VOICE GUIDE & STORAGE UNIT
VGS-1
SERVICE MANUAL
CIRCUIT DESCRIPTION
Recording/Playback Operation .................................................................... 2
I/O Ports ......................................................................................................... 2
Beat Shift Circuit ........................................................................................... 3
Amateur Transceiver Identification ............................................................. 3
SEMICONDUCTOR DATA
MCU : HD6433024D01TE (IC2) ...................................................................... 4
Reset IC : S-80930CNNBG80 (IC1) ................................................................ 5
Analog Switch : TC7W66FK (IC53, IC54)...................................................... 5
Bus Switch with Level Shifting : TC7MBD3244AFK (IC57) ........................ 5
COMPONENTS DESCRIPTION ......................................................................... 6
PARTS LIST ........................................................................................................ 6
PC BOARD
ACCESSORY UNIT (X42-3250-60) ................................................................ 8
SCHEMATIC DIAGRAM..................................................................................... 9
TERMINAL FUNCTION .................................................................BACK COVER
CONTENTS
VGS-1
2
CIRCUIT DESCRIPTION
Recording/Playback Operation
■Recording
The audio signal input from the AI pin (CN1 pin 12) passes
through a buffer amplifier (IC52 2/2) and goes to an anti-
aliasing filter amplifier (IC52 1/2).
The audio signal is amplified by approx. 30 times by IC52
1/2 and unwanted signal components exceeding 4kHz are
cut by an LPF.
The amplified audio signal is input to pin 78 of the MCU
(IC2 : Micro Controller Unit).
The MCU converts the audio signal to a digital data (by
8kHz/8-bit sampling) and writes it into a flash memory (IC3,
IC5).
When the input level of the AI pin is 100mVp-p, the MCU
input becomes approx. 3Vp-p, and the maximum S/N can be
achieved.
If a signal exceeding 100mVp-p is input to the AI pin, it is
clipped by IC52 so that the MCU input does not exceed 3Vp-
p to protect the MCU against over-voltage input.
■Playback and Prerecorded Voice
The audio signal saved in flash memory (IC3, IC5) is con-
verted to an analog signal by the MCU (IC2) and output as a
playback signal from pin 84.
This playback signal passes through two LPFs to cut har-
monic components and is input to the attenuator circuit.
The attenuator circuit consists of analog switch ICs (IC53,
IC54) and division resistors (R64, R66, R67, R71, R72).
The signal attenuated by the attenuator circuit is con-
verted to a low impedance by an output buffer (IC55), then
output from the AO pin (CN1 pin 11).
IC3, IC5
FLASH
IC2
MCU
–
–
+
+
–
+
–
+
IC53,IC54
ATT
IC55
Buffer
IC51
LPF
IC51
LPF
AO
AI
X1 X1
AN0
78
DA0
84
–
+
IC52
Buffer
IC52
LPF amp
X30
Fig. 1 Signal flow
■Attenuator Circuit
An attenuator circuit with division resistors is built by con-
trolling four analog switches of IC53 and IC54 with pins 95 to
98 of the MCU (IC2).
The output level is changed in 8 steps with 4-bit data.
R66
R67
R71
R72
R64 IC53 IC54
Fig. 2 ATT circuit
■Attenuator Circuit Control Table
95pin 96pin 97pin 98pin
PA2 PA3 PA4 PA5
ATT1 ATT2 ATT3 ATT4
Vol0 Lo Lo Lo Lo 100%
Vol1 Hi Lo Lo Lo 69%
Vol2 Lo Hi Lo Lo 55%
Vol3 Hi Hi Lo Lo 44%
Vol4 Lo Lo Hi Lo 36%
Vol5 Lo Hi Hi Lo 28%
Vol6 Lo Lo Lo Hi 15%
Vol7 Lo Lo Hi Hi 12%
I/O Ports
The VGS-1 is a 3V system unit, but it can be adapted to
both 3V and 5V systems for external connection devices with
an 8-bit CMOS bus switch (IC57).
IC57 can convert levels from 3V to 3V, from 3V to 5V, or
from 5V to 3V.
■If the External Device is a 3V System
It can be connected without a pull-up resistor.
■If the External Device is a 5V System
If the external connection device is a 5V system, the VGS-
1 output ports (BUSY, SO, PLAY) must to be pulled up to 5 V.
