Kenwood TK-2160 User manual

INSTRUCTION MANUAL
사용 설명서
使用說明書
© B62-1747-00 (M)
09 08 07 06 05 04 03 02 01 00
VHF FM TRANSCEIVER
UHF FM TRANSCEIVER
TK-2160/TK-3160
VHF FM 트랜시버
UHF FM 트랜시버
TK-2160/TK-3160
VHF 調頻對講機
UHF 調頻對講機
TK-2160/TK-3160
TK-2160/3160K00Covers 03.7.17, 8:50 PM1

TK-2160/ TK-3160
VHF FM TRANSCEIVER/ UHF FM TRANSCEIVER
INSTRUCTION MANUAL
TK-2160/3160 E 00 Covers 03.7.17, 9:25 AM2

i
EXPLOSIVE ATMOSPHERES (GASES, DUST, FUMES, etc.)
Turn off your transceiver while taking on fuel, or while parked in
gasoline service stations.
◆Government law prohibits the operation of unlicensed radio
transmitters within the territories under government control.
◆Illegal operation is punishable by fine or imprisonment or both.
◆Refer service to qualified technicians only.
Safety: It is important that the operator is aware of and
understands hazards common to the operation of any
transceiver.
THANK YOU
We are grateful you chose KENWOOD for your land
mobile radio applications. We believe this easy-to-use
transceiver will provide dependable communications to
keep personnel operating at peak efficiency.
KENWOOD transceivers incorporate the latest in
advanced technology. As a result, we feel strongly that
you will be pleased with the quality and features of this
product.
MODELS COVERED BY THIS MANUAL
• TK-2160: VHF FM Transceiver
• TK-3160: UHF FM Transceiver
NOTICES TO THE USER
TK-2160/3160 E 00i-iv 03.7.17, 9:25 AM1

ii
PRECAUTIONS
Observe the following precautions to prevent fire,
personal injury, and transceiver damage.
•Do not modify this transceiver for any reason.
•Do not expose the transceiver to long periods of
direct sunlight, nor place it close to heating
appliances.
•Do not place the transceiver in excessively dusty,
humid, and/or wet areas, nor on unstable surfaces.
•If an abnormal odor or smoke is detected coming
from the transceiver, switch OFF the power
immediately and remove the optional battery pack
from the transceiver. Contact your KENWOOD
dealer.
TK-2160/3160 E 00i-iv 03.7.17, 9:25 AM2

iii
CONTENTS
UNPACKING AND CHECKING EQUIPMENT ................... 1
SUPPLIED ACCESSORIES ......................................... 1
PREPARATION .................................................. 2
BATTERY PACK PRECAUTIONS .................................... 2
INSTALLING/ REMOVING THE (OPTIONAL) RECHARGEABLE
BATTERY PACK OR ALKALINE BATTERY CASE ...................... 7
INSTALLING/ REMOVING ALKALINE BATTERIES ...................... 8
INSTALLING THE (OPTIONAL) ANTENNA ............................ 9
INSTALLING THE BELT CLIP ....................................... 9
INSTALLING THE COVER OVER THE SPEAKER/ MICROPHONE JACKS ....10
INSTALLING THE (OPTIONAL) SPEAKER/ MICROPHONE .............10
GETTING ACQUAINTED .......................................11
PROGRAMMABLE AUXILIARY FUNCTIONS ..........................12
OPERATING BASICS ...........................................13
SWITCHING POWER ON/ OFF ..................................13
ADJUSTING THE VOLUME .......................................13
SELECTING ACHANNEL .........................................13
MAKING ACALL ...............................................14
RECEIVING ACALL .............................................14
SCAN ...........................................................15
PRIORITY SCAN ................................................15
TEMPORARY CHANNEL LOCKOUT ................................16
REVERT CHANNEL ..............................................16
2-TONE SIGNALLING ..........................................17
RECEIVING ....................................................17
TRANSMITTING .................................................17
TK-2160/3160 E 00i-iv 03.7.17, 9:25 AM3

