Kenwood BL370 series Installation guide

BL370 series
BL380 series
























2
before us ng your Kenwood
appl ance
●Read these instructions carefully and
retain for future reference.
●Remove all packaging and any
labels.
●Wash the parts: see ‘care and
cleaning’.
safety
●Switch off and unplug:
●
●before fitting or removing parts;
●●when not in use;
●●before cleaning.
●Never f t the blade un t to the
power un t w thout the
blender goblet or m ll jar
f tted.
●Always unplug the appliance before
putting your hands or utensils in the
goblet.
●Always take care when handling the
blade assembly and avoid touching
the cutting edge of the blades when
cleaning.
●Only operate the blender with the lid
in place.
●Only use the goblet with the blade
assembly supplied.
●Never let the power unit, cord or
plug get wet.
●Never use a damaged appliance.
Get it checked or repaired: see
‘service and customer care’.
●Never use an unauthorised
attachment.
●Liquids should be allowed to cool to
room temperature before blending.
●Never leave the appliance
unattended when it is operating.
●When removing the blender or mill
from the power unit:
●●wait until the blades have
completely stopped;
●●don’t accidentally unscrew the
goblet or mill jar from the blade
assembly.
●Never run the blender empty.
●Never blend more than the
maximum capacity stated in the
recommended speed chart.
●To ensure long life of your blender
and mills, do not run for longer than
60 seconds.
●Smoothie recipes - never blend
frozen ingredients that have formed
a solid mass during freezing, break it
up before adding to the goblet.
●Don’t use the blender as a storage
container. Keep it empty before and
after use.
●Always use the blender on a secure,
dry level surface.
●Never place this appliance on or
near a hot gas or electric burner or
where it could touch a heated
appliance.
●Misuse of your blender can result in
injury.
●This appliance is not intended for
use by persons (including children)
with reduced physical, sensory or
mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision or
instruction concerning use of the
appliance by a person responsible
for their safety.
●Children should be supervised to
ensure that they do not play with the
appliance.
●Only use the appliance for its
intended domestic use. Kenwood
will not accept any liability if the
appliance is subject to improper use,
or failure to comply with these
instructions.

4
before plugg ng n
●Make sure your electricity supply is
the same as the one shown on the
underside of the appliance.
Important - UK only
●The wires in the cord are coloured
as follows:
Blue = Neutral
Brown = Live.
●The appliance must be protected by
a 3A approved (BS1362) fuse.
Note:
●For non-rewireable plugs the fuse
cover MUST be refitted when
replacing the fuse. If the fuse cover
is lost then the plug must not be
used until a replacement can be
obtained. The correct fuse cover is
identified by colour and a
replacement may be obtained from
your Kenwood Authorised Repairer
(see Service).
●If a non-rewireable plug is cut off it
must be DESTROYED
IMMEDIATELY. An electric shock
hazard may arise if an unwanted
non-rewireable plug is inadvertently
inserted into a 13A socket outlet.
●This appliance conforms to EC
directive 2004/10 /EC on
Electromagnetic Compatibility and
EC regulation no. 1935/2004 of
27/10/2004 on materials intended
for contact with food.
key
blender
filler cap
locking lid
goblet
blender sealing ring
blender blade unit
power unit
speed + pulse control
cord storage
mult m ll ( f suppl ed)
blender sealing ring
blender blade assembly
multi mill jar
gr nd ng m ll ( f suppl ed)
mill jar
grinding mill blade assembly
grat ng m ll ( f suppl ed)
mill jar
grating mill blade assembly
to use your blender
Use your blender for soups, drinks,
pâtés, mayonnaise, breadcrumbs,
biscuit crumbs, chopping nuts and
crushing ice.
1 Fit the blender sealing ring into
the blender blade unit  - ensuring
the seal is located correctly in the
grooved area.
●Leak ng w ll occur f the seal
s damaged or ncorrectly
f tted.
2 Screw the blade assembly onto the
goblet - ensuring the blade
assembly is fully tightened . Refer
to the graphics on the underside of
the blade unit as follows:
- unlocked position
- locked position
3 Put your ingredients into the goblet.
4 Put the filler cap in the lid.
5 Fit the lid to the goblet and turn
clockwise to lock.
6 Place the blender onto the power
unit with the handle situated to the
right hand side and lock by turning
clockwise until you hear a “click” .
●The appl ance won’t work f
the blender s ncorrectly
f tted.
7 Select a speed (refer to the
recommended speed chart).
3

