Kenwood TS-711A User manual

KENWOOD
=TS-/T1A/E
144
MHz
ALL
MODE
TRANSCEIVER
INSTRUCTION MANUAL
Illustrated is the TS-711A version.
Thank
you
for
purchasing
of
our
latest
product,
the
TS-711A/E
transceiver.
Please
read
this
instruction
manual
carefully
before
placing
your
transceiver
in
service.
The
unit
has
been
carefully
engineered
and
manufactured
to
rigid
quality
standards,
and
should
provide
you
satisfactory
and
dependable
operation
for
many
years.
CONTENTS
ACCESSORIES (SUPPLIED)............:.ssssssssssssssesessesesesees 2
FEATURES
SPECIFICATIONS..
CONTROLS, CONNECTORS AND INDICATORS..
OPERATION
AUTO MODE SETTING... cscslssecseseeeesesestescsseeeseavees 11
DIAL FREQUENCY...
INITIAL FREQUENCY SETTING
CONFIRMATION BY MEANS OF BEEP SOUND
FM OPERATION...
SSB OPERATION..
CW OPERATION
SATELLITE COMMUNICATIONS .
FUNCTION CONTROLS AND SWITCHES.
DIGITAL FUNCTION.
ALERT OPERATION..
DCS SYSTEM FEATURES...
FIXED STATION OPERATION ...
MOBILE INSTALLATION [GENERAL]..
MAINTENANCE AND ADJUSTMENT.
TROUBLESHOOTING
ACCESSORIES (OPTION)
CIRCUIT DESCRIPTION
BLOCK DIAGRAM.....
PLL UNIT SCHEMATIC DIAGRAM

AFTER UNPACKING
@ Shipping container:
Save the boxes and packing in the event your unit
needs to be transported for remote operation, mainte-
nance, or service.
@ The following explicit definitions apply in this manual:
Note: If disregarded, inconvenience only, no risk
of equipment damage or personal injury.
Caution: Equipment damage may occur, but not per-
sonal injury.
ACCESSORIES (SUPPLIED)
c
it
Ie
2
3
4.
5
arefully
unpack
your
TS-711A/TS-711E
and
check
that
is
supplied
with
the
following
accessories:
Standby
plug
(E12-0401-15)...
23)
LPG;
-
13
pin
DIN
plug
(E07-1351-05)..
-
1
pe.
.
Wire
harness
kit
(E3
1-3064-00)
(for
VS-1)
-
pe.
Instruction
manual
(B50-4148-30).
a
T.pe:
.
AC
cord
(E30-1643-15)..
.
1pe.
(Europe)
(E30-1645-05)..
1
pe.
(Oseania)
(E30-1647-05)..
.
1
pe.
.
Spare
fuse
(3A)
(FO5-3022-05)
.......ccccccceeceeeeees
1
pe.
Note:
Units
shipped
to
USA,
Europe
and
Oseania
are
not
equipped
with
this
fuse.
.
Warranty
card
.
Microphone
(T91-0331-05)
.
*
For
the
TS-711E
only
FEATURES
. DCS = Digital Code Squelch
DCS uses digital code information to open squelch on
a receiver that has been programmed to accept the
specific code being transmitted. The system recog-
nizes 100,000 different 5 digit code signals, making it
possible for each station to have its own “private call”
code, as well as to have “group call” or “common call’
code. DCS is also effective in suppressing unwanted
signals.
.
COMPACT
DESIGN
144
MHz
ALL
MODE
TRANS-
CEIVER
capable
of
AC
or
DC
operation.
. HIGH STABILITY
Dual
10
Hz
step
digital
VFO
design,
incorporating
a
single
Temperature
Compensated
Crystal
Oscillator
for the ultimate in stability.
. HIGHLY VISIBLE FLUORESCENT TUBE DISPLAY.
. 40 CHANNEL MEMORY
Frequency,
mode,
dial
data,
TX
offset
and
sub-tone
data can be memorized.
. AUTO MODE SELECTION
Automatically selects the proper mode for the band
segment selected.
. MANUAL MODE SELECTION
Simple pushbutton switching. The first letter of each
mode is announced in Morse Code thru the built in
speaker.
. MULTIFUNCTION MAIN TUNING DIAL
Easily selected continuous tuning or channelized,
click-stop, type tuning is controlled by the CH.Q
switch. When in Mch mode, the main dial automati-
cally selects click type tuning.
1
1
1
1
9. RIT CONTROL
+/— 9.99 kHz in 10 Hz steps is possible.
0.
MICROPORCESSOR
CONTROLLED
FUNCTIONS
SCAN:
Programmable
band
scan,
memory
scan.
AL: Priority Alert (M CH 1)
M>V Memory to VFO
SPLIT:
Split
Frequency
Operation
(RXA-TXB
or
RXB-TXA)
A=B: For equalizing VFOA and B
CH.
S
In
VFO
mode,
allows
main
dial
to
select
memory
channel.
In
memory
scan
mode,
specifies
channels
to
be
skipped.
REV
&
LOCK:
Locks
dial
mode;
reverses
split
memory
channels.
1, MANUAL FUNCTIONS
@ All mode squelch
@ All mode RF Power control
@ IF shift
@
Speech
processor:
AF
speech
processor
for
SSB
and
FM
@
RF
ATTN:
Provides
approximately
20
dB
of
atten-
uation
@ CW Semi break-in: with adjustable delay
2. SELECTED OPTIONS
Voice Synthesizer
TU-5
(TS-711A)..
.
Sub
Audible
Tone
Encoder
3. PERSONAL COMPUTER INTERFACE
Use
of
the
optional
interface
will
allow
simple
“basic”
language
programming
of
major
functions.

