Kenmore Kenmore 911.40161 User manual

OWNER'S MANUAL
24" BUILT-IN
OVEN WALL MODEL NO.
911.40161
911.40168
911.40169
CAUTION:
Before using this range,
read this manual and
follow all its Safety Rules
and Operating
instructions.
• Safety Instructions
•Operation
• Care and Cleaning
•Problem Solving
_. _rs, Roebuck and Co,, Hoffman Estates, IL 60179 U.S.A.
229C4020P122 (SR- 10342)

Tableof Contents
Oven Safety........................... 3-4
24" BUlLT-IN WALLOVEN
Removal of Packaging Tape .... 5
Features of Your Oven .............. 5
Oven Control, Clock, Timer ...... 6
Control Display ......................... 7
Clock ........................................ 8
Kitchen Timer ........................... 8
Tones ........................................ 9
F Codes .................................... 9
Oven Cooking Tips ............ 10-11
Baking .................................... 12
Broiling ................................... 13
Special Features ................ 14-15
Oven Interior ........................... 16
Control Panel .......................... 16
Broiler Pan and Grid ............... 16
Oven Light Bulb ...................... 16
Oven Racks ............................ 17
Oven Door .............................. 17
Before Calling for Service ....... 18
Temperature Adjustment ....... 19
Warranty ................................. 21
Consumer Service Numbers .. 22
For your convenience and future reference, please write down
your model and serial numbers in the space provided. They are
located on the front frame behind the oven door.
MODEL NUMBER: SERIAL NUMBER:
2

IMPORTANTSAFETY
INSTRUCTIONS
SAVE THESE INSTRUCTIONS
Read all instructions before using this appliance. When using
gas or electrical appliances, basic safety precautions should
be followed, including the following:
IMPORTANT: To insure safety for
y,"':rself, family and home, please
,your Owner's Manual carefully.
Keep it handy for reference. Pay
close attention to Safety Sections.
BE SURE your appliance is in-
stalled and grounded by a qualified
technician.
• DO NOT leave children alone or
unattended near an appliance in use.
• TEACH CHILDREN not to play
with controls or any part of the
appliance, and not to sit, climb or
stand on the door or any parts of
the appliance.
•CAUTION: NEVER STORE
items of interest to children in
cabinets above the appliance.
Children climbing on the appliance
could be seriously injured.
•KEEP THIS book for later use.
• NEVER TRY to repair or replace
any part of the appliance unless
instructions are given in this
manual. All other work should be
done by a qualified technician.
• NEVER USE your appliance for
warming or heating the room.
•ALWAYS KEEP combustible wall
coverings, curtains, dishcloths,
/els, potholders, and other linens
_,safe distance from the appliance.
•NEVER USE atowel or other
bulky cloth as a potholder and
make sure the potholder is dry.
Moist potholders could cause
steam burns. DO NOT let
potholders touch hot surfaces.
•ALWAYS KEEP the appliance
area free from things that will burn.
Food, wooden utensils, and grease
buildup could catch fire. Plastic
utensils could melt and canned
foods could explode. Your
appliance should never be used as
a storage area.
•ALWAYS KEEP your appliance
clear of things that will burn
(gasoline and other flammable
vapors or liquids).
•NEVER HEAT unopened food
containers. Pressure buildup can
cause the container to burst and
cause in}ury.
•NEVER LEAVE jars or cans of fat
or drippings in your oven.
•NEVER TRY to clean a hot
surface. Some cleaners produce
noxious fumes, and wet cloths or
sponges could cause steam burns,
• NEVER WEAR loose fitting
clothing when using your
appliance.
•BE SURE the oven is securely
installed in a cabinet that is firmly
attached to the house structure.
3

IMPORTANTSAFETY
INSTRUCTIONS
•DO NOT touch heating elements,
surfaces near them, or interior oven
surfaces. These may be hot enough
to cause burns even though they
are dark in color. During and after
use, do not touch or let clothing or
flammable material contact the
elements or hot surfaces until they
have had time to cool. Other
surfaces near the oven vent
openings, oven door, and window
may also be hot enough to cause
burns.
READ AND UNDERSTAND
THIS INFORMATION
NOW!
Be sure everyone in your home
knows what to do in case of
fire. Never use water on a
grease fire; it will only spread
the flames.
OVEN FIRE:
Do not try to move the pan!
1. Close the oven door and turn
controls off.
2. If fire continues, carefully open the
door, throw baking soda on the
fire, or use a dry chemical, foam
or baton type extinguisher.
• PLACE OVEN RACKS in the
desired position while the oven is
cool. If racks must be moved while
oven is hot, do not let potholder
contact the hot oven element
•AFTER BROILING, always take
the broiler pan and grid out of the
oven and clean them. Leftover
grease in the broiler pan could
catch fire the next time you use your
oveN,
•ALWAYS USE care when opening
the oven door. Let hot air and steam
escape before moving foods.
•NEVER USE aluminum foil to line
the oven bottom. Improper use of
foil could start a fire or result in risk
of electric shock.
•NEVER BLOCK the oven vent
opening.

