INSTRUCTION MANUAL
KENYON®
KENYON
P.O. Box 925
8 Heritage Park Road
Clinton CT 06413 USA
Phone: (860) 664 - 4906
FAX: (860) 664 - 4907 Part #143117
Rev 7/26/2012
Mediterranean, Caribbean, Alpine, Arctic, Antarctic
and Cortez Ceramic Glass Cooktops
(120, 208 & 240 Volt Models)
Mediterranean 2-Burner
Alpine 2-Burner
Arctic
Caribbean 2-Burner
Antarctic
Cortez 2-Burner

Please read these
instructions in
their entirety before
installation and use
of aPPliance.
***
DO NOT DISCARD
this manual!
save for future
reference.

Mediterranean Series Cooktop
PRODUCT SPECIFICATIONS
Two Burner
B41510 - 120V AC - one 6 1/2” (165mm) burner @ 1200 watts
one 8” (200mm) burner @ 1400 watts
B41511 - 240V AC - one 6 1/2” (165mm) burner @ 1200 watts
one 8” (200mm) burner @ 1800 watts
B41591 - 208V AC - one 6 1/2” (165mm) burner @1200 watts
one 8” (200mm) burner @ 1800 watts
Overall dimensions: 23-1/4” x 14-1/4” x 2-5/8”
590.6mm x 362.0mm x 66.7mm
Cutout dimensions: 21-3/4” x 12-3/4” with 1/4” radius
552.5mm x 323.9mm with 6.4 radius
Trimline
B41515 - 120V AC - two 6 1/2” (165mm) burners @ 1200 watts each
B41516 - 240V AC - two 6 1/2” (165mm) burners @ 1200 watts each
B41596 - 208V AC - two 6 1/2” (165mm) burners @ 1200 watts each
Overall dimensions: 21” x 12” x 2-5/8”
533.4mm x 304.8mm x 66.7mm
Cutout dimensions: 20” x 10-3/4” with 1/4” radius
508mm x 273mm with 6.4 radius
Single Burner
B41517 - 120V AC - one 6 1/2” (165mm) burner @ 1200 watts
B41518 - 240V AC - one 6 1/2” (165mm) burner @ 1200 watts
B41598 - 208V AC - one 6 1/2” (165mm) burner @ 1200 watts
Overall dimensions: 12” x 12-1/2” x 2-5/8”
304.8mm x 317.5mm x 66.7mm
Cutout dimensions: 10-3/4” x 11-1/2” with 1/4” radius
273.0mm x 292.1mm with 6.4 radius
Caribbean Series Cooktop
PRODUCT SPECIFICATIONS
Two Burner
B41601 - 120V AC - two 6 1/2” (165mm) burners @ 1200 watts each
B41602 - 240V AC - two 6 1/2” (165mm) burners @ 1200 watts each
B41692 - 208V AC - two 6 1/2” (165mm) burners @ 1200 watts each
Overall dimensions: 21” x 12” x 2-5/8”
533.4mm x 304.8mm x 66.7mm
Cutout dimensions: 20” x 10-3/4” with 1/4” radius
508mm x 273mm with 6.4 radius
Single Burner
B41605 - 120V AC - one 6 1/2” (165mm) burner @ 1200 watts
B41606 - 240V AC - one 6 1/2” (165mm) burner @ 1200 watts
B41696 - 208V AC - one 6 1/2” (165mm) burner @ 1200 watts
Overall dimensions: 12” x 12-1/2” x 2-5/8”
304.8mm x 317.5mm x 66.7mm
Cutout dimensions: 10-3/4” x 11-1/2” with 1/4” radius
273.0mm x 292.1mm with 6.4 radius