SPECIFICATIONS
[General]
Freaquencyirange.: io.cd0. 2..c.scisscsiesssssRvexeasioscessss 144.0 ~ 148.0 Mbz..... (TS-711A)
144.0 ~ 146.0 Mbz..... (TS-711E)
. A3J (SSB), F2, F3 (FM), A1 (CW)
50 ohms
-10°C ~ +50°C
. AC120V/240V/220V, 50/60 Hz
DC 13.8V(12V ~ 16V)
. Negative
. 170W, 6.5A (DC13.8V) at maximum transmission
50W, 1.2A (DC13.8V) in receive mode without receiving signal
. Within + 3 ppM (SSB/CW)
Within + 5 ppM (FM)
Radio wave mode....
Antenna impedance
Operating temperature.
Power voltage
Grounding ...
Power consumption
Frequency tolerance (—10°C ~ +50°C)...
Frequency stability + 300 Hz 1 ~ 60 minutes after power on
Within 50 Hz/every 30 minutes 60 minutes later (after power on)
DiMONSIONS .. 3. css. icisesineswsscvsiecszeesaicesasescccvsienenees W270 x H96 x D260 mm
(W279 x H108 x D327 mm) - Projected parts measured.
Weight............ccouaat anahiin a JLacd. ag 7.1 kg (15.62 Ib)
[Transmitter]
RFioutput power. 0k AI Leathe 25 watts (One minute transmission/three minutes reception)
RF output variable from approx. 2W to maximum
Balanced (SSB), Reactance (FM)
Less than -60 dB
Less than —-40 dB
Less than -40 dB
Modulation..
Spurious radiation
Carrier surpression..
Side band surpression...
Maximum frequency deviation (FM).. +5 kHz
Modulation distortion (FM60%) Less than 3% (300 Hz ~ 3 kHz)
MIC impedance... 500 ~ 600 2
[Receiver]
Circuitry.
Intermediate frequency ...
.. Double superheterodyne
. Ist 30.265 MHz
2nd = 10.695 MHz (SSB/CW), 455 kHz (FM)
Receiver sensitivity FM .............cccceeceeeeeee 12 dB SINAD less than 0.22 wvV..... (TS-711A)
12 dB SINAD less than 0.2 wvV..... (TS-711E)
S+N/N more than 50 dB at 1.0 mV input
SSB/ CW i esscsscssiecerpsysionnsee S+N/N 10 cB less than 0.16 wV..... (TS-711A)
S+N/N 10 GB less than 0.13 wV..... (TS-711E)
More than 12 kHz (—6 dB)
Less than 24 kHz (-60 dB)
SSB/CW i cisisctes gat More than 2.2 kHz (-6 dB)
Less than 4.8 kHz (—60 dB)
Better than 70 dB
.. Less than 0.16 uV (threshold)
.. Less than 0.2 yV (threshold)
. More than 2.0 watts across 8 ohms load (5% dist.)
. 8 ohms
Receiver selectivity FM..
Spurious response..
Squelch sensitivity.
Auto scan stop level
Audio output power ..
Audio output impedance .
[DCS control]
.. NRZ equal-length code
. MSK modulation
. +2.5 kHz or more
+5 kHz or less
+3.5 kHz Standard
Mark frequency and deviation. .................0000. 1200 Hz + 200PPM
Space frequency and deviation .. 1800 Hz +200 PPM
Code transmission speed and deviation .. . 1200 bits/second +200 PPM
Modulation.
Frequency deviation..
Note: Circuit and ratings are subject to change without notice due to developments in technology.

CONTROLS,
CONNECTORS
AND
INDICATORS
Front Panel (Illustrated is the TS-711A)
@ POWER switch
Turns the transceiver ON and OFF.
® S meter
In receive mode, works as an S (signal) meter. In transmit
mode, indicates RF or ALC corresponding to the ALC/RF
switch setting.
In SSB/CW mode, indicates S-9 with 50 uV input. Gra-
duations of 9 + 20 dB, 9 + 40 dB and 9 + 60 GB are also in-
cluded.
POWER
=
as
ge
9,
2,
29,80
©
@®
Frequency
and
subfunction
display
Se
*
a)
Indicates
transmit
and
receive
frequency,
digital
code,
ose
Gr
oes
CALL
sign
(ASCII)
and
subtone
frequency.
b) Indicates memory CH number, digital code CH number
and subtone CH number (Not for TS-711E).
c)
Indicates
RIT
frequency
shift
(-9.9
~
9.9
kHz)
and
transmit
digital
code
CH
number.
d) Normally indicates MHz and kHz. When flashing, indi-
cates scan is in operation.
e) Lights when in memory CH mode.
f) Lights when VFO A or VFO Bis selected.
g) Lights when tone is operated.
h) Lights when VFOs are operated alternately or SPLIT
memory CH is operated.
i) Lights (-) when TX OFFSET shifts -600 kHz.
Lights (+) when TX OFFSET shifts +600 kHz.
j) Lights when Alert operation is set.
k) Lights when the RIT switch is set to ON.
@® CH.Q switch (Channel QSO abbreviated)
When in the VFO mode this switch selects either “channe-
lized” (click type) or continuously variable tuning on the
Main Dial. When in the M (memory) mode channelized
tuning is always selected.
VFO step
Main dial
CH.O SoBe rotation
FUNCTION
b>] =5)
CH.O ON 5 kHz Click
CH.O OFF 10 Hz Through
* For units designed for use in European countries.

@® MIC—@— RF PWR controle
@ Mic: In SSB mode, adjusts mic gain. Adjust for
an on scale reading on voice peaks.
@ RFPWR: Controls RF power continuously. Full clock-
wise rotation provides rated output. Coun-
terclockwise rotation reduces RF power to
approx. 2W.
MIC -D-RF PWR SQL —-IF SHIFT ©) soL—@)— IF.SHIFT controls
4 6
ia SY @ SQL: All mode squelch control. Normally, set this
= 10 . control to the position where the back-
i
ground noise is eliminated and the BUSY in-
dicator goes off.
@ IF SHIFT: In SSB/CW receive mode, used to eliminate
interference caused by adjacent channels
and control the received audio quality. Nor-
mally, leave this control at the center, click,
position.
@ RIT/CLEAR switches (built-in indicators)
@ RIT: Used to turn the RIT circuit ON and OFF.
Setting to ON lights RIT on the display.
@ CLEAR: Used to zero the RIT.
RIT control
Shifts only receive frequency, in 10 Hz steps, within the
range + 9.99 kHz. With the RIT switch ON, the display in-
dicates the amount of RIT shift and also changes the main
frequency display. With the RIT switch OFF, used for RIT
preset. The RIT circuit is active in any mode; even in COM
CH mode, and in locked-dial mode.
@ AF —®—RFF controls
@ AF: Used to control audio output level while re-
ceiving. Clockwise rotation increases
sound output. Adjust the control to the de-
sired level.
@ FF: Used to adjust RF gain. Maximum gain is
obtained with full clockwise rotation. As
the control is rotates counterclockwise, the
RF gain decreases. In normal operation, set
full clockwise. Note the RF control works
only in SSB/CW modes.