The waveform may become irregular due to IC57 output ca-
pacity and pull-up resistance.
BUSY and PLAY are Hi/Lo logic output ports and are not
much affected by pull-up resistance.
Even when 3V or 5V is input to an input port, the IC57
output is 3V.
• UART Control
For UART control, the maximum communication speed is
115200 bps, and SO pull-up resistor recommends approx
10kΩ.
• Synchronous Control
SO is not used for synchronous control.
Only PLAY and BUSY must to be pulled up.
VGS-1
3
CIRCUIT DESCRIPTION
O
O
I
I
IC57
VGS-1 External device
5V
5V
Pull-up
resistor
Pull-up
resistor
Fig. 3 External device, pull-up resistor
■AI Input Port
If input exceeds 100mVp-p, the input signal is clipped and
distortion occurs.
It is necessary to make setting so that no signals exceed-
ing 100mVp-p are input.
If the input level lowers, S/N decreases, so the maximum
input not exceeding 100mVp-p must be used.
■AO Output Port
When recording is performed with a 100mVp-p input, the
playback output becomes an approx. 2.8Vp-p level.
If Prerecorded Voice is generated, the output is approx
2Vp-p.
Beat Shift Circuit
To prevent VGS-1 clock oscillation for the MCU (IC2) from
causing spurious reception to transceivers to which VGS-1 is
connected, the clock oscillator (11.0592MHz) has a beat shift
circuit with a transistor switch (Q1).
■Beat Shift Circuit Off
Pin 94 of the MCU (IC2) goes Low level, Q2 turns off, and
Q1 turns on because a 5V bias is applied to its base. In this
condition, C10 is shorted, so the oscillation frequency is un-
changed.
■Beat Shift Circuit On
Pin 94 of the MCU goes High level, Q2 turns on, and Q1
turns off because its base is pulled down to GND. In this
condition, C10 is connected in series to the crystal oscillator
and the oscillation frequency increases by approx. 150ppm.
Fig. 4 Beat shift circuit
Amateur Transceiver Identification
The VGS-1 can be set as an amateur transceiver or a Land
Mobile Radio transceiver in the factory.
When it is used as a Land Mobile Radio transceiver, inter-
nal data in the VGS-1 is changed to suit the Land Mobile Ra-
dio transceiver, so it cannot be used as an amateur trans-
ceiver.
The VGS-1 set as a Land Mobile Radio transceiver can be
identified because the RV4 land on the PCB is at High level.
The default is Low level.
C10
X1
Q1
Q2
R19
R18
C11
C12
R17
5V
IC2 94 pin
PA1
High : Normal
Low : Shift
6667
XTAL EXTAL
IC2
MCU
RV1
RV2
RV3
RV4
Accessory unit
Foil side view
Fig. 5 RV4
VGS-1
4
SEMICONDUCTOR DATA
MCU : HD6433024D01TE (IC2)
Pin No. Port Name I/O Function Remarks
1VCC1 I 3.3V
2BUSY O Busy state output Hi : BUSY
3PLAY O Playback state output Hi : PLAY
4~9 NC O Not used
10 FWE O Not used Pull Down
11 VSS1 I GND
12 NC O Not used
13 TXD1 O Serial data output
14 RXD0 I Not used Pull Up
15 RXD1 I Serial data input
16 NC O Not used
17 SCK1 I Serial clock input
18~20 RV1~RV3 I/O
21 RV4 O AMR correspondence output Lo : For AMR
22 VSS2 I GND
23 NC O Not used
24 USEL I UART bit rate selection Lo : 19200bps, Hi : 115200bps
25 SELF I Transceiver connection selection Lo : Transceiver connected
26 P47 I Lo
27~34 D8~D15 I/O Data bus ↔IC3 · IC5
35 VCC2 I 3.3V