iv
DTMF SIGNALLING ............................................18
FleetSync™ OPERATION .....................................19
RECEIVING ....................................................19
TRANSMITTING .................................................19
SmarTrunk II®OPERATION ...................................20
QUIET TALK (QT)/ DIGITAL QUIET TALK (DQT) .............21
SCRAMBLER ...................................................22
VOX OPERATION ..............................................23
EMERGENCY CALLS ..........................................25
ADVANCED OPERATIONS .....................................26
SELECTING AN OUTPUT POWER .................................26
MONITOR/ SQUELCH OFF .......................................26
BACKGROUND OPERATIONS .................................27
TIME-OUT TIMER (TOT) .......................................27
BATTERY SAVE ................................................27
LOW BATTERY WARNING .......................................28
BUSY CHANNEL LOCKOUT (BCL) ...............................28
STUN .........................................................28
BEGINNING/ END OF TRANSMISSION (TX) SIGNAL ................28
(CONTENTS CONTINUED…)
TK-2160/3160 E 00i-iv 03.7.17, 9:25 AM4

1
UNPACKING AND CHECKING EQUIPMENT
Note: The following unpacking instructions are for use by your
KENWOOD dealer, an authorized KENWOOD service facility, or the
factory.
Carefully unpack the transceiver. We recommend that you
identify the items listed in the following table before discarding
the packing material. If any items are missing or have been
damaged during shipment, file a claim with the carrier
immediately.
SUPPLIED ACCESSORIES
Belt clip
Speaker/ microphone
jacks cap
Binding machine
screw
Speaker/ microphone
locking bracket
metI rebmuntraP ytitnauQ
pilctleBXX-1070-92J1
gnikcolenohporcim/rekaepS
tekcarb XX-4648-12J1
pacskcajenohporcim/rekaepSXX-6760-90B1
wercsenihcamgnidniBXX-4003-53N1
launamnoitcurtsnIXX-7471-26B1
TK-2160/3160 E 01-28 03.7.17, 9:25 AM1

2
PREPARATION
BATTERY PACK PRECAUTIONS
◆Do not recharge the battery pack if it is already fully charged.
Doing so may cause the life of the battery pack to shorten or the
battery pack may be damaged.
◆After recharging the battery pack, disconnect it from the charger.
If the charger power is reset (turned ON after being turned OFF),
recharging will start again and the battery pack will become
overcharged.
◆Do not use the transceiver while charging the battery pack. We
recommend you switch the transceiver power OFF while charging
is taking place.
◆Do not short the battery terminals or dispose of the battery by
fire.
◆Never attempt to remove the casing from the battery pack.
Information concerning the (optional) Li-ion battery pack:
The battery pack includes flammable objects such as organic solvent.
Mishandling may cause the battery to rupture producing flames or
extreme heat, deteriorate, or cause other forms of damage to the
battery. Please observe the following prohibitive matters.
•Do not disassemble or reconstruct battery!
The battery pack has a safety function and protection circuit to
avoid danger. If they suffer serious damage, the battery may
generate heat or smoke, rupture, or burst into flame.
•Do not short-circuit the battery!
Do not join the + and – terminals using any form of metal (such as
a paper clip or wire). Do not carry or store the battery pack in
containers holding metal objects (such as wires, chain-necklace or
hairpins). If the battery pack is short-circuited, excessive current
will flow and the battery may generate heat or smoke, rupture, or
burst into flame. It will also cause metal objects to heat up.
DANGER
TK-2160/3160 E 01-28 03.7.17, 9:25 AM2

3
•Do not incinerate or apply heat to the battery!
If the insulator is melted, the gas release vent or safety function is
damaged, or the electrolyte is ignited, the battery may generate
heat or smoke, rupture, or burst into flame.
•Do not use or leave the battery near fires, stoves, or other
heat generators (areas reaching over 80°C/ 176°F)!
If the polymer separator is melted due to high temperature, an
internal short-circuit may occur in the individual cells and the
battery may generate heat or smoke, rupture, or burst into flame.
•Do not immerse the battery in water or get it wet by other
means!
If the battery’s protection circuit is damaged, the battery may
charge at extreme current (or voltage) and an abnormal chemical
reaction may occur. The battery may generate heat or smoke,
rupture, or burst into flame.
•Do not charge the battery near fires or under direct sunlight!
If the battery’s protection circuit is damaged, the battery may
charge at extreme current (or voltage) and an abnormal chemical
reaction may occur. The battery may generate heat or smoke,
rupture, or burst into flame.
•Use only the specified charger and observe charging
requirements!
If the battery is charged in unspecified conditions (under high
temperature over the regulated value, excessive high voltage or
current over regulated value, or with a remodelled charger), it
may overcharge or an abnormal chemical reaction may occur.
The battery may generate heat or smoke, rupture, or burst into
flame.
•Do not pierce the battery with any object, strike it with an
instrument, or step on it!
This may break or deform the battery, causing a short-circuited.
The battery may generate heat or smoke, rupture, or burst into
flame.
•Do not jar or throw the battery!
An impact may cause the battery to leak, generate heat or smoke,
rupture, and/or burst into flame. If the battery’s protection circuit is
damaged, the battery may charge at an abnormal current (or
voltage), and an abnormal chemical reaction may occur. The
battery may generate heat or smoke, rupture, or burst into flame.
TK-2160/3160 E 01-28 03.7.17, 9:25 AM3