VOICE switch
Activates the optional voice synthesizer (VS-1).
@ NB switch (Noise Blanker)
Used when mobile ignition noise or pulse noise is present.
Works in SSB/CW mode.
@ DOWN/UP switches
Shifts
the
frequency
up
or
down
in
1
MHz
steps.
Holding
the
switch
depressed
shifts
the
frequency
downward
or
upward
rapidly.
@® COM switch
145.000 (FM mode) is preset for COM channel. To recall
the COM channel simply press “COM”. The data can be
changed. (See “Memory Entry”)
VFO/M switch
Used
to
switch
between
VFO
and
memory
channel.
In
the
VFO
mode
setting,
either
VFO
A
or
VFO
B
will
be
dis-
played.
When
set
to
M,
the
VFO
indicator
goes
off
and
the
M.CH
indicator
lights.
Selecting
M.CH
allows
memory
channel
recall
operation
and
automatically
sets
the
main
dial
to
click
type
rotation.
@ FUNCTION switches
@
[A/B]
Switches
VFO
A
and
VFO
B
alternately.
When
selecting
COM
channel
or
M.CH
channel
oper-
ation,
this
switch
memorizes
the
current
fre-
quency
VFO
for
future
recall.
This
is
useful
for
memorizing
SPLIT
frequencies.
e
Switches
the
frequency
step.
When
used
in
conjunction
with
the
CH.Q
switch,
this
switch
sets
the
following
step
sizes:
SSB/CW
ON OFF ON
5 kHz
"12.5 kHe| 10H
5 kHz] 100 Hz
*
For
units
designed
for
use
in
European
countries.
@
[SPLIT]
Allows
split
frequency
operation.
The
VFO
dis-
played
in
Rx
is
the
receive
VFO.
For
example:
146.000
is
in
VFO
A.
146.750
is
in
VFO
B.
VFO
A
is displayed
in
RX.
The
RX
frequency
is
therefore:
146.000
and
the
TX
frequency
is
146.750.
(A-Rx
and
B-Tx).
If
B
was
the
active
VFO
B-Rx
and
A-Tx.

~~ FUNCTION
=
Fe]
@ [A=B)] Used to equalize all data (frequency, mode, RIT
setting, OFFSET, AL, T and SPLIT).
@ |MPV! Switches all data from memory channel to VFO.
Also, switches from COM channel to VFO.
Main dial control
@ In VFO mode: Used to set frequency.
@ In M.CH mode: Used to select memory channel from
01 through 40 by click type rotation.
@ In CS mode: Used to select digital code channel from
CO through C9 by click type rotation.
@ In TONE SEL mode: Used to select subtone frequency
01 (67 Hz) through 37 (250.3 Hz) by click
type rotation.
* For the TS-711A only
@ When the main dial is in continuous tune mode, rapidly
rotating the dial will automatically select
the increased step size.
@ MODE/keys (1 ~ 0)
FM, USB, CW, LSB: Used to select the desired mode.
When pressed, initial letter of mode is an-
nounced by morse code thru the speaker.
@ [AUTO] Used to switch mode automatically in con-
junction with the frequency range selected.
The mode change is announced by single
beep.
) Used to activate and stop scan. To stop
scan, any of the ten keys can be used. Be-
fore initiating scan, the SQL control must be
set to the threshold point. The scan will
stop at a busy station (busy-scan). The
scan is time-operated (T/O scan), so that
the scan resumes after an 6 seconds delay
at the busy station. In the FM mode, the
scan stops at the center frequency. (center
stop function)
e (MIN) Used to store data in memory channel.
Storable data are: Frequency; mode; dial
click; offset; and tone frequency (TS-711A
only). (See page 14.)
@ |REV & LOCK) Used to lock frequency out of dial and
keyboard operation. However, the RIT cir-
cuit can be operated. Pressing the REV &
LOCK switch lights the REV & LOCK indica-
tor.
Memory channels 36, 37 and 38 are for
ODD SPLIT memory channels. When the
REV & LOCK switch is depressed in these
memory channels the Tx and Rx frequen-
cies will be reversed.

|
CS 0.SQ C.AL
AAG
Digitol
Code
Squel¢h
ocs
e [AL] Used to activate alert circuit to monitor me-
mory channel 1 (M.CH 1). Turning the
switch ON lights the AL indicator. Press
the switch again to turn the alert circuit
OFF.
e (CHS) (Channel Select abbreviated)
Allows selection of the desired memory
channel while in the VFO mode. Storing
memory data (pressing M.IN will release the
CH.S function. In M.CH operation selects
the memory channels to be locked out dur-
ing memory scan. Pressing CH.S will cause
a decimal point to appear to the RIGHT of
the CH ¥ indicator, as a visual indication of
LOCK OUT.
In AL operation — Setting the CH.S to ON,
the memory channel reverts to that of M.CH
Us
@ [1}-[0] Turning ON the CS switch sets the keys to
function as (1 - 0).
DCS (Digital Code Squelch)
Note: The DCS functions only in FM mode.
@ DCS switch: Used to activate the DCS system. The
DCS indicator lights when the switch is ON.
@ D.SO switch: Used to select digital code squelch ON/
OFF status, or watch/nonwatch status of
digital code channel.
@® CS switch OFF - The DCS indicator lights to show
the DCS watch mode. When the proper DCS signal
is received, the squelch opens and the D.SQ indica-
tor goes off.
@® CS switch ON - Used to select the digital code chan-
nel watch status (dot on bottom right).
@ CAL: Turns the code alert ON and OFF. With this
switch set to ON, the indicator lights.
@ ON - When the digital code squelch is opened, a tri-
ple beep will sound continuously, until reset.
@ OFF - When the digital code squelch is opened, tri-
ple beep will sound one time.
@CS
switch
ON
-
When
C-
is
displayed,
the
1st
3
characters
of
the
call
sign
are
entered.
When
C=
is
displayed,
the
last
3
letters
of
the
call
sign
are
en-
tered.
Call sign example: WD6DJY
C-: WD6, C=: DJY
@ CS switch: Code switch. Used when setting digital
codes, switching digital code channels, or
entering a call sign. When the CS switch is
ON, digital codes are entered using the 1 -
0 keys. Digital codes CO - C9 may be se-
lected by the main dial with the CS switch
ON.

