Keller LD350 User manual

smart slider
LD350 / LD700
05/2022 997-00220-EN
Operating
instructions

Operating instructions
smart slider - Operating instructions
General
Electric operation
Maintenance and care
Maintenance intervals
Faults
Decommissioning / Disassembly / Disposal
Maintenance report
Commissioning declaration
Legal notice
Contents
Index Title page
2
Keller minimal windows®| 997-00220 | 05-2022
Keller minimal windows®
03
04
07
08
11
12
13
15
16
01
02
03
04
05
06
07
08
09

01
Operating instructions
smart slider - Operating instructions
01. General
1.1 General
1.2 Application
1.3 Warranty and liability
• Completely observe this user manual.
• The automatic sliding section should only be operated by instructed adult persons.
• No people, animals or other objects may be in the moving zone when the automation is being operated.
• When operating the smart slider®, it must always be in sight.
• In case of any malfunctions, always call a qualified company or contact the manufacturer.
• Do not make any changes to the smart slider®!
• Never put fingers in or on parts of the moving sliding part, side part (sliding part walkway) during any
movement.
• Make sure that the smart slider®functions 100% properly and have it checked at least once a year by a
qualified company and have this recorded in writing!
• Visually inspect the smart slider®thoroughly at least 1x per month for damage, proper functioning, noise and
all parts are always properly tightened. Also make sure that all rail systems are clean and that the sliding part is
manually correct works.
The smart slider®is intended to operate a sliding action completely horizontal automatically.
The smart slider®is not allowed to use for other purposes.
In case of personal changes to the smart slider®that are not in accordance with this manual, the liability or
warranty is void.
This also applies to damage caused by incorrect operation, unauthorized use or failure to follow the instructions in
this one manual and / or due to poor maintenance of your smart slider®system.
3
Keller minimal windows®| 997-00220 | 05-2022
Keller minimal windows®

02
Operating instructions
smart slider - Operating instructions
02. Electric operation
2.1 Principle
2.2 If mode: DEAD MAN'S operation
The horizontally sliding unit is driven by an electric motor that is linked to your sliding mechanism via a toothed belt
entirely via the flight bar.
The whole movement is controlled via a “dead man's control”, that is, the user must press down the control button
until the sliding has completed its full cycle. The movement will stop as soon as the control button is released. The
user is therefore responsible for keeping an eye on the sliding operation, making sure that no one is in the danger
zone, and immediately release the button in case of abnormal situations.
To open
Give an open command via the control button and hold it down until the sliding part is fully open.
The system stops itself when fully open.
To close
Give a close command via the control button and hold it down until the sliding part is completely closed.
The system stops itself when fully closed.
IF THE CONTROL BUTTON IS RELEASED, THE SLIDING WILL STOP IMMEDIATELY WITH MOVING.
ALWAYS REMEMBER THERE IS A SMALL DELAY DEPENDING OF THE WEIGHT AND HOW LARGE
THE LEAF IS.
ALWAYS TAKE CARE, BEFORE AND WHEN OPERATING THE SLIDING UNIT, THAT THE ENTIRE
SLIDING ZONE IS FREE OF OBSTACLES AND/OR PERSONS AND THIS DURING THE ENTIRE RUN
PERIOD.
4
Keller minimal windows®| 997-00220 | 05-2022
Keller minimal windows®

02
Operating instructions
smart slider - Operating instructions
02. Electric operation
2.3 If mode: SEMI AUTOMATIC operation
This means that when the user presses the control button, the automation will open/close the sliding unit almost
completely automatically, up to approximately 25 cm from the end (or the danger zone for pinching). To open/close
the sliding assembly completely (the last 25cm), keep the command button pressed until the sliding assembly is
fully open/closed. The user is responsible for keeping an eye on the moving assembly, making sure that no one is in
the danger zone, and in the event of abnormal situations he can immediately release the control button to stop the
action.
TO OPEN
Give an open command via the control button, the sliding part will open automatically and stop about 25 cm
before the end. From here you have to give again an open command via the control button, at this time keep the
button pressed until the sliding part is fully open. The system stops itself when fully open.
TO CLOSE
Give a close command via the control button, the sliding part will close automatically and stop about 25
cm before the end. From here you have to give again an close command via the control button, at this time keep
the button pressed until the sliding part is completely closed. The system stops itself when completely closed.
IF YOU STOP PRESSING THE CONTROL BUTTON DURING THE LAST 25CM, THE SLIDING WILL
STOP IMMEDIATELY WITH MOVING. ALWAYS REMEMBER THERE IS A SMALL DELAY DEPENDING OF
THE WEIGHT AND HOW LARGE THE LEAF IS.
ALWAYS TAKE CARE, BEFORE AND WHEN OPERATING THE SLIDING UNIT, THAT THE ENTIRE
SLIDING ZONE IS FREE OF OBSTACLES AND/OR PERSONS AND THIS DURING THE ENTIRE RUN
PERIOD.
5
Keller minimal windows®| 997-00220 | 05-2022
Keller minimal windows®

