Kessel Aqatronic K Manual

INSTA ATION, OPERATING AND MAINTENANCE INSTRUCTIONS
KESSEL Aqatronic®Kswitching device
for K SS L
Aqabull® and Aqadive® rainwater pumping systems
Includes ultrasonic probe (20m cable length)
Digital level indicator for the rainwater tank
Reprogrammable switching points
Floating contact
Visual / acoustic backwater alarm
High level of operating safety and reliability
Nationwide service network
Art. Nr. 85 030
Product advantages
Name/Signature Date Town/City Specialist firm's stamp
Installation
on how to operate it are all provided by your local specialist
fir :
Putting into service Instruction
Revision Status: 08/2010
Reference Number: 010-495
Design and specifications are subject to
change without notice

2
Contents
1. General information .............................................................................................................................. Page 3
2. Safety Instructions .............................................................................................................................. Page 4
3. Technical Specifications .............................................................................................................................. Page 5
4. System Description .............................................................................................................................. Page 6
4.1 General system description.................................................................... Page 7
4.2
Aqabull system description..................................................................... Page 8
4.3
Aqadive system description.................................................................... Page 9
5. Installation 5.1 Switching device installation................................................................... Page 10
5.2 Ultrasound sensor installation ................................................................ Page 11
5.3 Installing the leakage probe.................................................................... Page 11
5.4 Levels and switching points in the tank .................................................. Page 12
6. Electrical Connection .............................................................................................................................. Page 13
7. Commissioning 7.1 Initial start-up.......................................................................................... Page 15
7.2 Normal operation.................................................................................... Page 15
7.3 Manual drinking water top-up (TWvH).................................................... Page 15
7.4 Other functions ....................................................................................... Page 16
7.5 Default factory settings........................................................................... Page 17
7.6 Checking the set values ......................................................................... Page 20
7.7 Changing the set values ......................................................................... Page 20
7.8 Master reset ........................................................................................... Page 21
8. Malfunctions and 8.1 Possible types of errors .......................................................................... Page 22
corrective action 8.2 Troubleshooting...................................................................................... Page 22
8.3 Simultaneous and Maintenance ............................................................. Page 23
9. Inspection and Maintenance .............................................................................................................................. Page 24
10. Warranty .............................................................................................................................. Page 25
11. Handover Certificate .............................................................................................................................. Page 27

3
1. General Information
Dear Customer,
Thank you for purchasing a K SS L pro-
duct.
The whole system was subjected to strict
quality control before leaving the factory.
Nevertheless, please check immediately
whether you have been delivered a com-
plete, undamaged system. If you find any
transport damage, please follow the in-
struction in the "Warranty" chapter of this
document.
These installation, operating and mainten-
ance instructions contain important infor-
mation which must be noted and follow du-
ring installation, operation, maintenance
and repair of the system. The owner / ope-
rator and the responsible skilled personnel
must carefully read this document before
carrying out any work on the system and
must follow the instructions given.
K SS L GmbH
Uses:
The Aqatronic K switching device is used to
control drinking water top-up and level mo-
nitoring for K SS L Aqabull and Aqadive
rainwater pumping systems.
In normal operation the water level in the
tank is displayed. Various functions can be
controlled using the buttons. Delivery inclu-
des an ultrasound sensor with which the
water level in the tank is measured.

2. Safety Instructions
The installation, operation, maintenance
and repair personnel must have the neces-
sary qualifications for this work. The
owner/operator must clearly define respon-
sibilities, accountability and monitoring of
the personnel.
Operating safety and reliability of the sup-
plied system is only guaranteed for its pro-
per intended use. The limit values given in
the technical specifications must never be
exceeded.
This system contains electrical voltages and
controls mechanical system parts. Failure to
follow the installation and operating instruc-
tions can result in substantial property da-
mage, physical injuries or even fatal acci-
dents.
The accident prevention regulations, rele-
vant DIN and VD standards and guidelines
as well as the regulations of the local power
supply company must be complied with du-
ring installation, operation, maintenance
and repair of the system.
The system is part of another, overall sy-
stem. You must therefore also note and fol-
low the operating instructions for the whole
system and the individual components.
ach time any installation, maintenance, in-
spection or repair work is carried out on one
of the components the whole system must
always be shut down and secured against
being switched back on again.
The system may not be operated in poten-
tially explosive atmospheres.
The switching device is live and may not be
opened. Qualified electricians only may
carry out work on electrical equipment. The
term "qualified electrician" is defined in VD
0105.
nsure that the electrical cables and all
other electrical parts of the system are in
perfect working order. If any damage oc-
curs, the system may not be started up and
must be repaired immediately.
The system has no effect on the quality of
the rainwater.
Modifications or changes to the system may
only be made in consultation with the ma-
nufacturer. Original spare parts and acces-
sories approved by the manufacturer help to
ensure safety. Use of other parts can can-
cel liability for any resulting consequences.
4