Arctic & Antarctic Series Cooktop
PRODUCT SPECIFICATIONS
Two Burner - Arctic - Black Glass
B41603 - 120V AC - one 6 1/2” (165mm) burner @ 1200 watts
one 8” (200mm) burner @ 1400 watts
B41604 - 240V AC - one 6 1/2” (165mm) burner @ 1200 watts
one 8” (200mm) burner @ 1800 watts
B41694 - 208V AC - one 6 1/2” (165mm) burner @ 1200 watts
one 8” (200mm) burner @ 1800 watts
Overall dimensions: 21” x 17” x 2-3/4”
533.4mm x 431.8mm x 69.9mm
Cutout dimensions: 19-1/2” x 16” with 1/4” radius
495.3mm x 406.4mm with 6.4 radius
Two Burner - Antarctic - White Glass
B49512 - 120V AC - one 6 1/2” (165mm) burner @ 1200 watts
one 8” (200mm) burner @ 1400 watts
B49513 - 240V AC - one 6 1/2” (165mm) burner @ 1200 watts
one 8” (200mm) burner @ 1800 watts
B49593 - 208V AC - one 6 1/2” (165mm) burner @ 1200 watts
one 8” (200mm) burner @ 1400 watts
Overall dimensions: 21” x 17” x 2-3/4”
533.4mm x 431.8mm x 69.9mm
Cutout dimensions: 19-1/2” x 16” with 1/4” radius
495.3mm x 406.4mm with 6.4 radius
Cortez Series Cooktop
PRODUCT SPECIFICATIONS
Two Burner
B41710 - 120V AC - two 6 1/2” (165mm) burners @ 1200 watts each
B41711 - 240V AC - two 6 1/2” (165mm) burners @ 1200 watts each
B41719 - 208V AC - two 6 1/2” (165mm) burners @ 1200 watts each
Overall dimensions: 21” x 12” x 2-5/8”
533.4mm x 304.8mm x 66.7mm
Cutout dimensions: 20” x 10-3/4” with 1/4” radius
508mm x 273mm with 6.4 radius
Single Burner
B41704 - 120V AC - one 6 1/2” (165mm) burner @ 1200 watts
B41705 - 240V AC - one 6 1/2” (165mm) burner @ 1200 watts
B41709 - 208V AC - one 6 1/2” (165mm) burner @ 1200 watts
Overall dimensions: 12” x 12-1/2” x 2-5/8”
304.8mm x 317.5mm x 66.7mm
Cutout dimensions: 10-3/4” x 11-1/2” with 1/4” radius
273.0mm x 292.1mm with 6.4 radius

Alpine Series Cooktop
PRODUCT SPECIFICATIONS
Two Burner - Large
B49510 - 120V AC - one 6 1/2” (165mm) burner @ 1200 watts
one 8” (200mm) burner @ 1400 watts
B49511 - 240V AC - one 6 1/2” (165mm) burner @ 1200 watts
one 8” (200mm) burner @ 1800 watts
B49591 - 208V AC - one 6 1/2” (165mm) burner @ 1200 watts
one 8” (200mm) burner @ 1800 watts
Overall dimensions: 23-1/4” x 14-1/4” x 2-5/8”
590.6mm x 362.0mm x 66.7mm
Cutout dimensions: 21-3/4” x 12-3/4” with 1/4” radius
552.5mm x 323.9mm with 6.4 radius
Two Burner - Small
B49515 - 120V AC - two 6 1/2” (165mm) burners @ 1200 watts each
B49516 - 240V AC - two 6 1/2” (165mm) burners @ 1200 watts each
B49596 - 208V AC - two 6 1/2” (165mm) burners @ 1200 watts each
Overall dimensions: 21” x 12” x 2-5/8”
533.4mm x 304.8mm x 66.7mm
Cutout dimensions: 20” x 10-3/4” with 1/4” radius
508mm x 273mm with 6.4 radius
Single Burner
B49517 - 120V AC - one 6 1/2” (165mm) burner @ 1200 watts
B49518 - 240V AC - one 6 1/2” (165mm) burner @ 1200 watts
B49598 - 208V AC - one 6 1/2” (165mm) burner @ 1200 watts
Overall dimensions: 12” x 12-1/2” x 2-5/8”
304.8mm x 317.5mm x 66.7mm
Cutout dimensions: 10-3/4” x 11-1/2” with 1/4” radius
273.0mm x 292.1mm with 6.4 radius

