Multi-
Multi-Charger Charger
User’s Guide
SCGN06
USING YOUR MULTI-CHARGER continued
If your microscope is unplugged before the charge is complete, the LED channel will stay blinking red for 30
seconds. This indicates that the cordless microscope should be plugged back in to complete charging and will
resume at the same level as before unplugged. However, if unplugged longer than 30 seconds and prior to com-
pleting the charge to the cordless microscope, the multi-charger will reset the channel time and turns off the
charge current for that channel. The entire charge cycle will restart, and the charge level will indicate zero.
Learn more about the complete line of Ken-A-Vision
Cordless Microscopes at 1.800.334.8407 or visit our
web site at: www.ken-a-vision.com
Ken-A-Vision's uniquely designed microscopes
and stereoscope with patented light source
technology equivalent to a 20-watt bulb, provides
you with quality optical illumination.
It's no ordinary microscope -
It's a Ken-A-Vision Cordless Microscope!
Ken-A-Vision Cordless microscopes and the Multi
Charger - It's the ideal tool when lack of electrical
outlets are of concern.
Ken-A-Vision Manufacturing Co., Inc.
5615 Raytown Road Kansas City, MO 64133 USA
Tel. [phone] * Fax: [phone]
Email: [email protected] * Web: www.ken-a-vision.com
INFORMATION TO THE USER – Ken-A-Vision reserves the right to make design improvements and other changes in accordance with the latest technology. There is no
obligation to make changes in products already manufactured. ©2002 Ken-A-Vision Corporation. Use only Ken-A-Vision products with the Multi-Charger.
Ken-A-Vision is not responsible for any loss or damage that may occur from use with other non Ken-A-Vision products.
INS-SCM

CONNECTING YOUR MULTI-CHARGER
1. Connect the power supply to the Multi-Charger and the other end into a 110v electrical
outlet (see drawing below). There is no on/off button to worry about. Once the power supply
is plugged in the LED will light up (red) and turn to green. The 16 LED meter will scan from
left to right and then from right to left, then stops. The channel LED remains green indicating
the charger is ready to go.
2. Next connect the pre-attached cables from the Multi-Charger to the power outlet located on
the back of your Ken-A-Vision Cordless microscopes.
Each channel of the charger is independent and the charge time is started when your cordless
microscope has been connected to the Multi-Charger. NOTE: It is not necessary to have a microscope
connected to each channel for operation.
1. Power Supply connection
2. Rear Panel
3. Push channel button for indicating amount of charge
4. LED Channel light with Red and Green
indicator lights
5. LED Meter indicator displays percent of charge
USING YOUR MULTI-CHARGER
When the charger cable is plugged into a cordless microscope, the LED channel indicator will
turn to red and the LED meter will start to scan indicating that the charger is charging the
cordless microscope.
After charging for a couple of hours, press the channel button and the LED meter will indicate
how much charge the cordless microscope has received from 0 – 100%. When a charge is
complete for a channel, it will change the channel LED color from red to green and blink on
and off. NOTE: Charging time is 8 hours – for optimum use, we recommend fully charging your cordless
microscope)
Disconnect the pre-attached cable of the multi-charger from your cordless microscope and
you’re ready to go. Ken-A-Vision Cordless microscopes last up to 40 hours of operation with-
out any electrical connections. NOTE: Do not leave your cordless microscopes connected to the Multi-
Charger for more than 1 week.
Multi-Charger User’s Guide
INTRODUCTION
Thank you for purchasing the Multi-Charger SCGN06.
This Multi-charger system is designed to charge (8) Ken-A-Vision® Cordless microscopes at
the same time on different channels with one electrical outlet. Each channel charges independ-
ently, so microscopes can be connected at various times or at the same time. LED lights indi-
cate channels in use and the percent of charge received.
NOTE: This charger will only charge NiMH (Nickel Metal Hydride) batteries found in Ken-A-Vision Cordless
microscopes.
FEATURES
• Eight station (channels) charger for NiMH Cordless Microscopes has 6’ pre-attached cables
that allow for multiple connections to charge your microscopes at one electrical outlet.
• LED Meter indicator with (6) red, (5) yellow, and (5) green displays the amount of charge
received.
• Eight LED Channels with RED and GREEN charging indicator lights lets you know when
you are charging or not.
• Power Supply: 100 – 240v AC Input, 12V 2.5A DC Output
• Charging time: 8 hours
SOME HELPFUL HINTS
1. The Multi-Charger is designed with a high precision microprocessor. Do not use other
power supplies (even if they fit). They could produce improper voltage and this would
seriously damage your Multi-Charger.
2. User maintenance of the unit is limited to cleaning the exterior of the unit. This can be
accomplished with a clean, damp cloth.
3. Operating Conditions: 0º — 40º C temperature * 30% — 80% humidity.
