Kerio NG series User manual

Kerio Control Box
NG series

Kerio Control Box NG Series
2
1 Purpose
This document is a quick guide for safely installing and implementing Kerio Control Box NG
series UTM appliances.
2 General Safety Instructions
During installation follow these security instructions:
•Theapplianceshouldbeplacedonaatsurfaceorsecurelymountedhorizontallyinrack
enclosure.
• The NG500 Series are intended primarily for server rooms due to noisy performance.
• Do not attempt to open or disassemble the appliance for any reason.
• Strictly follow the installation instructions (see section 4).
• Do not place the appliance near a heat source.
• Place the appliance in a ventilated space, making sure that the appliance fans and vents are
unobstructed at all times.
• Do not expose the appliance to liquids of any kind. In the event of liquid intrusion, unplug
the appliance immediately.
• Verify that the voltage and frequency of the power socket matches the values printed on
the power adapter before plugging in the appliance. Use only the power adapter supplied
with the appliance.
• Do not place any items on top of the power cable; keep the power cable away from walk-
waysorotherareaswhereitcouldposeatrippinghazard.
3 Appliance Description
Kerio Control Box types:
•KerioControlBoxNG100—Desktopappliance—seegure1.
•KerioControlBoxNG300—Sub-1Utablemountableappliance—seegure2.
•KerioControlBoxNG500—1Urackmountableappliance—seegure3.
Feature Description
Serial port Used for connecting to a console with a serial cable
USB ports Input for USB devices
Ethernet network ports Used for connecting to the Internet and the LAN with an
Ethernet cable
Table 1 Kerio Control Box Features
Figure 1 Kerio Control Box NG100 (front + back)
Ethernet Ports
USB Ports
Serial PortPower Switch HDMI Port

3
Figure 2 Kerio Control Box NG300 (front)
Figure 3 Kerio Control Box NG500 (front)
4 Kerio Control Box Installation and Conguration
Once a suitable place has been located for the appliance and it has been plugged into a power
outletaccordingtothesafetyinstructions,itistimetoconnectittothenetworkandcongure
settings.
Figure 4 Connecting Kerio Control Box NG100 to the network
Figure 5 Connecting Kerio Control Box NG300 to the network
Figure 6 Connecting Kerio Control Box NG500 to the network
Ethernet Ports USB PortsSerial Port
ENQuick Installation Guide
Ethernet Ports USB PortsSerial Port

© 2015 Kerio Technologies s.r.o. All rights reserved. www.kerio.com
Toconguretheappliance:
1. Connect the Internet port to the Internet (e.g. DSL or Cable modem) using an Ethernet
cable.
2. ConnecttheLANporttothecomputerthatwillbeusedtoconguretheappliance(see
theguresbelow).
3. Turn on the appliance.
Now you have two options:
• Add and manage the appliance through MyKerio (see http://kb.kerio.com/1846)
• Access the Kerio Control Administration through a browser (see below):
1. Set the networking preferences for Ethernet on the connected computer to “Automatic
DHCPconguration”.(Youcanchangeitlaterafterthecongurationiscomplete).
2. RenewtheDHCPleaseonthecomputerandconrmithasanIPaddressof10.10.10.11.
3. Open a web browser and connect to the Kerio Control Administration web interface us-
ing the following URL:
https://10.10.10.1/admin
4. IgnoretheSSLcerticatewarningsandproceedtothecongurationwizard.
5. Followtheinstructionsprovidedbythewizardandconguretheappliance.
Note: For troubleshooting purposes, you can use the serial port to connect the console to the
device. See http://kb.kerio.com/1875 for details.
5 Additional Information
Forfurtherassistancewithcongurationpleaserefertoadditionaldocumentationat:
• http://kb.kerio.com/category/kerio-control/
For online and community based support resources please visit :
• http://www.kerio.com/support