02
Operating instructions
smart slider - Operating instructions
02. Electric operation
2.4 If mode: AUTOMATIC operation
2.5 Disengaging the Lock
The whole movement is controlled via an “automatic control”, which means that when the user presses the
operating button, the automation will fully open or close the sliding assembly automatically. The user remains
responsible for the sliding whole in it keep an eye out, make sure that no one is in the danger zone.
TO OPEN
Give an open command via the control button, the sliding part will open fully automatically.
The system stops automatically when fully open.
TO CLOSE
Give a close command via the control button, the sliding part will full close automatically.
The system stops automatically when fully closed.
ALWAYS TAKE CARE, BEFORE AND WHEN OPERATING THE SLIDING UNIT, THAT THE ENTIRE
SLIDING ZONE IS FREE OF OBSTACLES AND/OR PERSONS AND THIS DURING THE ENTIRE RUN
PERIOD.
In the event of a power failure or a defect in the drive, and the window is closed, and you want to open it, you can
disengage the lock mechanism.
This allows you to manually open your sliding system by hand. First check whether your sliding assembly itself has
no defects !!
IF YOU MOVE THE SLIDING SYSTEM BY HAND, MAKE SURE THE MOVEMENT IS CONTROLLED. IF
NOT, THERE MAY BE DAMAGE TO THE SLIDING SYSTEM AND/OR TO THE WINDOW.
Disengage the automatic lock
Use the supplied hex socket wrench M5, locate the hex socket
bolt at the top of the motor u-housing in the running area
between the brushes.
Insert the key in it and turn it clockwise, until you feel resistance.
The lock is disengaged.
You can open the window manually.
If you close the window the lock still will be open.
If you want that the sliding system locks automatically again,
you must turn the same bolt counter wise until you feel again
resistance.
6
Keller minimal windows®| 997-00220 | 05-2022
Keller minimal windows®

03
Operating instructions
smart slider - Operating instructions
03. Maintenance and care
3.1 Care of your smart slider®system
3.2 General safety regulations for maintenance and service
Do not treat with caustic or aggressive products. Use water and mild polish to clean the motor u-housing.
• This manual describes the maintenance of the automation.
• Adding or omitting parts can adversely affect the functioning and thus the safety of the system is therefore
strongly forbidden!
• All indications about mounting right / left always apply from the inside, so from inside to outside view!
• All dimensions are in cm’s unless otherwise stated.
• You should keep this maintenance manual in a safe place.
• Make sure the power is off and stays off when doing electrical work!
• Wear personal safety measures such as gloves and clothing as well as safety shoes when servicing the system
• Make sure that you can always perform your work stably.
• Secure the installation/maintenance area with a safety tape so that third parties (children!) are kept at a
distance.
• Provide sufficient light.
IF ANYTHING IS UNCLEAR ABOUT THE MAINTENANCE OR SERVICE INSTRUCTION, PLEASE
CONTACT YOUR DISTRIBUTOR. TO AVOID SERIOUS PERSONAL INJURY, ALL DIRECTIONS AND
INSTRUCTIONS IN THIS SERVICE MANUAL MUST BE FOLLOWED CAREFULLY READ AND ADHERED
TO.
A LONG SERVICE LIFE OF YOUR AUTOMATION IS ONLY GUARANTEED WITH REGULAR
MAINTENANCE, CARE AND INSPECTION. IF THE MAINTENANCE IS NOT CARRIED OUT, IS
NEGLECTED, AND IS CARRIED OUT LEVEL 2 BY AN UNQUALIFIED COMPANY, YOUR SUPPLIER/
DISTRIBUTOR CANNOT BE HELD LIABLE FOR THE CONSEQUENCES OF THIS SHORTCOMING.
INSPECTION OF THE AUTOMATION MUST BE CARRIED OUT AT LEAST 1X PER YEAR BY A
QUALIFIED COMPANY AND MUST ALSO BE RECORDED IN WRITING.
7
Keller minimal windows®| 997-00220 | 05-2022
Keller minimal windows®