INSTALLATION INSTRUCTIONS FOR KENYON
CERAMIC GLASS COOKTOPS
STEP #1
Unpacking the Cooktop
Carefully unpack the cooktop from its shipping container. If possible, retain the original
shipping carton and protective packaging in the event the unit ever has to be returned for
service.
Verify and identify the package contents. The following items should be included in the
carton. If any components are missing or damaged, call KENYON immediately.
Ceramic glass cooktop • (2) Mounting brackets
(1) Package of mounting screws • (1) Ceramic cooktop cleaner
1
Important: Save this documentation for review by local inspector.
Important: This appliance must be properly installed and grounded
by a qualied technician.
Important: Do not remove the clear plastic covering lm on the
ceramic glass until cooktop is ready to use.
Cerama Brite
Ceramic Cooktop Cleaner
Kenyon Cooktop Mounting Brackets
Mounting Screws Package

The supply must be from an individual grounded circuit that is protected by a circuit breaker
 andratedperthespecicationsforthevariousmodelsasshowninthetableabove.
Warning: If the electric power supply does not meet the
product specications, consult with a licensed electrician
before proceeding with installation.
Max Connected Required Power Minimum
Kenyon Part # Model # Load Supply Input Wire Size
B41510 MED2 2600 Watts 120 VAC/22A/60Hz #12 AWG
B41511 MED2 3000 Watts 240 VAC /12.5A/60Hz #12 AWG
B41591 MED2 3000 Watts 208 VAC/14.5A/60Hz #12 AWG
B41515 MED2TL 2400 Watts 120 VAC/20A/60Hz #12 AWG
B41516 MED2TL 2400 Watts 240 VAC/10A/60Hz #12 AWG
B41596 MED2TL 2400 Watts 208 VAC/11.5A/60Hz #12 AWG
B41517 MED1 1200 Watts 120 VAC/10A/60Hz #12 AWG
B41518 MED1 1200 Watts 240 VAC/5A/60Hz #12 AWG
B41598 MED1 1200 Watts 208 VAC/6A/60Hz #12 AWG
B41601 CAR2 2400 Watts 120 VAC/20A/60Hz #12 AWG
B41602 CAR2 2400 Watts 240 VAC/10A/60Hz #12 AWG
B41692 CAR2 2400 Watts 208 VAC/11.5A/60Hz #12 AWG
B41603 ARCTIC2 2600 Watts 120 VAC/22A/60Hz #12 AWG
B41604 ARCTIC2 3000 Watts 240 VAC/12.5A/60Hz #12 AWG
B41694 ARCTIC2 3000 Watts 208 VAC/14.5A/60Hz #12 AWG
B41605 CAR1 1200 Watts 120 VAC/10A/60Hz #12 AWG
B41606 CAR1 1200 Watts 240 VAC/5A/60Hz #12 AWG
B41696 CAR1 1200 Watts 208 VAC/6A/60Hz #12 AWG
B41710 CORT2 2400 Watts 120 VAC/20A/60Hz #12 AWG
B41711 CORT2 2400 Watts 240 VAC/10A/60Hz #12 AWG
B41719 CORT2 2400 Watts 208 VAC/11.5A/60Hz #12 AWG
B41704 CORT1 1200 Watts 120 VAC/10A/60Hz #12 AWG
B41705 CORT1 1200 Watts 240 VAC/5A/60Hz #12 AWG
B41709 CORT1 1200 Watts 208 VAC/6A/60Hz #12 AWG
B49510 ALP2LG 2600 Watts 120 VAC/22A/60 Hz #12 AWG
B49511 ALP2LG 3000 Watts 240 VAC/12.5A/60Hz #12 AWG
B49591 ALP2LG 3000 Watts 208 VAC/11.5A/60Hz #12 AWG
B49512 ANTARCTIC2 2600 Watts 120 VAC/22A/60Hz #12 AWG
B49513 ANTARCTIC2 3000 Watts 240 VAC/12.5A/60Hz #12 AWG
B49593 ANTARCTIC2 3000 Watts 208 VAC/14.5A/60Hz #12 AWG
B49515 ALP2SM 2400 Watts 120 VAC/20A/60Hz #12 AWG
B49516 ALP2SM 2400 Watts 240 VAC/10A/60Hz #12 AWG
B49596 ALP2SM 2400 Watts 208 VAC/6A/60Hz #12 AWG
B49517 ALP1 1200 Watts 120 VAC/10A/60Hz #12 AWG
B49518 ALP1 1200 Watts 240 VAC/10A/60Hz #12 AWG
B49598 ALP1 1200 Watts 208 VAC/11.5A/60Hz #12 AWG
For future reference, please record the serial number of your
cooktop here: ____________________.
STEP #2
Check the Electrical Supply Requirements
This product must be installed in accordance with national, state and local electric codes.
The following table provides the correct voltage, amperage and frequency that must be
supplied to the cooktop.
2