36~43 A0~A7 O Address bus →IC3 · IC5
44 VSS3 I GND
45~56 A8~A19 O Address bus →IC3 · IC5
57 VSS4 I GND
58 _WAIT I Not used Pull Up
59 _BREQ I Not used Pull Up
60 NC O Not used
61 fai O For system clock frequency check
62 _STBY I Not used Pull Up
63 RESET I Reset input Lo : RESET
64 NMI I Not used Pull Up
65 VSS5 I GND
66 EXTAL I System clock input 11.0592 MHz
67 XTAL I System clock input 11.0592 MHz
68 VCC3 I 3.3V
69 NC O Not used
70 OE O SRAM/Flash memory read output Lo : Read, →IC3 · IC5
71 WE O SRAM/Flash memory write output Lo : Write, →IC3 · IC5
72 NC O Not used
73 MD0 I Microcomputer operation mode input 0 Hi
74 MD1 I Microcomputer operation mode input 1 Lo
75 MD2 I Microcomputer operation mode input 2 Hi
76 AVCC I 3.3V Analog power supply
77 VREF I 3.3V Analog reference voltage
VGS-1
5
SEMICONDUCTOR DATA
Reset IC : S-80930CNNBG80 (IC1)
■Block Diagram
+
–
Delay
circuit
VDD
VSS
CD
OUT
Vref
*
*
*
* : Parastic diode
Analog Switch : TC7W66FK (IC53, IC54)
■Block Diagram
■ Truth Value Table
CONTROL SWITCH FUNCTION
HON
LOFF
Bus Switch with Level Shifting
: TC7MBD3244AFK (IC57)
■ System Figure
■ Truth Value Table
Input Function
OE
LAport = B port
H Disconnect
18
7
6
5
2
3
4
IN/OUT1
IN/OUT2
OUT/IN1
OUT/IN2
CONT2
CONT1
GND
VCC
1OE
(2OE)
1A4
(2A4)
1A1
(2A1)
1B4
(2B4)
1B1
(2B1)
Pin No. Port Name I/O Function Remarks
78 AN0 I A/D conversion (Voice input)
79~83 AN1~AN5 I Not used Pull Down
84 DA0 O D/A conversion (Voice output)
85 NC O Not used
86 AVSS I GND Analog GND
87 EN I Enable input/Power save relese interruption Lo : Enable
88 _CS3 O Chip select output (IC5) Lo : Chip select
89 _CS2 O Chip select output (IC3) Lo : Chip select
90 _CS1 O Chip select output (SRAM) Lo : Chip select
91 NC O Not used
92 VSS6 I GND
93 RD/_BY I Flash memory busy input Lo : BUSY (Erasing / Writing), ←IC3 · IC5
94 PA1 O Beat shift control Hi : ON
95~98 ATT1~ATT4 O Voice output attenuation control Hi : ON
99 AFM O Voice output mute control Hi : ON
100 A20 O Address bus →IC3 · IC5
VGS-1
6
COMPONENTS DESCRIPTION / PARTS LIST
Accessory Unit (X42-3250-60)
Ref.No. Use / Fnction Opration / Condition
Q1 SW : 3V→5V Level Shifting When the beat shift is operating : ON
Q2 Beat Shift Switch When the beat shift is operating : OFF
Q51 Audio Mute Switch When a playback output is completed : ON
IC1 Reset For MCU (IC2) and Flash memory (IC3, IC5)
IC2 MCU
IC3 SRAM with Flash memory Firmware and data record
IC4 Inverter Switching SRAM of IC3 and IC5
IC5 SRAM with Flash memory Firmware and data record
IC51 Low Pass Filter LPF for a playback output
IC52 Buffer + Filter AMP For recording input signals
IC53 Analog Switch Attenuator Control
IC54 Analog Switch Attenuator Control
IC55 Buffer Buffer for a playback output
IC56 3V Regulator 3V Power Supply
IC57 Bus Switch with Level Shifting 3V↔5V Level Shifting & 3V↔3V Bus Switch
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
VGS-1
ACCESSORY UNIT (X42-3250-60)
✽New Parts. indicates safety critical components.
Parts without Parts No. are not supplied.
Les articles non mentionnes dans le Parts No. ne sont pas fournis.
Teile ohne Parts No. werden nicht geliefert.
