Kenwood KRF-V6060D User manual

70%
LOUDNESS SPEAKER EQ ACTIVE EQ DSP STEREO INPUT MODE DIMMER
SOUND TONE
SETUP
BAND AUTO MEMORY
MULTI CONTROL LISTEN MODE
TUNER
MD/TAPEVIDEO 3VIDEO 2VIDEO 1
AUXCD/DVD
DSP
DTS
CSII
DOLBY DIGITAL
SPEAKER EQ
ACTIVE EQ
STANDBY
ON/STANDBY
A SPEAKERS B
POWER
PHONES
DOWN
MUTE
AV AUX
S VIDEO VIDEO L-AUDIO-R
UP
VOLUME CONTROL
DVD/6CH
- ON – OFF
AUDIO-VIDEO SURROUND RECEIVER
© 2002-5 PRINTED IN KOREA
B51-5791-00 (K/K) 3529
Knob *
(K29-)
Knob(BUTTON) *
(K27-)
SUB WOOFER
SURROUND BACK
++--
++--
SPEAKERS(8-16)
FRONT A
FRONT B
CENTER SURROUND
VOLTAGE SELECTOR
-
+
PHONO CD/DVD MD/TAPE
REC OUT
VIDEO 1
PLAY IN PLAY IN
VIDEO 2 VIDEO 3
PLAY IN
DVD/6CH.INPUT
FRONT SURROUND
COAXIALSYSTEM CONTROL OPTICAL
CD/DVD
DIGITAL IN
IN
VIDEO
S VIDEO
IN
VIDEO
DVD/6CH
VIDEO 2
S VIDEO
IN
DVD MONITOR
OUT
VIDEO
PRE OUT
SUB WOOFER
IN IN REC OUT PLAY IN PLAY INPLAY INPLAY INREC OUT
CENTER
OUT IN
VIDEO
VIDEO
AC OUTLETS
AC120V 60Hz
150W 1.25A MAX.
SWITCHED TOTAL
GRAYWHITE GREEN BLUE
RED
L
RL
R
L
R
FM
75
GND
AM
ANTENNA
GND
AC 110-
120V~
AC 220-
240V~
DE-EMPHASIS
CHANNEL SPACE
50us
AM 9kHz
FM50kHz
75us
AM 10kHz
FM100kHz
Front glass *
(B10-)
Illust. is VR-6050/KRF-V6060D.
*Refer to parts list on page 35.
KRF-V6060D/V6060D-S/V7060D/V7060D-S/V8060D
SERVICE MANUAL
Metallic cabinet *
(A01-)
AC power cord *
(E30-)
KRF-V8060D-S/V8060D-G/X9060D/X9060D-S/X9060D-G
VR-6050/6060/6070
Phone jack
(E11-0271-05)
Knob(VOLUME) *
(K29-)
Panel *
(A60-)
Pin jack
(E63-1251-05)
Knob *
(K29-)
Knob *
(K29-)
Tuner ass'y *
(W02-)
Optical receiving module
(W02-2731-05)
Pin jack
(E63-1080-05)
AC outlet *
(E03-)
Pin jack
(E63-1246-05)
Lock terminal board
(E70-0161-05)
Knob ass'y *
(K29-)
Knob ass'y *
(K29-)
Cylindrical receptacle
(E56-0033-05)
Cylindrical receptacle
(E56-0042-05)
Slide switch
(S62-0034-05)
Miniature phone jack
(E11-0293-05)
Cylindrical receptacle
(E56-0040-05)
Slide switch
(S62-0001-05)
Pin jack
(E63-1253-05)
Pin jack
(E63-1246-05)
Pin jack
(E63-1248-05)
Pin jack
(E63-1247-05)
Screw terminal board
(E70-0150-05)
AC power cord bushing
(J42-0349-05)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

MODEL Destinations Parts number Model name Battery cover
VR-6050 KP A70-1555-05 RC-R0727 A09-1258-08
KRF-V6060D YA70-1555-05 RC-R0727 A09-1258-08
KRF-V6060D EA70-1554-05 RC-R0726 A09-1258-08
KRF-V6060D-S TE A70-1554-05 RC-R0726 A09-1258-08
KRF-V6060D-S MIXH A70-1555-05 RC-R0727 A09-1258-08
KRF-V7060D EA70-1554-05 RC-R0726 A09-1258-08
KRF-V7060D-S EA70-1554-05 RC-R0726 A09-1258-08
VR-6060 KP A70-1552-05 RC-R0816 A09-1258-08
KRF-V8060D EA70-1554-05 RC-R0726 A09-1258-08
KRF-V8060D-S EA70-1554-05 RC-R0726 A09-1258-08
KRF-V8060D-S XA70-1553-05 RC-R0725 A09-1258-08
KRF-V8060D-G MA70-1553-05 RC-R0725 A09-1258-08
VR-6070 KP A70-1549-05 RC-R0813 A09-1258-08
KRF-X9060D EA70-1551-05 RC-R0815 A09-1258-08
KRF-X9060D YA70-1550-05 RC-R0814 A09-1258-08
KRF-X9060D-S ET A70-1551-05 RC-R0815 A09-1258-08
KRF-X9060D-S X A70-1550-05 RC-R0814 A09-1258-08
KRF-X9060D-G MH A70-1550-05 RC-R0814 A09-1258-08
Remote controller
Resetting the Microcomputer
The microcomputer may malfunction (unit cannot be operated, or
shows an erroneous display) if the power cord is unplugged while
the power is ON, or due to some other external factor. If this
happens, execute the following procedure to reset the microcom-
puter and return the unit to its normal operating condition.
• Please note that resetting the microcomputer will clear the contents
of the memory and returns the unit to the state it was in when it left
the factory.
For the U.S.A. and Canada
Unplug the power cord from the wall outlet, then plug it
back in while holding down the POWER ON/STANDBY
key.
For other countries
With the power cord plugged in, turn the POWER ON/
OFF key OFF. Then, while holding down the ON/
STANDBY key, press POWER ON/OFF.
AC Plug Adaptor (1)
Use to adapt the plug on the
power cord to the shape of the
wall outlet.
(Accessory only for regions where
use is necessary.)
FM indoor antenna (1)
(T90-0877-05)
AM loop antenna (1)
(T90-0852-05)
RF remote antenna (1)
(For VR-6060/6070 only)
(T90-0899-05)
Remote control unit (1)
Refer to the table on this page below.
Batteries (R6/AA) (2)
(E03-0383-05) (E03-0382-05)
KRF-V6060D/V7060D/V8060D/X9060D/VR-6050/6060/6070
2
CONTENTS / ACCESSORIES / CAUTIONS
CONTENTS / ACCESSORIES / CAUTIONS............. 2
EXTERNAL VIEW .......................................................3
WIRING DIAGRAM .....................................................4
PC BOARD ................................................................ 5
SCHEMATIC DIAGRAM .......................................... 13
EXPLODED VIEW ....................................................33
PARTS LIST..............................................................35
SPECIFICATIONS ....................................................46
Contents
Accessories
Model name vs Remote controller
Cautions
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KRF-V6060D/V7060D/V8060D/X9060D/VR-6050/6060/6070
3
EXTERNAL VIEW
LOUDNESS SPEAKER EQ ACTIVE EQ DSP STEREO INPUT MODE DIMMER
SOUND TONE
SETUP
BAND AUTO MEMORY
MULTI CONTROL LISTEN MODE
TUNER
MD/TAPEVIDEO 3VIDEO 2VIDEO 1
PHONOCD/DVD
DSP
DTS
CSII
DOLBY DIGITAL
SPEAKER EQ
ACTIVE EQ
STANDBY
ON/STANDBY
A SPEAKERS B
POWER
PHONES
DOWN
MUTE
AV AUX
S VIDEO VIDEO L-AUDIO-R
UP
VOLUME CONTROL
DVD/6CH
- ON – OFF
++--
SPEAKERS(8-16) COMPONENT VIDEO
MONITOR OUT
RF REMOTE ANTENNA
IR
REPEATER
OUT
IR
RECEIVER
IN
PRE OUT
SPEAKERS(8-16)
FRONT A
FRONT B
CENTER
SURROUND BACK/
SUBWOOFER
VIDEO
3
IN
DVD
IN
SURROUND
-
+
PHONO CD/DVD MD/TAPE
REC OUT
VIDEO 1
PLAY IN PLAY IN
VIDEO 2 VIDEO 3
PLAY IN
DVD/6CH.INPUT
FRONT SURROUND
COAXIAL
SYSTEM CONTROL OPTICAL OPTICAL OPTICAL
CD/DVD VIDEO 3 MONITOR
DIGITAL IN DIGITAL OUT
IN
VIDEO
S VIDEO
IN
VIDEO
DVD/6CH
VIDEO 2
IN
DVD MONITOR
OUT
SUB WOOFER
IN IN REC OUT PLAY IN PLAY INPLAY INPLAY INREC OUT
CENTER
OUT IN
VIDEO
VIDEO
GRAY BLUE
WHITE GREEN
PURPLE
RED
L
R
L
L
YCB CR
YCBCR
R
R
L
R
FM
75
AM
ANTENNA
GND
GND
AC OUTLETS
AC120V 60Hz
150W 1.25A MAX.
