Kenwood TK-5210 User manual

VHF APCO P25 TRANSCEIVER
TK-5210
©2004-11 PRINTED IN JAPAN
B51-8703-00 (S) 658
SERVICEMANUAL
GENERAL ............................................................... 2
SYSTEM SET-UP ................................................... 2
REALIGNMENT ...................................................... 3
DISASSEMBLY FOR REPAIR ................................ 8
CIRCUIT DESCRIPTION ....................................... 13
TERMINAL FUNCTION ........................................ 19
SEMICONDUCTOR DATA ................................... 23
COMPONENTS DESCRIPTION ........................... 25
PARTS LIST .......................................................... 27
EXPLODED VIEW................................................. 37
PACKING .............................................................. 39
Does not come with antenna. Antenna is available as an option.
ADJUSTMENT ..................................................... 40
PC BOARD
TX-RX UNIT (X57-6820-XX) ........................... 54
SCHEMATIC DIAGRAM ....................................... 62
INTERCONNECTION DIAGRAM ......................... 74
BLOCK DIAGRAM ................................................ 75
LEVEL DIAGRAM ................................................. 78
OPTIONAL ACCESSORIES
KNB-31A/32N/33L .......................................... 79
KSC-32 ............................................................. 79
SPECIFICATIONS .............................. BACK COVER
Helical Antenna
(KRA-22: Option)
Main cabinet
(A02-3875-01)
Knob (16CH)
(K29-9323-03)
Knob (Volume)
(K29-9322-03)
TK-5210 K TK-5210 K2 TK-5210 K3
CONTENTS
Knob (PTT)
(K29-9328-02)
Key top
(EMG)
(K29-9319-03)
Main cabinet
(4key)
(A02-3877-01)
Knob (16CH)
(K29-9323-03)
Knob (Volume)
(K29-9322-03)
Knob (PTT)
(K29-9328-02)
Key top
(EMG)
(K29-9319-03)
Main cabinet
(DTMF)
(A02-3879-01)
Knob (16CH)
(K29-9323-03)
Knob (Volume)
(K29-9322-03)
Knob (PTT)
(K29-9328-02)
Key top
(EMG)
(K29-9319-03)
Helical Antenna
(KRA-22: Option)
Helical Antenna
(KRA-22: Option)
Key top
(DTMF)
(K29-9321-13)
Key top
(4key)
(K29-9320-03)
fineline6

58
JIHGFEDCBA
1
2
3
4
5
6
7
8
9
10
11
12
13
14
CN603
1 6
INT MIC– INT MIC+ INT SP+ INT SP+ INT SP– INT SP–
R719
R721
R723
R756
S1
A
S2
B
S3
C
S4
D
S5
3
S6
2
S7
1
D705
D706
D709 D713
D723
S901
S902
D901
J72-0926-19 B/5
J72-0926-19 C/5
TK-5210 PC BOARD
TX-RX UNIT (X57-6820-XX) (B/5) : Control section
-10 : K -11 : K2 -12 : K3 Component side view (J72-0926-19 B/5)
TX-RX UNIT (X57-6820-XX) (C/5) : Top section
-10 : K -11 : K2 -12 : K3 Component side view (J72-0926-19 C/5)
Ref. No. Address
D901 13B
fineline6