K:USA P:Canada
T:England E:Europe
X:Australia M:Other Areas
W:World M:South East Asia
B62-1741-00 INSTRUCTION MANUAL
F10-2492-04 SHIELDING COVER
✽G13-1974-04 CUSHION (21X21X1.0)
✽G13-1992-04 CUSHION (21X21X2.5)
✽G13-1993-04 CUSHION (20X30X2.0)
✽G13-1994-04 CUSHION (20X30X12)
✽G13-1995-04 CUSHION (20X30X1.0)
C1 CK73GB1A105K CHIP C 1.0UF K
C2 CC73HCH1H101J CHIP C 100PF J
C3 CK73HB1H471K CHIP C 470PF K
C4 CK73HB1A104K CHIP C 0.10UF K
C5 CK73HB1C103K CHIP C 0.010UF K
C6 CK73HB1A104K CHIP C 0.10UF K
C7 CC73HCH1H101J CHIP C 100PF J
C8 CK73GB1A105K CHIP C 1.0UF K
C9 CK73HB1H102K CHIP C 1000PF K
C10 CC73HCH1H030B CHIP C 3.0PF B
C11,12 CC73HCH1H150J CHIP C 15PF J
C13 CK73HB1A104K CHIP C 0.10UF K
C14 CK73HB1H471K CHIP C 470PF K
C15 CK73HB1A104K CHIP C 0.10UF K
C16 CK73HB1H471K CHIP C 470PF K
C51 CK73GB1A105K CHIP C 1.0UF K
C52 CK73HB1C822K CHIP C 8200PF K
C53 CK73HB1H102K CHIP C 1000PF K
C54 CK73HB1C822K CHIP C 8200PF K
C55 CK73HB1A104K CHIP C 0.10UF K
C56 CK73HB1H102K CHIP C 1000PF K
C57 CK73HB1H681K CHIP C 680PF K
C58 CK73HB1C103K CHIP C 0.010UF K
C59 CC73HCH1H101J CHIP C 100PF J
C60 CK73HB1C103K CHIP C 0.010UF K
C61 CC73HCH1H101J CHIP C 100PF J
C62 CK73HB1A104K CHIP C 0.10UF K
C63 C92-0772-05 CHIP-TAN 10UF 6.3WV
C64 CC73HCH1H101J CHIP C 100PF J
C65 CK73HB1C103K CHIP C 0.010UF K
C66 CC73HCH1H101J CHIP C 100PF J
C67 CK73HB1A104K CHIP C 0.10UF K
VGS-1
ACCESSORY UNIT (X42-3250-60)
VGS-1
7
PARTS LIST
C68 CK73HB1C103K CHIP C 0.010UF K
C69 C92-0772-05 CHIP-TAN 10UF 6.3WV
C70 CK73HB1H471K CHIP C 470PF K
C71 CK73GB1A105K CHIP C 1.0UF K
C72 CK73HB1H471K CHIP C 470PF K
C73 CK73HB1A104K CHIP C 0.10UF K
C74 CK73GB1A105K CHIP C 1.0UF K
C75 CC73HCH1H101J CHIP C 100PF J
C76,77 CK73HB1H102K CHIP C 1000PF K
C78 CK73HB1H471K CHIP C 470PF K
C80 CK73HB1H471K CHIP C 470PF K
C82,83 CK73HB1H471K CHIP C 470PF K
C84,85 CK73HB1H102K CHIP C 1000PF K
C86 C92-0634-05 CHIP-TAN 0.33UF 16WV
C87 CK73HB1A104K CHIP C 0.10UF K
C88 CK73HB1C103K CHIP C 0.010UF K
C89 CK73HB1H102K CHIP C 1000PF K
C90 CK73HB1E472K CHIP C 4700PF K
CN1 ✽E40-6358-05 PIN ASSY SOCKET
L51-53 L92-0163-05 BEADS CORE
