KitchenAid KPCB348SPM0 User manual

c2006 KITCHENAID
PROLINE CHEF’S BLENDER
MODELS:
4−06 Litho in U.S.A. (skr) Part No. 8204589 Rev. C
3−SPEED HOUSEHOLD/STAINLESS STEEL JAR
KPCB348SPM0 (Pearl Metallic)
4KPCB348SPM0 (Pearl Metallic)

JAR ASSEMBLY PARTS
2
8204589
For Models: KPCB348S_ _0, 4KPCB348S_ _0
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
Use & Care Guide
8204582 U.S.
8212224 Canada
8204589 Repair Parts List
2 8212228 Cap, Ingredient
3 8211478 Lid Assembly
4 8212231 Jar, Stainless
(Incl Blade Assy)
5 8212281 Blade Assembly

MOTOR AND HOUSING PARTS
38204589
For Models: KPCB348S_ _0, 4KPCB348S_ _0
Illus. Part
No. No. DESCRIPTION
1 4176868 Coupler, Lower
2 4176869 Housing
3 4176870 Cord, Power
6 4176873 Seal, Motor
7 4176874 Motor
8 4176875 Screw, 10 x 16
9 4176876 Base
10 4176877 Screw, 10 x 16
11 4176878 Screw, 8 x 3/8
12 4176879 Foot, Pedestal
13 4176880 Cover, Base
16 8211663 Sensor, Hall
Effect

ESCUTCHEON AND CONTROL PARTS
48204589
For Models: KPCB348S_ _0, 4KPCB348S_ _0
Illus. Part
No. No. DESCRIPTION
1 4176866 Seal, Nameplate
2 4176867 Nut, Washer
3 4176865 Nameplate
4 4176884 Control PCB Assy
3−Speed
5 4176864 Switch, Mount
8 4176861 Seal, Escutcheon
9 4176860 Escutcheon
10 4176859 Switch, On/Off
11 4176858 Bezel, Switch
12 4176883 Mount, Main PCB
13 4176882 Main PCB
14 4176897 Nut, Plastic
15 4176881 Screw, Plastic
16 4176875 Screw, PCB Mount
17 4176877 Screw 10 x 16
18 4176871 EMC Mount
19 4176872 EMC−PC Board