TONE SELECT OFFSET
|
wove.
Ta-7110~
f-—_t-
—@)
144MHz TRANSCEIVER
KENWOOD
PROC ALC ATT
oA AES
OFF RF OFF
PHONES
CAUTION:
Do not apply external vol-
tage to these terminals, or
Note: damage will result.
Do not short or apply ex-
ternal voltage to pin 5.
@vup
+8V ©
(less
than
10
mA)
@®
DOWN
NC
®
@STBY
(PTT)
Ground
MIC
@
@
mic
Ground (STBY)
MIC connector
< Front panel view >
PHONE jack
The headphone jack allows use of a 8 to 16 ohm head-
phone through a 1/4” phone plug.
When phones are used the speaker is disconnected.
@ 8-pin MIC connector
Impedance
is
500
-
600
ohms.
The
connector
consists
of
frequency
up/down
shift
input
terminal,
terminal
for
the
PTT,
and
8
V
terminal.
When using a microphone other than the one specified,
connect
the
ground
of
the
microphone
unit
to
pin
@
and
the ground of the standby circuit to pin ®.
A
microphone
which
has
a
common
ground
for
micro-
phone
unit
and
standby
circuit
cannot
be
used.
@ ATT attenuator switch
By
pressing
this
switch
approx.
20
dB
of
attenuation
is
inserted
into
the
antenna
circuit
of
the
receiver
to
reduce
interference
caused
by
other
services.
@ ALC/RF switch
Used
to
select
RF
meter
or
ALC
meter.
Pressing
this
switch
selects
ALC
meter.
@ PROC switch
Used
to
increase
average
modulation
ratio
in
FM
mode
and
to
increase
talk
power
in
SSB
mode.
@ RPT switch
@ TONE: Activates tone circuit.
lights.
@ TONE: (For British version)
When this switch is pressed, the repeater
control tone burst signal (1,750 Hz) is emit-
ted
for
about
1
seconds
at
the
beginning
of
each transmission.
@ TONE: (For European version)
When
this
switch
is
pressed,
the
repeater
control tone signal (1,750 Hz) circuit is
activated
and
the
unit
is
set
in
the
transmit
mode.
Indicates subtone frequency on the display.
Any
one
of
37
CH’s
(67
Hz
-
250.3
Hz)
can
be selected by the main dial. By pressing
the
switch
again,
the
display
returns
to
fre-
quency mode.
Used as a tone encoder when the optional
TU-5 is installed.
The T indicator
@ *SELECT:
*SELECT is not applicable to European
users.
@
OFFSET:
Used
to
select
TX
OFFSET
+
600
kHz.
The
indicator
shifts
in
the
following
sequence
(+,
=
8,4,
.)s
However,
on
the
display,
the
letter
“S”
indi-
cating
simplex
mode
will
not
be
indicated.
Note:
Although
OFFSET
indicator
can
be
lighted
in
both
SSB
and
CW
modes,
the
shift
operation
does
not
work
actually.
OFFSET
operation
is
available
in
FM
mode
only.

vows
q
O54
Pus
REAR PANEL
® Indicators
@ STEP: Lights when the STEP switch is ON.
® BUSY: Lights when the center signal is received
with the SQL switch ON.
© REV &LOCK: Lights when the REV & LOCK switch is
ON. :
@ ONAIR: Lights when transmitting.
© DCs: Lights when the DCS switch is ON.
@® CAL: Lights when the C.AL switch is ON.
@ D.sa: Lights when the D.SQ switch is ON.
Note:
When changing the voltage setting, be sure to
Note:
When operating by AC line source, be sure
the dummy plug (8) is connected to its jack,
otherwise the transceiver is not turned on.
® ANT jack
M type antenna jack of 50 ohm impedance.
@ GND terminal
Connect a good earth ground to this terminal.
@® EXT. SP jack
For connecting an external 8-ohm speaker.
@ ST BY switch
When using an external standby switch, use the supplied
plug.
@® KEY jack
For connecting a CW key. Use the supplied plug.
® ACC2 jack
For connecting data communication devices such as
10
use the correct fuse:
@ 2A fuse for 120V
@ 1A fuse for 220V/240V
RTTY, etc. (For details, see page 21.)
ACC1 jack
For connecting a computer interface. (For details, see
page 21.)
@® AC receptacle
AC line input. Use the supplied cable.
DC receptacle
For connecting a DC power source. Remove the dummy
plug and plug in the optional DC cable. Observe polarities
when connecting.
©® Voltage selection switch
Allows selection of three different voltages, 120V, 220V
and 240V.