SWITCHED TOTAL
Knob(BUTTON) *
(K27-)
Front glass *
(B10-)
Phone jack
(E11-0271-05)
Panel *
(A60-)
Pin jack
(E63-1251-05)
Knob *
(K29-)
Knob ass'y *
(K29-)
Knob ass'y *
(K29-)
Knob *
(K29-)
Metallic cabinet *
(A01-)
AC power cord *
(E30-)
Optical receiving module
(W02-2731-05)
AC outlet
(E03-0148-05)
Miniature
phone jack
(E11-0293-05)
Pin jack
(E63-1246-05)
Pin jack
(E63-1247-05)
AC power cord bushing
(J42-0349-05)
Cylindrical receptacle
(E56-0040-05)
Tuner ass'y *
(W02-)
Pin jack
(E63-1080-05)
Cylindrical receptacle
(E56-0033-05)
Oscillating module
(W02-2732-05)
Pin jack
(E63-1249-05)
Miniature phone jack
(E11-0291-05)
Miniature phone jack
(E11-0904-05)
Pin jack
(E63-1252-05) Pin jack
(E63-1246-05)
Pin jack
(E63-1248-05)
Pin jack
(E63-1250-05)
Miniature phone jack
(E11-0389-05)
Lock terminal board
(E70-0160-05)
Screw terminal board
(E70-0150-05)
Pin jack
(E63-1253-05)
Illust. is VR-6070/KRF-X9060D.
Illust. is VR-6070.
*Refer to parts list on page 35.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KRF-V6060D/V7060D/V8060D/X9060D/VR-6050/6060/6070
4
CIRCUIT DESCRIPTION
Input Tuner R (kΩ) Volt (V)
Voltage(V) Destination
0 K/P Open 0
1.6~2.0 E/T 27 1.79
2.1~2.5 - - -
2.6~3.0 Y/M/I(M2) 12 2.78
3.1~3.5 - - -
3.6~4.0 Y/M/V/X(E1) 4.7 3.81
4.1~4.5 - - -
Model Model
Model Type Type1 Type0
✽(94Pin) ✽(93Pin)
VR-6070/KRF-X9060D 0 0
VR-6060/KRF-V8060D 1 0
VR-6050/KRF-V6060D/KRF-V7060D 0 1
1. Model Type & TUNER Destination
1-1 Model Type
✽Pin Number of Microprocessor
1-2 TUNER Destination
Set Type Type Band Receiving Frequency Range Channel IF PLL
Space
K/P K1 FM 87.50MHz~108.0MHz 100kHz +10.7MHz 25kHz
AM 530kHz~1700kHz 10kHz +450kHz 10kHz
Y/M/I K2 FM 87.50MHz~108.0MHz 100kHz +10.7MHz 25kHz
AM 530kHz~1607kHz 10kHz +450kHz 10kHz
Y/M/V/X E1 FM 87.50MHz~108.0MHz 50kHz +10.7MHz 25kHz
H AM 531kHz~1602kHz 9kHz +450kHz 9kHz
E/T E3 FM 87.50MHz~108.0MHz 50kHz +10.7MHz 25kHz
RDS AM 531kHz~1602kHz 9kHz +450kHz 9kHz
For M type, K2/E1 are decided by CH SPACE
CH SPACE = 1 îK2 TYPE
CH SPACE = 0 îE1 TYPE
P.ch K1 K2 E1/E3 P.ch K1 K2 E1/E3
1 FM 98.3M FM 98.3M FM 98.3M 21 AM 530K AM 530K AM 531K
2 FM 108.0M FM 108.0M FM 108.0M 22 FM 87.5M FM 87.5M FM 87.5M
3 FM 89.1M FM 89.1M FM 89.1M 23 FM 87.5M FM 87.5M FM 87.5M
4 FM 87.5M FM 87.5M FM 87.5M 24 FM 87.5M FM 87.5M FM 87.5M
5 FM 90.0M FM 90.0M FM 90.0M 25 FM 87.5M FM 87.5M FM 87.5M
6 FM 87.5M FM 87.5M FM 87.5M 26 FM 87.5M FM 87.5M FM 87.5M
7 FM 87.5M FM 87.5M FM 87.5M 27 FM 87.5M FM 87.5M FM 87.5M
8 AM 1610K FM 87.5M AM 1503K 28 FM 87.5M FM 87.5M FM 87.5M
9 AM 1700K AM 1610K AM 1584K 29 FM 87.5M FM 87.5M FM 87.5M
10 AM 1050K AM 1050K AM 999K 30 FM 106.0M FM 106.0M FM 106.0M
11 AM 630K AM 630K AM 621K 31 FM 87.5M FM 87.5M FM 87.5M
12 AM 1440K AM 1440K AM 1350K 32 FM 87.5M FM 87.5M FM 87.5M
13 FM 106.0M FM 106.0M FM 106.0M 33 FM 87.5M FM 87.5M FM 87.5M
14 AM 530K AM 530K AM 531K 34 FM 87.5M FM 87.5M FM 87.5M
15 FM 87.5M FM 87.5M FM 87.5M 35 FM 87.5M FM 87.5M FM 87.5M
16 FM 98.0M FM 98.0M FM 98.0M 36 FM 87.5M FM 87.5M FM 87.5M
17 FM 98.5M FM 98.5M FM 98.5M 37 FM 87.5M FM 87.5M FM 87.5M
18 FM 87.5M FM 87.5M FM 87.5M 38 FM 87.5M FM 87.5M FM 87.5M
19 AM 990K AM 990K AM 945K 39 FM 108.0M FM 108.0M FM 108.0M
20 FM 97.4M FM 97.4M FM 97.4M 40 AM 1000K AM 1000K AM 945K
2. Tuner Preset Memory
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

* X25-649
VR-6060/6070 R/No. VR-6060 VR-6070 only IC202 NO YES
Configuration Sel. J201 NO YES
X08, IC12(NJU7311AM) * X25-649 Sub Circuit Unit J202 YES YES
IC202 J201
CLK/DATA/ST X14, A791 IR/RF IR IN
IR Switch J202 X14, ED78
Remocon IR OUT Det 1/2 FL
X14, IC65 S-Video & CTRL1~3 HNA-16MM36T
Video Sel. FL Driver
Rem 1 Rem 0 IR SW DIN/CL/CE X14, IC78(LC75711NED)
X25, IC10 Composite CTRL2 LED (X14)
Sel. TUNER/CS11/F. AUX
Melody 32 DSP IC STANDBY LED(D734) X08, IC50 LED Driver DSP INTREQ/DSP RESET X14, IC74(BU2090) DSP SCKO/DSP MISOO DATA/CLK D741~D752 DSP MOSIO Relay Cont. 96kHz 24Bit CODEC & DAC Power RLY/SP. A,B RLY X08, IC4(AK4529-VO) Center RLY CODEC CDIN/CODEC PDN Surr. RLY/Tap RLY CODEC CCLK/CODEC CS Encoder(X14) CODEC OVR Microcomputer Multi Cont.(S762)
Audio Serial data (IN/OUT) Listen Mode(S761) 96kHz 24Bit DIR MN101C49XXX
Volume Cont.(S763)
X08, IC2(AK4112BVF) X14 DIR CDIN/DIR CDOUT AD Key (1~4) DIR CCLKDIR PDN/DIR ERF
PROTECTION
Mute Cont. Protection (1,2) SB MUTE/SURR MUTE A.MUTE/T MUTE/6dB ATT SB/SW Switch IC 20dB ATT/V MUTE/CV MUTE X09, IC5 X09, IC4 SV MUTE SB/SW SB/SW
System Control Sel. PRE AMP X08, J800 S DATA/S BUSY X701
Input Sel. & E. Volume OSC According to Models or Destination X09, IC12(M61516FP) 8.38MHz
VOL.DT/VOL.CLK AM/FM IF MPX IC(TUNER ASSY) VOL ST TUNER DEST CLK /DATA IC1(LA1837M
Model Type (1, 0) RDS Demodulator DO/DI/CK/CE SD/ STEREO
Channel Space Destination X14, IC81(BU1923) S.LEVEL
X08, S800 E/T Type only PLL(TUNER ASSY)
M Type only IC2(LC72131M)
X05-518X
RF-RC
KRF-V6060D/V7060D/V8060D/X9060D/VR-6050/6060/6070
5
CIRCUIT DESCRIPTION
Key Display Function
SPEAKER EQ. RF ON Set up RF ON.
RF OFF Set up RF OFF.
Key Function
MUTE TUNER mute on/off
3. Test Mode
3-1 Entering the Test Mode
• While holding down the "BAND" key, plugged in the
power cord to AC power wall outlet.
3-2 Cancelling the Test Mode
• Initialized and cancel the test mode if plugged out the
power code.
3-3-2 RF ON/RF OFF (VR-6060/6070 only)
4. Microcomputer : MN101C49XXX (X14, IC90)
4-1 Microcomputer Periphery block diagram
• The key is functioning when selector is set to TUNER.
3-3 Contents of the Test Mode
3-3-1 TUNER mute on/off
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KRF-V6060D/V7060D/V8060D/X9060D/VR-6050/6060/6070
6
CIRCUIT DESCRIPTION
Pin No. Pin Name I/O Pin Description
1 VREF- - Connected to ground.
2 T DEST I Discrimination pin for tuner destination.
3 DET1 I Detection pin of output level for FL/FR.
4 DET2 I Detection pin of output level for SL/SR and Center.
5 S LEVEL I Input pin of FM S meter level.
6~9 AD KEY GET(1~4) I A/D key (1~4) input.