STEP #3
Countertop Preparation
Please read this section prior to making cutout for cooktop.
It is important to plan ahead for installation of the cooktop, keeping the following dimen-
sions in mind (please refer to Figure A).
A - 13 inches maximum depth of overhead cabinets
B-36inchesisminimumheightofcountertopaboveoor
C-Theminimumatcountertopsurfacethatthecooktop
will rest upon must be equal to or greater than the overall
cooktop dimensions (refer to the following page for overall
cooktop dimensions).
D - 30 inches minimum clearance between the top of the cooking
surface and the bottom of an unprotected wood or metal
cabinet or 24 inch minimum clearance when the bottom of
wood or metal cabinet is protected by not less than 1/4-inch-
thick ame retardant millboard covered with not less than
No. 28 MSG sheet steel, 0.015-inch-thick stainless steel,
0.024-inch-thick aluminum or 0.020-inch-thick-copper.
E - 1-inch minimum from backsplash of countertop to edge
of glass (refer to the following page for overall cooktop
dimensions).
“Do Not Install Closer Than 1/2 Inch (12 mm) From Any
Adjacent Surface”, and NE PAS INSTALLER A’MDINS DE
12MM DETOUTE SURFACE ADJACENTE.
Warning: To eliminate the risk of burns by reaching over
heated surface units, cabinet storage space located above
surface units should be avoided. If cabinet storage is to be
provided, the risk can be reduced by installing a range hood
that projects horizontally a minimum of 5” beyond the bottom
of the cabinets.
Before making the countertop cutout, check for clearance. Check to see if the cooktop will
clear the front and side walls of the base cabinet. It is also important to provide enough
ventilation.
Adequate ventilation of the space below the
countertop must be provided to ensure proper
operation of the cooktop. Heat transferred from
the cooktop bottom pan during operation will
overheat an improperly ventilated area.
3
Fig. B
Fig. A

Allow a 2” minimum clearance between the bottom of the metal pan of the cooktop and any
combustible surface located below, ie: the upper edge of a drawer installed below the
cooktop (see Fig. B on previous page). Failure to provide proper clearances and ventilation
mayresultinarehazard.
Cooktop dimensions and countertop cutout dimensions for each model are shown below:
Note:
When making countertop, radius the corner of the cutout (1/4” radius is typical). This will prevent
cracking of the countertop. Follow the countertop manufacturer’s instructions regarding the
minimum corner radius and reinforcement of corners.
12 " 12 1/2"
10 3/4"
11 1/2"
2 5/8"
Models: MED1, CAR1, ALP1, CORT1
23 1/4"
14 1/4"
2 5/8
21 3/4" 12 3/4"
Models: MED2, ALP2LG
12 "
21"
2 5/8"
10 3/4"
20"
Models: MED2TL, CAR2, ALP2SM, CORT2
4
19 1/2"
16"
17"21"
2 3/4"
Models: ARCTIC2, ANTARCTIC2