X1 ✽L77-1950-05 CRYSTAL RESONATOR (11.0592MHZ)
CP3 RK75HA1J103J CHIP-COM 10K J 1/16W
CP4-10 RK75HA1J473J CHIP-COM 47K J 1/16W
CP51,52 RK75HA1J472J CHIP-COM 4.7K J 1/16W
CP54-57 RK75HA1J561J CHIP-COM 560 J 1/16W
R1 RK73HB1J224J CHIP R 220K J 1/16W
R2 RK73HB1J103J CHIP R 10K J 1/16W
R3 RK73HB1J472J CHIP R 4.7K J 1/16W
R4 R92-1368-05 CHIP R 0 OHM
R5 RK73HB1J224J CHIP R 220K J 1/16W
R6 RK73HB1J104J CHIP R 100K J 1/16W
R8 R92-1368-05 CHIP R 0 OHM
R12 RK73HB1J104J CHIP R 100K J 1/16W
R13 RK73HB1J473J CHIP R 47K J 1/16W
R14 RK73HB1J224J CHIP R 220K J 1/16W
R16 RK73HB1J100J CHIP R 10 J 1/16W
R17 RK73HB1J472J CHIP R 4.7K J 1/16W
R18 R92-1368-05 CHIP R 0 OHM
R19 RK73HB1J103J CHIP R 10K J 1/16W
R23 R92-1368-05 CHIP R 0 OHM
R24 RK73HB1J102J CHIP R 1.0K J 1/16W
R25 R92-1368-05 CHIP R 0 OHM
R27,28 R92-1368-05 CHIP R 0 OHM
R51-53 RK73HB1J223J CHIP R 22K J 1/16W
R54 RK73HB1J472J CHIP R 4.7K J 1/16W
R55 RK73HB1J473J CHIP R 47K J 1/16W
R56-58 RK73HB1J223J CHIP R 22K J 1/16W
R59 RK73HB1J393J CHIP R 39K J 1/16W
R60 RK73HB1J473J CHIP R 47K J 1/16W
R61 RK73HB1J122J CHIP R 1.2K J 1/16W
R62 RK73HB1J152J CHIP R 1.5K J 1/16W
R63 RK73HB1J473J CHIP R 47K J 1/16W
R64 RK73HB1J103J CHIP R 10K J 1/16W
R66 RK73HB1J562J CHIP R 5.6K J 1/16W
R67 RK73HB1J182J CHIP R 1.8K J 1/16W
R69 RK73HB1J473J CHIP R 47K J 1/16W
R71 RK73HB1J223J CHIP R 22K J 1/16W
R72 RK73HB1J123J CHIP R 12K J 1/16W
R74,75 RK73HB1J103J CHIP R 10K J 1/16W
R76 RK73HB1J101J CHIP R 100 J 1/16W
R77 R92-1368-05 CHIP R 0 OHM
R78 RK73HB1J101J CHIP R 100 J 1/16W
R87 RK73HB1J474J CHIP R 470K J 1/16W
R88 RK73HB1J105J CHIP R 1.0M J 1/16W
R89 RK73HB1J103J CHIP R 10K J 1/16W
R91 RK73HB1J224J CHIP R 220K J 1/16W
R92 R92-1368-05 CHIP R 0 OHM
IC1 S-80930CNNBG80 MOS IC
IC2 ✽HD6433024D01TE MCU
IC3 ✽MB84VD21091KW2 ROM IC
IC4 TC7S04FU MOS IC
IC5 ✽MB84VD21091KW2 ROM IC
IC51,52 TC75W51FU MOS IC
IC53,54 TC7W66FK MOS IC
IC55 TC75S51FE MOS IC
IC56 XC6204B332M MOS IC
IC57 ✽TC7MBD3244AFK MOS IC
Q1 DTC114YE DIGITAL TRANSISTOR
Q2 2SK1824 FET
Q51 2SK1824 FET
ACCESSORY UNIT (X42-3250-60)
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
Ref. No.