10 VREF+ - A/D reference voltage.
11 VDD - Power supply (+5V) for microcomputer.
12 OSC2 O Main clock output (8.388MHz).
13 OSC1 I Main clock input (8.388MHz).
14 VSS - Connected to be ground.
15 XI - Connected to be ground.
16 XO - Unused.
17 MMOD - Memory mode switch input pin (unused).
18 FL DIN O Transfer data output to FL driver.
19 FL CS O Chip enable output to FL driver.
20 FL CLK O Synchronism clock output to FL driver.
21 FL RESET O System reset signal output to FL driver.
22 IR SW O Switching pin for IR/RF.
23 RF CS O Chip select output to PLL of RF-RC demodulator.
24 RF DATA O Data output to PLL of RF-RC demodulator.
25 RF CLK O Clock output to PLL of RF-RC demodulator.
26 REM I I Remote control signal input 1(Front panel).
27 REM 0 I Remote control signal input 1(Rear panel).
28 DIR ERF I Detection pin for DIR ERROR signal.
29 DSP INTREQ I Detection pin for DSP INTREQ.
30 CE2/RDS CLK I Clock input of RDS demodulator IC.
31 CE1 I Detection pin for DSP INTREQ.
32 N.C. - Unused.
33 RESET I Reset signal input for microcomputer.
34 S BUSY I/O Serial busy signal input/output.
35 S DATA I/O Serial data signal input/output.
36 DSP RESET O Reset signal output to DSP.
37 CODEC OVR I Analog overflow detection pin.
38 CODEC PDN O Power down mode pin for CDDEC.
39 DIR PDN O Power down mode pin for DIR.
40 AK CS O Chip select output to DIR (X08, IC2).
41 N.C. - Unused.
42 AK CDTI O Control data output to DIR (X08, IC2).
43 DIR CDTO I Control data input from DAC (X08, IC4).
44 AK CLK O Clock output to DIR (X08, IC2).
45 DSP MOSIO O Data output pin to DSP (X08, IC50).
46 DSP MISOO I Data input pin from DSP (X08, IC50).
47 DSP SCKO O Clock output pin to DSP (X08, IC50).
48 SEL. ST O Strobe 1output to selector IC (X08, IC12).
49 SEL. CLK O Clock output to selector IC (X08, IC12).
50 SEL. DATA O Data output to selector IC (X08, IC12).
51~53 V. CTL 1~3 O Video switch control.
54 SV. MUTE O Mute control to S-video & video selector (X14, IC65).
55 CV. MUTE O Mute control to video selector IC (X25, IC102).
56 STEREO I Stereo signal input from IC1(TUNER ASSY).
57 SD I Synchronized signal detection input.
58 T MUTE O Mute signal output for TUNER.
59 PLL DO I Data input from PLL IC (TUNER ASSY).
4-2Pin Description for Microcomputer : MN101C49XXX (X14, IC90)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KRF-V6060D/V7060D/V8060D/X9060D/VR-6050/6060/6070
7
CIRCUIT DESCRIPTION
Input AD Key Get 1 AD Key Get 2 AD Key Get 3 AD Key Get 4 R (kΩ) Volt (V)
Voltage (V) (Pin 6) (Pin 7) (Pin 8) (Pin9)
0.0 to 1.0 Key Off
1.1 to 1.5 DVD/6CH LOUDNESS SOUND - 43 1.29
or THX
1.6 to 2.0 CD/DVD SP EQ TONE STANDBY 27 1.79
2.1 to 2.5 PHONO ACTIVE EQ SET UP - 18 2.27
2.6 to 3.0 TUNER DSP BAND SPA 12 2.78
3.1 to 3.5 VIDEO 1 STEREO AUTO SPB 7.5 3.33
3.6 to 4.0 VIDEO 2 INPUT MODE MEMORY - 4.7 3.81
4.1 to 4.5 VIDEO 3 DIMMER UP MUTE 2.4 4.31
4.6 to 5.0 MD/TAPE - DOWN AV AUX 0.62 4.80
Pin No. Pin Name I/O Pin Description
60 PLL CLK O Clock output to PLL IC (TUNER ASSY).
61 PLL DIN O Data output to PLL IC (TUNER ASSY).
62 PLL CE O Chip enable output to PLL IC (TUNER ASSY).
63 SURR.MUTE I Mute control for surround.
64 SB PREMUTE O Mute control for SB.
65 SP. A RLY O Relay control for A speaker.
66 C RLY O Relay control for center speaker.
67 SURR.RLY O Relay control for surround speaker.
68 SP. B RLY O Relay control for B speaker.
69 SB SW SELECT O Selection port for SB and SW.
70 VOL SEL. ST O Strobe output to E. volume IC (X09, IC2).
71 VOL. SEL DATA O Data output to E. volume IC (X09, IC2).
72 VOL. SEL CLK O Clock output to E. volume IC (X09, IC2).
73 TAP RLY O Switching port for transformer tap.
74 LIMITER O Power control for A class.
75 DSP CS I CS input port from DSP.
76 CH SPACE/RDS DIN I Data input of RDS demodulator IC.
77 A. MUTE O Audio mute control.
78 PROT2 I Protection signal detection pin for over voltage.
79 PROT1 I Detection pin of protection for shorted supply voltage.
80 P0WER RLY O Control port of power relay.
81 LED DATA O Data output to led driver (X14, IC74).
82 LED CLK O Clock output to led driver (X14, IC74).
83 F AUX LED O LED (F.AUX) control port.
84 TUNER LED O LED (TUNER) control port.
85 STANDBY LED O LED (STANDBY) control port.
86 CS ¿LED O LED (CS¿) control port.
87 MULTI ENC A I Encoder (Multi control) upward detection.
88 MULTI ENC B I Encoder (Multi control) downward detection.
89 LISTEN ENC A I Encoder (LISTEN MODE) upward detection.
90 LISTEN ENC B I Encoder (LISTEN MODE) downward detection.
91 VOL. ENC A I Encoder (Vol. Cont.) clockwise detection.
92 VOL. ENC B I Encoder (Vol. Cont.) counterclockwise detection.
93 MODEL TYPE 0 I Discrimination port for model type.
94 MODEL TYPE 1 I Discrimination port for model type.
95 DAVSS - Connected to be ground.
96,97 N.C. - Unused.
98 20dB ATT. O 20dB attenuator control.
99 6dB ATT. O 6dB attenuator control.
100 DAVDD - +5V power supply.
5. Key Matrix
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KRF-V6060D/V7060D/V8060D/X9060D/VR-6050/6060/6070
8
CIRCUIT DESCRIPTION
Pin No. Pin Name I/O Pin Description
1 OSCB - Colpitts oscillation circuit.
2 OSCE - Colpitts oscillation circuit. (Unused)
3 MVCC - Supply power for mixer section.
4 MOUT O Mixer output port.
5 DECPL1 - Bypass capacitor connection for limiter amplifier.
6 IF IN I Input port of limiter amplifier.
7 DECPL2 - Bypass capacitor connection for limiter amplifier.
8 CGND - Data comparator ground.
9 COUT O Data comparator output.
10 CIN- I Data comparator input.
11 CIN+ I Data comparator input.
12 AOUT O Ope. Amplifier output.
13 AIN- I Ope. Amplifier input.
14 AIN+ I Ope. Amplifier input.
15 DOUT - Detector output. (Unused)
16 DIN I Detector input.
17 IFOUT - IF limiter output. (Unused)
18 RSSI O RSSI output port.
19 IGND - IF section ground.
20 IVCC - Supply power for IF section.
21 PWSAVE - Connected to power supply.
22 MGND - Mixer section ground.
23 MIN1 I Mixer input port.
24 MIN2 I Mixer input port.
Pin No. Pin Name I/O Pin Description
1 XIN I Reference signal input pin (X'tal oscillation pin).
2 CL I Data input pin.
3 DI I Data input pin.
4 CE I Data input pin.
5 VCCR - ECL block power supply pin.
6 PI I Comparison signal input pin.
7 GND R - ECL block GND pin.
8 TEST - GND
9 CP O Built-in charge pump output pin.
10 PDP O Phase comparator output for an external charge pump. (Connected to GND)
11 PDN O Unused.
12 GND D - GND pin for circuits except the ECL block.
13 VCC D - Power supply pin for circuits except the ECL block.
14 PE O Phase error output pin for phase comparator (Unused).
15 OUT O Output port pin for switching external SW (GND).
16 XOUT O Output pin for X'tal oscillation.
6. Pin description of ICs
6-1 PLL Frequency Synthesizer LSI : (X05, IC3) VR-6060/6070 (K/P) Type Only
6-2 IF MIXER : TK14583V (X05, IC4) VR-6060/6070 (K/P) Type Only
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KRF-V6060D/V7060D/V8060D/X9060D/VR-6050/6060/6070
9
CIRCUIT DESCRIPTION
Pin No. Pin Name I/O Pin Description
1 SDOS I SDTO Source Select Pin (unused)
2 I2C I Control Mode Select Pin (unused)
3 SMUTE I Soft Mute Pin (Unused)
4 BICK I Audio Serial Data Clock Pin
5 LRCK I Input Channel Clock Pin
6~8 SDTI (1~3) I DAC(1~3) Audio Serial Data Input Pin
9 SDTO O Audio Serial Data Output Pin
10 DAUX I AUX Audio Serial Data Input Pin (GND)
11 DFS I Double Speed Sampling Mode Pin (GND)
12 SDTI4 I DAC4 Audio Serial Data Input Pin (GND)
13 DZFE I Zero Input Detect Enable Pin (GND)
14 TVDD - Output Buffer Power Supply Pin (+3.3V)
15 DVDD - Digital Power Supply Pin (+5.0V)
16 DVSS - Digital Ground Pin
17 PDN - Power Down & Reset Pin
18 TST - Test Pin (GND)
19 CAD1 - Chip Address 1 Pin (GND)
20 CAD0 - Chip Address 0 Pin
21 LOUT4 O DAC4 Center Channel Output Pin
22 ROUT4 O DAC4 SW Channel Output Pin
23 LOUT3 O DAC3 SBL Channel Output Pin
24 ROUT3 O DAC3 SBR Channel Output Pin
Pin No. Pin Name I/O Pin Description
1 DVDD - Digital power supply pin. (3.3V)
2 DVSS - Digital ground pin.
3 TVDD - Input buffer power supply pin. (5.0V)
4 TX O Transmit channel (through data) output pin in serial mode.
5 XTI I X'tal input pin.
6 XTO O X'tal output pin. (Open)
7 PDN I Power down mode pin. When "L", the AK4112B is powered-down and reset.
8 R - External resistor pin.
9 AVDD - Analog power supply pin.
10 AVSS - Analog ground pin.
11 RX1 I Receiver channel 1 This channel is selected in parallel mode or default of serial mode.
12 RX2 I Receiver channel 2 in serial mode.
13 RX3 I Receiver channel 3 in serial mode.
14 RX4 I Receiver channel 4 in serial mode.
15 AUTO O Non PCM detect pin. "L" : No detect, "H" : Detect (Open)
16 P/S I Parallel/Serial select pin. "L" : Serial mode, "H" : Parallel mode (Analog ground)
17 FS96 O 96kHz sampling detect pin. (RX Mode) "H" : fs=88.2kHz or more, "L" fs=54kHz or less.
(X'tal Mode) "H" : XFS96=1, "L" : XFS96=0.