OPERATION
@ AUTO MODE SETTING
Automatically selects the proper mode, for the frequency
segment selected. See chart below.
144.0 144.5 145.0 145.8 146.0 147.0 148.0 MHz
1144.10
few fuse | FM ‘use | FM f
in 4 4 1
TS-711A
144.0 144.5 145.0 145.85 146.0 MHz
144.15
'cw!usa | FM ‘use |
u hs do |
TS-711E
Notes:
1. To release auto mode operation, press any key other
than the AUTO key.
2. In AUTO mode operation, frequency cannot be
changed during transmission (No. TX QSY). If the
frequency is to be changed during transmission,
such as in satellite communications, Release AUTO
mode first.
@ DIAL FREQUENCY
1. The frequency displayed is the center for carrier fre-
quency. When switching needs the display will not
shift frequency, thus the displayed frequency is the ac-
tual transmit frequency.
2. In CW operation, the displayed frequency is the trans-
mit frequency. The actual receive frequency is 800 Hz
below the transmit frequency.
@ INITIAL FREQUENCY SETTING
When the backup battery is replaced or the microcom-
puter is reset, frequencies are preset as shown in the table
below.
VFO A
VFO B
COM
Mch 1
144.000 AUTOCW Dial click
| 144.000.0 AUTO CW Dial through
AUTO FM
| 145.000
| 144.000
AUTO CW
Ch2 ~ Ch40
@ CONFIRMATION BY MEANS OF BEEP SOUND
Audio feedback in the form of a series of beeps confirms
various input functions. See Chart below for additional in-
formation.
Types of beep
When beep sounds
Single beep
Confirm key input.
Double beeps
When Mch 1 is busy in alert
mode.
3 beeps
When operation fails.
4 beeps
repeated
Beep sounds until transmit freq.
for split operation is stored.
5 beeps
When operating another keys
with REV & LOCK on.
8 beeps
When waiting memory entry.
Approx. 1.5
second beeps
When memory data is entered.
Beep also sounds when DCS is operated. (Refer to DCS
operation.)
@ FM OPERATION
After
the
AC
cable,
antenna
and
microphone
are
connect-
ed, proceed as follows:
Initial Switch Settings
Power switch: OFF
MIC control: 10 o'clock position
RF PWR control: Fully clockwise
SQL control: Fully counterclockwise
IF SHIFT control: 12 o'clock position (click)
AF control: Fully counterclockwise
RF control: Fully clockwise
< Receive operation >
1.
Set
the
POWER
switch
to
ON.
The
meter
and
display
are
illuminated.
The
FM,
AUTO
and
BUSY
indicators
light.
2. Pressing the CHQ key generates a mechanical noise.
When rotating the main dial, the rotation is felt as either
click or through. Press the CHQ key so that the main
dial is set to click type rotation.
3. Turn the AF control clockwise to adjust audio level to
the desired level.
4. Select a clear channel with the main dial and adjust the
SQL control to the threshold point (the point which
noise just disappears and the BUSY indicator goes
off.)
11

5.
Select
the
desired
frequency
with
the
main
dial.
When
a
signal
is
received,
the
S
meter
will
deflect
and
the
BUSY
indicator
will
light.
.
When
there
is
interference
in
reception,
caused
by
other
stations,
set
the
ATT
switch
to
ON
and
the
re-
ceive
gain
is
lowered
approx.
20
dB.
This
may
improve
audibility.
Note:
The
BUSY
indicator
will
light
within
the
center
fre-
quency
range
of
+
2.5
kHz.
When
the
frequency
of
the
other
station
drifts,
the
audio
signal
will
be
distorted
and
the
BUSY
indicator
does
not
light.
Therefore,
frequency
drift
of
other
station
and
incorrect
tuning
of
your
station
can
be
determined
by
this
BUSY
indicator.
< Transmit operation >
@ SSB OPERATION
< Reception procedure >
Tune
precisely
Set
to
OFF
.
Before
transmitting,
make
sure
the
antenna
connected
is
of
50-ohm
impedance.
.
Be
sure
not
to
transmit
if
the
frequency
is
occupied.
.
Pressing
the
PTT
switch
of
the
microphone
allows
transmission.
The
ON
AIR
indicator
will
light
and
the
meter
will
indicate
transmit
power
output.
The
proper
distance
between
your
mouth
and
the
microphone
is
5
cm.
If
it
is
too
close
to
the
microphone,
audio
distortion
of
the
transmitted
signal
may
occur.
.
The
MIC
control
is
used
for
controlling
SSB
mic
gain.
In
FM
mode,
this
control
is
not
used.
When
other
sta-
tions
report
your
modulation
is
weak,
set
the
PROC
switch
to
ON.
Setting
the
PROC
switch
to
ON
may
dis-
tort
the
modulation
in
FM
mode.
.
SSB
mode
consists
of
USB
and
LSB.
According
to
operational
custom,
USB
mode
is
used
in
144
MHz
band.
Tuning
techniques
(zero-in)
in
SSB
mode,
re-
quires
practice.
.
The
transceiver
digital
VFO
varies
10
kHz
per
revolu-
tion,
in
10
Hz
steps.
Adjust
the
main
tuning
control
for
natural
sounding
audio
in
receive.
< Transmission procedure >
Keep
ALC
zone
MIC
control
.
Set
the
PROC
switch
to
OFF
and
ALC
switch
to
ON
(for
ALC
reading).
.
Speak
in
a
normal
voice
with
the
MIC
PTT
switch
held
depressed
and
observe
the
meter
reading.
Adjust
the
MIC
control
so
that
the
meter
reading
remains
within
the
ALC
zone.

@ PROC SWITCH OPERATION
In SSB DX communications, when your signal is insuffi-
ciently strong for another station to understand, set the
PROC switch to ON to increase talk power.
In normal operation, set the PROC switch to OFF.
m@ CW OPERATION
For CW operation, your transmit frequency should be
“zeor-beat” to the transmit frequency of the station you
are contacting. This also allows your contact to receive
your signal without having to retune his receiver. Tuning
methods are detailed in the following paragraphs.
Your frequency Displayed frequency
Receiver carrier frequency
(BFO)
Transmit-Receive frequency
(Displayed frequency)
sy
|
I
=
800Hz
Beat note
Tuning for CW Operation
This transceiver utilizes semi break-in CW. Depressing the
key sets the transceiver in transmit mode. Semi break-in
delay time adjustment can be done with a small (+) screw-
driver through the opening on the top cover, as shown.
——Opening
Top view
1. Connect a key to the rear panel KEY jack. If the key
plug does not match the jack, use an adapter plug or
connect the supplied plug.
2. The side-tone circuit is built in, to allow monitoring your
CW signal. When in other than CW mode operation,
this is used for monitoring your CW keying practice. In
this status, transmission is inhibited.
3. Reception in CW is USB. AGC is automatically set to
fast.
KEY
Connection for CW (cno)
@ SATELLITE COMMUNICATIONS
The present Amateur Satellites in orbit are OSCAR 10 and
RS 5 ~ 8 (USSR). Communications using these satellites
use various frequencies by transponders installed in those
satellites. When satellite communication through OSCAR
10 is to be performed using the TS-711A/E and
TS-811A/E, proceed as follows. In this operation, use
mode B. Perform the uplink on the 430 MHz band
(TS-811A/E) and the downlink on the 144 MHz band
(TS-711A/E).
OSCAR 10
Uplink frequency ............5 435.025 ~ 435.175 MHz
(LSB)
Downlink frequency .......... 145.978 ~ 145.828 MHz
(USB)
General beacon freq........... 145.810 MHz
Engineering beacon freq.... 145.987 MHz
A0-10
Satellite communications require advanced techniques
and skill (orbit information, use of beacon signal, use of an-
tenna, operation behavior, etc.), compared with ordinary
communications. Before transmitting, study satellite com-
munications techniques. Several publications are available
from organizations such as the ARRL and JARL.
T3

