KERN OZB-IF User manual

OZB-A4515-BA-e-1810
KERN & Sohn GmbH
Ziegelei 1
D-72336 Balingen
E-Mail: [email protected]
Tel: +49-[0]7433- 9933-0
Fax: +49-[0]7433-9933-149
Internet: www.kern-sohn.com
User instructions
Gooseneck illumination
KERN OZB-IF
OZB-A4515
Version 1.0
01/2018

OZB-A4515-BA-e-1810 2
GB
KERN OZB-A4515
Version 1.0 01/2018
User instructions
Gooseneck illumination
Table of contents
1Before use....................................................................................3
1.1 Notes on the electrical system................................................................................................ 3
1.2 Storage ...................................................................................................................................... 3
2Nomenclature...............................................................................4
3Technical data / Features ............................................................5
4Operation......................................................................................6
5Changing the bulbs......................................................................6
6Changing the fuse........................................................................6
7Service..........................................................................................7
8Disposal........................................................................................7
9Further information......................................................................7

3 OZB-A4515-BA-e-1810
1 Before use
1.1 Notes on the electrical system
Before connecting to a mains power supply, you must make sure that you are using
the correct input voltage. The information to select the correct mains cable is located
on the device, on the rear of the product directly above the cable entry. You must
comply with this information. If you do not comply with these specifications, then fires
or other damage to the device could occur.
The main switch must also be switched off before the mains cable is connected. In
this way you will avoid triggering an electric shock.
If you are using an extension cable, then the mains cable you use must be earthed.
If the original fuse should blow, it must only be replaced by an appropriate fuse.
When carrying out any procedures whereby you come into contact with the electrical
system of the device, such as, for example, changing the bulb or fuse, only carry out
these procedures when the power is disconnected.
Never open the housing of the illumination unit in order to change anything on the
electrics. Otherwise the guarantee expires immediately and by incorrect operations
the device might get damaged / unusable.
1.2 Storage
You should ensure that the device is not exposed to direct sunlight, temperatures
which are too high or too low, vibrations, dust or a high level of humidity.
The ideal temperature range is between 0 and 40°C and a relative humidity of 85%
should not be exceeded.
The device should always be located on a rigid, smooth, horizontal surface.

OZB-A4515-BA-e-1810 4
2 Nomenclature
Mains cable
Housing
Main switch
Rotary dimmer
LED lights
Goosenecks

5 OZB-A4515-BA-e-1810
3 Technical data / Features
Product dimensions:
120x370x250 mm
Packaging dimensions:
300x250x250 mm
Net weight:
1,5 kg
Gross weight:
2 kg
Input voltage:
AC 100-240V, 50-60Hz
Fuse:
2A 5x20mm

OZB-A4515-BA-e-1810 6
4 Operation
1. Connect the power plug to the power outlet.
2. Power on the device by pressing the main switch.
3. Bend the flexible goosenecks in order to point the LED lights in the
preferred direction.
4. Select the preferred light intensity by turning the rotary dimmer.
5 Changing the bulbs
Please contact the KERN Optics Technical Service.
6 Changing the fuse
The fuse housing is on the rear of the illumination unit next to the mains power
supply entry. With the device switched off and unplugged, you can screw out the
housing. When doing this, it is helpful to use a screwdriver or similar tool. The
defective fuse can be removed from its housing and be replaced with a new one.
After that, you just need to insert the fuse housing back into the insertion point.

7 OZB-A4515-BA-e-1810
7 Service
If, after studying the user manual, you still have questions about commissioning or
using the illumination unit, or if unforeseen problems should arise, please get in touch
with your dealer. The device may only be opened by trained service engineers who
have been authorised by KERN.
8 Disposal
The packaging is made of environmentally-friendly materials, which you can dispose
of at your local recycling centre. Disposal of the storage box and device must be
carried out by the operator in accordance with all national or regional laws in force in
the location of use.
9 Further information
The illustrations may differ slightly from the product.
The descriptions and illustrations in this user manual are subject to change without
notice. Further developments on the device may lead to these changes.
All language versions contain a non-binding translation.
The original German document is the binding version.
