Kenmore 417 User manual

DRYER
Use & Care Guide
SECADORA
Manual de Uso & Mantenimiento
ESPAÑOLENGLISH
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A. P/N131823700(9901)
www.sears.com

2
Product Record ....................................................... 2
Dryer Warranty ........................................................ 2
Sears Maintenance Agreement ................................. 2
IMPORTANT SAFETY INSTRUCTIONS ................. 3-4
Drying Procedures ............................................. 5-6
Common Drying Problems ..................................... 6
Care and Cleaning .............................................. 7
Avoid Service Checklist ..................................... 8
Español ............................................................ 9
Service .................................................... Back Cover
Full One Year Warranty on Mechanical and Electrical Parts
For one year from the date of purchase, if this Dryer is installed and operated according to the instructions in the Use
and Care Guide, Operating Instructions, and Installation Instructions, Sears will repair or replace any of its mechanical
or electrical parts if they are defective in material or workmanship.
Warranty Restriction
If this Dryer is used for any purpose other than Private Family Use, all warranty coverage is effective for only 90 days.
Warranty Service
Warranty service is available by contacting your nearest Sears Service Center in the United States.
This warranty applies only while this Dryer is in use in the United States.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state.
Sears, Roebuck and Co., Dept. 817WA, Hoffman Estates, IL 60179
Table of Contents Product Record
In the space below, record the date of purchase, model
and serial number of your product. You will find the
modelandserialnumber printed onanidentificationplate
located on the left side of the door opening.
ModelNo.______________________________________
DateofPurchase_______________________________
SerialNo._____________________________________
Save these instructions and your sales receipt for future
reference.
417.
DryerWarranty
Sears Maintenance Agreement
"We Service What We Sell" is our assurance to you that you can depend on Sears for service. Your Kenmore appliance
has added value when you consider that Sears has service units nationwide, staffed with professional technicians trained
on all appliances Sears sells. They have the knowledge and skills, tools, parts and equipment to ensure our pledge to you
that "We Service What We Sell."
Maintainthe value of your purchase with aSears Maintenance Agreement. Kenmore appliances are designed,
manufactured, and tested for years of dependable operation. Yet any major home appliance may require service from
time to time. The Sears Maintenance Agreement offers you an outstanding service program for your product.
TheSearsMaintenanceAgreement:
€ Is your way to buy tomorrow's service at today's prices.
€ Eliminates repair bills resulting from normal use.
€ Allows for as many service calls as you need.
€ Providesan annualPreventive Maintenance Check at yourrequest
tokeepyourKenmoreApplianceinproperrunning condition.
For more infomation, call 1-800-827-6655.