FUNCTION CONTROLS AND SWITCHES
@® RIT
RIT (Receiver Incremental Tuning) is a function to only
shift receive frequency without changing transmit fre-
quency.
1. The RIT variable range is +9.99 kHz. The two most
significant digits are displayed.
2. The RIT allows you to obtain the exact frequency of the
other station.
3. Restoring to “0.0” (zero offset) can be done simply, by
pressing the CLEAR switch.
4. The RIT works in any mode, COM ch, M ch, or dial
locked.
5. The RIT frequency display works even with the RIT
switch OFF, and allowing you to preset the RIT.
@ IF SHIFT
Turned in © direction Turned in @ direction
IF filter passband
i characteristic teh
Interfering signal
Interfering signal
SQL —@> iF SHIFT SQL —@> IF SHIFT
Ke
SQL ~@> IF SHIFT
KE
® oO ®
Turn in © direction
to eliminate inter-
ference from signal
Turn in @ direction
to eliminate inter-
ference from signal @)
The IF SHIFT control is used to shift the passband of the IF
filter without changing receive frequency. By turning this
control in either direction, the IF passband is shifted as
shown in above figure. The IF SHIFT is effective in elimin-
ating interference when nearby signals are supperimposed
on the receive signal during either SSB or CW operation.
IF SHIFT does not operate in FM mode.
a) To eliminate interference from signal (B), turn counter-
clockwise (-).
b) To eliminate interference from signal (A), turn clockwise
(+).
14
@ RF GAIN control
For normal operation, this control should be turned fully
clockwise for maximum sensitivity. Receive sensitivity is
reduced by turning the control counterclockwise. :
Adjust the RF control so the S-meter does not show ex-
cessive deflection. This minimizes noise during reception
and allows the S-meter to indicates signal peak (or a little
below that point). Noise is markedly reduced when signal
is absent.
S meter peak point
AF -@— RF
6
1 or -s7 20 40 60
48
0
S-meter reading Full
Signals below at partial counter Clockwise
position
this level are clockwise position
attenuated of RF GAIN control
AF-—@— AF
6
20 40 60
dB Turn
counter-
clockwise
lo
RF PWR control
RF GAIN Control Operation
@ RF PWR control
Gacacachda
BEE es
U0 0
This function continuously varies transmit power output
from approx. 2W through the maximum (rated output) in
any mode. In QSO is with local stations (relatively near
stations), lowering the transmit power output, reduces in-
terference to other stations, and also saves on power con-
sumption.
RF
8
of
the
meter
graduation
corresponds
to
the rated output (at 50-ohm load). Meter reading “RF 6”
indicates approx. 1/2 the rated output. Minimum RF
power output is indicated by meter reading “RF 1 ~ 2”.
MIC ——RF PWR
@ Auto reset thermal protector
This unit is equipped with a thermal protector circuit
which prevents part deterioration due to heat caused
from continuous transmission. If the PTT switch is left
on or the transmission continuous for 40 minutes to 1
hour, the auto reset thermal protector functions to stop
operation.
At this time, leave the unit for 10 — 15 minutes to cool
it. If your unit is equipped with a cooling fan, keep the
fan activated.

@ DIGITAL FUNCTION
@ Memory
There are 40 memory channels.
M1: Frequency; 144.000 MHz, Mode;
AUTO CW, and Dial; click are the de-
fault values.
M2 ~ M35: Ordinal memory channels.
M36 ~ M38: Split memory channels, i.e., transmit
and receive frequencies can be stored
individually.
M39 ~ M40: The program scan range is stored in
these two channels.
@ Memory contents
Frequency, mode, main dial status (click or continuously
variable), offset, and tone can be stored in each memory
channel RIT status cannot be stored.
@ Memory entry
<M.CH>
M. IN CH. S VFO/M
1. In VFO mode, select the data to be memorized with the
main dial.
2. Set the CHS switch to ON and select the desired me-
mory channel.
3. Press the M.IN switch, and 8 beeps will sound.
Press the M.IN switch again while the beeps are sound-
ing. When memory entry has been performed, the beep
sounds again to verify memory storage.
4. Channels M36 through M38, require input of both
transmit and receive frequencies.
After the RX frequency has been entered the radio will
emit a series of 4 beeps.
Select the desired transmit frequency and then press
the M.IN key. A single beep will sound to confirm entry.
< COM>
M. IN COM
1. Inthe VFO mode, set the data to be memorized with the
main dial.
2. Press the M.IN switch and a double beep will sound and
repeat. Press the COM switch while the beep is sound-
ing. A single beep will confirm entry.
<M.CH data replacement >
M. IN VFO/M
Recall the desired M.CH with the VFO/M switch. If the
stored data except frequency fails, reset the required data.
Press the M.IN switch and beep will sound. Press the M.IN
switch again while the beep is sounding and the replaced
data is stored.
@ SCAN
The scan modes of this transceiver are:
Program scan in VFO; memory scan in M.CH; and mode
scan in M.CH.
@ Program scan
1. In VFO A or B, when the SCAN switch is set to ON,
scan will start within the limits stored in M39 and M40.
When VFO is at a point, scan starts as follows.
a
Lower limit 4145.0
Upper limit
M39
When VFO is at b point, scan starts as follows.
b
Lower limit 145.0 Upper limit
Lower limit 145.0
i
Down scan
* The indicated range is not scanned.
15