04
1
2
Operating instructions
smart slider - Operating instructions
04. Maintenance intervals
4.1 General
4.2 Maintenance levels
The maintenance intervals must be checked according to the service interval specified by the distributor.
This service inspection must be recorded in writing.
This service inspection must be inspected by a recognized installer or company.
Maintenance can be divided into two levels:
Maintenance level 1: User level maintenance
WHEN: with normal use 1 x per month
WHO: maintenance that can possibly be carried out by the end user himself!
PAGE: see this manual at page 25
Maintenance level 2: Quallified level maintenance
WHEN: with normal use 1 x per year
WHO: maintenance to be carried out by a qualified company!
PAGE: see this manual at page 26 →qualified company
8
Keller minimal windows®| 997-00220 | 05-2022
Keller minimal windows®

04
1
Operating instructions
smart slider - Operating instructions
04. Maintenance intervals
4.3 User level maintenance
This monthly service can be performed by yourself without the intervention of a qualified technician.
• Only use suitable tools.
• Subject to technical changes without written notice.
• Disconnect the installation from the electrical mains and ensure that it remains disconnected during
maintenance work!
• Check manually whether the sliding assembly still runs smoothly. Keep the slide course free of dirt.
• Check whether the flight bar is still nicely and centered between the brushes.
• Check the operation of the automation by checking whether the sliding part has a nice continuous movement
exhibits.
• Check the guide arm and flight bar for loosening of the sliding part, cracks or damage.
• If loosened, damaged or cracks are visible, you must always contact your distributor to have it replaced.
• Check the construction for cracks or damage. If damaged or cracks are visible, please contact your distributor
at all times to have it replaced.
9
Keller minimal windows®| 997-00220 | 05-2022
Keller minimal windows®

04
2
Operating instructions
smart slider - Operating instructions
04. Maintenance intervals
4.4 Quallified level maintenance
This annual service can only be performed by a qualified technician from your distributor.
If anything is not clear about the maintenance or service instruction please contact Keller Minimal Windows SA.
To avoid serious personal injury, all directions and instructions in this one should be taken service manual must be
carefully read and followed.
• Only use suitable tools.
• Subject to technical changes without written notice.
• Disconnect the installation from the electrical mains and ensure that it remains disconnected during
maintenance work!
• Bearings, guides and moving parts must be lubricated with oil (SAE 20 quality).
• Check suspensions, timing belt and reversible discs for cracks or damage.
• Check closing and open forces
• Check play between sliding part with surrounding parts
• General check bolts and nuts for loose
• Check the guide arm and flight bar if it is still securely attached and if it is still centered between the brushes
• Check end-of-run
• Check the construction for cracks or damage.
• Check all possible parts for cracks or damage.
• Check all possible safety devices for proper operation.
10
Keller minimal windows®| 997-00220 | 05-2022
Keller minimal windows®

05
Operating instructions
smart slider - Operating instructions
05. Faults
5.1 General possible faults
Malfunction Possible cause Solution
Sliding part does not open/close
properly
Obstacle detected See if running way is completely
free of obstacles and dirt
No power Call an qualified technician
No command? Call an qualified technician
Broken control unit Call an qualified technician
Sliding part runs not smoothly Obstacle detected See if running way is completely
free of obstacles and dirt
Mechanical issue Call an qualified technician
Motor moves but sliding part does not Mechanical issue Call an qualified technician
Motor unlocked Lock motordrive (see chapter 2.5
of this manual)
Strange noise during operation Mechanical or electrical issue Call an qualified technician
11
Keller minimal windows®| 997-00220 | 05-2022
Keller minimal windows®

06
• Disconnect the installation from the electrical mains and ensure that it remains disconnected during
maintenance work!
Only qualified assembly / disassembly personnel may be entrusted with the disassembly.
Make sure only assembly / disassembly personnel is present at the installation site during the disassembly and
keep third parties at a distance, if necessary by using a safety tape.
Provide sufficient light when disassembling.
Make sure you are using the correct tools and that you are standing firm.
Always use gloves, safety shoes, hard hat and safety glasses.
Remove the power plug from the socket and secure against re-plugging during work.
Remove the front cover. Remove the top cover. Unscrew the carrier bracket. Disassemble the beam completely.
Pay attention sufficient support so that the beam does not fall when unscrewed.
Carefully lower the motor bar and remove it carefully following the local waste disposal regulations.
All parts of the automation are easy to separate and process again. After disassembly, separate the parts.
Note:
Material is only recyclable if it is returned separately. Hand in materials to the appropriate authority responsible is for
processing separated materials.
AB-Matic nv
Duifhuisstraat 37
3800 Sint-Truiden
Belgium
www.ab-matic.be
Operating instructions
smart slider - Operating instructions
06. Decommissioning / Disassembly / Disposal
6.1 Take out of operation
6.2 Disassembly General
6.3 Procedure
6.4 Removal
6.5 The manufacturer
12
Keller minimal windows®| 997-00220 | 05-2022
Keller minimal windows®