STEP #4
Installing the Cooktop
There are two mounting brackets supplied with the glass ceramic cooktop. These brackets
aredesignedtoholdthecooktoprmlyinplace.Thecooktopdoesnothaveametalframe
and should be bedded to the countertop using a soft bedding compound that will prevent
damage if later removal for service is necessary. We recommend a very small bead of
silicone sealant.
Attach the two mounting brackets supplied with the KENYON cooktop (as shown) to the
inside vertical surface of the cutout. The brackets are to be mounted on opposing sides. If
your counter material is granite you will need to glue two wood strips underneath the
countertoacceptthemountingbrackets.Centerthebracketintheopening,ushwiththe
countertop and secure with long self-tapping screws that are provided. Position the
cooktopinthecutoutopeningandpressrmlyonallsidestosealtheframeintothe
bedding compound. Secure the cooktop to the brackets from underneath with the small
sheet metal screws that are supplied.
BE CAREFUL NOT TO OVERTIGHTEN THE SCREWS.
KENYON COOKTOP
# 8 X 1/4" SCREW
# 6 X 1 1/4" S/S SCREW
MOUNTING BRACKET
COUNTER SURFACE
5

STEP #5
Electrical Connection
Before proceeding further, verify that the power supply is disconnected. Verify that the
appropriate electrical supply requirements have been met. Please refer to the table on
page 2 for appropriate electrical requirements. The cooktop is supplied with a 36-inch
long conduit for a connection to an accessible junction box. The 240V and 208V conduit
consists of three insulated wires. There are two insulated hot lead conductors (red and
black) and one insulated ground conductor (green). The 120V conduit consists of three
insulated wires. There is the hot lead conductor (black), the neutral conductor (white) and
one insulated ground conductor (green).
Attach conductor wires to residence wiring in accordance with national, state and local
electric codes.
Warning - Grounding
The entire appliance must be grounded at all times when the
electrical power supply is on. Do not ground the appliance with the
neutral house supply wire (white). A separate ground must be used.
6
STEP #6
Final Preparations Prior to Use
Removetheplasticlmfromthecooktop.Cleanthecooktopbeforeyouuseitfortherst
time. A thorough cleaning with a recommended cooktop cleaner (Cerama Brite Ceramic
Cooktop Cleaner) will provide a clean, shiny coating on the cooktop surface.
The next section of the manual covers cooktop use, maintenance, safety and service
information.
Please keep these instructions with the KENYON cooktop for future reference.
Name Plate
Label Location

Proper Installation
Besureyourapplianceisproperlyinstalledandgroundedbyaqualiedtechnician.
Never use your appliance for warming or heating the room.
Do not leave children alone.
Children should never be left alone or unattended in the area where the appliance is in use.
They should never be allowed to sit or stand on any part of the appliance. Do not store
items of interest to a child in cabinets above cooktop. Children climbing on the cooktop to
reach such items could be seriously injured.
Wear proper clothing/apparel.
Loosettingorhanginggarmentsshouldneverbewornwhileusingtheappliance.
User Servicing
Do not repair or replace any part of the appliance. If service ever becomes
necessary, this appliance should be serviced by AUTHORIZED PERSONNEL ONLY or
call KENYON Customer Care at [phone].
Keep ammable materials away from cooktop.
Do not store plastic material (such as plastic utensils) in storage areas beneath
cooktop.
Plastic items with low melting temperatures should not be stored under/over or near the
cooktop.
This cooktop, like all appliances, has the potential to create safety problems
through careless and improper use. Please observe all of the following
safety precautions.
USER’S GUIDE & CARE
SAFETY
Read this section BEFORE operating the cooktop.
The following information applies to all KENYON
Electric Cooktops.
7

