AEMC 193-24-BK User manual

nCOMPATIBLE CURRENT
PROBES & SENSORS FOR
POWER QUALITY METERS
193-24-BK
193-36-BK
MA193-BK
MN93-BK
MN193-BK
MR193-BK
SL261-BK
SR193-BK
ENGLISH User Manual
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Thank you for purchasing an AEMC current probe.
For best results from your instrument and for your safety, read the enclosed
operating instructions carefully and comply with the precautions for use. These
products must be only used by qualied and trained users.
WARNING, risk of DANGER! The operator must refer to these instructions
whenever this danger symbol appears.
CAUTION! Risk of electric shock. The voltage at the
parts marked with this symbol may be dangerous.
Application or withdrawal authorized on conductors carrying dangerous voltages.
Type A current sensor as per IEC 61010-2-032.
Must not be applied to or removed from conductors at dangerous voltages.
Type B current sensor as per IEC 61010-2-032.
Equipment is protected by double insulation.
Battery
Important instructions to read and to fully understand.
Useful information or tip to read.
The CE marking guarantees conformity with European directives and with
regulations covering EMC.
The trash can with a line through it means that in the European Union, the
product must undergo selective disposal for the recycling of electric and
electronic material, in compliance with Directive WEEE 2002/96/EC.
Denition of Measurement Categories (CAT)
CAT IV Measurement category IV corresponds to measurements taken at the
source of low-voltage installations.
Example: power feeders, counters and protection devices.
CAT III Measurement category III corresponds to measurements on building
installations.
Example: distribution panel, circuit-breakers, machines or xed indus-
trial devices.
CAT II Measurement category II corresponds to measurements taken on cir-
cuits directly connected to low-voltage installations.
Example: power supply to domestic electrical appliances and portable
tools.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

PRECAUTIONS BEFORE USE
The protection assured by the current probe can be compromised if it is used in a
way that is not recommended by the manufacturer.
■Comply with the rated maximum voltage and current, and the measurement
category. Do not use the current probe on networks where the voltage or
category exceeds those specied.
■Comply with the conditions of use (e.g. temperature, humidity, altitude, degree
of pollution, location).
■Do not use the current probe if its housing is open, deteriorated, or incorrectly
reassembled. Before each use, check the integrity of the insulation of the unit,
jaws, clamps, housing, and leads.
■Do not subject the current probe to water or other liquids.
■Keep the jaw contacts of the clamp absolutely clean.
■Use suitable personal protective equipment when hazardous voltages may be
accessible in the installation where the measurement is made.
■Any repairs must be carried out by accredited skilled personnel.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

2Custom Current Probes & Sensors
Table of Contents
1. INTRODUCTION .....................................................................3
1.1 Receiving Your Shipment......................................................................3
1.2 Ordering Information.............................................................................3
2. PRODUCT FEATURES ............................................................4
2.1 Control Features...................................................................................4
2.1.1 AmpFlex®Model 193-24-BK & 193-36-BK ...............................4
2.1.2 MiniFlex®Model MA193 ...........................................................5
2.1.3 AC Current Probe Model MN93 & MN193................................6
2.1.4 AC Current Probe Model MR193..............................................7
2.1.5 AC Current Probe Model SL261...............................................8
2.1.6 AC Current Probe Model SR193 ..............................................9
3. OPERATION..........................................................................10
4. SPECIFICATIONS .................................................................12
4.1 Electrical .............................................................................................12
4.2 Environmental.....................................................................................13
4.3 Mechanical..........................................................................................13
4.4 Safety..................................................................................................13
5. MAINTENANCE ....................................................................15
5.1 Cleaning..............................................................................................15
5.2 Battery Replacement ..........................................................................15
5.2.1 Model MR193 .........................................................................15
5.2.2 Model SL261 ..........................................................................15
5.3 Repair and Calibration........................................................................16
5.4 Technical and Sales Assistance..........................................................16
5.5 Limited Warranty.................................................................................17
5.6 Warranty Repairs................................................................................17
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Custom Current Probes & Sensors 3
1. INTRODUCTION
1.1 Receiving Your Shipment
Upon receiving your shipment, make sure that the contents are consistent with the
packing list. Notify your distributor of any missing items. If the equipment appears
to be damaged, le a claim immediately with the carrier and notify your distributor
at once, giving a detailed description of any damage. Save the damaged packing
container to substantiate your claim.
1.2 Ordering Information
NOTE: The current probes in this manual are compatible only with AEMC®Models
8220, 8230, 3945-B, 8335 and PEL100 Series.
AmpFlex®Sensor 24" Model 193-24-BK ..........................................Cat. #2140.34
AmpFlex®Sensor 36" Model 193-36-BK ..........................................Cat. #2140.35
MiniFlex®Sensor 10" Model MA193-10-BK......................................Cat. #2140.48
AC Current Probe Model MN93-BK..................................................Cat. #2140.32
AC Current Probe Model MN193-BK................................................Cat. #2140.36
AC Current Probe Model MR193-BK................................................Cat. #2140.28
AC Current Probe Model SR193-BK ................................................Cat. #2140.33
AC/DC Current Probe Model SL261* ...............................................Cat. #1201.51
* Adapter for SL261 - BNC Adapter............................................Cat. #2140.40
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