3
ENGLISH
For your safety, the information in this manual must be followed to minimize the risk of fire or
explosion or to prevent property damage, personal injury or loss of life.
-Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS:
•Do not try to light any appliance.
•Do not touch any electrical switch; do not use any phone in your building.
•Clear the room, building or area of all occupants.
•Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
•If you cannot reach your gas supplier, call the fire department.
Installation and service must be performed by a qualified installer, service agency or the gas supplier.
Important Safety Instructions
Read all instructions before using this dryer.
To reduce the risk of fire, electrical shock, or injury to persons
when using this dryer, comply with the basic warnings listed below.
Failure to comply with these warnings could result in serious personal
injuries.
Prevent Fire
Do not dry items that have been previously cleaned in, soaked
in, or spotted with gasoline, cleaning solvents, kerosene, cooking oils, waxes,
etc. Do not store these items on or near the dryer. These substances give off
vapors that could ignite or explode.
To prevent fire, do not use heat to dry items containing plastic,
foamrubber or similarlytextured rubber-likematerials,or itemscontaining
feathers or down. Use Air Fluff (No Heat) only.
Clean the lint screen before or after each load. The interior of
the dryer, lint screen housing and exhaust duct should be cleaned
approximately every 18 months by qualified service personnel. An excessive
amount of lint build-up in these areas could result in inefficient drying and
possible fire. See Care and Cleaning, page 7.
Do not operate the dryer if the lint screen is blocked, damaged
or missing. Fire hazard, overheating and damage to fabrics can occur. If your
dryer has a drying rack, always replace the lint screen when finished using the
dryingrack.
Keepareaaroundtheexhaustopeningandsurroundingareas
free from the accumulation of lint, dust and dirt.
Do not obstruct the flow of ventilating air. Do not stack or place
laundry or throw rugs against the front or back of the dryer.
Do not spray any type of aerosol into, on or near dryer at any
time.
Do not use fabric softeners or products to eliminate static
unless recommended by the manufacturer of the fabric softener or product.
Failure to comply with these warnings could result in fire, explosion,
serious bodily injury and/or damage to the rubber or plastic parts of the dryer.
Yoursafetyandthesafety of
others is very important.
Wehaveprovidedmanyimportant
safety messages in the Use and
CareGuide,OperatingInstructions,
Installation Instructions and on your
appliance.Always read and obey all
safety messages.
This is the safety alert symbol.
This symbol alerts you to hazards
that can kill or hurt you or others. All
safety messages will be preceded by
the safety alert symbol and the word
"DANGER"or"WARNING".These
wordsmean:
DANGER
You will be killed or
seriously injured if you don't follow
instructions. You can be killed or
seriously injured if you don't follow
instructions.
Allsafetymessageswillidentify
the hazard, tell you how to reduce
the chance of injury, and tell you
what can happen if the
instructionsare notfollowed.
Printed in U.S.A.

4
Protect Children
Do not allow children to play on or in the dryer. Close
supervision of children is necessary when the dryer is used near children. As
children grow, teach them the proper, safe use of all appliances.
Destroy the carton, plastic bag and other packing materials after
the dryer is unpacked. Children might use them for play. Cartons covered with
rugs, bedspreads or plastic sheets can become airtight chambers.
Keep laundry products out of children's reach. To prevent
personalinjury,observeall warnings onproductlabels.
Before the dryer is removed from service or discarded, remove
thedryerdoortopreventaccidentalentrapment.
Failure to comply with these warnings could result in serious personal
injuries.
Prevent Injury
To prevent shock hazard and assure stability during operation,
the dryer must be installed and electrically grounded by a qualified service
person in accordance with local codes. Installation instructions are packed in
thedryerfortheinstaller'sreference.RefertoINSTALLATIONINSTRUCTIONS
for detailed grounding procedures. If the dryer is moved to a new location, have
it checked and reinstalled by a qualified service person.
To prevent personal injury or damage to the dryer, the electrical
powercord ofa gas dryer must beplugged intoa properlygrounded and
polarized3-prong outlet.The third grounding prong must never be
removed. Never ground the dryer to a gas pipe. Do not use an extension
cord or an adaptor plug.
ALWAYS disconnect the dryer from the electrical supply before
attempting any service or cleaning. Failure to do so can result in electrical
shock or injury.
Do not use any type spray cleanser when cleaning dryer interior.
Hazardous fumes or electrical shock could occur.
To prevent injury, do not reach into the dryer if the drum is
moving. Wait until the dryer has stopped completely before reaching into the
drum.
To prevent injury and damage to the dryer:
• All repairs and servicing must be performed by an authorized servicer
unless specifically recommended in this Owner's Guide. Use only
authorizedfactoryparts.
• Do not tamper with controls.
• Do not install or store the dryer where it will be exposed to the weather.
A thermal limiter switch automatically turns off the motor in the unlikely
event of an overheated situation (electric dryers only). A service technician
must replace the thermal limiter switch after correcting the fault.
Failure to comply with these warnings could result in serious personal
injuries.
SAVE THESE INSTRUCTIONS
Note:Theinstructionsappearingin
this Use and Care Guide are not
meant to cover every possible
condition and situation that may
occur.Common sense andcaution
must be practiced when installing,
operatingandmaintainingany
appliance.
ThisUseandCareGuide provides
generaloperatinginstructionsforyour
dryer. It also contains information
aboutfeaturesforseveralother
models. Your dryer may not have
everyfeatureincluded.
Use the dryer only as instructed in
this Use & Care Guide and the
OperatingInstructionsincludedwith
yourdryer.
Avoid fire hazard or
electrical shock. Do not use an
adaptorplugorextensioncordor
removegroundingprongfrom
electricalpowercord. Failure to
follow this warning can cause
serious injury, fire or death.
CORRECT
UsethiswayONLY
ELECTRIC DRYERS:
DRYER
FUSED 30 AMP
120/240 V OR
120/208 V
WALL
RECEPTACLE DRYER
SERVICE
CORD
14-30R
GAS DRYERS:
CORRECT
UsethiswayONLY
Grounding type
w
all receptacle
Power supply
cord with 3-prong
grounding plug
Do not under
any circumstances
cut, remove,
or bypass
the grounding prong
from this plug.