blender h nts
●To blend dry ingredients - cut into
pieces, remove the filler cap, then
with the machine running, drop the
pieces down one by one. Keep your
hand over the opening. For best
results empty regularly.
●The processing of spices is not
recommended as they may damage
the plastic parts.
●When making mayonnaise, put all
the ingredients, except the oil, into
the blender. Remove the filler cap.
Then, with the appliance running,
add the oil slowly through the hole in
the lid.
●Thick mixtures, e.g. pâtés and dips,
may need scraping down. If the
mixture is difficult to process, add
more liquid.
to use your multi mill
(if supplied)
Use your multi mill for milling herbs,
nuts, coffee beans and purees.
1Put your ingredients into the jar .
Fill it no more than half full.
2 Fit the blender sealing ring into
the blender blade unit  - ensuring
the seal is located correctly in the
grooved area.
●Ensure that the seal s f tted
correctly.
3 Turn the blade unit upside down.
Lower it into the jar, blades down .
Turn anti-clockwise to lock.
4 Place the mill onto the power unit
and lock by turning clockwise until
you hear a “click” .
5 Select a speed or use the pulse
control.
43
blender recommended speed chart
speed usage/food tems max. quant ty
1Frothing milk 00 ml
Light mixes e.g. batters, milkshakes,
scrambled egg 00 ml
2Soups & drinks 1.2 litres
Thicker mixes e.g. pâtés
Mayonnaise 3 eggs + 450ml
oil
Smoothie drinks
Place the fresh fruit and liquid ingredients in 00ml
first (includes yoghurt, milk and fruit juices) liquid
Then add ice or frozen ingredients (includes
frozen fruit, ice or ice cream)
Operates the motor in a start/stop action.
(P) The pulse will operate for as long as it is held in –
pulse position.
Ice crushing - operate in short bursts until 6 cubes
crushed to the desired consistency.

6
to use your grinding mill
(if supplied)
Suitable for grinding spices, coffee
beans and processing ginger, garlic
and chillies.
1 Place your ingredients into the blade
assembly .
2 Fit the jar  and turn anti-clockwise
to lock .
3 Place the mill onto the power unit
and lock by turning clockwise until
you hear a “click” .
4 Select a speed or use the pulse (P)
control.
to use your grating mill
(if supplied)
Suitable for grating parmesan
cheese, nutmeg, coconut and dried
fruit.
1 Place your ingredients into the blade
assembly .
2 Fit the jar  and turn anti-clockwise
to lock .
3 Place the mill onto the power unit
and lock by turning clockwise until
you hear a “click” .
4 Select a speed or use the pulse (P)
control.
5
m ll recommended speed chart
ngred ents m ll max qty speed operat ng
t me
Herbs - best chopped Multi 15g 2 5 – 10 secs
when clean and dry
Nuts Multi or Grinding 50g 2 10 – 15 secs
Coffee Beans Multi or Grinding 50g 2 30 secs
Baby Foods & Purees Multi 50g 2 30 secs
Spices – such as black Grinding 50g 2 30 – 60 secs
peppercorns, cardamom
seeds, cumin seeds,
coriander seeds, fennel
seeds, whole cloves etc.
Chillies Grinding 30g 2 10 secs
Fresh Root Ginger Grinding 30g 2 10 secs
Garlic Grinding 4 cloves 2 10 secs
Parmesan Cheese – cut Grating 60g 2 10secs
into 1cm cubes
Dried Fruit Grating 50g 2 10 secs
Coconut Grating 50g 2 20 secs
Nutmeg Grating 2240 secs
h nts
●For optimum performance when
processing spices we recommend
that you do not process more than
50g at a time in the mill.
●Whole spices retain their flavour for a
much longer time than ground
spices so it is best to grind a small
quantity fresh at a time to retain the
flavour.
●To release the maximum flavour and
essential oils whole spices are best
roasted prior to milling.