2. Scan direction up or down can be reversed by the main
dial during scanning.
3. Releasing scan can be done with any key, other than
MHz, UP and DOWN.
4. When no data is stored in M39 and M4O, scan is per-
formed throughout the entire frequency range.
@ Memory scan
In M.CH operation, pressing the SCAN switch starts me-
mory scan. Vacant channels will be skipped.
1. Scanning all memory channels
By pressing the AUTO switch and the SCAN switch, in
that order, all memory channels are scanned.
2. Locking out memory channel(s)
To lock out a memory channel from memory scan, first
select the desired channel.
Pressing the CH.S key will cause the momory lock out
indicator (small decimal point to the right of the CH
number) to turn on.
Pressing the CH.S key again will turn off the lockout
function.
P= Lock out indicator
@ Memory channel mode scan
To scan on the same mode such as FM or CW mode only,
first press the AUTO switch so that the AUTO indicator
goes off. Next, press the required mode switch and start
scan by pressing the SCAN switch. During this operation,
locked out channel(s) are skipped.
Notes:
1. In FM mode, the center stop function stops scan, at the
center frequency.
2. In SSB/CW mode, scan stops if a signal is present.
3. To activate scan, the SQL control should be set at the
threshold point.
@ ALERT OPERATION
16
While receiving any frequency with the ALERT switch set
to ON, the frequency in M1 can be monitored. When M1
is busy, a double beep will sound.
Current receive frequency, 6 seconds
Example 145.32_____-
Frequency stored in CH1.
Example 145.50° ~~ 7 =
0.3 seconds
As shown above, M1 is monitored approximately every 6
seconds. However, received audio is muted while M1 is
monitored. Note the keyboard functions are locked for the
0.3 seconds of M1 reception.
CH.S switch operation with AL switch ON
In M.ch operation — Pressing the CH.S switch ON switches
to M1 operation from any memory channel.
In VFO operation — Pressing the CH.S switch ON switches
to M1 display from any memory channel display.
m@ DCS SYSTEM FEATURES
1. Coded squelch operation.
2. 5 digit, ASCII Code variations are possible. Additional-
ly, the TS-711A/E can store 10 different code groups,
any of which can be placed in a “standby” or active
mode.
3. Automatic transmission of call sign data whenever the
DCS system is activated. (ATIS-Automatic Transmitter
Identification System).
4. Several methods of signalling the reception of desired
stations are available.
5. Microprocessor control minimizes system malfunc-
tions.
@ Call sign entry
FM mode

The TS-711A/E employs a method of displaying and en-
tering the call sign 3 digits at a time, using decimal ASCII
codes. First encode the callsign into ASCII using the table
on page 17.
O After the call sign has been entered, it will not be
necessary to reenter it as long as you operate the
TS-711A/B. (However, if the reset switch is depressed,
or the lithium battery were to fail reprogramming may
be necessary.)
A
B
c
D
E
F
G
H
4al/a|/a/O/v7/O}/Z2/S/r|x~
olaolniloalal/alwlnrn
Entry example: WD6DJY
1. With FM mode selected, set the CS switch to ON.
Then, the display is:
en" a
Grad LE as By Da a)
2. Set the C. AL switch to ON. Then, the display shows
as follows:
r Te fired C0 a. ot
Cott a hed Has ti
C-: Waits for setting 3 letters from the beginning
of the call sign, i.e, W, D and 6. To enter this
setting, press keys 8, 7, 6, 8, 5 and 4 in that
order.
3. Then, the display will show the following:
| r re ae as
eS Woe we
C=; Indicates the radio is waiting for you to enter
the last 3 digits. From the example enter 6, 8,
7,4, 8, 9. After the last digit has been entered
a long beep will sound and the display will re-
turn to:
re Lt AED
Eo oui
4. Press the C. AL switch twice to verify the data entry.
WDE6DJY call sign entry is now complete. Now, press
the CS switch and the display is restored to the digital
code display. Press it again and the display is restored
to the normal frequency display.
@ Digital code entry
Digital code: Any 5 digit number
This tranceiver has 10 (CO ~ CQ) digital code memor-
ies. Multiple digital codes can be monitored. However,
only one digital code is transmitted at a time.
Entry examples: CO
c5
1. With FM mode selected set the CS switch to ON.
Then, the display will show:
The CO denotes channel number.
2. Press keys 1, 2, 3, 4 and 5 in that order and a single
beep will sound, to confirm completion of data entry.
The display will show:
r a a
Céad Pe eh Fe
low.
Press keys 5, 5, 6, 6 and 7 in that order. A single beep
will sound and the display will show the following:
jar
4. Data entry for digital code memory CO and C5 is now
complete. Entry of other channels can be done in the
same manner.
cet
aa
r
5
a]
un
wo
a
@ Digital code usage
1. With a code displayed, rotate the Main dial control to
display the required code (for transmission).
2. Press the D. SQ switch to place the standby indicator
as shown below.
17

