Kenmore 27-Inch Electric Double Oven
22-48762 – White
22-48763 – Stainless
22-48764 – Bisque
22-48769 – Black
• Flush-to-cabinet design
• 3.5 cu. ft. capacity (both ovens)
• Select Clean® self-clean oven (both ovens)
• Two porcelain-coated, self-clean oven racks with integrated
handles (both ovens)
• Easy Set™ 615W1 controls with lockout
• Cook & hold warm oven
• Delay cook and clean (both ovens)
double oven | 22-48762/3/4/9
Because of our continuous program of product improvement, Sears
reserves the right to change materials and specications without
notice. Consult installation instructions packed with the product for
nal dimensional data. For complete warranty information, contact
your local Sears Commercial Account Manager.
Model 22-48762 22-48763 22-48764 22-48769
Overall White Stainless Bisque Black
Console White Stainless Bisque Black
Controls White Black Bisque Black
Door White Stainless Bisque Black
Handle White Stainless Bisque Black
Selection
White 22-48762
Stainless 22-48763
Bisque 22-48764
Black 22-48769
Oven Features
Overall Width, Inches 27
Oven Capacity (cu. ft.) 3.5 Upper / 3.5 Lower
Cleaning System Upper Oven Self-Clean
Cleaning System Lower Oven Self-Clean
Variable Time Self-Cleaning Select Clean® (2-3-4 Hrs.)
Electronic Oven Controls Easy Set™615W2
Control Lockout •
Add-1-Minute Timer •
Temperature Recall •
Cook & Hold Warm Oven •
Delay Start Cook / Clean
Automatic Oven Shutoff •
Sabbath Mode** Certified
Hidden Bake Element •
Variable Broiling System Hi / Lo
Integrated Handle Oven Racks 2 Upper / 2 Lower
Self-Clean Porcelain-Coated Racks
•
Oven Rack Positions 4 In Each Oven
Oven Lights Auto / Manual
Removable Glass Door
•
(48763: Stainless Door)
Frameless Oven Door •
Window X-Large
Reach-Through Handle(s) Metal
Upper Oven Interior WxHxD (In.) 20 1⁄2x 16 1⁄2x 18 1⁄32
Lower Oven Interior WxHxD (In.) 20 1⁄2x 16 1⁄2x 18 1⁄32
General Features
Flush Fit Design •
Power Rating (kW) @ 240V / 208V 6.8 / 5.1
Bake @ 240V (Watts)
Both Ovens 6-Pass 2,700
Broil @ 240V (Watts)
Both Ovens 6-Pass 3,400
Breaker / Copper Wire Size (240V) 30 / 10
Shipping Weight (Approx. Lbs.) 252
Warranty
1-Year Limited Warranty –
Entire Appliance Parts & Labor
If used for other than private family purposes, warranty applies for only
90 days.
**Sabbath Mode overrides auto oven shutoff

page 2 of 2
Effective 09/14/09
09909
Because of our continuous program of product improvement, Sears
reserves the right to change materials and specications without
notice. Consult installation instructions packed with the product for
nal dimensional data. For complete warranty information, contact
your local Sears Commercial Account Manager.
22-4876X.PDF
double oven | 22-48762/3/4/9
Because of our continuous program of product improvement, Sears
reserves the right to change materials and specications without
notice. Consult installation instructions packed with the product for
nal dimensional data. For complete warranty information, contact
your local Sears Commercial Account Manager.
50
1/2"
Spacer
24
5/8"
48 5/8"
11 1/2"
24
1/2"
21 "
49
1/8"-
49 7/8"
27
1/8"
24
7/8"-
25
1/4"
23 1/2"
min.
27 "
1" min.
3"
max.
1
1/4"min.
Electrical Junction Box
(Right or Left Side
Depending on Model)
27" & 30" Models:
2" Wide Wood
Spacer if Needed
Hole for Cable
(Right or Left
Side Depending
on Model)