18 ERF O Unlock & Parity Error output pin. "L" : No error, "H" : Error
19 LRCK I/O Output channel clock pin.
20 SDTO O Audio serial data output pin.
21 BICK I/O Audio serial data clock pin.
22 DAUX I Auxiliary audio data input pin. (Analog ground)
23 MCK02 O Master clock #2 output pin. (Open)
24 MCK01 O Master clock #1 output pin.
25 CSN I Chip select pin in serial mode.
26 CCLK I Control data clock pin in serial mode.
27 CDTI I Control data input pin in serial mode.
28 CDTO O Control data output pin in serial mode.
6-3 96kHz 24Bit DIR : AK4112BVF (X08, IC2)
6-4 96kHz 24Bit CODEC & DAC : AK4529-VQ (X08, IC4)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KRF-V6060D/V7060D/V8060D/X9060D/VR-6050/6060/6070
10
CIRCUIT DESCRIPTION
Pin No. Pin Name I/O Pin Description
1 L V3 I Input pin of L channel VIDEO 3.
2 L 6CH I Input pin of FL channel DVD/6 channel.
3 L REC I Input pin of L channel REC.
4 L MD REC O Output pin of L channel MD REC.
5 L V1 REC O Output pin of L channel VIDEO1 REC.
6 N.C. - Unused.
7 N.C. - Unused.
8,22,52,53 VOL GND(1~4) - Analog ground for 8channel volume.
9 FL IN I Input pin of FL channel.
10 SL IN I Input pin of SL channel.
11 SBL IN I Input pin of SBL channel.
12 C IN I Input pin of C channel.
13 SW IN I Input pin of SW channel.
14 SBR IN I Input pin of SBR channel.
15 SR IN I Input pin of SR channel.
16 FR IN I Input pin of FR channel.
17,18,42,43 BASS( L1,L2,R1,R2) - Frequency characteristic setting pin of the tone control (Bass).
19,41 TRE(L,R) - Frequency characteristic setting pin of the tone control (Treble).
20,40 L T/RT OUT O Output pin of tone.
21 FL VIN I Input pin of FL channel volume.
23 TIM1 - Timer setting pin for Zero-Cross detector.
24 DVDD - Power supply to internal logic circuit.
25 LATCH I Latch input from CPU.
26 DATA I Data input from CPU.
27 CLOCK I Clock input from CPU.
28 DGND - Ground of internal logic circuit.
29 AVCC - Positive power supply to internal analog circuit.
30 OUT GND - Ground for output block.
31 FL OUT O Output pin of FL channel.
32 SL OUT O Output pin of SL channel.
30 OUT GND - Ground for output block.
31 FL OUT O Output pin of FL channel.
Pin No. Pin Name I/O Pin Description
25 LOUT2 O DAC2 SL Channel Output Pin
26 ROUT2 O DAC2 SR Channel Output Pin
27 LOUT1 O DAC1 FL Channel Output Pin
28 ROUT1 O DAC1 FR Channel Output Pin
29 NC1 - Unused
30 NC2 - Unused
31 LIN I Lch Analog Input Pin
32 RIN I Rch Analog Input Pin
33 OVR O Analog Input Overflow Detect Pin
34 VCOM O Common Voltage Output Pin
35 VREFH I Positive Voltage Reference Input Pin
36 AVDD - Analog Power Supply Pin (+5.0V)
37 AVSS - Analog Ground Pin
38 DZF1 - Zero Input Detect 1 Pin (unused)
39 MCLK I Master Clock Input Pin
40 P/S I Parallel/Serial Select Pin (GND)
41 CSN I Chip Select Pin in 3-wire Serial Control Mode
42 CCLK I Control Data Clock Pin in Serial Control Mode
43 CDTI I Control Data Input Pin in Serial Control Mode
44 TDM I TDM I/F Format Mode Pin (GND)
6-5 Input Selector & E. Volume : M61516FP (X09, IC2)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KRF-V6060D/V7060D/V8060D/X9060D/VR-6050/6060/6070
11
CIRCUIT DESCRIPTION
Pin No. Pin Name I/O Pin Description
32 SL OUT O Output pin of SL channel.
33 SBL OUT O Output pin of SBL channel.
34 C OUT O Output pin of C channel.
35 SW OUT O Output pin of SW channel.
36 SBR OUT O Output pin of SBR channel.
37 SR OUT O Output pin of SR channel.
38 FR OUT O Output pin of FR channel.
39 FR VIN I Input pin of FR channel volume.
44 DVD/6CH FR I Input pin of FR channel DVD/6 channel.
45 DVD/6CH SR I Input pin of SR channel DVD/6 channel.
46 N.C. - Unused.
47 DVD/6CH SW I Input pin of SW channel DVD/6 channel.
48 DVD/6CH C I Input pin of C channel DVD/6 channel.
49 N.C. - Unused.
50 DVD/6CH SL I Input pin of SL channel DVD/6 channel.
51 DVD/6CH FL I Input pin of FL channel DVD/6 channel.
54 LCH O Output pin of L channel balance (+).
55 L LOUDNESS - Frequency characteristic setting pin of the loudness part and
output pin of L channel balance (-).
56 IN GND - Ground for input block.
57 R LOUDNESS - Frequency characteristic setting pin of the loudness part and
output pin of R channel balance (-).
58 RCH O Output pin of R channel balance (+).
59 N.C. - Unused.
60 N.C. - Unused.
61 R V1 REC O Output pin of R channel VIDEO1 REC.
62 R MD REC O Output pin of R channel MD REC.
63 R REC I Input pin of R channel REC.
64 R 6CH I Input pin of FR channel DVD/6 channel.
65 R V3 I Input pin of R channel VIDEO 3.
66 R V2 I Input pin of R channel VIDEO 2.
67 R V1 I Input pin of R channel VIDEO 1.
68 R MD/TAPE I Input pin of R channel MD/TAPE.
69 R AUX I Input pin of R channel AUX.
70 R TUNER I Input pin of R channel TUNER.
71 R PHONO I Input pin of R channel PHONO.
72 R CD/DVD I Input pin of R ch CD/DVD.
73 AVEE - Negative power supply to internal analog circuit.
74 L CD/DVD I Input pin of L channel CD/DVD.
75 L PHONO I Input pin of L channel PHONO.
76 L TUNER I Input pin of L channel TUNER.
77 L AUX I Input pin of L channel AUX .
78 L MD/TAPE I Input pin of L ch MD/TAPE.
79 L V1 I Input pin of L channel VIDEO 1.
80 L V2 I Input pin of L channel VIDEO 2.
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KRF-V6060D/V7060D/V8060D/X9060D/VR-6050/6060/6070
12
CIRCUIT DESCRIPTION
Pin No. Pin Name I/O Pin Description
1 VSS - GND
2 DATA I Serial data input.
3 CLOCK I Shift clock of data.
Parallel data output ( N ch Open Drain FET).
4~15 OUT1~OUT12 O Latch Data L H
Output FET ON OFF
16 VDD - Power supply.
Pin No. Pin Name I/O Pin Description
2 VC1IN I Input of C signal for S-video terminal.
4 NFBCG - Negative feed-back pin of amplifier (unused).
6 VC2IN I Input of C signal for DVD.
8 VC3IN I Input of C signal for video 3.
10 VC4IN I Input of C signal for video 2.
12 VC5IN I Input of C signal for video 1.
14 VC6IN I Unused.
15 GND - GND
16 MUTE - Mute time constant changing pin.
17~19 MUTE(3~1) - Changeover pin of mute.
