Keys Fitness Power System KF-2060 User manual

Owner’s Manual
215-00132
11/06 Rev A
KF-2060

Table of Contents
2
Before You Start 3
Important Safety Information 4
Assembly 5-40
Weight Ratios 41
Weight Stack Sticker Placement 42
Cable View 43
Top View 44
Exploded View 45
Parts List 46
Warranty Information 47

Before You Start
3
KEYS FITNESS SERIES
QUESTIONS?
CALL
1-888-380-0482
Monday-Friday
8:30-5:30 Central Time
When calling please have the following product information available:
Model Name : KF-2060
Serial #:
Manufactured Date :
PO # :
Model Name Decal Location
THANK YOU for making this unit a part of your exercise program.
Keys Fitness assures the very best in value, appearance, durability
and biomechanics.
This manual will guide you through the assembly process. If at any
time you are having trouble with the assembly or use of this product, then
please contact us at our Keys Fitness Helpline. We have trained service techni-
cians on site to take care of you, our valued customer.
REGISTRATION CARD
To avoid unnecessary delays in warranty parts and to insure that a permanent
record of your purchase is on file with our company, be sure to send in the war-
ranty registration card or register on-line at www.keysfitness.com within 10 days
of purchase.

Important Safety Information
4
Prior to assembly, remove components from the box and verify that all the listed parts were
supplied.
WARNING!
Before using this unit or starting any exercise program, consult your
physician. This is especially important for persons over the age of
35 and/or persons with pre-existing health problems. Keys Fitness
Products LP assumes no responsibility for personal injury or property
damage sustained by or through the use of this product.
It is the owner’s responsibility to ensure that all users of this unit
have read the Owner’s Manual and are familiar with safety informa-
tion and precautions.
SAFETY PRECAUTIONS
• This unit should only be used on a level surface and is intended for
indoor use only. Keys Fitness recommends an equipment mat be
placed under the unit to protect the floor or carpet and for easier
cleaning.
• Wear comfortable, good-quality walking or running shoes and
appropriate clothing. Do not use this unit with bare feet, sandals,
socks or stockings!
• Always examine your unit before using to ensure all parts are in
working order.
• Do not leave children unsupervised near or on the unit.
• Service to your unit should only be performed by an authorized
service representative, unless authorized and/or instructed by a
Keys Fitness technician. Failure to follow these instructions will void
the warranty.
NOTE:Hand tighten bolts and nylon nuts until machine is fully assembled.
Read all precautions and instructions in this manual before using this equipment.

Box 1
Assembly
5

Box 2
Assembly
6

Box 3
Assembly
7

Box 4
Assembly
8

Box 5
Assembly
9

Assembly
10
Box 6

【５２】５pcs
【５２】５pcs
【５３】９pcs
【５３】９pcs
【５４】５pcs
【５４】５pcs
Assembly
11
Box 7 Box 8
Box 10
Box 12
Box 9
Box 11

Assembly
12

Assembly
13

Assembly
14

Step 1
Attach Right Base Frame (4) to Rear Frame (1) using two Nuts (144), four Washers
(143), and two Bolts (137).
Attach Left Base Frame (8) to Rear Frame (1) using two Nuts (144), four Washers
(143), and two Bolts (137).
Insert Guide Rods (47) into Rear Frame (1). Next, slide Weight Stack Bumpers (99)
onto Guide Rods (47).
Attach Rear Upright (3) to Rear Frame (1) using two Nuts (144), four Washers (143),
and two Bolts (136).
Assembly
15
Figure 1

Assembly
16
Step 2
Slide the weight plates down the Guide Rods (47) in this order - five 15lb Plates (52), nine
10lb Plates (53), five 5lb Plates (54), and the Top Plate (55). Note: Number of weight plates
may vary depending on your specific configuration.
Attach Top Frame (2) to all four Guide Rods (47) and secure to Rear Upright (3) using two
Nuts (144), four Washers (143), and two Bolts (136).
Figure 2

Assembly
17
Step 3
Attach Front Upright (19) to Seat Pad Support Receptacle (6) using two Nuts (144), four
Washers (143), and two Bolts (136).
Attach Seat Pad Support Receptacle (6) to Base Frame assembly using two Nuts (144), four
Washers (143), and two Bolts (136).
Figure 3

Step 4
Attach Main Upright (7) to Seat Pad Support Receptacle using two Nuts (126), four Washers
(125), and two Bolts (131).
Attach Right Top Frame (5) to Top Frame assembly using two Nuts (144), four Washers (143),
and two Bolts (137). Next, use two Washers (143), two Spring Washers (119), and two Bolts
(142) to connect Right Top Frame (5) to Main Upright.
Assembly
18
Figure 4

Step 5
Slide Press Station Base Frame (11) over Press Arm Support (10). Next, attach both pieces
to Base Frame using two Nuts (144), four Washers (143), and two Bolts (134).
Install Left Top Frame over Press Arm Support (10) and Top Frame assembly. Secure top
section using two Nuts (144), four Washers (143), and two Bolts (137). Next, Secure lower
section using two Nuts (144), four Washers (143), and two Bolts (136). Secure top of Guide
Rods (47) using two Washers (143), two Spring Washers (119), and two Bolts (142).
Assembly
19
Figure 5

Assembly
20
Step 6
Attach Pec Dec Mount (21) onto Seat Pad Support Receptacle using two Nuts (144), four
Washers (143), and two Bolts (136). Secure in place with one Washer (129), one Spring
Washer (119), and one Bolt (137).
Figure 6