OPERATION
FEATURESOF YOUROVEN
Oven Vent Range Con_ol ClockPad
""_1Element
Grid
Number Location
Bake Element
4utornatic Oven
_witch
Oven Temperature
(location
may vary)
Oven Rack
Guides
Removable Oven
Racks
Removable
Oven Door
To remove the adhesive left from packaging tape, use household dishwashing
liquid, mineral oil or cooking oil. With a soft cloth rub into the area and allow to
soak. Rinse and dry well. Repeat procedure using an appliance polish to insure
no damage is done. This should be done before the range is turned
on for the first time, The tape cannot be removed once the oven
h_s heated. Packaging tape may be found in the following areas: door
Jle, control panel area, door trim and oven area.
5

fOh3
Oh3
OPERATION
Clock, Timer and Oven Control
i88"88
@ @@
TEMP HOUR MIN
@ QQ
TIMER OVEN VJTOHEN
TIMER
J
Your new touch pad oven control will
allow you to set oven functions with
ease. Below are the different types of
functions and a description of each.
BAKE -- Cooks foods in the traditional
oven with a temperature range of 170°F
to 550'F.
BROIL -- Cooks foods at 550°F HI
broil or 450° LO broil from the direct
heat of the upper element. Broiling
should be done with the door opened to
the broil stop position.
Set the amount of time you
want foods to cook. The oven
turns off automatically at the
end of this time.
@Set the time of day you want
the oven to turn on. The oven
will turn on automatically at the
time you have set.
HOUR MIN
The HOUR/MIN UP anc
DOWN arrow pads set the
time of day, length of
cooking time, the delayed
start time, and the time set
on the Kitchen Timer.
The TEMP pads set the
temperature used for
TEMP cooking.
The START pad must be
_ pressed to activate any
oven function.
The CLEAR/OFF pad is
used to cancel any oven
function and the end of
cycle tone. It will net
cancel the Clock or
Kitchen Timer.
The ON/OFF pad is used to
turn the Kitchen Timer on or
off. It will not control any of
the other oven functions.

OPERATION
Flashing
Indicator To
Alert You
A Tmperat ure
Or A Time
ControlDisplay
Oven Temperature
Indicator Indicator To Let You
Know the Oven Has
Turned On
Location For The
- Time Of Day Clock,
Kitchen Timer,
Delay Start Time,
Or Oven Cooklng
Oven Function
Indicator Oven Function
Indicator
""'e Control Display is an easy
arence for using your oven control.
Below are descriptions of how the
Control Display works.
OVEN TEMPERATURE
INDICATOR --This indicator has a
multiple purpose.
• Displays the temperature
• Displays an error code --
"ERR" -If the oven temperature
indicator flashes "ERR", then you
have set an invalid time or
temperature.
•Displays Oven Problems -- if
your control flashes "F" and a
number or letter, you have
experienced an oven problem.
P_ease read the section on
F-CODES in your manual.
"ON" INDICATOR -- Will light
when the oven turns on.
SET INDICATORS -- The set
indicator will flash in combination with
an oven function or timed function to
let you know you need to set a time or
temperature. Example: "SET" and
"BAKE" will Flash to let you know
you need to set the bake
temperature.
TIMED INDICATOR -- Displays
the time of day, cooking time, delay
start time, or the time set on the
kitchen timer.
•Displays a reminder code --
"PUSH START" If the time
indicator flashes the word "PUSH
START", then you need to press
the START pad to activate your
setting.
OVEN FUNCTION INDICATORS
-- Displays which oven function has
been set, and if the function is
delayed.