20 CTL 3 I Video switch control 3 input.
21 CTL 2 I Video switch control 2 input.
22 CTL 1 I Video switch control 1 input.
23 VCOUT 2 O Output of C signal for DVD.
24 VC OUT1 O Output of C signal for video 1.
25 VCC- - Negative power supply.
26 VBOUT 2 O Output of Y signal for DVD.
27 VBOUT 1 O Output of Y signal for video 1.
28 VCCDR- - Negative power supply.
29 VAOUT 2 O Monitor output of ROOM B.
30 VAOUT 1 O REC output of video 1.
33 VCCDR+ - Positive power supply.
35 VA6IN I Unused.
37 NFBAG - Negative feed-back pin of amplifier (unused).
39 VA5 IN I Input of video signal for video 1.
41 VA4 IN I Input of video signal for video 2.
43 VA3 IN I Input of video signal for video 3.
45 VA2 IN I Input of DVD signal.
47 VAIN I Input of video signal for composite.
50 VB1IN I Input of Y signal for S-video terminal.
52 NFBBG - Negative feed-back pin of amplifier (unused).
54 VB2 IN I Input of Y signal for DVD.
56 VB3 IN I Input of Y signal for video 3.
58 VB4 IN I Input of Y signal for video 2.
60 VB5 IN I Input of Y signal for video 1.
62 VB6 IN I Unused.
63 VCC+ - Positive power supply.
6-6 S-Video & Video Selector : LA79510M (X14, IC65)
6-7 Serial in / Parallel out Driver : BU2090F (X14, IC74)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KRF-V6060D/V7060D/V8060D/X9060D/VR-6050/6060/6070
13
CIRCUIT DESCRIPTION
Pin No. Pin Name I/O Pin Description
1 IN1B I Composite Cr signal input.
2,7,12 CTL(1~3) I Video switch control input.
3 OUT1 O Composite Cr signal output.
4,10,15 GND(1~3) - GND
5 OUT2 O Composite Cb signal output.
6 OUT3 O Composite Y signal output.
8 IN3A I Composite Y signal input.
9 IN3B I Composite Y signal input.
11 IN2A I Composite Cb signal input.
13 V - Power supply
14 IN2B I Composite Cb signal input.
16 IN1A I Composite Cr signal input.
Pin No. Pin Name I/O Pin Description
1 QUAL O Output signal of demodulation quality.
2 RDATA O RDS Demodulation data output.
3 VREF - Reference voltage connection pin.
4 MUX I Composite signal input.
5 VDD1 - Analog power supply (+5.0V).
6 VSS1 - Analog ground.
7 VSS3 I Comparator input.
8 CMP O Comparator output.
9 T2 I Connected to ground.
10 T1 I Connected to ground.
11 VSS2 - Connected to ground.
12 VDD2 - Digital power supply (+5.0V).
13 XI I Crystal oscillator (4.332MHz) output.
14 X0 O Crystal oscillator (4.332MHz) input.
15 NC - Unused.
16 RCLK O Demodulation clock (1.1875MHz) output.
Pin No. Pin Name I/O Pin Description
1~35 AM1~AM35 O Output pin of Anode.
36~38 AA1~AA3
39~43 AA4~AA8/ O Output pin of Anode and Grid.
G16~G12
44~54 G11~G1 O Output pin of Grid.
55 VFL - Power supply for driver section.
56 TEST - Connected to be ground.
57 VSS - GND
58 OSCO O Crystal oscillation circuit output.
59 OSCI I Crystal oscillation circuit input.
60 VDD - Power supply for logic section (+5.0V).
61 RES I Input pin of system reset.
Serial data transfer pin.
62 CE I Chip enable input.
63 CL I Synchronism clock input.
64 DI I Transfer data input.
6-8 VFD Display Controller Driver : LC75711NED (X14, IC78)
6-9 RDS Demodulator IC : BU1923 (X14, IC81) E/T Type Only
6-10 Composite Selector : NJM2284D (X25, IC101)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KRF-V6060D/V7060D/V8060D/X9060D/VR-6050/6060/6070
14
CIRCUIT DESCRIPTION
Pin No. Pin Name I/O Pin Description
1 X IN I Crystal resonator connection.
2 CE I Chip enable.
3 DI I Input serial data.
4CLI
Used as the synchronization clock when serial data is input to the DI(pin 3), or
when serial data is output DO(pin 5).
5 DO O Outputs serial data.
6 B01 • Dedicated output pins.
7 B02 O• The output states are determined by B01 to B04 in the serial data.
8 B03 "Data" =0 : Open "Data" =1 : Low
9 B04 • These pins go to the open state after the power-on reset.
Pins used for both input and output.
10,12 I01, I02 I/O The input or output state is determined by bits I0C1and I0C2 in the serial data.
"Data" = 0 : Open, "Data" = 1: Low
11 IF IN I IF count input.
13 AM IN I Local oscillator signal input.
14 FM IN I Local oscillator signal input.
15 VDD - Power supply.
16 PD O PLL charge pump output.
17, 18 AIN I The MOS transistor used for the PLL active low-pass filter.
AOUT O
19 VSS - Ground.
20 X OUT O Crystal resonator connection.
Pin No. Pin Name I/O Pin Description
1 MUTE I Mute control pin.
2 INA I Composite Y signal input.
3,5,8 GND - Ground pin.
4 INB I Composite Cb signal input.
6,11 N.C. - Unused.
7 INC I Composite Cr signal input.
9 OUTC2 O Output of the composite Cr signal.
10 OUTC1 O Output of the composite Cr signal.
12 OUTB2 O Output of the composite Cb signal.
13 OUTB1 O Output of the composite Cb signal.
14 OUTA2 O Output of the composite Y signal.
15 OUTA1 O Output of the composite Y signal.
16 VCC - Power supply pin.
6-11 3 Channel 75ΩDriver : BA7666FS (X25, IC102)
6-12 PLL Frequency Synthesizer LSI : LC72131M (Tuner Assy IC2)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KRF-V6060D/V7060D/V8060D/X9060D/VR-6050/6060/6070
15
ADJUSTMENT
No. ITEM INPUT
SETTINGS
OUTPUT
SETTINGS
RECEIVER
SETTINGS
ALIGNMENT
POINTS ALIGN FOR FIG.
AUDIO SECTION SPEAKER : A
<1> IDLE CURRENT
CN11, FL ch.
CN10, FR ch.
CN14, SL ch.
CN13, SR ch.
CN12, C ch.
CN15, SW ch.
X09(A/4)
(FRONT 2ch
MODE)
Volume:
Minimum
VR1(FL)
VR2(FR)
VR3(SL)
VR4(SR)
VR5(CENTER)
VR6(SUB WOOFER)
X09(A/4)
Adjust every
potentiometer
10 minutes later
after turned
the power on.
Idling Current Adjustment
All power amplifier stage need idling current adjustment after the installation of TRAIT transistor.
1. Connect a voltmeter to CN11 with the correct polarity as indicated by the PCB silk print.
2. Adjust the preset, VR1 to get 8.8mV (Idling current = 20mA ) at the voltmeter reading.
3. Repeat step 1 and 2 for all other channels.

w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

KRF-V6060D/V7060D/V8060D/X9060D/VR-6050/6060/6070
15
WIRING DIAGRAM
(X09-6580-10) : VR-6050
(X09-6582-71) : KRF-V7060D/-S
(X09-6580-12) : VR-6070
(X09-6580-23) : KRF-X9060D-G
(X09-6580-11) : VR-6060
(X09-6580-22) : KRF-V8060D-G
(X09-6582-72) : KRF-V8060D
(X09-658X-XX) : KRF-V6060D/-S
KRF-V8060D-S
KRF-X9060D/-S
(X25-6492-71) : KRF-V8060D/-G/-S
(X25-6490-10) : VR6060
(X25-6490-11) : VR6070
(X25-6492-72) : KRF-X9060D/-G/-S
(X25- ) (B/2)
(X09- ) (A/5)
(X09- ) (B/5)
TUNER ASSY
(W02-2893-05) : K,P TYPE
(W02-2895-05) : Y,H,X,M,I TYPE
(W02-2896-05) : E,T TYPE
(X14-) (K/11)
(X14- ) (H/11)
VOLTAGE SELECTOR
(X09- ) (C/5)
POWER AMPLIFIER UNIT
SPEAKER UNIT
(X14-7420-10) : VR-6050
(X14-74XX-XX) : KRF-V6060D/-S
(X14-7422-71) : KRF-V7060D/-S
(X14-7430-10) : VR-6060
(X14-7430-11) : VR-6070
(X14-7432-71) : KRF-V8060D
(X14-7430-21) : KRF-V8060D-G
KRF-V8060D-S
KRF-X9060D/-G/-S
(X14- ) (A/11)
DISPLAY PCB
HEAD PHONE PCB
(X08-3130-10) : VR-6050
KRF-V7060D/-S
(X08-3130-12) : VR-6070
KRF-X9060D-S
KRF-V8060D/-S
(X08-3130-11) : VR-6060
(X08-3130-22) : KRF-V8060D-G
DSP UNIT
TUNER PCB (X14- ) (B/11)
SELECTOR
SWITCH
(X14- ) (C/11)
STANDBY
VOLUME (X14- ) (I/11)
AC/STD. TRANS
(X25- ) (A/2)
COMPONENT VIDEO UNIT
DEMODULATOR
(X05-5180-10)
UNIT
(X14- ) (F/11)
I/C AVR
(X14- ) (D/11)
TRANSFORMER
POWER
POWER
TRANSFORMER
POWER SWITCH
(X14- ) (J/11)
RF-RC
COMPOSITE
VIDEO
VR-6050/6060/6070/KRF-V6060D/V7060D/8060D/X9060D
FRONT AUX.