care and cleaning
●Always switch off, unplug and
dismantle before cleaning.
●Empty the goblet before unscrewing
it from the blade unit.
●Don’t immerse the blade unit in
water.
●Do not place any parts n the
d shwasher.
power un t
●Wipe with a damp cloth, then dry.
●Don’t immerse the power unit in
water.
●Store excess cord in the storage
area at the back of the power
unit .
blade assembl es
blender and mult m ll
●Remove the blade unit from the
goblet or mill by turning to the
unlock position to release.
gr nd ng and grat ng m lls
●Remove the blade unit from the jar
by turning in a clockwise direction.
1blender/mult m ll: remove and
wash the sealing ring.
2 Don’t touch the sharp blades –
brush them clean using hot soapy
water, then rinse thoroughly under
the tap. Don’t mmerse the
blade un t n water.
3 Leave to dry upside down.
other parts
Wash by hand, then dry.
service and customer
care
●If the cord is damaged it must, for
safety reasons, be replaced by
KENWOOD or an authorised
KENWOOD repairer.
UK
If you need help with:
●using your appliance or
●servicing, spare parts or repairs (in or
out of guarantee)
call Kenwood customer care on 023
9239 2333. Have your model
number ( e BL370) and date
code (4 d g t code e 10D13)
ready. They are on the underside of
the power unit.
●spares and attachments
call 0 70 2413653.
●other countr es
Contact the shop where you bought
your appliance.
●Designed and engineered by
Kenwood in the UK.
●Made in China.
65

7
IMPORTANT INFORMATION FOR
CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE
WITH EC DIRECTIVE
2002/96/EC.
At the end of its working life, the
product must not be disposed of as
urban waste.
It must be taken to a special local
authority differentiated waste collection
centre or to a dealer providing this
service.
Disposing of a household appliance
separately avoids possible negative
consequences for the environment and
health deriving from inappropriate
disposal and enables the constituent
materials to be recovered to obtain
significant savings in energy and
resources. As a reminder of the need
to dispose of household appliances
separately, the product is marked with
a crossed-out wheeled dustbin.
guarantee (uk only)
If your blender goes wrong within
one year from the date you bought
it, we will repair it (or replace it if
necessary) free of charge provided:
●you have not misused, neglected or
damaged it;
●it has not been modified (unless by
Kenwood);
●it is not second-hand;
●it has not been used commercially;
●you have not fitted a plug
incorrectly; and
●you supply your rece pt to
show when you bought t.
This guarantee does not affect your
statutory rights.
carrot and coriander
soup
25g butter
50g onion chopped
1 clove garlic crushed
4 0g carrot cut into 11⁄2cm cubes
cold chicken stock
10-15ml (2-3tsp) ground coriander
salt and pepper
1 Melt the butter in a pan, add the
onion and garlic and fry until soft.
2 Place the carrot into the liquidiser,
add the onion and garlic. Add
sufficient stock to reach the 1.2 L
level marked on the goblet. Fit the
lid and filler cap.
3 Blend on maximum speed for 5
seconds for a coarse soup or longer
for a finer result.
4 Transfer the mixture to a saucepan,
add the coriander and seasoning
and simmer the soup for 30 to 35
minutes or until cooked.
5 Adjust the seasoning as necessary
and add extra liquid if required.
2

Head Office Address:
Kenwood Limited, New Lane, Havant, Hampshire PO9 2NH, UK
www.kenwoodworld.com
Designed and engineered by Kenwood in the UK
Made in China 40427/1