K-5210 SPECIFICATIONS
KENWOOD CORPORATION
2967-3, Ishikawa-machi, Hachioji-shi, Tokyo 192-8525, Japan
KENWOOD U.S.A. CORPORATION
P.O. BOX 22745, 2201 East Dominguez Street, Long Beach, CA 90801-5745,
U.S.A.
KENWOOD ELECTRONICS CANADA INC.
6070 Kestrel Road, Mississauga, Ontario, Canada L5T 1S8
KENWOOD ELECTRONICS DEUTSCHLAND GMBH
Rembrücker Str. 15, 63150 Heusenstamm, Germany
KENWOOD ELECTRONICS BELGIUM N.V.
Leuvensesteenweg 248 J, 1800 Vilvoorde, Belgium
KENWOOD ELECTRONICS FRANCE S.A.
13, Boulevard Ney, 75018 Paris, France
KENWOOD ELECTRONICS U.K. LIMITED
KENWOOD House, Dwight Road, Watford, Herts., WD18 9EB, United Kingdom
KENWOOD ELECTRONICS EUROPE B.V.
Amsterdamseweg 37, 1422 AC Uithoorn, The Netherlands
KENWOOD ELECTRONICS ITALIA S.p.A.
Via G. Sirtori, 7/9 20129 Milano, Italy
KENWOOD IBERICA S.A.
Bolivia, 239-08020 Barcelona, Spain
KENWOOD ELECTRONICS AUSTRALIA PTY. LTD.
(A.C.N. 001 499 074)
16 Giffnock Avenue, Centrecourt Estate, North Ryde, N.S.W. 2113, Australia
KENWOOD ELECTRONICS (HONG KONG) LTD.
Unit 3712-3724, Level 37, Tower one Metroplaza, 223 Hing Fong Road,
Kwai Fong, N.T., Hong Kong
KENWOOD ELECTRONICS SINGAPORE PTE LTD.
1 Ang Mo Kio Street 63, Singapore 569110
GENERAL
Models ............................................................................. K : Basic Model K2 : 4-Key w/LCD Model K3 : Full Key w/LCD Model
Frequency Range ............................................................. 136~174 MHz
Number of Channels ........................................................ 512
Zones ............................................................................... 50
Max. Channels per Zone ................................................. 250
Channel Spacing .............................................................. Analog : 12.5/15/20/25/30 kHz Digital : 12.5 kHz
Operating Voltage ............................................................ 7.5V DC ± 20%
Battery Life (5-5-90 duty cycle) ....................................... KNB-31A, 7.5VDC, 1700 mAh : 8 hours
KNB-32N, 7.5VDC, 2500 mAh : 12 hours
KNB-33L, 7.5VDC, 1700 mAh : 8 hours
Operating Temperature Range ........................................ –22°F to +140°F (–30°C to +60°C)
Frequency Stability (–22°F to +140°F) ............................ ±2.0 ppm
Antenna Impedance ........................................................ 50Ω
Dimensions (W x H x D) ..................................................
2-5/16 x 6-3/32 x 1-13/16 in. (58 x 155 x 45.7 mm) with KNB-31A or KNB-32N battery
(Projections not included) 2-5/16 x 6-3/32 x 1-9/16 in. (58 x 155 x 39.2 mm) with KNB-33L battery
Weight
Radio only ................................................................... TK-5210 K : 11.11 oz. (315g)
TK-5210 K2 : 11.64 oz. (330g)
TK-5210 K3 : 11.64 oz. (330g)
TK-5210 K2 with battery, ............................................ 22.22 oz. (630g) with KNB-31A battery
antenna(KRA-22) and belt clip(KBH-11) 23.28 oz. (660g) with KNB-32N battery
17.64 oz. (500g) with KNB-33L battery
RECEIVER
Sensitivity ........................................................................ Digital (5% BER) : 0.25µV Digital(1% BER) : 0.40µV
Analog 12dB SINAD : 0.25µV
Selectivity ........................................................................ Digital : -60dB Analog @25/30kHz : -78dB Analog @12.5kHz : -67dB
Intermodulation Distortion ............................................... Digital : -75dB Analog @25/30kHz : -75dB Analog @12.5kHz : -68dB
Spurious and Image ......................................................... Digital : -80dB Analog :- 80dB
Audio Distortion ............................................................... Digital : Less than 1.5% Analog : Less than 2%
Audio Output ................................................................... 500mW/ 8Ω
TRANSMITTER
RF Output Power ............................................................. 5W / 1W
Spurious and Harmonics.................................................. 70dB
FM Hum and Noise ......................................................... Analog @25kHz : 50dB Analog @12.5kHz : 45dB
Audio Distortion ............................................................... Less than 2%
Modulation ....................................................................... 16K0F3E, 11K0F3E, 8K10F1E, 8K10F1D
Analog measurements made per TIA/EIA-603
Digital measurements made per TIA/EIA-102CAAA
KENWOOD reserves the right to change specifications without prior notice or obligation.