Address
Parts No. Description Desti-
nation
New
parts
JIHGFEDCBA
1
2
3
4
5
6
7
8
9
10
11
12
13
14
C85
C1
C2
C5
C7
C8
C9
CP10
IC2
IC3
IC5
R12
R13
R14 R16
R17
R18
R24
Q1
R25
L52
R3
R8
X1
C10
CP4
C11
CP5
C12
CP6CP7
CP8
CP9
C51
C52
C53
C54
C55
C56
C57
C58
IC51
1
45
8
C59
IC52
IC53
IC54
IC55
1
23
4
IC56
IC57
C60
C61
C62
C63
C64
C65
C66
C67
C68
C69
C70
C71
C72
C73
C74
C75
C76
C77
C78
C80
C82
C83
C84
C86
C87
C88
C89
C90
C3
C4
C6
Q51
IC1
CP51CP52
IC4
1
34
5
CP54CP55
CP56 CP57
R19
R23
Q2
R27
R28
L51
L53
R1
R2
R4
R5
R6
R51
R52
R53
R54
R55
R56
R57
R58
R59
R60
R61
R62
R63
R64
R66
R67
R69
R71 R72
R74
R75
R76
R77
R78
R87
R88
R89
CN1
R91
R92
CP3
C13
C14
C15
C16
1
100
25
26
50
51 75
76
J72-0897-19
J72-0897-19
D
S
G
D
S
G
+
+
+
1
1
34
5
45
8
1
45
8
1
23
4
1
10 11
20
1
45
8
12
25 26
BUSY
SO
CLK
USEL
DG
AO
AG
PLAY
SI
EN
RESET
AG
AI
5C
RV1RV2RV3RV4
ACCESSORY UNIT (X42-3250-60)
Component side view (J72-0897-19)
ACCESSORY UNIT (X42-3250-60)
Foil side view (J72-0897-19)
Component side
Foil side
Layer 1
Layer 2
Layer 3
Layer 4
Layer 5
Layer 6
Component side
Foil side
Layer 1
Layer 2
Layer 3
Layer 4
Layer 5
Layer 6
Ref. No. Address
IC2 4F
IC3 4C
IC5 6C
Q1 7E
Ref. No. Address
IC1 12C
IC4 9C
IC51 9E
IC52 9F
IC53 10D
IC54 11E
IC55 11F
IC56 11E
IC57 12F
Q2 9D
Q51 10F
VGS-1 PC BOARD
8
SCHEMATIC DIAGRAM VGS-1
9
7
6
5
4
3
2
1
EDCBA
XTAL
EXTAL
PA1
DA0
AN0
A20
A19
A18
A17
A16
A15
A14
D8
D9
D10
D11
D12
D13
D14
D15
A0
A1
A2
A3
A4
A5
A6
A7
A8
A9
A10
A11
A12
A13
/CS1
/CS2
/CS3
MD2
MD1
MD0
A16
A13
A7
A4
A12
A9
A8
A17
A1
A15
A11
A18
A5
A2
A14
A10
A19
A6
A3
A8
A9
A12
A4
A7
A20
A13
A16
A3
A15
A11
A18
A5
A2
A14
A10
A19
A6
A1
A17
D8
D10
D11
D12
D13
D14
D9
D15
D8
D12
D15
D10
D13
D9
D14D11
EN
USEL
MD0
A0
/CS1 /CS1
/CS3
/CS2
MD1
MD2
SCK1
PLAY
FWE
XTAL
ATT3
ATT2
ATT1
PLAY
TXD1
BUSY
EN
FWE
RESET
DA0
A20
A0
RV2
RV3
RV4
USEL
RV1
BUSY
RXD1
RV4
RV3
RV2
RV1
TXD1
RXD1
ATT4
RESET
SCK1
/STBY
/BREQ
/WAIT
NMI
/BREQ
/WAIT
NMI
/STBY
ATT3
ATT2
ATT4
ATT1
AFM
AFM
3CI5
PA1
EXTAL
AN0
C67
0.1u
R71
22k
R67
1.8k
R66
5.6k
1
2
3
45
6
7
8
IC53
TC7W66FK
IC54
TC7W66FK
1
IN_oUT1
2
oUT_IN1
3
CoNT2
4
GND
5
IN_oUT2
6
oUT_IN2
7
CoNT1
8
VCC IN_oUT1
oUT_IN1
CoNT2
GND IN_oUT2
oUT_IN2
CoNT1
VCC
R52
22k
R51
22k
R53
22k
C53
1000p
C52
8200p
R59
39k
R62
1.5k
C62
0.1u
R54
4.7k
C12
15p
C11
15p
C9
1000p
IC2
HD6433024D01TE
11
22
33
44
55
66
77
88
99
10 10
11 11
12 12
13 13
14 14
15 15
16 16
17 17
18 P40
19 P41
20 P42
21 P43
22 22
23 P44
24 P45
25 P46
26 P47
27 27
28 28
29 29
30 30
31 31
32 32
33 33
34 34
35 35
36 36
37 37
38 38
39 39
40 40
41 41
42 42
43 43
44 44
