
Replace the blanking plate with the appropriate mains plug adapter, or use
IEC 60320 TYPE 7 connector (not supplied) See Fig 2.
Switch on your Lithium Charger by plugging it into a mains outlet. Place
your handle in your Lithium charger as shown in Fig 3.
No LED Battery is fully charged
Flashing LED Top up charge
Solid LED Battery is charging
The handle can be used at any time during the charging cycle and will
automatically resume charging when handle is placed back in the charging
well.
When using the Mini charger the handle can be left in place during use.
Fig. 3
Fig. 2

Charging Cycle - Fig 4
The battery will take approximately 2-3 hours to fully charge
The battery will last approximately 2-3 hours on full power.
Warranty & Service
No user serviceable parts - all preventative maintenance and servicing must
only be performed by authorised Keeler representatives.
Your Keeler Charger is guaranteed for 3 years and will be replaced or
repaired free of charge subject to the following:
1. Any fault is due to faulty manufacture
2. The power supply has been used in compliance with these instructions
3. Proof of purchase accompanies any claim.
Fig. 4

Technical Information
Input data see name plate: 120-240V - 50/60Hz
Power Consumption: 2.5 Amps
Charging Current: 1 Amp
Operation: Continuous
Classication: Class II equipment
Type B Protection against electric
shock
Safety Class: Double insulated
Ambient Temperature: +10oC to +35oC
Transportation: -40oC to +70oC 10% to 95% RH
This equipment may be affected by electromagnetic interference.
Other electrical equipment in the close vicinity may also be affected by the
Lithium Double/Mini Charger.
If such effects are suspected, either switch off the offending equipment or
shorten the connecting leads.
Cleaning Instructions
Only manual non-immersion cleaning as described below should be used for
the instrument:
1. Wipe the external surface with a clean absorbent, non shedding cloth
dampened with a water / detergent solution (2% by volume) or water /
isopropyl alcohol solution (70% by volume).
2. Ensure that excess solution does not enter the instrument. Use caution to
ensure cloth is not saturated with solution.
3. Surfaces should be carefully hand-dried using a clean non-shedding cloth.
4. Safely dispose of used cleaning materials.

MANUFACTURED IN THE UK BY:
Keeler Limited
Clewer Hill Road
Windsor
Berkshire SL4 4AA
England
Tel: [phone]
Fax: [phone]
FREEPHONE: 0800 521 251
Keeler Instruments Inc
456 Parkway
Broomall
PA 19008, USA
Toll Free: 1 800 523 5620
Tel: [phone]
Fax: [phone]
Distributor
EP59 - 11138 Issue C
A
HALMA GROUP
COMPANY
Distributed by:
The CE mark on this 
product indicates it has 
been tested to and 
conforms with the 
provisions noted within 
the 93/42/eec Medical 
Device Directive.