3. Technical Specifications
5
Voltage / frequency 230 VAC / 50 Hz
Power consumption of electronics 5W
Degree of protection / class IP54 / I
Temperature range 0 to 40 °C
Ultrasound sensor
Maximum measuring range / resolution 20 - 500 cm / 1 cm
Accuracy < 1% in relation to final value 500 cm dispersion angle 2a = 12° (sensitivity = 25)
Temperature range -10 to 40 °C
Degree of protection IP 67 / 5m for 10 min.; 1m for 24 hr.
Cable sheath diameter 6 mm
Cable sheath material PVC
Conductor cross-section 3 x 0.75 mm²
Cable length 20 metre
Changes to ultrasound sensor/cable to be made in consultation with KD only
Maximum cable length 80 metre, cable connection IP68 or better
Connection • Drinking water top-up 230VAC/ max. 450 W
• Output 1 = Rainwater filter rinsing 230VAC/ max. 450 W
• Output 2 = Operating safety 230VAC/ max. 450 W
• Floating contact 230 VAC / 2A; 10 - 30 V DC / 10 mA – 2 A;
without fusing and suppressor circuit for inductive loads
lectrical connections suitable for all copper conductors 0.08 - 2.5 mm2
Cable sheath diameter 5 - 9 mm
Leakage probe: a) Conductivity probe Conductivity range 10 - 1500µS / cm (for 3m cable length)
b) Optical probe Conductivity range unlimited
Dimensions • Housing L x W x H in mm 180x200x70
• Ultrasound probe Diameter x length in mm 85 x 80
Weight • Aqatronic K switching device 970 g
• Ultrasound probe without connection lead 260 g

1
6
7
8
9
2
3
4
14 15 16 17
13
5
10
11
12
20
19
18
4. System Description
Switching device housing
Screw M4x28 (4x)
Power supply cord 1.5m
Quick reference guide
7 segment display, 3-digit
L D green display, normal operation
L D orange display, drinking water top-up
L D orange display, output 1 =
rainwater filter rinsing
L D orange display, output 2 =
operating safety
"T" button
Up "▲" button
Down "▼" button
Ultrasound sensor connection
Drinking water top-up connection
Rainwater filter rinsing connection
Operating safety connection
Floating contact connection
Leakage probe connection
Ultrasound sensor with 20m connection
lead
Mounting plate with accessories for fixing
the ultrasound sensor
6

7
4. System Description
4.1 General system description
7 segment display, 3-digit (5)
In normal operation the current water level is
displayed in cm. The following are also dis-
played: Top-up time, error, set points and set
values.
ED green display, normal operation (6)
In normal operation the green LED is lit.
ED orange display, drinking water top-
up (7)
The orange LED is lit during drinking water
top-up.
ED orange display, output 1 = rainwater
filter rinsing (8)
The orange LED is lit if output 1 is activated.
ED orange display, output 2 = operating
safety (9)
The orange LED is lit if output 2 is activated.
"T" button (10)
The "T" button is used to manually switch on
drinking water top-up. In addition, the "T"
button is used to acknowledge errors, to
switch off the acoustic alarm, to select set
points and to save set values.
"▲
▲" button (11) and "▼ ▼" button (12)
The two "▲" and "▼" buttons are used to sel-
ect set points and set values.
Ultrasound sensor (19)
The ultrasound sensor measures the water
level in the tank.
The Aqatronic K switching device is used to
control drinking water top-up and level mo-
nitoring for KESSEL Aqabull and Aqadive
rainwater pumping systems.
The difference between the two systems is
the type of drinking water top-up and the lo-
cation of the pump.
With the KESSEL Aqabull rainwater pum-
ping system the water is topped up as and
when necessary via a separate top-up sup-
ply tank. The pump is located outside the
tank. With the KESSEL Aqadive rainwater
pumping system the top-up supply is fed di-
rectly into the tank. The pump is located in-
side the tank.
Note:
If the Aqatronic K switching device is
purchased without the rainwater pumping
system the switching device is in the Aqabull
basic setting.

