Kenwood Kmix SJM020A series Installation guide

before using your Kenwood
appliance
●Read these instructions carefully
and retain for future reference.
●Remove all packaging and any
labels.
safety
●Always use the filter and never
overfill - boiling water may splash
out.
●Avoid contact with steam coming
out of the spout area when pouring
and out of the lid or spout area
when refilling.
●Beware: the metal body of the
kettle will get hot during operation.
●Never let the cord hang down
where a child could grab it.
●Always unplug your kettle
when not in use.
●Never put the kettle, powerbase,
cord or plug in liquid.
●Never use a damaged appliance.
Get it checked or repaired: see
‘service and customer care’.
●Caution: Do not operate the kettle
on an inclined surface.
●Only use the powerbase supplied
and keep it clean and dry.
●Make sure the lid is secure before
switching the kettle on.
●Warning: Do not open the lid
while the water is boiling.
●Take care when opening the lid -
droplets of hot water may be
ejected.
●Make sure the kettle is switched off
before lifting or pouring.
●Remove the kettle from the base
before filling or pouring.
●Never put the kettle near or on
cooker hot plates or gas burners.
●This kettle is for boiling water only.
●This appliance is not intended for
use by persons (including children)
with reduced physical, sensory or
mental capabilities, or lack of
experience and knowledge, unless
they have been given supervision or
instruction concerning use of the
appliance by a person responsible
for their safety.
●Children should be supervised to
ensure that they do not play with
the appliance.
●Only use the appliance for its intended
domestic use. Kenwood will not
accept any liability if the appliance is
subject to improper use, or failure to
comply with these instructions.
before plugging in
●Make sure your electricity supply is
the same as the one shown on the
underside of your kettle.
Important UK only
●The wires in the cord are coloured
as follows:
Green and Yellow Earth
Blue Neutral
Brown Live.
●The appliance must be protected
by a 13A approved (BS1362) fuse.
●WARNING: THIS APPLIANCE
MUST BE EARTHED.
Note:
●For non-rewireable plugs the fuse
cover MUST be refitted when
replacing the fuse. If the fuse cover
is lost then the plug must not be
used until a replacement can be
obtained. The correct fuse cover is
identified by colour and a
replacement may be obtained from
your Kenwood Authorised Repairer
(see Service).
●If a non-rewireable plug is cut off it
must be DESTROYED
IMMEDIATELY. An electric shock
hazard may arise if an unwanted
non-rewireable plug is inadvertently
inserted into a 13A socket outlet.
●This appliance conforms to EC
directive 2004/108/EC on
Electromagnetic Compatibility and
EC regulation no. 1935/2004 of
27/10/2004 on materials intended
for contact with food.
before using for the first time
1 Wrap any excess cord around the
bracket on the underside of the
powerbase .
2 Fill to ‘MAX’, boil, then pour the
water away. Repeat 2 to 3 times.
key
햲spout
햳finger pad
햴flip top lid
햵lid release button
햶water level gauge
햷on/off switch with indicator light
햸360° powerbase
햹cord wrap
햺filter
to use your kettle
1 Fill the kettle through either the
spout or lid. The water level must
be between ‘MAX’ and ‘MIN’.
●Be economical: do not boil more
water than you need.
●To improve the quality of your
drinks always use fresh water.
●Empty the kettle after each use.
2 Check the lid is closed. Close the
lid by pushing down on the finger
pad area .
3 Plug in and switch on.
4 Your kettle will boil and switch off
automatically. To re-boil, wait a few
seconds - the on/off switch needs
time to reset.
●If you experience problems
with your kettle switching on
and off during use or
switching off before boiling,
check that the flat element is
free from scale see
“descaling”.
●Your kettle is fitted with a filter to
hold back limescale particles.
●If you find drops of water under
your kettle, don’t worry - it is just
condensation.
boil dry protection
●If you switch on with too little water,
your kettle will cut out automatically.