Example:
{ley}
‘
=? Standby indicator
Note:
Whenever recalling another memorized code, first
erase the standby indicator by pressing the D. SQ swit-
ch and repeat steps 1 and 2.
@ Digital code standby
The “Standby” indicator is a visual indication of which di-
gital access codes will actually open the squelch of the ra-
dio. Simply stated it shows the “Active” codes. When the
indicator is on the code is active. When the indicator is
off, the code is not used.
The digital code displayed when the [CS] key is pressed
“ON” (called the transmit digital code) becomes an “active”
code regardless of the standby indicator.
However, when using the digital code standby mode, light
the standby indicator by pressing [D. SQ] key for the
transmission digital code.
C5. i c i valk 4
Standby indicator
To activate a digital code, select the desired code with the
main dial. Then press the [D.SQ] key to turn on the
standby indicator. To turn off the indicator press the
[D.SQ] key again.
@After setting digital code
When the CS switch is pressed, the display indication is as
follows:
Memory Frequency Transmit digital code
Channel channel number
number
The frequency can be set with the main dial and the trans-
mission digital code channel can be set with CS switch.
@ Digital code squelch operation
The new DCS system gives the operator the ability to select
which stations he wants to listen to. Only those stations
that transmit the proper data will be able to “open” the
squelch of the TS-711A/E when the DCS system is ON.
You must prearrange which codes will be used, since once
you have turned on the system only the proper codes will
open the squelch.
18
D.SQ
< Operation >
1. Press the [DCS] key and then the [D.SQ] key. The DCS
system is now active. The DCS and D.SQ indicators
will light, and undesired signals will not open squelch.
2. Select the codes you wish the system to recognize by
turning on the appropriate stanby indicators.
3. When any of the selected codes is received the squelch
will open, an alert tone will sound, and the microproces-
sor will select the proper transmit code to allow normal
two-way communications.
4. Two different [DCS] alert signal functions are available.
When the [DCS] and the [D.SQ] keys are on and the
proper access code is received, the radio will beep 3
times and the [D.SQ] indicator will turn off.
When the [D.SQ], [C.AL], and [DCS] keys are on and the
proper access code is received, the radio will beep 3
times continuously until reset, and the [D.SQ] indicator
will turn off.
Use of these alert functions, in conjunction with the op-
tional CD-10 call sign display, will allow unattended
monitoring. When you return and discover that the
alert function has been activated you can recall the call
signs of those stations who have attempted to contact
you. Further information on the CD-10 is contained in
the operating manual for that accessory.
To reset the DCS system, press the [D.SQ] key, and the
[C.AL] key, if desired.
5.
The
DCS
data
string
takes
approximately
.2
seconds
at
the
beginning
of
each
transmission.
Wait
a
short
period
before
speaking
to
allow
completion
of
the
data
string.
6. Once normal communications have been established
turn off the DCS system to avoid this delay.
@ Code scan operation
1. Press the SCAN switch while [D.SQ] is active.
2. While scanning (memory or program scan), the scan
will stop temporarily when a signal is received. If the
received signal has the proper digital code, the [D.SQ]
indicator will go off, and squelch will open. Scan will be
stopped at this frequency.

@ FIXED STATION OPERATION
@ Antenna
Yagi antennas (ARRAY)
Ground plane
antenna
|
Rotor Control cable
@ Connections
Various
types
of
fixed
station
antennas
are
commercially
available,
select
your
antenna
accord-
ing
to
your
installation
space
and
application.
Note
that
the
SWR
of
your
antenna
should
be
less
than
1.5.
A
high
SWR
will
cause
the
TS-711A/E
protective
circuit
to
operate,
reducing
the
transmit
output
power.
Transceiver
performance
de-
pends
largely
on
the
type
of
an-
tenna
used.
For
fixed
station
operation
there
are
ground
plane
antennas
(omni-directional)
and
Yagi
antennas
(uni-directional).
The
Yagi
antenna
is
suitable
for
long
distance
operation
(DX)
or
communication
with
a
specific
party.
Antenna
Use an antenna of 50 ohms
impedance. The antenna can
be connected through an M
type coaxial cable connector.
|44MHz
Key
For CW operation
the key through a phone
plug. Use shielded cable.
connect
Ground
To prevent electric shock, TVI and BCI,
select a good grounding location: Con-
nect the unit to the ground using a heavy
earth line and an appropriate earthing
rod. The earth line should be as short as
possible.
O sud
aca
Srannat
nonag
HN,
UGuuuty
ngre 7
External speaker
A speaker is included in the unit. If you
wish to use an external speaker, connect
it by using the supplied speaker plug. A
communication-use (low/high cut type)
speaker rated at 4 ~ 8 ohms is reco-
mended. The option speaker (SP-430) is
designd to perfectly match th
ST-711A/E. Plugging in an extrnal
speaker will automatically disconnect the
built-in speaker. Do not connect the
speaker to the PHONES jack, as this jack
has a level adjusting resistor.
Connection of electric
Power supply
sure to observe the following points:
1. Turn off the power switch.
(or battery) with care.
damage to the unit
The unit is designed to operate on AC (120/240/220V) or DC (13.8V)
Switching between AC and DC is accomplished by replacing th power
cord (DC power cord optional.). When connecting Ithe power cord, be
2. When replacing the power cord, disconnect it from the AC supply
Failure to observe the above procedure might result in electric shock or
When connecting an external speaker, be
careful not short circuit the AF output
The speaker cord should be of a shielded
type and should be as short as possible
to prevent RF from being induced.
@ MOBILE INSTALLATION [GENERAL]
®@ Installation location
Using the optional mounting bracket, install the trans-
ceiver under the dashboard in your car. If your car is
equipped with electronic fuel injection, the transceiver
should be as far from the control equipment as possible.
@ Antenna installation
Various
types
of
antennas
for
2
meters
mobile
operation
are
available.
Note:
For gutter-mount installation, the antenna bracket must be
grounded to the car body as shown on the following page.
Affix
the
antenna
securely,
referring
to
the
antenna
in-
struction.
@ Power supply
Connect
the
supplied
power
cord with
fuse
directly
to
the
battery
terminals.
Connecting
to
the
cigarette
lighter
socket
can
cause
a
poor
connection,
and
excessive
vol-
tage
drop.
® Ignition noise
The
transceiver
is
designed
to
suppress
ignition
noise;
however,
if
excessive
noise
is
present,
it
may
be
necessary
to
use
suppressor
spark
plugs
(with
resistors).
19

Antenna
TS-711A/E
12V
Use short heavy leads
Battery
Fuse should be as close to the battery Fuse
terminal as possible
Turn POWER switch OFF
before connecting/
disconnecting the power cord
MAINTENANCE AND ADJUSTMENT
@ BEEP SOUND VOLUME ADJUSTMENT @ TO MONITOR YOUR CALL SIGN
Remove
8
screw
from
the
top
cover
and
remove
the
cover.
When
the
optional
call
sign
display
is
connected,
your
call
By adjusting VR1 (yellow) on sign can be monitored when transmitting.
the control unit, the require
audio volume can be ob-
tained.
@ MAIN DIAL TORQUE ADJUSTMENT
Adjust the torque adjusting
screw on the bottom cover
with a (—) head screwdriver.
Turning the screw clockwise
increases drag and counter.
clockwise decreases it.
20
d UL 1) Remove 8 screws from the transceiver top cover with a
(+) screwdriver and remove the cover.
2) As shown in the figure below, link the terminals marked
Y and X with a jumper wire on the control unit. Use a
low wattage pencil type iron.
VR-1
Note:
When transmitting with this jumper wire connected, noise may be
observed. If so, remove the jumper.