45 45
46 46
47 47
48 48
49 49
50 50
51
51
52
52
53
53
54
54
55
55
56
56
57
57
58
58
59
59
60
60
61
61
62
62
63
63
64
64
65
65
66
66
67
67
68
68
69
69
70
70
71
71
72
72
73
73
74
74
75
75
76
76
77
77
78
78
79
79
80
80
81
81
82
82
83
83
84
84
85
85
86
86
87
IRQ0
88
88
89
89
90
90
91
91
92
92
93
93
94
94
95
95
96
96
97
PA4
98
PA5
99
PA6
100
100
IC3
MB84VD21091KW2
1
NC1
2A7
3LBS
4WP/ACC
5WE
6A8
7A11
8A3
9A6
10 UBS
11 RESET
12 CE2S
13 A19
14 A12
15 A15
16 A2
17
A5
18
A18
19
RY/BY
20
NC2
21
A9
22
A13
23
NC3
24
NC4
25
A1
26
A4
27
A17
28
A10
29
A14
30
NC5
31
NC6
32
NC7
33
A0
34
VSS1
35
DQ1
36
DQ6
37
SA
38
A16
39
NC8
40
CEF
41
OE
42
DQ9
43
DQ3
44
DQ4
45
DQ13
46
DQ15/A-1
47
CIOF
48
CE1S
49 DQ0
50 DQ10
51 VCCF
52 VCCS
53 DQ12
54 DQ7
55 VSS2
56 DQ8
57 DQ2
58 DQ11
59 CIOS
60 DQ5
61 DQ14
IC5
MB84VD21091KW2
1
NC1
2A7
3LBS
4WP/ACC
5WE
6A8
7A11
8A3
9A6
10 UBS
11 RESET
12 CE2S
13 A19
14 A12
15 A15
16 A2
17
A5
18
A18
19
RY/BY
20
NC2
21
A9
22
A13
23
NC3
24
NC4
25
A1
26
A4
27
A17
28
A10
29
A14
30
NC5
31
NC6
32
NC7
33
A0
34
VSS1
35
DQ1
36
DQ6
37
SA
38
A16
39
NC8
40
CEF
41
OE
42
DQ9
43
DQ3
44
DQ4
45
DQ13
46
DQ15/A-1
47
CIOF
48
CE1S
49 DQ0
50 DQ10
51 VCCF
52 VCCS
53 DQ12
54 DQ7
55 VSS2
56 DQ8
57 DQ2
58 DQ11
59 CIOS
60 DQ5
61 DQ14
R12
100k
C8
1u
R16
10
R8
0
R6
100k
C6
0.1u
C68
0.01u
C69
10u 6.3
R76
100
R60
47k
R72
12k
L51
0163
L52
0163
C1 1u
R13 47k
R14
220k
R25
0
R56
22k
R57
22k
R58
22k
C54
8200p
C56
1000p
IC1
S-80930CNNBG80
1VSS
2VDD
4
oUT
3
CD
C4 0.1u
IC52
TC75W51FU
1
2
3
45
6
7
8
R69
47k
C55
0.1u
R61
1.2k
C57
680p
R63
47k
IC51
TC75W51FU
1
OUT-A
2
IN(-)-A
3
IN(+)-A
4
VSS
5
IN(+)-B
6
IN(-)-B
7
OUT-B
8
VDD
OUT-A
IN(-)-A
IN(+)-A
VSS IN(+)-B
IN(-)-B
OUT-B
VDD
R55
47k
IC55
TC75S51FE
1
2GND
3-4
OUT
5
VDD
C65
0.01u
R75
10k
C63
10u 6.3
0772
CP4 47k
CP5 47k
IC4
TC7S04FU
1NC
2IN
3GND 4
OUT
5
VCC
C74 1u
C71
1u
R2
R1
10k
CP51 4.7k
CP52 4.7k
220k
R5 220k
R4 0R3
4.7k
C73 0.1u
R78
100
C83 470p
C82 470p
C80 470p
C76 1000p
C77 1000p
C78 470p
C84 1000p
C85 1000p
L53
0163
C66 100p
C15
0.1u
C13
0.1u
C64
100p
C70
470p
C3
470p
C7
100p
C14
470p
C16
470p
C72
470p
C60
0.01u
C61
100p
C58
0.01u
C59
100p
R74
10k
CP3 10k
R87 470k
R27
0
R28
0
R23
0
CN1
E40-6358-05
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
CP9 47k
CP10 47k
IC57
TC7MBD3244AFK
11oE
21A1
32B4
41A2
52B3
61A3
72B2
81A4
92B1
10 GND 11
2A1 12
1B4 13
2A2 14
1B3 15
2A3 16
1B2 17
2A4 18
1B1 19
2oE 20
VCC
C86
0.33u 16
0634
Q51
2SK1824
C87
0.1u
R88
1.0M
R89
10k
C2
100p
C5
0.01u
R64
10k
C75
100p
C88
0.01u
CP8 47k
R24
1k
IC56
XC6204B332M
1
VIN
2
VSS
3
CE
4NC
5VOUT