8
4. System Description
4.2 Aqabull system description
 Gutter, downpipe
 Rainwater drain with silt trap
 Rainwater filter
 Rainwater filter rinsing
 Solenoid valve, rainwater filter rinsing
 Tank
 Inlet calming device
 Overflow trap
 Intake with float
 Drinking water top-up supply tank
 Float valve
 Solenoid controlled emergency
mains supply
 mergency overflow with odour trap
 Leakage probe
 Pump with automatic pressure switch
 3-way changeover valve,
drinking water top-up
 Aqatronic K switching device
 Ultrasound sensor
 Non-potable water system
3a
3b
4a
4b
4c
5a
5b
6a
9a
1
5b
5a
5
6
7
8
9
10
2
3
3a
3b
4
4a
4b
9a
4c
6a

4. System Description
4.3 Aqadive system description
 Gutter, downpipe
 Rainwater drain with silt trap
 Rainwater filter
 Rainwater filter rinsing
 Solenoid valve, rainwater filter rinsing
 Tank
 Inlet calming device
 Overflow trap
 Intake with filter
 Pump
 Automatic pressure switch
 Service water system shut-off valve
 Drinking water top-up
 Solenoid valve, drinking water top-up
 Solenoid valve, operating safety, drinking
water top-up
 Leakage probe
 Non-potable water system
 A qatronic K switching device
 Ultrasound sensor
3a
3b
4a
4b
4c
7b
7a
6a
7c
9a
9
1
2
4a
4b
4c
5
6
7
7a
6a
3b
7b
7c
89
9a
3
3a
4

10
5. Installation
5.1 Switching device installation
Note and follow the Safety Instructions
chapter!
In a K SS L Aqabull or Aqadive rainwater
pumping system the switching device is an
integral part of the system and is already
completely installed. If used separately, the
switching device is installed in a suitable po-
sition, e.g. mounted on the wall at eye level.
To do this, remove the four screws M4x25,
pull up the cover slightly and open up. Use
the 4 screws 3.5x30 to fix the control box to
the wall as illustrated. The screws as well as
plastic wall plugs and a drilling template are
included with the device.
Hinge (2x)
Plastic wall plug 5mm (4x)
Screw 3,5x30 (4x)
Cover screws (4x)
1
1
2
3
4
Schematic diagram of the switching device without electronic components.

11
5. Installation
5.2 Ultrasound sensor installation
the following must be noted:
 "Safety instructions" chapter
 Handle the ultrasound sensor with care
 Do not damage the sealing rubber bet-
ween the attachment and tank
 The ultrasound sensor must be aligned
perpendicular to the surface of the
water. The maximum deviation is 2°
 Ensure there are no objects between the
ultrasound sensor and the surface of the
water (e.g. ball of the floating extractor)
 The distance between the bottom edge
of the sensor housing and the highest
water level in the tank must be greater
than 20 cm
 The levels and switching points in the
tank (see following diagrams)
 The ultrasound sensor must be secured
with the bracket.
 The connection cable must be secured
with strain relief (cable grip).
5.3 Installing the leakage probe
Note and follow the "Safety
Instructions" chapter!
Install the leakage probe as given in the
original operating instructions.

