Kenmore Elite Series User manual

Kenmore Elite®
P/N 134779000B(0807)
1.3 HP Blender
with Single Serve Cup
1.3 HP Blender
with Single Serve Cup
Models/Modelos: 100.76773410
English / Español
Use & Care Guide
Manual de Uso y Cuidado
Customer Assistance/Asistencia al Cliente
1-855-438-7899
Sears Brands Management Corporation
Hoffman Estates, IL 60179 U.S.A.
www.kenmore.com
www.sears.com
www.kmart.com
KENMORE ELITE LIMITED WARRANTY
FOR FIVE YEARS from the date of sale this appliance is warranted against defects in
material or workmanship.
WITH PROOF OF SALE, return a defective appliance to the retailer from which it was
purchased for free replacement.
This warranty is void if this appliance is ever used for other than private household purposes.
This warranty does not cover blender blades, which are expendable parts that can wear out
from normal use within the warranty period.
This warranty gives you specific legal rights, and you may also have other rights which vary
from state to state.
Sears Brands Management Corporation, Hoffman Estates, IL 60179
KENMORE ELITE LIMITED WARRANTY
FOR FIVE YEARS from the date of sale this appliance is warranted against defects in
material or workmanship.
WITH PROOF OF SALE, return a defective appliance to the retailer from which it was
purchased for free replacement.
This warranty is void if this appliance is ever used for other than private household purposes.
This warranty does not cover blender blades, which are expendable parts that can wear out
from normal use within the warranty period.
This warranty gives you specific legal rights, and you may also have other rights which vary
from state to state.
Sears Brands Management Corporation, Hoffman Estates, IL 60179

23
IMPORTANT SAFEGUARDS PARTS AND FEATURES
SAVE THESE INSTRUCTIONS!
When using electrical appliances, basic safety precautions should always be
followed, including the following:
1. READ all instructions.
2. To protect against risk of electrical shock do not put blender in water or other liquid.
3. Close supervision is necessary when any appliance is used by or near children.
4. UNPLUG from outlet when not in use, before putting on or taking off parts, and
before cleaning.
5. AVOID contact with moving parts.
6. DO NOT operate any appliance with a damaged cord or plug, or after the
appliance malfunctions or has been dropped or damaged in any manner. Return
appliance to the nearest authorized service facility for examination, repair or
adjustment.
7. The use of accessory attachments, including canning jars, is not recommended by
the appliance manufacturer and may cause a risk of personal injury.
8. DO NOT use outdoors.
9. DO NOT let the cord hang over the edge of table or counter.
10. Keep hands and utensils out of container while blending to reduce the risk of
severe injury to persons or damage to the blender. A scraper may be used, but
must be used ONLY when the blender is not running.
11. Blades are sharp. Handle carefully.
12. To reduce the risk of injury, never place cutter-assembly blades on base without
jar properly attached.
13. ALWAYS operate blender with cover in place.
14. When blending hot liquids remove measuring cup from the two-piece lid. Do not
fill jar beyond 3-cup level.
15. To protect against electrical shock this appliance is equipped with a cord having
a 3-prong grounding-type plug for insertion into a proper grounding-type receptacle
DO NOT alter the Plug for use in a 2-prong receptacle. lf the plug will not fit into
a receptacle, have the proper receptacle installed by a qualified electrician.
16. A short power supply cord (or detachable power supply cord) is to be provided
to reduce risks resulting from becoming entangled in or tripping over a longer
cord. This appliance is equipped with a short power supply cord.
17. This appliance is for HOUSEHOLD USE ONLY.
Jar
Lid
Measuring Cup
(middle of the lid)
Lid Lock Flap
Motor
Base
Single
Serve Cup
Drinking
Lid
Blade
Assembly
Blade
Assembly
Fig. 1
Control
Panel
Single
Serve
Stir
On/Off
Chop
Mix
Liquefy
Pulse
Ice
Crush