S-VIDEO UNIT
(X14- ) (G/11)
POWER TRANSFORMER
(L07-3138-05) : K,P TYPE
(L07-3140-05) : H,X TYPE
(L07-3139-05) : Y,M,I TYPE
(L07-3141-05) : E,T TYPE
(L07-31XX-05)
(L07-31XX-05)
(X08-3130-XX) : KRF-V6060D/-S
KRF-X9060D/-G
6dB
PRE AMP
(X09- ) (E/5)
J5
J2
J3
J6
J4
WH2
SW
SB
Lch
Lch
Rch
Lch
Rch
Rch
Lch
Rch
REC
VIDEO 1
VIDEO 3
J1
Rch
Lch
Rch
Lch
Rch
Lch
Rch
Lch
FRONT A
SPEAKERS
/AUX
PHONO
CD
REC
MD/TAPE
PLAY
MD/TAPE
PLAY
VIDEO 1
VIDEO 2
FL
FR
SL
SR
C
SW
J7
DVD/6ch
Lch
Rch
Cch CENTER
Rch
Lch
FRONT B
SPEAKERS
Lch
Rch
Rch
Lch
FRONT B
SPEAKERS
SURROUND
AM
GND
FM
KRF-X9060D/-G/-S
EXCEPT
VR-6070
WH1
KRF-V6060D/-S
VR-6050
KRF-V7060D/-S
ONLY
EXCEPT
VR-6050
KRF-V6060D/-S
KRF-V7060D/-S
KRF-V8060D-S (X09-658X-XX)
KRF-X9060D-S (X09-658X-XX)
KRF-X9060D (X09-658X-XX)
KRF-V6060D (X09-658X-XX)
KRF-V6060D-S (X09-658X-XX)
WH221
CN303CN302
P201
FL
FR
SL
SR
SBL
SBR
J302
J301
Rch
Lch
SUB WOOFER
PRE OUT
SPEAKERS
J303
C
SW
Cr
Cr
Cb
J101
Cb
Y
Y
VIDEO IN
DVD &
Y
Cb J102
Cr
OUT
MONITOR
J202
IR OUT
J201
IR IN
ROOM B
L
R
ROOM B
J1
SURROUND BACK/
KRF-X9060D/-G/-S
ONLY
VR-6070
CN5
CN301
75
CN21
E22
E21
PLAY IN DVD
MONITOR
OUT
PLAY IN
J67
PLAY IN
VIDEO3
VIDEO2
J66
J68
IN
VIDEO1
PLAY
OUT
REC
J65
P2
J5
J4
J3
PLAY IN
VIDEO2
DVD
OUT
MONITOR
PLAY IN
PLAY IN
VIDEO3
J2
E603
VIDEO1
J63
J62
IN
PLAY J61
OUT
REC
S-VIDEO
J21
P1
J20
Lch
COM
AV-AUX
Rch
P3
S1
J501
PHONES P501
S2
CN22 WH93
CN7
WH91 WH92
CN6
KRF-V8060D-S (X14-743X-XX)
KRF-X9060D-S (X14-743X-XX)
KRF-X9060D-G (X14-74XX-XX)
KRF-X9060D (X14-7432-XX)
KRF-V6060D-S (X14-742X-XX)
KRF-V6060D (X14-742X-XX)
CN51 WH90
WH88
CN5
WH89
CN4
CN3CN4
CN1
A1
S800
DVD
VIDEO2
COAXIAL IN J1
A2
VIDEO3
OPTICAL IN
CD/DVD
A3
OPT OUT
J800
SYSTEM
CONTROL
CHANNEL
SWITCH
SPACE
M,Y,I TYPE
ONLY
EXCEPT
KRF-V7060D/-S
KRF-V6060D/-S
VR-6050
KRF-X9060D/-G/-S
VR-6070
ONLY
KRF-V6060D (X08-3130-XX)
WH70
CN70
CN80 WH80
CN50WH78
H TYPE ONLY
K,P,Y TYPE ONLY
E,M,I TYPE ONLY
T TYPE ONLY
X TYPE ONLY
WH87
CN202
ONLY
VR-6070
VR-6060
WH94
EXCEPT
Y,M,I TYPE
ONLY
Y,M,I TYPE
CN47
Y,M,I TYPE
EXCEPT
CN49 EXCEPT
K,P TYPE
WH5
CN46
CN48
Y,M,I TYPE
ONLY
WH1
CN1
CN1 CN201
VR-6060/6070
ONLY
VR-6050
KRF-V6060D/-S
KRF-V7060D/-S
EXCEPT
VR-6070
ONLY
CN1
WH66
CN101
PLAY IN
VIDEO
KRF-V7060D/-S
KRF-V6060D/-S
ONLY
VR-6050
CN65
ROOM B
OUT
MONITOR
VR-6070
ONLY
KRF-X9060D/-G/-S
KRF-V7060D/-S
KRF-V6060D/-S
EXCEPT
VR-6050
E602E601 WH69
WH3 CN2
WH20
CN68
CN3
CN2
WH42
CN67
CN41
CN10 CN11 CN13CN12 CN14 CN15
WH21
KRF-X9060D-G (X08-3130-XX)
KRF-X9060D (X08-3130-XX)
KRF-V6060D-S (X08-3130-XX)
CN45
WH7 CN8
CN304
WH4
WH1
WH2
WH5 WH6
KRF-V6060D/-S/V7060D/-S
EXCEPT VR-6050
KRF-X9060D/-G/-S
VR-6070
ONLY
ANTENNA
REMOTE
RF
41
EUROPE
AUSTRALIA
COUNTRY
DESTINATION
2-72E
UNIT
0-22
X
ABB.
EUROPE
AUSTRALIA
DESTINATION
COUNTRY
EUROPE
U.K.
PX
UNIT
0-23
2-73
E
T
X
ABB.
0-23
2-73
Y
E
DESTINATION
COUNTRY
UNIT
ABB.
EUROPE
AUSTRALIA
KOREA
MALAYSIA
GENERAL MARKET
EUROPE
COUNTRY
DESTINATION
DESTINATION
COUNTRY
U.K.
PX
UNIT
2-71
0-21
T
E
X
H
I
M
ABB.
0-21
UNIT
2-71
Y
E
ABB.
14
1441 1
19
19
1
15
11
15
51
51
T1
F2
CN22 CN21
F1
CN12 CN11
W
WW
WW
WW
WW
CN3 CN4
F3
1
99
1
19
91 15
15 1
1
GENERAL MARKET
GENERAL MARKET
E 2-72EUROPE
COUNTRY
AUSTRALIA
EUROPE
DESTINATION
No.
UNIT
ABB.
E
X0-71
2-71
EUROPE
U.K.
AUSTRALIA
2-72
0-52
0-72
X
T
E
COUNTRY
DESTINATION
KOREA
DESTINATION
COUNTRY
ABB.
UNIT
No.
24-12
30-22
H
M
No.
UNIT
ABB.
PX
COUNTRY
DESTINATION
ABB.
UNIT
No.
Y2-92
U.K.
EUROPE
AUSTRALIA
KOREA
MALAYSIA
COUNTRY
DESTINATION
EUROPE
2-71
0-51
0-71
0-21
E
T
X
H
I
M
ABB.
UNIT
No.
4-11
2-71E
PX
DESTINATION
COUNTRY
2-91
Y
UNIT
No.
ABB.
3
11
3
10
110
113
113
21
1
21
1
1
2
1
50kHz
100KHz
1
3
3
1
1
3
3
1
1
7
1
7
2
1
K,P TYPE : 10A 125V
EXCEPT K,P TYPE
: T4A L250V : T2.5A L250V
EXCEPT K,P,H TYPE
1
7
7
1
15
12 1212
12
T4A L250V
220-240V
110-120V
3
1
13
51
1
7
7
1
1
5
14
14
51
1
66
1
3
13
1
71
14
1
3
14 61
21
31
12 2112212121
EUROPE E
GENERAL MARKET
KOREA H
M0-23
0-12
Y0-23PX
DESTINATION
COUNTRY
EUROPE
ABB.
UNIT
No.
E 0-12
COUNTRY
DESTINATION
ABB. No.
UNIT
EUROPE E 0-10
COUNTRY
DESTINATION
PX
UNIT
ABB.
Y
No.
0-21
AUSTRALIA
MALAYSIA
GENERAL MARKET
KOREA
U.K.
H
T
X0-10
I
M0-21
DESTINATION
COUNTRY ABB.
UNIT
No.
No.
No.
No.
No.
No.