12
5. Installation
5.4 evels and switching points
in the tank
Important!
Tank height >= RSP + 15cm > OSP >=
USP + 1cm
Set value range
50-500 cm
35-485 cm
10-60 cm
0-50 cm
Factory setting
No default setting
No default setting
21 cm
20 cm
Pers. Ein stellung in cm Set point
Tank height
Backwater switching point RSP
pper switching point OSP
Lower switching point SP
Tank height
Backwater switching point RSP
Upper switching point OSP
Lower switching point USP

13
6. Electrical Connection
Important!
To be connected by a qualified electrici-
an only. Comply with the relevant, cur-
rently valid regulations, laws and stan-
dards. Also read and follow the "Safety
Instructions" chapter. The seals of the
cable glands which are not used, i.e. no
cable is connected through them, may
not be penetrated. They help to seal the
housing.
The connection lead of the ultrasound sen-
sor must be connected in accordance with
the circuit diagram (see next page). First,
use a screwdriver to push through the cable
gland seal concerned (Figure a), feed
through the cable (Figure b) and connect
(Figure c).
Then tighten the nut of the cable gland by
hand (Figure d).
Note the technical specifications when
connecting the drinking water top-up supp-
ly, outputs 1 and 2, the floating contact and
the leakage probe. Use products approved
by the manufacturer only. Otherwise the
above text applies.
Do not penetrate the seals of the cable
glangs which are not used, i.e. through
which a cable is not connected. hey
help to seal the housing

14
6. Electrical Connection
Important!

 To be connected by a qualified electri-
cian only.

 Comply with the relevant, currently
valid regulations, laws and standards.

 Also read and follow the "Safety In-
structions" chapter.

 If the potential free contact is connec-
ted, a very dangerous interference vol-
tage may exist at the terminals, even if
the mains plug has been disconnec-
ted.

 If the potential free contact is connec-
ted with 230 VAC the same phase must
be used as for the mains connection.
Z = additional equipment
ZLT = central measurement and control
Connection plan
Mains
230 ~
50 Hz
3-way changeo-
ver valve 230 ~
50 Hz
Solenoid valve,
drinking water
top-up
230 ~ 50 Hz
Solenoid valve,
rainwater filter
rinsing
230 ~ 50 Hz
Solenoid valve,
operating safety
230 ~ 50 Hz
Floating contact
Ultrasound sensor
Leakage probe
(conductivity probe)
Leakage probe
(optical probe)
optical probe

7.1 Initial start-up
Note and follow the "Safety Instruc-
tions" chapter!
If all the electrical and mechanical compo-
nents have been properly connected, the
system can now be put into service.
 Plug the mains plug into the earthing
socket.
 The switching device displays the cur-
rent version number.
 Soon after, "HHH" appears.
 Press the "T" button
 020" appears in the display
 An acoustic signal is emitted.
 Use the "▲" and "▼" buttons to set the tank
height in cm.
 Press the "T" button for more than 2 se-
conds to confirm the value.
 An acoustic signal is emitted.
 Value has been saved
The device is in normal operation. After a
short time the current water level is display-
ed in cm. The green L D for normal opera-
tion is lit. The device is running with the de-
fault factory settings. These are shown in
the table "5.4 Default factory settings"
7.2 Normal operation:
In normal operation, the switching device
compares the water level in the tank with
the set switching points. If there is sufficient
water in the rainwater tank (water level
above the USP) the system runs in rainwa-
ter mode, i.e. when a fixture (i.e. toilet, fau-
cet) connected to the service water system
is opened, rainwater is pumped into the
pipe network. If the water level falls below
the USP, the drinking water top-up is auto-
matically activated until the water level has
reached the OSP. Activation of the drinking
water top-up is indicated by the orange drin-
king water top-up L D.
7.3 Manual drinking water top-up
( WvH)
The "T" button can be used to switch on
drinking water top-up (TWvH). TWvH auto-
matically switches off after a defined time.
The TWvH time is stored in set point 02
and can be changed at any time. During
TWvH the remaining time in minutes ap-
pears in the display. The decimal points of
the display flicker and the orange drinking
water top-up L D is lit. The TWvH can be
switched off manually at any time.
15
7. Commissioning

7. Commissioning
16
7.4 Other functions:
a) Backwater switching point
This has a different effect on the drinking
water top-up depending on the two system
types:
Aqabull:
Drinking water top-up is switched on auto-
matically. The non-potable water system is
supplied directly from the drinking water
top-up tank until the error is acknowledged
at the switching device.
Aqadive:
Drinking water top-up is blocked until the
error is acknowledged at the switching de-
vice.
b) Rainwater filter rinsing
The rainwater filter is rinsed at regular in-
tervals. Activation of this function and the
times for the rinsing interval and duration
can be set as required. Rainwater filter rin-
sing can be switched on manually at any
time.
c) Detection of leaking water
If the leakage probe detects water, the
drinking water top-up, output 1, output 2,
the floating contact and the acoustic alarm
are affected according to the selected set-
tings.
d) he floating contact
The floating contact is used to signal a
mains power failure or error.
e) Sensitivity of the ultrasound sensor
The sensitivity of the ultrasound sensor
can be adjusted to match the installation
conditions.