R77 0
CP54
560
CP55
560
CP56
560
CP57
560
C10
3p
CP6
CP7 47k
47k
C89
1000p
Q2
2SK1824
R17
4.7k
R19
10k
X1
L77-1950-05
11.0592
MHz
C90
4700p
C51
1u
R91
220k
R92
0
R18
0
Q1
DTC114YE
AI
AO
AG
5C
SI(I)
EN(I)
SO(O)
CLK(I)
RESET(I)
BUSY(O)
PLAY(O)
DG
RV1(I)
RV2(I)
RV3(I)
3C
3D
3A 3C
3C
3D
RV4(O)
3C
DGND DGND
DGND
DGND
REF
REF
AI
DGND DGND DGND
RESET
RESET
WE
3C
3D
SELF
USEL(I)
5C
DG
AO
AI
5C
3C
AG
(Ver CHECK)
5C5C
5C
+
KENWOOD CORPORATION
2967-3, Ishikawa-machi, Hachioji-shi, Tokyo, 192-8525 Japan
KENWOOD U.S.A. CORPORATION
P. O. BOX 22745, 2201 East Dominguez Street, Long Beach, CA 90801-5745, U.S.A.
KENWOOD ELECTRONICS CANADA INC.
6070 Kestrel Road, Mississauga, Ontario, Canada L5T 1S8
KENWOOD ELECTRONICS DEUTSCHLAND GMBH
Rembrücker Str. 15, 63150 Heusenstamm, Germany
KENWOOD ELECTRONICS BELGIUM N.V.
Leuvensesteenweg 248 J, 1800 Vilvoorde, Belgium
KENWOOD ELECTRONICS FRANCE S.A.
13, Boulevard Ney, 75018 Paris, France
KENWOOD ELECTRONICS U.K. LIMITED
KENWOOD House, Dwight Road, Watford, Herts., WD18 9EB United Kingdom
KENWOOD ELECTRONICS EUROPE B.V.
Amsterdamseweg 37, 1422 AC Uithoorn, The Netherlands
KENWOOD ELECTRONICS ITALIA S.p.A.
Via G. Sirtori, 7/9 20129 Milano, Italy
KENWOOD IBERICA S.A.
Bolivia, 239-08020 Barcelona, Spain
KENWOOD ELECTRONICS AUSTRALIA PTY. LTD.
(A.C.N. 001 499 074)
16 Giffnock Avenue, Centrecourt Estate, North Ryde, N.S.W. 2113 Australia
KENWOOD ELECTRONICS (HONG KONG) LTD.
Unit 3712-3724, Level 37, Tower one Metroplaza, 223 Hing Fong Road, Kwai Fong, N.T., Hong Kong
KENWOOD ELECTRONICS TECHNOLOGIES(S) PTE LTD.
Sales Marketing Division
1 Ang Mo Kio Street 63, Singapore 569110
VGS-1
TERMINAL FUNCTION
Accessory Unit CN1
Pin No. Name I/O Function Remarks
1BUSY O Busy signal output Hi : During the Flash memory writing data/During communication
command processing
2PLAY O Playback signal output Hi : During Playback Output
3SOOSerial data output Control command data input
4SIISerial data input Control command data output (At the time of UART control)
5CLK I Serial synchronous clock input At the time of clock synchronous control
6ENIEnable input Lo : Enable/Power save release/Recording or Playback stop
7 USEL I Bit rate select signal input for UART Hi : 115200bps, Lo : 19200bps
8RST I Reset signal input Lo : Reset
9DGND - Digital GND
10 AGND - Analog GND
11 AO O Prerecorded Voice & Playback output
12 AI I Recording voice input
13 AGND - Analog GND
14 5C I 5V Regulator
15~26 NC
Other manuals for VGS-1
1
Table of contents
Other Kenwood Computer Hardware manuals