4Custom Current Probes & Sensors
2. PRODUCT FEATURES
2.1 Control Features
2.1.1 AmpFlex®Model 193-24-BK & 193-36-BK
2
3
4
1
1. Flexible sensor
2. Sensor opening connector
3. Shielded lead
4. Custom 4-pin input connector
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Custom Current Probes & Sensors 5
2.1.2 MiniFlex®Model MA193
2
3
4
1
1. Flexible sensor
2. Sensor opening device
3. Shielded lead
4. Custom 4-pin input connector
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

6Custom Current Probes & Sensors
2.1.3 AC Current Probe Model MN93 & MN193
200V CAT IV
600V CAT III 200A
5
4
2
3
6
1
1. Jaws
2. Protective guard
3. Two-position range switch (MN93 only)
4. Jaw opening lever
5. Shielded lead
6. Custom 4-pin input connector
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Custom Current Probes & Sensors 7
2.1.4 AC Current Probe Model MR193
5
2
4
3
7
6
1
1. Jaws
2. Protective guard
3. Jaw opening lever
4. Two-position range switch
5. Shielded lead
6. Zero adjustment
7. Custom 4-pin input connector
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

8Custom Current Probes & Sensors
2.1.5 AC Current Probe Model SL261
2
3
5 6
4
1
1. Jaws
2. Zero adjust knob
3. Range selection switch
4. Battery compartment screw
5. Battery compartment cover
6. BNC Adapter (sold separately - Cat. #2140.40)
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Custom Current Probes & Sensors 9
2.1.6 AC Current Probe Model SR193
4
2
3
5
1
1. Jaws
2. Protective guard
3. Jaw opening lever
4. Shielded lead
5. Custom 4-pin input connector
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

10 Custom Current Probes & Sensors
3. OPERATION
The current probes and exible sensors are used to measure the current owing
in a conductor or bus bar without opening the circuit. They also insulate the user
from dangerous voltages in the circuit.
The choice of current probe or sensor to be used depends on the amperage to be
measured and the diameter of the cables or size of the bus bar.
■For three-phase measurements, use the color-coded ID markers to associate
a color for each current input to match the phase identiers on the measured
system.
NOTE: Always connect the probes with the indicating arrows pointing toward the
load.
For Example Only (instrument may vary):
■Connect the current probe or sensor to the current terminals of the instrument.
For MR193 and SL261 Probes:
■MR193: Set the switch to 1mV/A; the ON indicator will light up.
SL261: Set the switch to 10mA or 100mA/A; the ON indicator will light up.
■Connect the probe to the instrument.
■Adjust the zero by turning the potentiometer with no conductor in the jaws of the
clamp.
■When the measurement is nished, turn the probe switch to OFF.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Custom Current Probes & Sensors 11
For Probes:
■Press the jaw opening lever on the probe to open the jaws.
■Clamp the probe around the conductor to be tested. For best results, center the
conductor in the jaws of the clamp.
I
For AmpFlex® and MiniFlex® Sensors:
■AmpFlex®: Press simultaneously on both sides of the opening connector.
■MiniFlex®: Press the opening device to open the exible sensor.
■Clamp the sensor around the conductor to be tested. For best results, center the
conductor in the jaws of the clamp.
■Close the sensor by pushing the moving part into the connector until it clicks.
NOTE: For details of the measurement configuration and technical specifications,
refer to the user manual of the instrument the current probe is being used with.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

