CIRCUIT DESCRIPTION
Pin No. Pin Name I/O Description
1 S. DATA I/O Serial data signal.
2 S.BUS I/O Serial busy signal.
3 SEL. ST1 O Strobe output to input selector ( IC106).
4 SEL/VOL/PLL DT O Data output to selector,volume and PLL IC.
5 SEL/VOL/PLL CLK O Clock output to selector,volume and PLL IC.
6 SEL. ST2 O Strobe 2 output to input selector ( IC109).
7 PLL. CE O PLL chip enable.
8 Vdd (+5v) - Power supply.
9 OSC OUT O 8MHz clock output.
10 OSC IN I 8MHz clock input.
11 Vss - Connected to ground.
12 X IN - Connected to ground.
13 X OUT - No used.
14 MMCD - Connected to ground.
15 Vref- - Connected to ground.
16,17 KEY2,KEY1 I Input terminal of key1 and key2.
18 MODEL TYPE I Discrimination port of models.
19 TH. SENS I No used.
20 PROTECT I Detection port of protection signal 1.
21 PROTECT2 I Detection port of protection signal 2.
22 S.LEVEL/CH SPACE I RDS S level and channel space changeover.
23 PLL DO I RDS PLL data signal input.
24 Vref+ - Reference voltage of AD converter..
25 CE I Chip enable.
26 RESET I Reset signal input.
27 T. MUTE O Muting signal output to tuner.
28 RF ST O CE signal output of RF receiver IC.
29 RF DT O Data signal output of RF receiver IC.
30 RF CLK O Clock signal output of RF receiver IC.
31 VOL.ST O Latch output of electric volume.
32 DSP INTREQ I/O Detection port of DSP INTREQ.
33 DTS DET I Detection port of DTS data.
34 REMOCON I Remote control signal input.
35 DIR ERR I Detection port of DIR error signal.
36 DZF I Detection port of CODEC zero input.
37 RDS.CLK I RDS clock input.
38 RDS.DAT/CE2 I RDS data input./u-COM chip enable 2.
39 DSP/DIR/CORDEC CDIN O Serial data output.
40 DSP/DIR/CDOUT I Serial data input.
41 DSP/DIR/CORDEC CCLK O Clock output to IC2, IC5 and IC51on X08.
42 DSP CS O DSP chip select.
43 DSP PD O DSP power down.
44 DIR CODEC CS O CODEC chip select.
45 DIR CODEC PD O DIR CODEC power down.
46 NO USE - No used.
47-57 1G-11G O FL grid control(1G-11G).
58-74 P1-P17 O FL segment control(P1-P17).
75 PACK CONT. O Power pack control.
76 LIMMITER O Control port of A class power supply.
77 REAR RE O Relay control terminal of surround speaker.
78 CENTER RE O Relay control terminal of center speaker.
79 FB RE O Relay control terminal of front B speaker.
80 FA RE O Relay control terminal of front A speaker.