Switch off, remove from the
powerbase and let it cool down
before re-filling. When it has cooled
down, the switch will reset itself.
care and cleaning
●Before cleaning, unplug your kettle
and let it cool down.
the outside and powerbase
●Wipe with a damp cloth, then dry.
Do not use abrasives - they will
scratch the metal and plastic
surfaces.
the inside
●Even though your kettle comes with
a filter, you still need to clean the
inside (and the filter) regularly.
the filter
1 Open the lid.
2 Slide the filter out .
3either rinse under the tap or use a
soft brush.
or when descaling your kettle, drop
the filter in too. Rinse thoroughly.
4 Slide the filter back in to refit .
descaling
●Regular descaling of the flat
element will improve the
performance of your kettle. If the
kettle is not descaled regularly the
build up of limescale may result in
the following:
●problems may be experienced
with the kettle switching on and
off during use or switching off
before boiling.
●the kettle may take longer to boil.
●the flat element may be
damaged.
1.0L
max
0.5L
min
햺
햳
햴
햵
햶
햸
햷
햹
햲




SJM020A series
1.0L
max
0.5L
min
Please note: Failure to descale your
kettle may invalidate your guarantee.
●When limescale starts to build up
on the heating element, buy a
suitable descaler and descale your
kettle. After descaling, boil with
fresh water several times and
discard. Clean any descaler off the
kettle - it can damage the parts.
●Some regions of the country have
chalky water. This makes boiled
water look cloudy and leaves a
deposit on the side of the kettle.
This is normal but can be removed
with regular cleaning.
●Alternatively, to reduce limescale
build up, use filtered water to fill
your kettle.
service and customer
care
●If the cord is damaged it must, for
safety reasons, be replaced by
KENWOOD or an authorised
KENWOOD repairer.
UK
If you need help with:
●using your kettle
●servicing or repairs (in or out of
guarantee)
콯call Kenwood Customer Care on
023 9239 2333.Have your
model number ready - it is
located on the underside of your
kettle and powerbase.
●spares and attachments
콯call 0870 2413653.
other countries
●Contact the shop where you
bought your kettle.
●Designed and engineered by
Kenwood in the UK.
●Made in China.
IMPORTANT INFORMATION
FOR CORRECT DISPOSAL OF
THE PRODUCT IN
ACCORDANCE WITH EC
DIRECTIVE 2002/96/EC.
At the end of its working life, the
product must not be disposed of as
urban waste.
It must be taken to a special local
authority differentiated waste collection
centre or to a dealer providing this
service.
Disposing of a household appliance
separately avoids possible negative
consequences for the environment
and health deriving from inappropriate
disposal and enables the constituent
materials to be recovered to obtain
significant savings in energy and
resources. As a reminder of the need
to dispose of household appliances
separately, the product is marked
with a crossed-out wheeled dustbin.
guarantee (UK only)
If your kettle goes wrong within
one year from the date you bought
it, we will repair or replace it free of
charge provided:
●you have not misused, neglected
or damaged it;
●it has not been modified (unless by
Kenwood);
●it is not second-hand;
●it has not been used commercially;
●you have not fitted a plug
incorrectly; and
●you supply your receipt to
show when you bought it.
This guarantee does not affect
your statutory rights.
children and burns or scalds
advice from the British Burn Association
Every year, 30,000 children go to hospital with burns. What might be a minor
burn for an adult could horrifically injure - or even kill - a child.
take these precautions
●Keep hot drinks out of children’s reach.
●Don’t drink while holding your baby. If you’re passing someone a drink, make
sure a child isn’t underneath.
●Keep your kettle, and its cord, well back from the worktop edge so that
children can’t grab them.
●Keep children away from the kitchen work area.
●For baby’s bath, run the cold water first, then add the hot. Mix well and test
the temperature with your elbow before you put baby in.
●Teach children about hot things.
run cold water over a burn immediately, then get medical help.
Don’t stop to remove clothing.
Head Office Address:
Kenwood Limited, New Lane, Havant, Hampshire PO9 2NH, UK
www.kenwoodworld.com
Designed and engineered by Kenwood in the UK
Made in China 19593/1