12 Custom Current Probes & Sensors
4. SPECIFICATIONS
4.1 Electrical
The current probes listed are compatible with AEMC®Models 8220, 8230, 3945-B,
8335 and PEL 100 Series.
NOTE: The measurement ranges specied are for the probes and sensors.
In some cases, they may differ from the ranges that can be measured by the
instrument with which they are used with.
Model Measurement Range Clamping Diameter
AmpFlex®193-24-BK
24"(610mm)
50mA to 6500AAC*
(12,000A)** 7.64"(190mm)
AmpFlex®193-36-BK
36"(910mm)
50mA to 6500AAC*
(12,000A)** 11.46"(290mm)
MiniFlex®MA193
10"(250 mm)
50mA to 3000A*
(12,000A peak)** 2.75"(70mm)
MN93 2 to 240AAC
(I >200A not permanent) 0.8"(20mm)
MN193 5A: 0.005 to 6AAC
100A: 0.1 to 120AAC 0.8"(20mm)
MR193 10 to 1000AAC;
10 to 1300APEAK AC+DC
One 1.6"(42mm) or two 0.98"
(25mm) or two bus bars
1.96 x 0.19"(50 x 5mm)
SL261 100mV/A: 100mA to 10A peak
10mV/A: 1 to 100A peak 0.46"(11.8mm)
SR193 1 to 1200AAC
(I > 1000A not continuously) 2"(52mm)
*200mA to 10,000A measurement range for the PEL 100 Series.
**12,000A is specied for the PEL 100 Series only.
NOTE: For specific Min/Max values, refer to the product user manual that is sup-
plied with each instrument.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Custom Current Probes & Sensors 13
4.2 Environmental
Indoor use.
Operating Temperature: 14° to 131°F (-10° to 55°C); 10% to 85% RH
Storage Temperature: -40° to 158°F (-40° to 70°C); 10% to 90% RH
Degree of pollution: 2
Altitude: < 2000 m
4.3 Mechanical
Model Cable Length
(nominal)
Dimensions Weight
AmpFlex®193-24-BK
24"(610mm) 10 ft (3m) 6.6 x 6.2 x .98"
(170 x 158 x 25mm) 7.7 oz (270g)
AmpFlex®193-36-BK
36"(910mm) 10 ft (3m) 11 x 10.4 x .98"
(280 x 265 x 25mm) 9.5 oz (220g)
MiniFlex®MA193
10"(250mm) 10 ft (3m) 4.0 x 2.5 x 1.1"
(103 x 64 x 28mm) 1.94 oz (55g)
MN93 10 ft (3m) 5.47 x 2.00 x 1.18"
(135 x 51 x 30mm) 24 oz (690g)
MN193 10 ft (3m) 5.47 x 2.00 x 1.18"
(135 x 51 x 30mm) 24 oz (690g)
MR193 10 ft (3m) 8.8 x 3.82 x 1.73"
(224 x 97 x 44mm) 19 oz (540g)
SL261 6.5 ft (1.9m) 9.09 x 1.42 x 2.64"
(231 x 36 x 67mm) 11.6 oz (330g)
SR193 10 ft (3m) 8.5 x 4.4 x 1.8"
(216 x 111 x 45mm) 24 oz (690g)
4.4 Safety
Protection index IP 40 for the probes and IP 30 jaws open, according to IEC 60 529
■IP 65 for the AmpFlex®according to IEC 60 529
■IK 04 according to IEC 50102
Drop test: According to IEC 61010-1
Electrical safety according to IEC 61010-2-032.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