45
PREPARING YOUR BLENDER
TO OPERATE BLENDER
1. Place Blender motor base on a dry, level, stable surface.
2. Set jar assembly into place on motor base.
3. Place the food solids and liquids to be blended into the jar and put the lid on the
jar before blending. Secure the lid onto the jar by snapping the Lid Lock Flaps over
the tabs on the side of the jar. See Fig. 4. Be sure the measuring cup is in place in
the middle of the lid.
4. Plug power cord into a standard 120-V, 60 Hz AC-only, 3-prong electrical outlet.
Press the On/Off button to turn on the blender controls. The blue LED will flash
0:00 for the timer, and the On/Off button words will flash.
IMPORTANT: Always rest one hand on top of blender jar with lid securely in place
when operating blender.
BLENDER FUNCTIONS
When a function button is pressed,
the function operates continuously
(except Ice Crush) at one speed for
a 1 minute cycle and then stops. Press
the button again to turn the function
off prior to 1 minute. To reactivate
the function past the 1 minute
cycle, simply repress the button.
NOTE: Once the On/Off button is pressed, the button and window display will
go out if no function button is pressed within 2 minutes.
SINGLE SERVE
Use SINGLE SERVE function only when the Single Serve Cup is inserted onto the
motor base. See USING THE SINGLE SERVE CUP section in this Use & Care Guide.
STIR, CHOP, MIX or LIQUEFY
Press the On/Off button. The button words will flash and timer will flash 0:00 in
window. Press Stir, Chop, Mix or Liquefy function button to start blender blade
rotation. Timer will count up to 1 minute and blender will stop. Press On/Off
or function button at any time during cycle to cancel operation.
CONTROL PANEL (Fig. 3)
Your blender has been designed to work
in a variety of ways to suit your blending
needs. You can easily control its blending
function by means of the control panel
buttons: Single Serve, Stir, Chop, Mix,
Liquefy, Ice Crush and Pulse
Single Serve and Pulse allow intermittent
operation. Stir, Chop, Mix and Liquefy are
continuous operation in an ascending
scale of speed from Stir (slowest) to
Liquefy (fastest). Ice Crush is fastest speed
with programmed pauses to optimize ice
crushing performance.
1. Before assembling your blender, wipe blender base with a warm sudsy cloth,
then wipe clean with a damp cloth. Dry with a soft cloth. Wash blender jar, lid,
and blades in warm, sudsy water. Rinse and wipe parts dry.
2. Align the guide ribs inside the
jar collar with the guide grooves
on the motor base and lower the
jar securely into place (Fig. 2).
OPERATING YOUR BLENDER
CAUTION: NEVER place blender motor base in water or other liquid.
WARNING: To avoid severe
cuts or amputation, NEVER
reach fingers or hands into the
blender jar once jar is secured
into place.
CAUTION: Blades are sharp. Handle carefully
Single
Serve
Stir
On/Off
Chop
Mix
Liquefy
Pulse
Ice
Crush
Single
Serve
Stir
On/Off
Chop
Mix
Liquefy
Pulse
Ice
Crush
Fig. 2
Fig. 4
Fig. 3
Guide
Groove