4
•Do not use the battery pack if it is damaged in any way!
The battery may generate heat or smoke, rupture, or burst into
flame.
•Do not solder directly onto the battery!
If the insulator is melted or the gas release vent or safety function
is damaged, the battery may generate heat or smoke, rupture, or
burst into flame.
•Do not reverse the battery polarity (and terminals)!
When charging a reversed battery, an abnormal chemical
reaction may occur. In some cases, an unexpected large amount
of current may flow upon discharging. The battery may generate
heat or smoke, rupture, or burst into flame.
•Do not reverse-charge or reverse-connect the battery!
The battery pack has positive and negative poles. If the battery
pack does not smoothly connect with a charger or operating
equipment, do not force it; check the polarity of the battery. If the
battery pack is reverse-connected to the charger, it will be
reverse-charged and an abnormal chemical reaction may occur.
The battery may generate heat or smoke, rupture, or burst into
flame.
•Do not touch a ruptured and leaking battery!
If the electrolyte liquid from the battery gets into your eyes, wash
your eyes out with fresh water as soon as possible, without
rubbing your eyes. Go to the hospital immediately. If left
untreated, it may cause eye-problems.
TK-2160/3160 E 01-28 03.7.17, 9:25 AM4

5
•Do not charge the battery for longer than the specified time!
If the battery pack has not finished charging even after the
regulated time has passed, stop it. The battery may generate
heat or smoke, rupture, or burst into flame.
•Do not place the battery pack into a microwave or high
pressure container!
The battery may generate heat or smoke, rupture, or burst into
flame.
•Keep ruptured and leaking battery packs away from fire!
If the battery pack is leaking (or the battery emits a bad odor),
immediately remove it from flammable areas. Electrolyte leaking
from battery can easily catch on fire and may cause the battery to
generate smoke or burst into flame.
•Do not use an abnormal battery!
If the battery pack emits a bad odor, appears to have different
coloring, is deformed, or seems abnormal for any other reason,
remove it from the charger or operating equipment and do not
use it. The battery may generate heat or smoke, rupture, or burst
into flame.
■Using the Li-ion Battery Pack
•Charge the battery pack before using it.
•To keep the battery discharge at a minimum,
remove the battery pack from the equipment
when it is not in use. Store the battery pack in a
cool and dry location.
•When storing the battery pack for a long period:
1Remove the battery pack from the equipment.
2Discharge the battery pack, if possible.
3Store the battery pack in a cool (below 25°C/ 77°F) and
dry location.
TK-2160/3160 E 01-28 03.7.17, 9:25 AM5

6
■Characteristics of the Li-ion Battery Pack
•As the battery pack is charged and discharged
repeatedly, the battery capacity decreases.
•Even if the battery pack is unused, the battery
pack degrades.
•It takes a longer time to charge the battery pack
in cooler areas.
•The life of battery pack is shortened when it is
charged and discharged in hotter areas. When
the battery pack is stored in a hot location, the
battery pack degrades quicker. Do not leave the
battery pack in vehicles or near heating
appliances.
•When the battery pack operating time becomes
short, even if it is fully charged, replace the
battery pack. Continuing to charge and discharge
the battery pack may result in electrolyte leakage.
■Charging the Li-ion Battery Pack
When charging a transceiver with a KNB-24L battery
pack, the safety catch of the battery pack may stick
out past the battery. When inserting the transceiver
with the battery pack into the charger, the safety
catch will touch the metal contacts of the charger
and the charger LED will momentarily light red. Be
sure to push the transceiver fully into the battery
pack slot so the safety catch no longer touches the
charger terminals. Once in place, the battery pack
will begin charging.
For charging procedures, refer to the KSC-25
Instruction Manual.
TK-2160/3160 E 01-28 03.7.17, 9:25 AM6