17
7. Commissioning
7.5 Default factory settings
Set point Significance Range of the set values Factory setting Your personal
setting
00 Master reset
01 The device determines the
distance to the surface of
the water in cm
02 Manual drinking water
top-up time 001 to 999 = 1 - 999 minutes 001 = 1 minute
03 System type 000 = Aqadive
001 = Aqabull 001
10 Tank height 050 bis 500 = 50 - 500 cm No default setting
11 Lower switching point USP,
drinking water top-up 000 bis 050 = 0 - 50 cm 020 = 20 cmg
12 Upper switching point OSP 010 bis 060 = 10 - 60 cm
drinking water top-up OSP >= USP + 1cm 021 = 21cm
13 Backwater switching point 035 bis 485 = 35 - 485 cm
RSP tank height >= RSP + 15cm No pre-setting

Set point Significance Range of the set values Factory setting Your personal
setting
20 Rainwater filter rinsing 000 = Time control inactive 000
001 = Time control active
002 = Immediate operation active, i.e.
rinsing starts immediately
23 Time interval of the rinsing 001 bis 020 = 1 - 20 weeks 001 = 1 week
24 Rinsing duration 001 bis 999 = 1 - 999 seconds 030 = 30 seconds
P40 Leakage probe 000 = no leakage probe installed 000
001 = leakage probe is an optical probe
002 = leakage probe is a conductivity probe
P41 ffect on drinking water 000 = no effect 000
top-up if leaking water is 001 = switch on drinking water top-up
detected 002 = switch off drinking water top-up
P42 ffect on rainwater filter 000 = no effect 000
rinsing if leaking water is 001 = switch on rainwater filter rinsing
detected 002 = switch off rainwater filter rinsing
18
7. Commissioning

Set point Significance Range of the set values Factory setting Your personal
setting
P43 ffect on operating safety 000 = no effect 002
output water if leaking water 001= switch on operating safety
is detected 002 = switch off operating safety
P44 ffect on the floating contact 000 = floating contact relay remains picked up 001
and acoustic alarm if 001 = floating contact relay drops out
leaking water is detected 001 = acoustic alarm on
P50 Inversion of drinking 000 = not inverted 000
water top-up 001 = inverted
P51 Inversion of rainwater 000 = not inverted 000
filter rinsing 001 = inverted
P53 Inversion of operating 000 = not inverted 001
safety output 001 = inverted
P54 Inversion of floating 000 = not inverted 001
contact relay 001 = inverted
P70 Sensitivity of the 000 to 050; 025
ultrasound sensor 000 = insensitive
050 = sensitive
025 = average sensitivity
7. Commissioning
19

7. Commissioning
20
7.6 Checking the set values:
In normal operation the "T", "▲" and "▼" but-
tons can be used to check set values.
A set value is assigned to each set point
(see default factory settings table).
Important! A master reset is performed
under set point E00. he distance to the
surface of the water is measured under
set point E01.
 Simultaneously press "T", "▲" and "▼"
buttons.
 An acoustic signal is emitted and 00
is displayed.
 Use the "▲" and "▼" buttons to select the
required set point.
 Confirm with "T" button.
 The set value is displayed.
 Briefly press the "T" button.
 The set point is displayed again.
 Press the "T" button until an acoustic sig-
nal is emitted.
 The device is in normal operation.
If the "T" button is not pressed for 20 se-
conds, the device automatically switches to
normal operation. At the same time, an
acoustic signal is emitted.
7.7 Changing the set values:
In normal operation the "T", "▲" and "▼" but-
tons can be used to change set values.
A set value is assigned to each set point
(see default factory settings table).
Important! A master reset is performed
under set point E00. he distance to the
surface of the water is measured under
set point E01.