Do not use water on grease res.
Smotherreorameorusedrychemicalorfoam-typeextinguisher.
Use only dry potholders.
Moist or damp potholders on hot surfaces may result in burns from steam. Do not let
potholder touch the heating elements on the appliance. Do not use a towel or other bulky
cloth in place of a potholder.
Do not cook on broken cooktop.
If cooktop should break, cleaning solutions and spillovers may penetrate the broken
cooktop and create a risk of electric shock. Contact an authorized service center or
KENYON Customer Care immediately at [phone].
Clean cooktop with caution.
If a wet sponge or cloth is used to wipe spills on a hot cooking surface, be careful to avoid
steam burns. Some cleaners produce noxious fumes if applied to a hot surface. Read the
cleaner label for details prior to using.
DO NOT TOUCH HEATING ELEMENTS
The heating elements on the cooktop may be hot even if they are dark in color. These
areas may be hot enough to cause burns. Never touch heating elements until they
havehadsufcienttimetocool.Likewise,neverallowclothingorammablematerials
to come in contact with heating elements or cooktop surfaces until they have had
sufcienttimetocool.Othersurfacesoftheappliancemaybecomehotenoughto
cause burns.
Use proper pan size.
This appliance is equipped with one or more surface units of different size. Select
utensilshavingatbottomslargeenoughtocoverthesurfaceunitheatingelement.
The use of undersized utensils will expose a portion of the heating element to direct
contact and may result in ignition of clothing. Proper relationship of utensil to burner
willalsoimproveefciency.
Never Leave Surface Units Unattended at High Heat Settings.
Boilover causes smoking and greasy spillovers that may ignite.
Utensil Handles Should be Turned Inward and Not Extend Over Adjacent Surface
Units.
Toreducetheriskofburns,ignitionofammablematerials,andspillagedueto
unintentional contact with the utensil, the handle of a utensil should be positioned so
that it is turned inward, and does not extend over adjacent surface units.
Do not discard these instructions, keep them with the KENYON cooktop for future
reference.
8

Thecookingsurfaceareasofyourglassceramiccooktopareidentiedbypermanent
patterns in the cooktop. The appliance is easy to maintain and easy to clean. Keeping the
cooktop in top performance can be achieved by following the simple guidelines for use and
cleaning below:
Cookware
Chancesarethatyourexistingcookwarewillworkjustnewithyourglassceramic
cooktop. Cooking on a glass ceramic cooktop does not require special pots or pans. Since
cookwareplaysanimportantroleincookingefciencyandconvenience,keepinmindthe
following information when selecting your cookware.
Thecookwareshouldhaveaatbottom.Althoughglassandothertypesofcookwarecan
beused,metalcookwarewiththick,smooth,atbottomswillgenerallyconducttheheat
well. Aluminum and stainless steel cookware usually works best. Avoid cookware with
shaped and rounded bottoms as well as utensils that warp when heated.
Use cookware of the correct diameter only. The base of the pot or pan should be about as
wide as the cooking zone on which it is used – not much wider or much narrower. By using
utensilswiththecorrectdiameter,youshouldachievemaximumheatingefciencywiththe
shortest possible boiling times.
Be certain that both the cooktop panel and the bottom of your pots and pans are clean
and dry before use. By doing so, you will help prevent scratches and stains.
Heating Elements
This KENYON cooktop contains ribbon-type, radiant heating elements. The radiant
elements will “light up” about 4-5 seconds after being turned on. The special design of
theseelementsdirecttheheatupthroughtheceramicglassprovidingefcientcooking.
Temperature limiters are included in each element to ensure that the safe operating
temperature of the ceramic glass top is not exceeded. The temperature limiter will cycle the
radiant element off to prevent exceeding the maximum surface temperature.
Knobs & Indicator Lights
Thecookingareacontrolsarecalled“innite”controls.Thistypeofcontrolhasaninnite
selection of heat settings. The control settings begin at high and decrease heat output by
cycling the heating elements between “off” and “on” as you turn the knob clockwise.
The heating elements will stay “off” for longer periods and “on” for shorter periods as you
turn the knob clockwise, thus reducing the heat output.
OPERATION
READ SAFETY INSTRUCTIONS BEFORE OPERATING YOUR APPLIANCE
9