07
Operating instructions
smart slider - Operating instructions
07. Maintenance report
7.1 Report
1. Description : sliding automation unit Type : smart slider®
Performance : Serial Number :
Year of construction.: Commissioning on :
Manufacturer : AB-Matic nv, Duifhuisstraat 37, 3800 Sint-Truiden, Belgium
2. Customer :
3. Installer :
4. Sliding unit to be operated :
Type:
Dimension:
Weight:
5. Control :
6. Working mode
Type: deadman semi automatic automatic 
Name technician :
Date of execution :
Signature:
7. List of installed components :
13
Keller minimal windows®| 997-00220 | 05-2022
Keller minimal windows®

07
Operating instructions
smart slider - Operating instructions
07. MAINTENANCE REPORT
7.2 List of inspections
List of inspections following maintenance procedures in this manual
Date Description of works Signature Signature
(installation, start-up, adjustments, safety checks, repairs...) technician customer
• Always note works that have been carried out in writing!
• Fill in the maintenance sheet and work order for each inspection / maintenance / repair and have them signed.
• Archive the work order in the dealer's file!
14
Keller minimal windows®| 997-00220 | 05-2022
Keller minimal windows®

08
Operating instructions
smart slider - Operating instructions
08. Commissioning declaration
8.1 Commissioning declaration (file this in the dealer's file)
1. Description : sliding automation unit Type : smart slider®
Performance : Serial Number :
Year of construction.: Commissioning on :
Manufacturer : AB-Matic nv, Duifhuisstraat 37, 3800 Sint-Truiden, Belgium
2. Customer :
3. Installer :
4. Sliding unit to be operated :
Type:
Dimension:
Weight:
Prior checks carried out Control during operation
The product is complete and in good condition Movement is running smoothly
Safety devices are in good shape and condition Start – Stop function
No defects found Adjustments
Installation check-up Performance tests
Checking the assembly Absence of abnormal vibrations
Markings Absence of abnormal noise
Mechanical protections Performance met
Absence of damage and permanent deformations
Remarks I, the undersigned hereby declare:
The operating manual, maintenance manual with
maintenance data sheet and disassembly has been
handed over to the customer. The operation and
operation is fully explained to the customer. The
customer is warned of permanent risks and for wrong use.
/
(signature customer / Date)
15
Keller minimal windows®| 997-00220 | 05-2022
Keller minimal windows®

09
Operating instructions
smart slider - Operating instructions
09. Legal notice
All information contained in this manual has been compiled to the best of our knowledge and tested
with care. Nevertheless, errors cannot be completely ruled out. For this reason, the information contained
in these instructions is not associated with any obligation or guarantee of any kind. As a result, Keller
Minimal Windows S.A. accepts no responsibility and will not accept any consequential or other liability
arising in any way from the use of this information - or any part thereof - including for any infringement
of patent rights which may result.
Likewise, Keller Minimal Windows S.A. does not guarantee that the processes described are free
from the property rights of third parties. The reproduction of common names, trade names, product
descriptions, etc. in this work does not justify the assumption that such names are to be considered
free in the sense of trademark and brand protection legislation and may therefore be used by anyone,
even without special labelling.
The contents and data contained in this work are protected by copyright. All rights to the contents are
the sole property of Keller Minimal Windows S.A..
Any transfer to third parties and any further use or exploitation of the contents outside the legal limits
- in particular those of the copyright law - is not permitted without the prior written consent of Keller
Minimal Windows S.A..
Luxembourg law applies.
Copyright © 2021 Keller Minimal Windows S.A.
Responsible publisher
Keller Minimal Windows S.A.
38-40, Route de Wilwerdange
L-9911 Troisvierges
Tel. [phone]
[e-mail]
www.minimal-windows.com
16
Keller minimal windows®| 997-00220 | 05-2022
Keller minimal windows®

05/2022
Keller Minimal Windows S.A.
38-40, Route de Wilwerdange
L-9911 Troisvierges
www.minimal-windows.com