OPERATION
ClockandTimer
The clock must be set for the correct
time of day before a delayed oven
function can work properly. The time
of day cannot be changed during a
timed oven function, but can be
changed during a bake or broil
function.
HOW TO SET THE CLOCK
@@
1. Press the CLOCK pad.
2. Press the UP and/or DOWN
arrow pads to set the time.
3. Press the START pad.
RECALL THE CLOCK
While using your oven for cooking,
press the CLOCK pad if you wish to
check the time of day. The current
time of day will show in the display.
POWER FAILURE
If you have experienced a power
failure, the time will flash in the display
and will be incorrect. Reset your
clock.
Any oven cooking function that was in
process will need to be reset.
The Kitchen Timer is used to time
cooking processes or other
household activities. It does not
control the oven. It can be set for up
to 9 hours and 59 minutes. Itwill
count down in minutes until the LAST
S0 SECONDS is reached, then the
control will beep once. When the
countdown reaches ZERO, the
control will beep 3 times followed by
one beep every 6 seconds until the
KITCHEN TIMER ON/OFF pad is
pressed. The 6 second beep can be
removed for future cycles if desired
For directions on removing this
continous beep, see Tones on the
following page.
HOW TO SET THE TIMER
1. Press the KITCHEN TIMER
ON/OFF pad.
2. Press UP and/or DOWN arrow
pads to set time.
3. Press the START pad.
4. When the countdown has reached
zero, press the KITCHEN
TIMER ON/OFF pad to turn off
the beep.
To cancel the timer during the
countdown, press the KITCHEN
TIMER ON/OFF pad TWICE.
8

OPERATION
Oven Control, Clock and Timer
Your new conl;rolhas a series oftones
that will sound at different times. These
tones may sound while you set the
control for an oven function, or at the
end of the oven function. It will also alert
there may be a problem with the
.lions, Below are the types of tones
and a brief description of each.
TONES WHILE SETTING THE
CONTROL--When you press a touch
pad you wilt hear a beep. This beep will
let you know you have placed enough
pressure on the pad to activate it, (The
arrow pads do not beep.)
END OF TIMED CYCLE TONE_t
the end of a timed cooking function,
you willhear 3 short beeps followed by
Ibeep every 6 seconds. This6 second
beep will continue to sound until the
CLEAR/OFF pad is pressed or you
may select the special feature to cancel
this 6 second beep from sounding at
the end of future cycles.
TO CANCEL THE 6 SECOND
BEEP
1. Press and hold the BAKE and
BROIL pads, at the same time
for 3 seconds, until the display
shows "SF".
2. Press the KITCHEN TIMER pad.
The display willshow "CON
BEEP" (continous beep).
3. Press the KITCHEN TIMER pad
'_gein. The display will show
BEEP' (beep canceled).
4, Press the START pad to cancel the
6 second beep and leave the
special feature mode.
If you would like to return the 6 second
beep, repeat steps above until the
display shows your choice and press
Start.
ATTENTION TONE--This tone will
sound if you make an error or an
oversight is made while setting an
oven function.
Examples would be:
a. Setting function and not pressing
Start.
b. Pressing an additional function pad
without first setting a temperature or
time.
e, ERR will flash if you set an invalid
temperature. Press the CLEAR/OFF
pad to dear the control and reset
your oven function.
Any of these can be quickly identified
by watching the display.
PREHEAT TONE--When you set an
oven temperature, the oven
automatically starts to heat. When the
temperature inside the oven reaches
the temperature you have set, a tone
will sound to let you know the oven is
ready for baking.
Ifyou set an oven function and the
control beeps while the display is
flashing "F" and a number or letter
such as "F.4" or "Fr' there may be a
problem with the control or oven.
Simply press the CLEAR/OFF pad and
wait about an hour. Try setting the
function again. If the code repeats, write
down the flashing code and ca!l for
service. Te!l the technician what code
was flashing.
9

OPERATION
Oven Cooking Tips
It is normal to have some odor when
using your oven for the first time, To
help eliminate this odor, ventilate
the room by opening a window
or using a vent hood.
IMPORTANT: Never cover the oven
bottom or oven rack with aluminum
foil. Improper use can cause poor
heat flow, poor baking results, and
may damage the oven finish.
Preheating is bringing the
temperature up to the temperature
you will be using during baking. Let
the oven preheat thoroughly when
recipes call for preheating.
In the back of the oven you will notice
a small tube. This is a heat sensor
that maintains the temperature of the
oven. Never move or bend this tube.
erature Sensor
The low temperature zone of your
oven (between 170°and 200°F) is
available to keep hot cooked foods
warm. However, foods should not be
kept at these temperatures longer
than 2 hours.
The oven vent is located under the
control panel. This area could
become hot during oven use. The
vent is important for proper air
circulation. Never block this
vent.
Oven Vent
_L...,.,_ Location
When using your convenient Delay
Start operation, foods such as dairy
products, fish, poultry, etc., should
never sit more than 1 hour before
cooking. Room temperatures and the
heat from the oven light promote
bacterial growth.
Opening the door often to check
foods will cause heat loss and poor
baking results.
10