7
INSTALLING/ REMOVING THE (OPTIONAL) RECHARGEABLE BATTERY
PACK OR ALKALINE BATTERY CASE
1Match the guides of the
battery pack with the
corresponding grooves on
the upper rear of the
transceiver, then firmly
press the battery pack to
lock it in place.
2Flip the safety catch into
place to prevent
accidentally pressing the
release latch and
removing the battery.
3To remove the battery
pack, lift the safety catch,
press the release latch,
then pull the battery pack
away from the transceiver.
Note:
◆To lift the battery pack safety catch, use a piece of hardened
plastic or metal, such as a screwdriver, that is no more than
6 mm wide and 1 mm thick. It is imperative that you place the
implement under only the lip of the safety catch so that you do
not damage the release latch.
◆Before charging a battery pack that is attached to the transceiver,
ensure that the safety catch is firmly closed.
◆While operating the transceiver using a Li-ion or Ni-MH battery
pack in areas with an ambient temperature of –10°C/ +14°F and
lower, operating time may be shortened.
TK-2160/3160 E 01-28 03.7.17, 9:25 AM7

8
INSTALLING/ REMOVING ALKALINE BATTERIES
◆Do not install batteries in a hazardous environment where sparks
could cause an explosion.
◆Never discard old batteries in fire; extremely high temperatures
can cause batteries to explode.
◆Do not short circuit the battery case terminals.
◆Do not use commercially available rechargeable batteries.
Note:
◆If you do not plan to use the transceiver for a long period, remove
the batteries from the battery case.
◆This battery case has been designed for transmitting at a power
of approximately 1 W (the low power setting on your transceiver).
If you want to transmit a stronger signal (using the high power
setting on your transceiver), use an optional rechargeable battery
pack.
1To open the battery case,
press on the two tabs on the
upper rear of the case then
pull the two halves apart.
2Insert 6 AA (LR 6) alkaline
batteries into the battery
case.
•Be sure to match the polarities
with those marked in the bottom
of the battery case.
3Align the tabs of the cover
with the base, then push
down on the cover until it
locks in place.
TK-2160/3160 E 01-28 03.7.17, 9:25 AM8

9
Screw the antenna into the
connector on the top of the
transceiver by holding the
antenna at its base and turning
it clockwise until secure.
INSTALLING THE (OPTIONAL) ANTENNA
INSTALLING THE BELT CLIP
Note: When first installing the belt clip, you must remove the battery
pack from the rear of the transceiver.
1Remove the two screws
from the rear of the
transceiver, then remove the
small, plastic black covering
that was held in place.
2Insert the belt clip mount
into the space on the rear of
the transceiver.
3Using the 2 screws, affix the
belt clip in place.
Note: Do not dispose of the plastic
black covering! If you remove the
belt clip, replace the covering into the
space on the rear of the transceiver.
Either this covering or the belt clip
must be in place, otherwise the
battery pack may not remain installed
properly.
TK-2160/3160 E 01-28 03.7.17, 9:25 AM9

10
If you are not using a speaker/
microphone, install the cover
over the speaker/ microphone
jacks using the supplied screw.
Note:
◆To lift the cover after it has been
installed, use a piece of
hardened plastic or metal, such
as a small screwdriver. Lift the
cover by its tab, beside the
screwhole, taking care not to
damage the cover.
◆To keep the transceiver water
resistant, you must cover the
speaker/ microphone jacks with
the supplied cover.
INSTALLING THE COVER OVER THE SPEAKER/ MICROPHONE JACKS
Note: When installing the speaker/ microphone jack cover, you must
remove the battery pack from the rear of the transceiver.
INSTALLING THE (OPTIONAL) SPEAKER/ MICROPHONE
Note: When installing the speaker/ microphone locking bracket, you
must remove the battery pack from the rear of the transceiver.
1Insert the speaker/
microphone plugs into the
speaker/ microphone jacks.
2Attach the locking bracket
using the supplied screw.
Note: To lift the locking bracket after
it has been installed, use a piece of
hardened plastic or metal, such as a
small screwdriver. Lift the bracket by
its tab, beside the screwhole, taking
care not to damage the bracket.
TK-2160/3160 E 01-28 03.7.17, 9:25 AM10

