Introduction
Due to a change of manufacturer of the noise diodes, adjustment of bias current is now necessary
to ensure that the noise source performs within its specified ENR range. This document is supplied
with all the following replacement parts.
The noise source diode inside the noise source cartridge changed at serial prefix MY/SG/US5323
for models 346A and N4000A including options 001, 002, and 004.
Noise sources with serial prefixes manufactured before MY/SG/US5323 will now have a noise
cartridge replacement kit that will include both a new noise cartridge and new attenuator. Both
must be replaced.
Noise sources manufactured with serial prefix MY/SG5323 and later will have a new noise cartridge
replacement part number. Refer to Table 1.
Replacement Parts List
This Installation Note applies to the installation of the following replacement parts:
CAUTION
Repair or parts replacement of noise sources should NOT be attempted without full
calibration capability and official field calibration software.
Table 1 Replacement parts list
Model Replacement bulkhead Replacement noise cartridge
Noise cartridge kit[a]
(Serial Prefix up to MY/SG/
US5322)
Noise cartridge
(Serial Prefix up to MY5323 or
SG5323 and later)
346A Std. 00346-60168 00346-60194 00346-60193
346A Opt. 001 00346-60169 00346-60194 00346-60193
346A Opt. 002 00346-60170 00346-60194 00346-60193
346A Opt. 004 00346-60171 00346-60194 00346-60193
Noise cartridge (All serial prefixes)
346B Std. 00346-60172 00346-60179
346B Opt. 001 00346-60164 00346-60179
346B Opt. 002 00346-60165 00346-60179
346B Opt. 004 00346-60166 00346-60179
Noise cartridge kit[a]
(Serial Prefix up to MY/SG/
US5322)
Noise cartridge
(Serial Prefix up to MY5323 or
SG5323 and later)
N4000A Std. N4000-60020 00346-60194 00346-60193
N4000A Opt 001 N4000-60021 00346-60194 00346-60193
12 Keysight 346A, 346B, N4000A, and N4001A Installation Note
The replacement parts listed in Table 1 are tested in the factory to determine the bias current level
necessary to ensure that it meets ENR specification.
For the 346A and 346B, bias levels are determined by installing the appropriate resistor value for
R7 on the printed circuit board (Figure 1). The appropriate resistor is supplied with the part.
Replacement Bulkheads for the 346A and 346B have the recommended bias level written on the
part. The appropriate resistor is enclosed in a small envelope. The resistor value and part number
are written on the envelope. The N4000/1A bulkheads are not supplied with an envelope and
resistor. However, the value of the current is marked on the part.
Replacement Noise Cartridges are used in all the listed models. These parts are labeled with a
tracking number. The appropriate resistor is enclosed in an envelope which is marked with the
tracking number of the cartridge, resistor value, part number and recommended bias current level.
Also, the cartridges are shipped with Installation Note 00346-90024, Attenuator Replacement, in
case attenuator tuning is necessary to bring the unit to within specification. It may be necessary, in
rare cases, to replace the attenuator to meet specification.
On the N4000A and N4001A models, the bias is set electronically by using field calibration
software to calibrate the Noise Source and re-burn the EEPROM. The bias value of current supplied
with the Replacement Noise Cartridge is to be used to program the sensor. The enclosed resistor
can be discarded.
346A/B Replacement Noise Cartridge Installation Instructions
1Ensure that the cartridge was shipped with a resistor contained in a small envelope.
2Ensure that the tracking number on the cartridge matches the number on the envelope.
3Ensure that the value of the current marked on the envelope corresponds to the resistor value
and part number provided (refer to Table 2).
4Ensure that the resistor value on the envelope matches the resistor supplied.
5Ensure that Installation Note 00346-90024 has been provided.
6Disassemble the Noise Source by removing the two flat head screws near the output connector
and slide the bulkhead out of the housing.
Noise cartridge (All serial prefixes)
N4001A Std. N4001-60011 00346-60179
N4001A Opt 001 N4001-60012 00346-60179
[a] 00346-60194 contains a compatible noise cartridge and attenuator assembly. Both must be installed.
Table 1 Replacement parts list (continued)
Model Replacement bulkhead Replacement noise cartridge
NOTE
This Installation Note also applies to the replacement of the 00346-60001 and N4000-60001
printed circuit boards. To replace the PC board, please order the 00346-60157 (for 346A/B) or
N4000-60016 (for N4000A/1A) Replacement PC Board Kit.
Keysight 346A, 346B, N4000A, and N4001A Installation Note 13
7Next, remove the two flat head screws near the BNC connector and slide out the printed circuit
board assembly.
8Remove the old cartridge from the bulkhead and install the replacement cartridge. Ensure that
the tiny bellows remains on the attenuator pin.
9Check the resistor installed in position R7 on the 00346-60183 printed circuit board; please
refer to Figure 1. If it matches the resistor supplied, it is not necessary to install it in the printed
circuit board.
10 Install the supplied resistor in R7 position (refer to Figure 1).
11 Reassemble the unit and do a preliminary ENR measurement.
12 For the 346B, if the ENR is not within specification, refer to the supplied 00346-90024
Installation Note for instructions on how to tune the attenuator to meet the ENR specification at
frequencies above 12 GHz. The 346A should not require polyiron tuning.