1
2
1
10 10
1
2
3
4
5
6
7
8
9
21
21
1
2
2
1
2112
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

ACEBD
2
1
3
5
7
4
6
PC BOARD (Component side view)
16
C932
C922
R501
R503
R504
C912
C126
C8
C9
C12
C15
C17
C35
C38
R11
R107
R108
R207
R208
R307
R308
R407
R408
R502
R505
R506
R507
R508
C1
C2
C10
C16
C123
C124
CP600
CP601
CP603
CP604
R1
R2
R4
R9
R10
R15
R16
R17
R18
R19
R20
R21
R22
R30
R109
R110
R111
R112
R123
R124
R125
R126
R127
R128
R129
R130
R209
R210
R211
R212
R213
R216
R309
R310
R311
R312
R409
R410
R411
R412
R513
R541
R542
R543
R121
R122
C914
R156
R155
R157
R158
R14
R23
C19
C20
CP51
CP52
C514
R514
R32
C39
113
CP602
128
1514
1
34
5
1
89
16
1
45
8
1
11 23
33
3444
2212
17
148
1
4
8
5
3772
36
1
108
73
144109
71
148
1732
161
1
1
121
220
10
22
4423
5
81
4
1
45
8
15 1
3016
4
18
5
1
45
8
1
45
8
50kHz 100kHz
C515
C33
C930
C920
C910
C31
C5
GIO
GIO
GIO
GI O
C6
C7
C34
C900
C101
C102
C127
C128
C201
C202
C209
C210
C301
21
C302
C309
C310
C401
C402
C409
C410
R513
R920
R930
X1
D930
IC2 IC4
IC60
D1
D920
IC6
IC50
IC51
IC52
IC61
D910
IC11
IC12
IC21
IC31 IC41
IC123
IC3
IC7
IC5
X08-3131-10
IC93
IC92
A1
A2
A3
CONTROL
SYSTEM
DVD/6CH
VIDEO 2
COAXIAL
CD/DVD
DIGITAL IN
VIDEO 3OUT
D900
J1 J800
CN3
CN5
S800
CN1
CN4
IC91
IC90
(J70-1571-22)
OPTICAL
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

17
BE
BE
X08-3131-10 (J70-1571-22)
D3
D4
D800 D801
D950
Q951
D901
D902
D951
Q950
C32
C600
C931
R3
R5
R6
C11
C500
C502
C504
C505
C507
C508
C509
C511
C512
C513
C601
C921
C501
C503
C506
C510
C911
C108
C121
C122
C125
C206
C308
C408
R950
C107
C207
C307
C407
C30
C3 C4
C18
C36
C37
C103 C104
C203 C204
C303
C304
C403
C404
C802
C913
C923
C933
R7 R8
R103
R104
R203 R204
R303
R304
R402
R403
R512
R955
R214
R215
C800
C801
C105
C106
C205
C208
C305
C306
C405
C406
C901
R101
R102
R105
R106
R201
R202
R205
R206
R301
R302
R305
R306
R401
R404
R405
R406
R509
R510
R511
R900
R910
R951
R952
R953
R954
R608
R601
R602
R603
R604
R605
R606
R607
C908
C803
C909
C154
C153
L1 L2
W999
R31
C602
C603
R931
R151
R152
R153
R154
R515
C109
C110
C411
FGIHJ
2
1
3
5
7
4
6
PC BOARD (Component side view)
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

2
KMOQSLNPRT
1
3
5
7
4
6
Refer to the schematic diagram for the value of resistors and capacitors.
PC BOARD (Component side view)
78
1
1
121
220
19
218
80
65
64
41
40
25 24
95mm
SW IDLE
IDLE
SR
IDLE
W35 1
W350
W25
W49
W14 W12
W15 W11
W13 W10
W1
1
11
43
5
4
2
W2
C364
/
BLK
BLK
W56
W75
C319
W293
W53
R315 EB
E
B
R461
C320
R316
R450
R462
R313
C312
R312
C310
C313
R354
R355
C314
C1 C2
C5 C6
C7 C8
C17 C18
C19
C20
C21
C22
C23 C24
C25
C26
C27
C28 C29
C30
C31
C32
C33
C34
C35
C36
C37
C38
C46
C47
C55
C56
C66
C67
C72
C73
C74
C75
C115
C116
C121
C122
C123
C124
C165
C166
C171
C172
C173
C174
C231
C232
C304
C351
C352
C353
C354
C361
C362
C363
C369C365 C367
R3 R4
R13 R14
R19
R20
R23
R24
R27
R28
R31
R32
R35
R36
R39
R40
R43
R44
R49
R50
R53 R54
R57
R59
R60
R63
R64
R67
R68
R113
R114
R117
R118
R163
R164
R167
R168
R223
R224
R225
R226
R229 R230
R233 R234
R413
R414
R466 R472
C92
C93
C94
C95
C141
C142
C143 C144
C191
C192
C193
C195
C196
C308
C309
C315
C316
C317 C318
W222
C3 C4
C9 C10
C11 C12
C13 C14
C15 C16
C44
C45
C51
C52
C53
C54
C57
C58
C62
C63
C64
C65
C68
C69
C70
C71
C76
C77
C78
C79
W235
C82
C83
C84
C85
C86
C87
C88
C89
C90
C91
C111
C112
C113
C114
C117
C118
C119
C120
C125
C126
C127
C128
C133
C134
C135
C136
C137
C138
C139
C140
C161
C163
C164
C167
C168
C169
C170
C175
C176
C177
C178
C181
C183
C184
C185
C186
C187
C188
C189
C190
C221
C222
C223
C224
C225
C226
C227
C228
C229
1
1
14
7
14 8
4
85
C230
C307
C355
C356
C357
C358
C359
C360
C366
C368
R1 R2
R5 R6
R7 R8
R9 R10
R11 R12
R15
R16
R17
R18
R21
R22 R25
R26 R29
R30
R33 R34
R37
R38
R41
R42
R45
R46
R47
R48
R51
R52
R55
R56
R65
R66
R69
R70
R71
R72
R73
R74
R75
R76
R77
R78
R79
R80
R81
R82
R83
R84
R85
R86
R87
R88
R89
R90
R91
R92
R93
R94
R95
R96
R97
R98
R99 R100
R111
R112
R115
R116
R119
R120
R121
R122
R123
R124
R125
R126
R127
R128
R129
R130
R131
R132
R133
R134
R135
R136
R137
R138
R139
R140
R141
R142
R143
R144
R145
R146
R147
R148
R149
R150
R161
R162
R165
R166
R169
R170
R171
R172
R173
R174
R175
R176
R177
R178
R179
R180
R181
R182
R183
R184
R185
R186
R187
R188
R189
R190
R191
R192
R193
R194
R195
R196
R197
R198
R199
R200
R221
R222
R227
R228
R231
R232
R235
R236
R302
R303
R305
R306
R307
R308
R309
R321
R322
R325
R326
R327
R328
R329 R330
R351
R352
R353
R356
R357
R358
R359
R360
R361
R362
R363
R364
R365
R366
R367
R381
R382
R383
R384
R385
R386
R387
R388
R389
R390
R391
R392
R401
R402
R403
R404
R405
R406
R407
R408
R409
R410
R411
R412
R431
R432
R433
R434
R435
R436
R437
R438
R451
R452
R453
R455
R456
R457
R458
R304
R460
R463
R464
R465
R467
R468
R469
R471
R473
R474
R475
W294
W266
W265
W225
W189
W66
W4
W52
W76
W6
W64
W61
W58
W68
W88
W60
W83
W155
W78
W62
W98
W201
W229
W267
W298
W256
W140
W299
W137
W77
W72
W281
W254
W270
W218
W257
W232
W192
W207
W206
W272
W216
W230
W231
W271
W226
W278
W241 W261
W263
W247 W245
W277
W282
W286
W250
W258
W214
W157
W217
W236
W211
W175
W115
W54 W51
W173
W292
W259
W253
W237
W240
W7
W198
W228
W268
W5
W221
W194
W190
W243 W246
W239
W260
W209
W121
W205
W210
W63
W182
W185
W70
W159
W93
W184
W124
W161
W160
W129
W227
W219
W297
W3
W122
W170
W296
W280
W283
W262
W264
W238
W242
W249
W224
W111
W118
W279
W125
W120
W117
W183
W110
W71
W69
W97
W87
W74
W80
W84
W151
W131
W150
W134
W145
W154
W180
W89
W109
W106
W116
W199
W123
W203
W187
W196
W191
W59
W57
W114 W152
W104
W105
W113
W91
W96
W107
W119
W130
W103
W136
W147
W163
W179
W158
W168
W186
W169
W82
W90
W95
W193
W165
W171
W178 W174
W144
W73
W92 W94
W81
W100 W101
W108
W85
W112
W99
W102
W177
W67
W132 W135
W139 W143 W148
W149
W128
W204
W133
W200
W141
W234
W126
W142
W127
W138
W176
W162
W181
W146
W167
W164
W153
C600
R600
W195
W212
W166
W233
W220
W244
R609
R610
R608
R607
R603
R601
R605
W291
W284
W290
W289
R602
R604
R606
W21
W20
W213
W208
W252
W276
W65
C321
W223
W215
19
C323
W86
W50
W55
C322
W302
W307
W306
W301
W172
W287
W156
W188
115
R339 R338
R340
W79
R341
R336
C370
R335
R337
R334
W255
R324
R323
W197
W248
R476
R470
W318
C325
W303
W305
W300
W273
C324
W311
W312
W309
W310
W314
W313
W308
W251
W317
R237
C303
R319
C233
W315
W319
W8
C326
31
41
51
W22
W23
R314
VR1
VR2
VR3
VR4 VR5
VR6
W27 45mm
R58
K3
K2
R201
R101
R102
K4
K5
W26 60mm
R152
R151
R202
80mm
R333 L6
L3
C450
L4
L5
L1
R332
R331
L2
18
W24
55mm
C451
C453
K1
C311
R454
R342
R343
R311
R310
R459
C305
R104
R103
C306
R301
C301
C452
C302
R318
RC
IDLE
L
IDLE
R317
SL
IDLE
C502
C501
R624
R618 R616
R615 R617
R621
C607
141
1
4
8
5
87
W323
W322R614
R613 R612
R611
R622
W325
R623
W324
C608
R619
R620
C605
C606
C603 C604
W321
W320
W269
W275
W274
115
142
11
24
5
9
W288
W285
W295
BE
E
13
B
EE EE
BBBBEE EE BBBBEE EE BBBBEE EE BBBBEE EE BBBBEE EE BB
21
21
21
21
21
21
BB
EB
EB
E
E
B
B
EB
EB
BE
BE
BE
BE
BE
B
EB
E
E
E
B
E
E
B
B
B
E
B
EE
B
B
B
E
EB
E
E
E E
B
E
B
B
B
E
E
E
E
E
B
B
B
E
E
B
B
EB
E
E
BEB
B
B
B
E
B
B
B
E
E
B
B
E
EB
E E
E
E
B
E
B
B
E
E
E
B
B
E
B
E
E
B
B
E
B
E
B
B
E
E
B
B
B
E
B
BE
B
EB BE
E
EB
B
BE
E
B
B
B
E
E
E
BEB
IC2
Q54 Q52 Q34 Q32 Q12Q14 Q53 Q51 Q13 Q11 Q33 Q31
WH7.2
WH7.7
WH7.6
WH7.10
WH7.1
WH7.9
WH7.8
WH7.5
WH7.4
D601
D64
D21
D22
D20
D600
Q351
Q352
D603
D17
D63
D65
D67
Q302
Q331
Q332
Q333
Q334
Q335
Q336
Q337
Q338
Q360
Q361
D19
D25
Q301
Q305
Q308
Q309
Q310
Q312
Q603
D604
Q604
D602
Q602
D1
D2
D3
D4
D5
D6
D13
D14
D15
D16
D18
D23
D24
D28
D29
D30
D32
D33
D34
D35
D51
D52
D53 D54
D55
D56 D57
D58
D59
D60
D61
D62
D66
D221
Q1
Q2
Q3
Q4
Q5
Q6
Q7
Q8
Q9
Q10
Q21
Q22
Q23
Q24
Q25
Q26
Q27
Q28
Q29
Q30
Q41
Q42
Q43
Q44
Q45
Q46
Q47
Q48
Q49
Q50
Q303
Q304
Q306
Q307
Q353
Q354
Q355
Q356
Q357
Q358
Q359
Q362
Q365
Q607
Q605
Q606
D68
Q311
D27
D69
Q313
D26
J1
BLK
E22
WH21
RED
BLU
J3 J2
J4
J5
IC4
WH4
J6
J7
(J70-1573-31)
WH1
IC5
WH221
WH2
BLK
WHT
YEL
GRY
ORG
BLK
WH2
CN3
CN2
IC1
WH3
D11
CN6
WH6
BLU
WH5
RED
BLK
CN5
BLU
CN4
RED
WH5 BLU
WH6
Q363
Q364CN7
D12
CN1
CN15
CN13
CN10 CN12 CN11 CN14
E501
CN51
P501
X09 C/5
J501
Q609
D607
Q608
D606
IC3
D605
IC6
X09 E/5
CN8
CN21
X09 B/5
WH21
CN22 E21
PHONES
A/5
X09-6580-10
LR
FRONT B
SPEAKERS
FRONT A
LRC
CENTER
SPEAKERS
PRE OUT WOOFER
SUB SURROUND
CENTER
FRONT
DVD/6CH INPUT
PLAY IN PLAY IN PLAY IN REC OUT
VIDEO 1
REC OUTPLAY IN
MD/TAPEVIDEO 2VIDEO 3 CD/DVD PHONO
IN IN
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299

UVXZABADWYAAAC
2
1
3
5
7
4
6
Refer to the schematic diagram for the value of resistors and capacitors.