6
7
OPERATING YOUR BLENDER OPERATING YOUR BLENDER
ICE CRUSH
Press the On/Off and then the Ice Crush button. the Blender will spin for one second
and rest for two seconds. This will repeat 5 times. The blender will then run
continuously for 45 seconds and then turn off. See CRUSHING ICE in BLENDER TIPS
AND TECHNIQUES section for further ice crushing details.
PULSE MODE
The blender has a Pulse function that is controlled by pressing one of the other
function buttons after the Pulse button has been pressed. To run the blender
intermittently (pulse mode) rather than continuously, first press the PULSE button.
The PULSE button words will illuminate. P will flash in the display window. Press one
of the six function buttons in the row above the display window. When you release
the button the blender will stop and turn off. Press the Pulse button again if you want
to leave Pulse operation.
MEASURING CUP LID HOLE
To add food or pour liquid into the jar
while blender is in operation, remove the
measuring cup in the middle of the lid.
Add the ingredients through the hole in
the middle of the lid, and then replace
the measuring cup
After adding ingredients, DO NOT allow the
blender to run without the lid and measuring
cup securely in place. The speed of the blades
will throw contents high up in the jar, and
without the lid could spill out.
WARNING: Do not touch blades.
Always turn blender off and wait until
blades have stopped rotating before
removing jar or lid.
CAUTION: When removing jar from motor base after recent blender
operation, avoid contact with the metal gear on the underside of the blade
assembly. The gear will be hot from use.
Single
Serve
Stir
On/Off
Chop
Mix
Liquefy
Pulse
Ice
Crush
USING THE SINGLE SERVE CUP
1. Insert the appliance plug into an appropriate
wall socket.
2. Fill the single serve cup with desired food and
secure the blade assembly lid onto the cup
as shown.
3. Turn the single serve cup upside down and
place it onto the motor base, aligning the
tabs on the cup with the motor base. Press
the On/Off button. The Single Serve button
words will flash 3 times and then go out. The
On/Off button words and the timer in the
window display will begin flashing.
4. Press the Single Serve button to
start blending. The timer in the window display
will count the number of seconds each time
the Single Serve button is pressed. Operate
blender with Single Serve button until
ingredients are satisfactorily blended. Press
On/Off button to leave Single Serve function.
5. Rotate the single serve cup counterclockwise
and take it out from the motor base (Fig. 7).
Turn the single serve cup over and rest it on a
flat surface. Replace the blade assembly with
the drinking lid (Fig. 8). Raise the cap on the
drinking lid to drink the blended contents
directly out of the cup.
Fig. 5
Fig. 6
Fig. 8
Single
Serve
Stir
On/Off
Chop
Mix
Liquefy
Pulse
Ice
Crush
Fig. 7

8
9
NOTESBLENDER TIPS AND TECHNIQUES
CARE AND CLEANING
For quicker, easier blending, cut food into 2-in. long pieces before adding to blender
jar. To chop or grate either fresh or frozen fruit, cut fruit into pieces about 3/4 -inch
long.
To best circulate foods or fruit that are to be blended with liquid, pour the liquid into
the jar first, then add the solid foods or fruit.
The following tasks cannot be performed efficiently with a blender: beating egg
whites, whipping cream, mashing potatoes, grinding meats, mixing dough, and
extracting juices from fruit and vegetables.
The following items should never be placed in the blender jar, as they can cause
damage: bones, large pieces of solid frozen foods, or dense, tough foods such as
turnips.
CRUSHING ICE
To crush ice, ALWAYS have liquid in the jar. Start out with 2 cups
of liquid, and add about 2 cups of ice cubes. Hold one hand firmly on the lid.
Push the Ice Crush button.
If more ice is needed, remove the measuring cup in the middle of the lid and add cubes
one at a time through the hole in the lid. DO NOT CRUSH ICE WITHOUT LIQUID.
1. Before cleaning, unplug the blender.
2. Rinse parts (jar with fixed blade assembly, jar lid and measuring cup, and single
serving cup blade assembly) immediately after blending for easier clean up.
3. All removable parts can be washed by hand or in a dishwasher. The jar lid and
measuring cup, and single serve lid and blade assembly should be placed in the
top rack only. Disassemble all parts from each other before placing in the
dishwasher. The jar with fixed blade assembly and single serve cup are bottom
rack dishwasher-safe. Do not place the jar or any other parts in boiling liquids.
4. The motor base is designed to be resistant to liquids. If liquids spill into the
motor base:
• Unplug the motor base.
• Wipe with a damp cloth and dry thoroughly.
• NEVER immerse the motor base in water.
5. Do not use abrasive scouring pads or cleaners on motor base as finish may
become scratched or damaged.
CAUTION: Failure to follow all of the above directions can result in damage
to the blades, jar, blender motor, and possibly result in personal injury.
CAUTION: The blender blades are sharp. Be very careful when washing
them by hand to avoid being cut.