5
ENGLISH
•Followtheguidelinesbelowforpreparingtheloadfordrying.
•ReadtheOperating Instructions card foroperatingyourspecific model.
• Always read and follow fabric care labels and laundry product labels.
To reduce the risk of fire, electrical shock, or injury to persons,
readImportant SafetyInstructions,pages3-4,beforeoperatingthisdryer.
1. Prepare items for drying.
•Dry items of similar fabric, weight and construction in the same load.
•Separate dark items from light-colored items. Separate items that shed
lint from those that attract lint. If an item sheds lint, turn it inside out.
•Be sure buckles, buttons and trim are heatproof and won't damage the
drum finish. Close zippers, fasten hooks and Velcro®-like fasteners.
Tie strings and sashes to prevent snagging and tangling.
•If possible, turn pockets inside out for even drying.
•Check for stains which may not have been removed in washing. Dryer
heat may permanently set some stains. Repeat stain removal process
beforedrying.
•Place small items in a mesh bag to prevent tangling and for easy
removal.
2. Check that lint screen is clean and in place.
3. Load the dryer.
• The average load will fill the drum 1/3 to 1/2 full. Items need room to
tumble freely for even drying and less wrinkling. Do not overload
dryer.
• When drying large items, dry only 2 or 3 at a time. Fill out the load with
small and medium sized items.
• For delicate or very small loads, add 2 lint-free towels for better drying,
less wrinkling, and to prevent grease stains caused by fabric softener
sheets.
• Do not overdry items. Overdrying can cause wrinkling, shrinkage,
harshness, and a build-up of static electricity, which can produce more
lint.
• If desired, add a dryer fabric softener sheet.
4. Close the dryer door and set dryer controls (some
models).
See Operating Instructions card for your specific model controls.
5. Turn cycle selector clockwise to the desired setting.
6. Start the dryer.
• Turn the START knob clockwise to ON. Hold for 1-2 seconds and
release.
• To add or remove items when the dryer is running, open the door. The
dryer will always stop when the door is opened. Allow the drum to
come to a complete stop before reaching inside.
• To restart dryer, close the door then turn the START knob clockwise to
ON.Hold for 1-2 seconds andrelease.
7. When the cycle ends, remove items immediately and
hangorfold.Ifloadisremovedbeforethecycleends,turncycleselector
toOFF.
Drying Procedures
Follow fabric care label instructions.
Fill dryer drum 1/3 to 1/2 full.
Place small items in a mesh bag.

