KD-DH12
KD-DH12 is a digital (ATSC) and analog (NTSC) Video/Audio tuner, switcher, video processor
and distribution amplifier with capability of switching, scaling and distributing between
switchable 2 RF, 1 Composite and 1 Component Inputs to up to 12 HDTV/Component Outputs
KD-DH12
Cable Box
RF Antenna
RF Antenna
Component
ATSC/NTSC
ATSC/NTSC
Component
Component
Component
Component
Component
Component
Component
Component
Component
Component
Component
Component
RS232 Control
Optical IR
Tradeshow Booth Application
Model: KD-DH12
Key Digital
®
Exclusive Technologies Supported Technologies
4Distributes 2 RF (ATSC/NTSC) input (480i, 1080i) up to
12 HDTV/Component (480p, 720p, 1080i) outputs/displays
4Distributes 1 Component Video input (480i, 480p, 720p,
1080i) up to 12 HDTV (480p, 720p, 1080i) outputs/displays
4Distributes 1 Composite input (480i) up to
12 HDTV/Component (480p, 720p, 1080i) outputs/displays
4Each output can be individually switched to black
video (mute) from IR, RS232 or OFF Button
4Supports Left, Right analog stereo, and Coaxial/Digital
(PCM) Audio
4Each channel/output can support cable runs up to 300 ft.
4Can be daisy chained to support additional output
to more displays
4Incorporates 5 Key Digital™Exclusive Technologies
4Optical IR, RS 232, Front Panel Controls with LCD,
RCA connectors
Key Benefits
Key Solutions General Info
Is a digital (ATSC) analog (NTSC) tuner that distributes the tuned signal along with
any other video input them up to 12 HDTV/Component Video/Audio outputs/displays
Is heat resistant and can withstand noisy environments
Built-in video amplifier circuitry allows cable (RG6) runs up to 300 ft.
without signal degradation
Supports 3rd party control systems via RS232 and IR
›
›
›
›
Power: 100VAC to 240VAC,
50Hz and 60Hz, NTSC, PAL
Rack Mount: Yes -2U
Remote Control: Included
Enclosure Type: Metal
Dimensions:
17.5” x 10.5” x 3.5”
Shipping Carton Dimensions:
23” x 13” x 6”
Product Weight: 12 lbs
Shipping Weight: 14 lbs
›
›
›
›
›
›
›
›
Video/Audio Distribution Amps