13 Retest ENR after tuning the attenuator.
14 If the ENR is still out of specification, substitute another resistor for R7 from Table 2. Decreasing
the bias current by 10% increases the ENR response by 0.5dB at 10MHz.
15 Retest ENR.
346A/B Replacement Bulkhead Assembly Installation Instructions
1Ensure that the bulkhead was shipped with a small envelope containing a resistor.
2Ensure that the value of the current marked on the bulkhead matches the value on the
envelope.
3Ensure that the value of the current marked on the envelope corresponds to the resistor value
and part number provided (refer to Table 2).
4Ensure that the resistor value on the envelope matches the resistor supplied.
5Disassemble the Noise Source by removing the two flat head screws near the output connector
and slide the bulkhead out of the housing.
6Remove the two flat head screws near the BNC connector and slide out the printed circuit
board assembly.
7Install the replacement bulkhead.
8Check the resistor installed (if any) in position R7 on the 00346-60183 printed circuit board;
refer to Figure 1. If it matches the resistor supplied, it is not necessary to install it in the printed
circuit board.
9Install the supplied resistor in R7 position (refer to Figure 1).
10 Reassemble the unit and perform a preliminary ENR measurement.
11 If the ENR is not meeting specification, substitute another resistor for R7 from Table 2.
Decreasing the bias current by 10% increases the ENR response by 0.5dB at 10MHz.
12 Retest ENR.
14 Keysight 346A, 346B, N4000A, and N4001A Installation Note
346A/B Replacement Printed Circuit Board Assembly Installation Instructions
1Disassemble the Noise Source by removing the two flat head screws near the BNC connector,
and slide out the printed circuit board assembly.
2R7 is not loaded in the replacement printed circuit board assembly. Install the same value of R7
as in the printed circuit board being replaced.
3Install the replacement printed circuit board, reassemble the unit and do a preliminary ENR
measurement.
4If the ENR is not meeting specification, substitute another resistor for R7 from Table 2.
Decreasing the bias current by 10% increases the ENR response by 0.5dB at 10MHz.
5Retest ENR.
N4000A/ N4001A Replacement Noise Cartridge Installation Instructions
1Ensure that the cartridge was shipped with a small envelope.
2Ensure that the value of the current is marked on the envelope (the resistor will not be used).
3Ensure that Installation Note 00346-90024 has been provided.
4Disassemble the Noise Source using the procedure in the SNS Series Operating and Service
Guide, N4000-90001.
5Remove the old cartridge and install the replacement cartridge.
6Using the field calibration software, set the bias current to the value on the envelope (in mA).
Discard the resistor enclosed.
7Reassemble the unit and do a preliminary ENR measurement.
8If the ENR is not within specification, refer to the supplied 00346-90024 Installation Note for
instructions on how to tune the attenuator to meet the ENR specification at frequencies above
12 GHz.
9Retest ENR after tuning the attenuator.
10 If the ENR is not meeting specification, use the field calibration software to reprogram the bias
current using the values from Table 2. Decreasing the bias current by 10% increases the ENR
response by 0.5dB at 10MHz.
11 Retest ENR.
Keysight 346A, 346B, N4000A, and N4001A Installation Note 15
N4000A/ N4001A Replacement Bulkhead Assembly Installation Instructions
1Ensure that the value of the current is marked on the replacement bulkhead.
2Disassemble the Noise Source using the procedure in the SNS Series Operating and Service
Guide, N4000-90001.
3Remove the old bulkhead and install the replacement bulkhead.
4Using the field calibration software, set the bias current to the value on the bulkhead (in mA).
5Reassemble the unit and do a preliminary ENR measurement.
6If the ENR is not meeting specification, use the field calibration software to reprogram the bias
current using the values from Table 2. Decreasing the bias current by 10% increases the ENR
response by 0.5dB at 10MHz.
7Retest ENR.
N4000A/ N4001A Replacement Printed Circuit Board Assembly Installation
Instructions
1Using the field calibration software, determine the bias current applied to the noise diode or use
the bias current value written on the bulkhead.
2Disassemble the Noise Source using the procedure in the SNS Series Operating and Service
Guide, N4000-90001.
3Install the replacement printed circuit board.
4Reassemble the unit.
5Using the field calibration software, set the bias current to the original value
6Perform a preliminary ENR measurement.
7If the ENR is not meeting specification, use the field calibration software to change the bias
setting. Refer to Table 2 for bias current values. Decreasing the bias current increases the ENR
response.
8Retest ENR.
16 Keysight 346A, 346B, N4000A, and N4001A Installation Note
Printed Circuit Board Assembly Graphic and Resistor List
Figure 1 00346-60183
Table 2 Parts list
Current (mA) R7 ohms R7 part number
11 237 0698-3442
12 200 0698-6377
13 162 0757-0405
14 133 0698-7215
15 100 0757-0401
16 75 0698-7209
17 51.1 0757-0394
18 28.7 0698-7199
19 10 0757-0346
20 162[a]
[a] In addition, replace R6 with 0698-7216 (147 ohms)
0698-7217
R7 R6
This information is subject to change
without notice. Always refer to the
Keysight website for the latest
revision.
© Keysight Technologies 2001 - 2019
Edition 3, December 16, 2019
Printed in Malaysia
*00346-90137*
00346-90137
www.keysight.com
This manual suits for next models
3
Table of contents
Other Keysight Technologies Recording Equipment manuals
