Kenwood TK-8102H User manual

TK-7102H/8102H
Compact HF/UHF/FM Mobile Radios
•Time Out Timer
•Accessory Interface Cable Option
•8 rogrammable I/O orts3
•Ignition Sense4
•Horn Alert Output5
•16-Key DTMF Mic Option
•Windows rogramming & Tuning6
•Cloning
•MIL-STD-810 C/D/E/F
FleetSync®
•TT ID Digital ANI
•Emergency Status
GENERAL FEATURES
•50W (146-174, 136-162 MHz) Models
•45W (450-490, 485-512, 400-430 MHz) Models
•8 Channels (4 Channels er Group)
•2 Conventional Groups
•Normal Scan
•Backlit Keys
•Channel / Transmit / Busy LED’s
•4 Channel Keys
•2 Function Keys
•Up/Down Volume Keys
•Enhanced Kenwood Audio
•Front anel Speaker
•Emergency Call Features
•QT/DQT
•DTMF Encode / Decode1
•Special Alert Tone atterns2
•Busy Channel Lockout

All accessories and options may not be available in all markets.
Contact an authorized Kenwood dealer for details and complete
list of all accessories and options.
Options Specifications
Model TK-7102H TK-8102H
GENERAL
Frequency Range
Type 1 146-174 MHz 450-490 MHz
Type 2 136-162 MHz 485-512 MHz
Type 3 - 400-430 MHz
umber of Channels 8 (4 Channels x 2 Groups)
Channel Spacing
Wide 25 kHz
arrow 12.5 kHz
Channel Step 2.5 kHz / 5 kHz 5 kHz / 6.25 kHz
6.25 kHz / 7.5 kHz
Operating Voltage 13.6V DC±15%
Current Drain
Standby 0.4 A
Receive 1.0 A
Transmit (High Power) 14.0 A
Operating Temperature Range -30°C ~ +60°C
Frequency Stability ±2.5ppm
(-30°C ~ +60°C)
Antenna Impedance 50 Ω
Channel Frequency Spread
Type 1 28 MHz 40 MHz
Type 2 26 MHz 27 MHz
Type 3 - 30 MHz
Dimensions (W x H x D)
6.29” x 1.69” x 5.39”
(160 mm x 43 mm x 137 mm)
weight (net)
(body only, approx.) 2.6 lbs (1.18 kg)
FCC ID
Type 1 ALH32933210 ALH32943210
Type 2 ALH32933220 ALH32943220
Type 3 - ALH32943230
RECEI ER (Measurements made per TIA/EIA-603)
Sensitivity (12dB SI AD)
Wide 0.28 µV
arrow 0.35 µV
Selectivity
Wide 75 dB
arrow 60 dB
Intermodulation Distortion
Wide 70 dB
arrow 60 dB
Spurious Response 75 dB
Audio Output (4W at 4 Ω) with less than 5% distortion)
TRANSMITTER (Measurements made per TIA/EIA-603)
RF Output Power
50 W 45 W
Spurious Response 70 dB
(High Power)
Modulation
Wide 16KØF3E
arrow 11KØF3E
FM Hum & oise
Wide 45 dB
arrow 40 dB
Audio Distortion Less than 3%
Microphone Impedance 600 Ω
■KMC-30
Micro hone
(su lied micro hone
■KMC-32
16-Key Key ad
Micro hone
■KES-3
External S eaker
■KLF-2
Line Noise Filter
■KPS-15
DC Power Su ly
■KMB-10
Key Lock Ada ter
Applicable MIL-STD
Standard MIL 810C MIL 810D MIL 810E MIL 810F
Methods/Procedures Methods/Procedures Methods/Procedures Methods/Procedures
Low Pressure 500.1/Procedure I 500.2/Procedure I, II 500.3/Procedure I, II 500.4/Procedure I, II
High Temperature 501.1/Procedure I, II 501.2/Procedure I, II 501.3/Procedure I, II 501.4/Procedure I, II
Low Temperature 502.1/Procedure I 502.2/Procedure I, II 502.3/Procedure I, II 502.4/Procedure I, II
Temperature Shock 503.1/Procedure I 503.2/Procedure I 503.3/Procedure I 503.4/Procedure I, II
Solar Radiation 505.1/Procedure I 505.2/Procedure I 505.3/Procedure I 505.4/Procedure I
Humidity 507.1/Procedure II 507.2/Procedure II, III 507.3/Procedure II, III 507.4
Salt Fog 509.1/Procedure I 509.2/Procedure I 509.3/Procedure I 509.4
Dust 510.1/Procedure I 510.2/Procedure I 510.3/Procedure I 510.4/Procedure I, III
ibration 514.2/Procedure VIII, X 514.3/Procedure I 514.4/Procedure I 514.5/Procedure I
Shock 516.2/Procedure I, II, III, V 516.3/Procedure I, IV, V 516.4/Procedure I, IV, V 516.5/Procedure I, IV, V
ADS#07709 Printed in USA
JQA-QMA1205
JQA-QMA1205
footnotes from front:
1DTMF includes PTT ID, Emergency ANI, Manual Encode
(KMC-32), Auto-Dial (9 numbers) & tun.
2pecial Alert Tone Patterns operate for DTMF, selective call decode.
3KCT-39 required for 4 CH remote control, ignition sense (KCT-18),
KGP-2A/B, KD -100, data modems, external GP interface.
4KCT-39 & KCT-18 ignition sense cable options required.
5KCT-39 required: Horn Alert operates for DTMF selective
call decode.
6KPG-70D program software required: Windows® 2000Me/XP.
Kenwood reserves the right to change specifications and features without prior notice.
Windows is a registered trademark of Microsoft Corporation in the U and other countries.
Fleet ync®is a registered trademark of Kenwood Corporation.