11
GETTING ACQUAINTED
Antenna
The transceiver is shown with the optional KNB-24L battery pack.
qq
qq
qLED indicator
Lights red while transmitting. Lights green while receiving.
Flashes orange while receiving a 2-Tone, DTMF, or
FleetSync signal that matches the one set up in your
transceiver. If programmed by your dealer, flashes red
when the battery power is low while transmitting.
ww
ww
wChannel Switch
Rotate to select a channel from 1 to 16.
ee
ee
ePower switch/ Volume control
Turn clockwise to switch ON the transceiver. Rotate to
adjust the volume. To switch OFF the transceiver, turn
counterclockwise fully.
Microphone Speaker
4
1 2 3
58
6
7
TK-2160/3160 E 01-28 03.7.17, 9:25 AM11

12
rr
rr
rAUX key
This is a PF (Programmable Function) key. Press it to
activate its auxiliary function (below). The default setting
for this key is None.
tt
tt
tPTT (Push-to-Talk) switch
Press this switch, then speak into the microphone to call a
station.
yy
yy
ySide 1 key
This is a PF (Programmable Function) key. Press it to
activate its auxiliary function (below). The default setting
for this key is None.
uu
uu
uSide 2 key
This is a PF (Programmable Function) key. Press it to
activate its auxiliary function (below). The default setting
for this key is Squelch Off Momentary.
ii
ii
iSP/MIC jacks
Connect an optional speaker/ microphone here.
PROGRAMMABLE AUXILIARY FUNCTIONS
The AUX, Side 1, and Side 2 keys can be programmed with
the auxiliary functions listed below:
•2-Tone Encode
•Emergency1
•Monitor Momentary
•Monitor Toggle
•None
•RF Power Low
•Scan
•Scan Temporary Delete
•Scrambler
•Squelch Off Momentary
•Squelch Off Toggle
1This function can be programmed only on the AUX key.
TK-2160/3160 E 01-28 03.7.17, 9:25 AM12

13
OPERATING BASICS
SWITCHING POWER ON/ OFF
Turn the Power switch/ Volume control clockwise to switch the
transceiver ON.
Turn the Power switch/ Volume control counterclockwise to
switch the transceiver OFF.
ADJUSTING THE VOLUME
Rotate the Power switch/ Volume control to adjust the volume.
Clockwise increases the volume and counterclockwise
decreases it.
•You may need to adjust the volume more precisely while
communicating with other parties.
Note: If your dealer programmed Squelch Off Momentary or
Squelch Off Toggle onto a PF key, you can press that key to hear
background noise while adjusting the volume level (refer to “MONITOR/
SQUELCH OFF” on page 26).
SELECTING ACHANNEL
Rotate the Channel switch to choose your desired channel
from 1 to 16. Clockwise increases the number and
counterclockwise decreases it.
•If a channel has not been programmed, it cannot be used. When
a non-programmed channel is selected, the LED indicator flashes
red and orange and an alert tone sounds.
TK-2160/3160 E 01-28 03.7.17, 9:25 AM13

14
MAKING ACALL
1Make sure no parties are currently transmitting on your
selected channel.
2Press the PTT switch and speak into the microphone in
your normal speaking voice.
•For best sound quality at the receiving station, hold the
microphone approximately 1.5 inches (3 ~ 4 cm) from your
mouth.
3Release the PTT switch to receive.
RECEIVING ACALL
Your dealer may have programmed QT, DQT, 2-Tone, DTMF,
or FleetSync signalling on your transceiver. If your selected
channel is programmed with one of these features, you will
hear calls only when another party in your system makes a
call. All other calls will not be heard.
If your selected channel is not set up with a signalling type,
you will hear calls made by any party (not just those in your
system).
TK-2160/3160 E 01-28 03.7.17, 9:25 AM14