6
Cycle Signal Control (some models)
When the Cycle Signal Control is ON, a signal will sound at the end of each
cycle and during the WRINKLE-RID setting (some models). The volume is
adjustable on some models.
Drum Light(some models)
A drum light will come on whenever the door is opened to illuminate the dryer
drumduring loading and unloading. Closing the doorturns off thelight.
Reversible Dryer Door
Your dryer is equipped with a reversible door. The door can be hinged on the
right or left side. Refer to the INSTALLATION INSTRUCTIONS for directions
onchangingthedoor.
Drying Rack (some models)
Use the drying rack to dry items which should not be tumble dried.
1. Open the dryer door and remove the lint screen.
2. Insert drying rack into the dryer drum. Place the front bar under the lip of
thelintscreen opening.
3. Place items to be dried on top of the rack. Weight should not exceed 10
lbs. Leave space between items, but do not let items hang over the sides
or through the grids. Do not tumble other items when using the drying
rack.
4. Select a timed dry setting best suited for items being dried. Use only the
Air Fluff (no heat) temperature setting for items containing plastic, foam
rubber,rubber-likematerials,feathersordown.
5. When items are dry, remove the rack and replace the lint screen. If lint
screen is not in place, tumbling items could enter the exhaust system and
cause damage to the dryer.
Features
PROBLEM • Add a few bath towels to small loads for
proper tumbling.
• Some "silk-like" fabrics should be air
dried.
• Use proper drying temperature.
• Place fabric softener sheet on top of load
before starting the dryer.
• Do not overload dryer.
• Use fabric softener in washer or dryer to
reduce static electricity.
• Remove items when they are slightly
damp to avoid overdrying.
• Check that lint screen is clean and in
place.
• Use fabric softener to lubricate fibers.
• When ironing, use spray starch or fabric
finish on collars and cuffs.
• Turn items inside out to reduce abrasion.
• Follow fabric care label directions.
• If shrinking is a concern, check load often.
• Remove items while slightly damp and
hang or lay flat to complete drying.
• Block knits into shape.
• Do not overload dryer.
• Remove items as soon as cycle ends.
PREVENTIVE MEASURES
Many drying problems involve poor cleaning results, poor soil and stain removal, residues of lint and scum, and fabric
damage. For satisfactory drying results, follow these suggestions provided by The Soap and Detergent Association.
Common Drying Problems
Greasy, oily
stains
Lint
Pilling
(Fibers break
off, ball up and
cling to fabric.)
Shrinking
Wrinkling
POSSIBLE CAUSES
• Fabric softener sheet.
• Overloading.
• Overdrying causes static
electricity.
• Lint screen not clean
when cycle began.
• Lint is attached to "pills."
• Pilling is normal with
synthetic and permanent
press fabrics. This is due
to abrasion from normal
wear.
• Overdrying.
• Overloading.
• Leaving items in dryer
after cycle ends.
SOLUTIONS
• Rub fabric softener stains with bar
soap. Rinse and rewash.
• Reduce load size and rewash using
liquid fabric softener in the final rinse.
• Or, add a fabric softener sheet and
tumble without heat.
• Use lint brush or roller to remove lint.
• Use a lint brush or shaver to remove
pills.
• Irreversible condition.
• Reduce load size and tumble at
medium or low heat for 5-10 minutes.
• Remove items immediately. Hang or
fold.
Place the front bar under
the lip of the lint screen opening.