PC BOARD (Component side view)
109
C510
BLKYEL 6 1
79
78
BLK
17
WHT
C401
C409
C403 C402
R410
C408
W204
W304
TH1
C501
C502
C503
C504
C505
C506
C507
C508
C509
C511
R501
R502
R503
R504
R505
R506
R507
R508
R509
R510
W105
W106
W107
W109
W110
W108
W119
W112
W117
W116
W114
W115
W113
W122
W140
W142
P3
VOLUME CONTROL
13
R721
R722
R723
R725
C854
R854
W756
VIDOEO-1
W709
VIDEO-2
W715
W711
VIDEO-3
MD/TAPE
R814
C815
C853
R853
C764
BAND
AUTO
MEMORY
DOWN
R764
C763
R763
R961
R962
W766
W767
WHT
R964
W761
BLK
LISTEN MODE
R963
R762
W771
W807
C908
W303
W731
W727
C101
R834
W716
R749
DVD/6CH
R750
R751
R752
BLU
CD/DVD
R701
R702
R703
R704
R746
R747
R748
R709
C793
C792
W717
C831
GI
R831
R832
O
W714
81
916
R710
R715
R791
R711
R712
R713 R714
R754
R705
R706
R707
R708
PHONO/AUX
TUNER
W725
C819
C818
R813
W302
C817
18
16 9
C816
4.3MHz
C811
R982
W723
R833
C833
C832
W301
BE
W720
W721
R983
X811
C813 C814
C812
W732
ACT. EQ
SPK. R745
W705
C794
LOUDNESS
THX/
W702
W701
W703
RED
SPK. EQ
ACT.
EQ
R990
E
EQ
B
1
1
IOG 3
71
7
CSII
W718
R755
R741
DTS
BE
RED
W708
W707
W706
GRY
BLK
BLU
W710
DSP/
THX
W713
DOL.
R742
R744 D.
R743
R882
W712
R884
R997
C791
STEREO
W722
DSP
W726
MODE
INPUT
W735
W730
BE
W804
W803
W802
W801
W719
R885
W724
67
69
R780
C856
R973 R974
R975
C855
W752
R859
R862
W736
SOUND
TONE
W737
W738
W739
W740
SETUP
R718 R719
R720
UP
W744
R724
R861
R860
R902
W745
W743
W748
W750
C841
R843
R852
C852
EB
DIMMER
C844
R844
R841
R842
O
I
G
W742
W749
C842
W741
EB
R996 R976
R986
R987
R988
R989
W763
W759
R984
R985
W753
CONTROL
MULTI
R855
R999
R966
W769
W805
W734
W760
W762
W770
R761
R978
R921
R979
R121
W950
C858
R856
W751
W755
W704
C857
W951
W764
R980
WHT
R995
R994
R981
R107
DISPLAY & MICRO-COMPUTER PCB
R115
B
E
R846
R845
C843
C778
C779
R776
C777
W746
W747
R105
R106
R102
R101
R103 R104
W806
R867
R883
R901
R905
R906
R914
R781
W757
R864
R863
R865
C702
R866
W754
C851 W758
R851
R778
W728
R777
8.38MHz
X701
R112
R108 R109
R110
R111
R113
R114
110 1 13 1
15
13
19
26
25
1
15 1
19
100
76
51
75
50
321
1
16
17
32 33
48
49
64
22
R881
R835
W765
R868
R869
R870
R836
W772
BLU
W768
R946
W777
W776
W775
R766
R765
R965
W774
W778
R753
F. AUX
R717
R947
R948
ORG
R925
R930
R931
R928
R929
R932
R933
BLK
R992
R857
R934
R937
R936
R927
R991
R949
R950
MUTE
R716
R893
R895
R858
R944
R940
BLK
R941
R942
R943
R804
R886
R945
BLK
YEL
WHT
R887
R903
R912
R904
R899
R998
R900
R806
R909
R890
R891
R892
W773
BLK BLU
R888 R889
R907
R908
R913
BLK
SW
12
W145
R733
13
13
R732
R734
R731
STANDBY
SP-B SP-A
C407
I
13
GO
IGO
C411
C405
C404
C406
C410
C762
R924
R969
C845
C103
R120
C766
C703
R952
C761
R977
C704
R951
R972
R971
R993
R922
R923
R970
C741
C780
R782
C705
C907
R779
R911
C909
C765
R968
R926
C701
R935
R938
R939
R803
R802
R801
R967
R910
R805
R897
R896
R898
R894
IC79
IC78
IC90
WH42
WH20
IC402
D401
IC401
D501
D502
D503
D504
J21 J20
CN41
X14 E/11 X14 D/11 X14 H/11
X14-7420-10 A/11 (J70-1572-31)
CN70
S705 S706 S707 S708 S721 S722 S723
S725
WH91
S763
D964
D846
S709 S710 S711 S712 S713
WH90 D749
S701
D750
D748
D751
S702
IC74
IC83
D831
D747 D746
S703
D752
S704
D754
IC81
Q777
D744
Q731
D791
WH80
Q843
D741
WH78
WH87
D743
D742
E703
D755
S714
D841
D843
D745
Q778 A791
ED78
S715
S718 S719 S720 S724
Q841
D842
Q776
S762
D962
E702
D961
D963
D776
D844
Q842
IC84
E701
D801
D803
D802
D804
D753
S717
S761
X14 B/11
S716
WH92
WH93
WH70
D806
WH94
WH89
D805
WH88
X14 K/11
CN46
S2
D734
X14 C/11
S731
CN80
S733 S732
POWER
ANTENNA
RF REMOTE
S VIDEO VIDEO L AUDIO R
C19
C21
C36
L4
X1
EB
EB
EB
J1
X05-5180-10 (J70-1483-21)
(J70-1483-21)
X05-5180-10
DATA
CE
ANT
+B
CLK
VT
GND
+5V
IF
OUT
C4
C5
C12
C14
C16
C18
C22
C24
C25
C26
C27
C29
C30
C31
C32
C33
C34
C35
C37
C39
C40
C41
R34
C45
C47 CF1
L1
L5
R1
R3
R7
R13
R21
R32
C1
C2 C3
C6
C13
C17
C20
C23
C28
C38
C43
C44
L6
L7
L9
L10
L12
R2
R4
R6
R8
R9
R10
R11
R12
R14
R15
R16
R17
R18
R19
R20 R24
R25
R26
R31
R33
61
34
112
1324
51
34
1
8
16
9
71
D1
IC1
IC3
IC4
IC7
Q3
D2
Q2
Q4
CN1
13
54
w w w . x i a o y u 1 6 3 . c o m
Q Q
3
7
6 3
1 5 1 5
0 9 9
2
8 9
4 2
9 8
T E L 1 3 9 4 2 2 9 6 5 1 3 9 9 2 8 9 4 2 9 8 0 5 1 5 1 3 6 7 3
Q Q
TEL [phone] QQ 376315150 892498299 TEL [phone] QQ 376315150 892498299