14 Custom Current Probes & Sensors
Maximum applicable voltage:
AmpFlex®: 1000V CAT III; 600V CAT IV
MiniFlex®: 1000V CAT III; 600V CAT IV
MN93 /MN193: 600V CAT III; 300V CAT IV
MR193: 600V CAT III; 300V CAT IV
SL261: 600V CAT III
SR193: 1000V CAT III; 600V CAT IV
Specications are subject to change without notice.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Custom Current Probes & Sensors 15
5. MAINTENANCE
Use only factory specied replacement parts. AEMC®will not be held responsible
for any accident, incident, or malfunction following a repair done other than by its
service center or by an approved repair center.
CAUTION: Risk of electric shock. Disconnect the instrument from any source of
electricity.
5.1 Cleaning
■Use a soft cloth, dampened with soapy water. Rinse with a damp cloth
and dry rapidly with a dry cloth.
■Do not use alcohol, solvents, or hydrocarbons.
■Do not splash water directly on the instrument.
5.2 Battery Replacement
5.2.1 Model MR193
■Disconnect the MR193 completely and turn the rotary switch to OFF.
■Use a screwdriver to unscrew the screws and remove the battery
compartment cover on the backside of the unit.
■Withdraw the battery from its compartment.
■Disconnect the old battery without pulling on the wires and replace with
a new one, observing the polarity.
■Put the battery into its compartment.
■Put the cover back in place and screw the screws back in.
5.2.2 Model SL261
■Disconnect the SL261 completely and turn the rotary switch to OFF.
■Unscrew the battery compartment screw and pull off the battery
compartment cover.
■Replace the battery with a new one, observing the polarity.
■Put the cover back in place and screw the screw back in.
Used batteries must not be treated as ordinary household waste.
Recycle them appropriately.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

16 Custom Current Probes & Sensors
5.3 Repair and Calibration
To ensure that your instrument meets factory specications, we recommend
that it be scheduled back to our factory Service Center at one-year intervals for
recalibration, or as required by other standards or internal procedures.
For instrument repair and calibration:
You must contact our Service Center for a Customer Service Authorization Number
(CSA#). This will ensure that when your instrument arrives, it will be tracked
and processed promptly. Please write the CSA# on the outside of the shipping
container. If the instrument is returned for calibration, we need to know if you want
a standard calibration, or a calibration traceable to N.I.S.T. (Includes calibration
certicate plus recorded calibration data).
Ship To: Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments
15 Faraday Drive
Dover, NH 03820 USA
Phone: [phone] (Ext. 360)
[phone] (Ext. 360)
Fax: [phone] or [phone]
E-mail: [email protected]
(Or contact your authorized distributor)
Costs for repair, standard calibration, and calibration traceable to N.I.S.T. are avail-
able.
NOTE: You must obtain a CSA# before returning any instrument.
5.4 Technical and Sales Assistance
If you are experiencing any technical problems, or require any assistance with the
proper operation or application of your instrument, please call, mail, fax or e-mail
our technical support team:
Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments
200 Foxborough Boulevard
Foxborough, MA 02035 USA
Phone: [phone]
[phone]
Fax: [phone]
E-mail: [email protected]
www.aemc.com
NOTE: Do not ship Instruments to our Foxborough, MA address.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

Custom Current Probes & Sensors 17
5.5 Limited Warranty
The current probes and sensors are warranted to the owner for a period of one
year from the date of original purchase against defects in manufacture. This limited
warranty is given by AEMC®Instruments, not by the distributor from whom it was
purchased. This warranty is void if the unit has been tampered with, abused or if
the defect is related to service not performed by AEMC®Instruments.
Full warranty coverage and product registration is available on our website at
www.aemc.com/warranty.html.
Please print the online Warranty Coverage Information for your records.
What AEMC® Instruments will do:
If a malfunction occurs within the one-year period, you may return the instrument
to us for repair, provided we have your warranty registration information on le or
a proof of purchase. AEMC®Instruments will, at its option, repair or replace the
faulty material.
5.6 Warranty Repairs
What you must do to return an Instrument for Warranty Repair:
First, request a Customer Service Authorization Number (CSA#) by phone or by
fax from our Service Department (see address below), then return the instrument
along with the signed CSA Form. Please write the CSA# on the outside of the ship-
ping container. Return the instrument, postage or shipment pre-paid to:
Ship To: Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments
15 Faraday Drive
Dover, NH 03820 USA
Phone: [phone] (Ext. 360)
[phone] (Ext. 360)
Fax: [phone] or [phone]
E-mail: [email protected]
Caution: To protect yourself against in-transit loss, we recommend you insure
your returned material.
NOTE: You must obtain a CSA# before returning any instrument.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

03/13
99-MAN 100391 v1
Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments
15 Faraday Drive • Dover, NH 03820 USA • Phone: [phone] • Fax: [phone]
www.aemc.com
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]