7
ENGLISH
Care and Cleaning To reduce risk of fire or serious injury to persons or property,
comply with the basic warnings listed in Important Safety Instructions, pages
3-4, and those listed below.
• Beforecleaning the dryer interior, unplug the electrical power cord to
avoid electrical shock hazards.
• Do not use any type spray cleanser when cleaning dryer interior.
Hazardous fumes or electrical shock could occur.
Inside
• Clean the lint screen after every load. Lint build-up in the screen restricts
air flow, which causes longer drying times. The screen is located at the
bottom of the door opening. Remove by pulling straight up. Remove the lint
andreplacethescreen.
• Occasionally a waxy build-up may form on the lint screen from using dryer-
added fabric softener sheets. To remove this build-up, wash the lint screen
inwarm, soapywater. Drythoroughly andreplace. Donot operatethe dryer
without the lint screen in place.
• If the dryer drum becomes stained from noncolorfast fabrics, clean the
drum with a damp cloth and a mild liquid household cleanser. Remove
cleanserresidue before dryingthe nextload.
• Every 18 months an authorized servicer should clean the dryer cabinet
interior and exhaust duct. These areas can collect lint and dust over time.
An excessive amount of lint build-up could result in inefficient drying and
possiblefirehazard.
Outside
• Clean the cabinet with mild soap and water. Never use harsh, gritty or
abrasivecleansers.
• If the cabinet becomes stained, clean with diluted chlorine bleach [1/2 cup
(120 ml) in 1 quart (.95 liter) water]. Rinse several times with clear water.
• Remove glue residue from tape or labels with a mixture of warm water and
mild detergent. Or, touch residue with the sticky side of the tape or label.
•Before moving the dryer,place astrip ofcardboard orthin fiberboard
under the front leveling legs to prevent damage to floor.
Clean lint screen after every load.
Do not store or place laundry products
on top of dryer at any time. They can
damage the finish or controls.

8
Make sure the plug fits tightly in wall outlet.
Reset circuit breaker or replace fuse.
Make sure electrical line is not overloaded and the
dryer is on a separate circuit.
Call authorized service person for replacement.
Replace fuse.
Check to make sure supply valve is open. See
INSTALLATION INSTRUCTIONS for procedure.
See INSTALLATION INSTRUCTIONS.
Refill or replace tank.
Dryer should heat when utility service is restored.
Make sure all lint has been removed from the dryer lint
screen before starting each cycle.
Exhaust duct must be at least 4 inches in diameter and
made of rigid or flexible metal.
When in place, the duct must have no more than two
90° bends and must not exceed length listed in
INSTALLATIONINSTRUCTIONS.
Drying time will be 20% longer than drying on a 240
volt circuit.
See Drying Procedures, page 5.
Clean out any obstruction.
Use a dehumidifier near the dryer.
Do not overload. See Drying Procedures, page 5.
Remove items as soon as cycle ends.
See Drying Procedures, page 5.
Follow fabric care label instructions.
Always remove foreign objects from pockets before
laundering. Remove objects from drum and restart
dryer.
It may be necessary to baste a scrap of material
securely around ornaments before drying to prevent
scratching and damage to the dryer.
Drum damage caused by foreign objects or
permanently attached items is not covered by the
warranty.
Electrical power cord is not securely
plugged in or plug may be loose.
House fuse blown or circuit breaker
tripped.
Thermal limiter tripped.
There are 2 house fuses in the dryer
circuit. If 1 of the 2 fuses is blown, the
drum may turn but the heater will not
operate.
Gas supply valve is not open (gas
models).
Dryer does not have anough air supply
to support the burner flame (gas models).
LP gas supply tank is empty or there has
been a utility interruption of natural gas
(gas models).
Lint screen is clogged with lint.
Exhaust duct requirements have not
been met.
Electric dryer is connected to a 208 volt
circuit.
Drying procedures have not been
followed.
Outside exhaust hood or exhaust duct
may be clogged or restricted.
High humidity.
Dryer is overloaded.
Items left in dryer too long.
Insufficient sorting of items.
Drying temperature too high.
Foreign objects such as coins, pins, clips
or buttons are inside the dryer.
Permanently attached items such as belt
buckles, zippers and fasteners may be
hitting the inside of the drum.
Avoid Service
Checklist Beforecallingforservice,reviewthislist.Itmaysavebothtimeandexpense.Thelistincludes
commonoccurrencesthatarenottheresultofdefectiveworkmanshipormaterialsinthisdryer.
OCCURRENCE SOLUTIONPOSSIBLE CAUSE
Dryer does not start.
Dryer runs but won't heat.
Drying cycle takes too long,
outsideofthedryerfeelstoo
hot or smells hot.
Excessive wrinkling.
Scratchingorchippingofthe
drumfinish.

9
ENGLISH