Knobs & Indicator Lights (continued)
There are a series of lights that provide indications of burner operation and hot surfaces.
These lights are located adjacent to the control knobs. When the control is in the “on”
position, a red light is lit indicating which burner is on.
For your safety, we have incorporated a “HOT” indicator light. When lit, this light indicates
that some part of the glass ceramic cooktop is too warm to touch or place articles upon.
Do not place articles other than cookware on the cooking surface while this light is glowing.
Cleaning
To help ensure that the KENYON cooktop stays clean, follow these easy-care tips:
Cleanthecooktopbeforeyouuseitforthersttime.Athoroughcleaningwithour
recommended cooktop cleaner (Cerama Brite Ceramic Cooktop Cleaner) will provide a
coatingonthecooktoppriortoitsrstuse.AsampleisincludedwithyourKenyoncooktop.
Always remove food spills, grease spatters and metal rub-off from cookware. A razor blade
scraper or the equivalent works well to remove spillovers.
Clean the cooktop with a paper towel or a clean, soft cloth and a recommended cleaner.
After cleaning, always wipe the cooktop with a clean, damp cloth to avoid cooked-on
cleaner residue. Wipe the cooktop dry.
Donotuseadishtowelorspongetowipeoffthecooktop.Almmaybeleftbythe
detergent and may cause discoloration of the cooktop surface.
Avoid abrasive scouring cleaners of any kind. Also avoid using plastic, nylon or metal
cleaning pads. They may scratch or melt onto the cooktop.
Avoidchemicalcleanerssuchaschlorinebleach,ammonia,hydrouoricacidorchemical
oven cleaners. They can etch or discolor the surface.
Do not let anything that melts - plastic, aluminum foil, sugar, etc. come into contact with the
cooktop surface when it is hot. Should something melt onto the surface, immediately
move it to a cool area of the cooktop with a razor blade scraper and then remove it from
the cooktop as soon as possible.
10

Warranty
KENYON International (the “Company”) warrants its products in normal usage to be free of
defects in materials and workmanship subject to the conditions and limitations below.
Any part which proves to be defective in normal usage during the warranty period will be
repaired or replaced by the Company.
This warranty covers all products built by the Company and is subject to the following conditions and
limitations:
1. The Company’s liability shall be limited to repair or replacement (choice of remedy at Company’s option)
of goods or parts as may be defective in materials or workmanship. This liability is limited to three years
from the date of original installation; this warranty covers parts and labor at approved Company rates of
$75 per hour.
2. Determination of suitability of the product for the use contemplated by the buyer is the sole responsibility
of the buyer and the Company shall have no responsibility in connection with such suitability.
3. The Company shall not be liable for any damage resulting from:
• failures due to use of the products in applications for which they are not intended
• failures due to corrosion, wear and tear, abuse or improper installation or maintenance
4. The Company shall be responsible for ground shipping charges to the location of the appliance (home)
within the continental United States and Canada. Any other or express or special shipping charges are at
the expense of the buyer.
5. All labor allowed by the Company under this warranty must be performed by an authorized Kenyon
Internationalservicecenter,unlessotherwisespeciedinwritingbytheCompany.
6. This warranty does not cover the cost of repair or replacement for glass damage.
THERE ARE NO OTHER WARRANTIES OF MERCHANTABILITY, FITNESS FOR PURPOSE OR ANY
OTHER KIND, EXPRESSED OR IMPLIED AND NONE SHALL BE IMPLIED BY LAW. The duration of any
suchwarrantiesthatareneverthelessimpliedbylawforthebenetofaconsumer,shallbelimitedtoa
period of three years from original purchase. Some countries do not allow limitations on how long an implied
warranty lasts, so this limitation may not apply to you.
THE COMPANY SHALL NOT BE LIABLE FOR CONSEQUENTIAL OR INCIDENTAL DAMAGES ARISING
FROM THE BREACH OF THIS WARRANTY, WHETHER EXPRESSED, IMPLIED OR STATUTORY. Some
countries or states do not allow exclusion or limitation of coincidental or incidental damages so this limitation
or exclusion may not apply to you.
THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS AND YOU MAY ALSO HAVE OTHER LEGAL
RIGHTS WHICH MAY VARY FROM COUNTRY TO COUNTRY AND STATE TO STATE.
Kenyon International, Inc.
P.O. Box 925 •8 Heritage Park Road •Clinton, CT 066413 USA
Phone [phone] FAX: [phone]
E-mail: [email protected]
Effective date January 1, 2007
